Kodak 4C8894 Installation Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TM
DIGITAL SCIENCE
and
TM
IMAGELINK
Scanners
Installation Questionnaire
Instructions
A-61097
Mode Setup Instructions
Part Number 4C8894

Advertisement

Table of Contents
loading

Related Manuals for Kodak 4C8894

Summary of Contents for Kodak 4C8894

  • Page 1 DIGITAL SCIENCE IMAGELINK Scanners Installation Questionnaire Instructions A-61097 Mode Setup Instructions Part Number 4C8894...

  • Page 2: Installation Requirements

    1 Introduction The KODAK DIGITAL SCIENCE™ Mode Setup Software 9000 has been developed to enable you to customize applications using the: • KODAK DIGITAL SCIENCE Document Scanner 9500 • KODAK DIGITAL SCIENCE Scanner/Microimager 990 • KODAK IMAGELINK Microimager 70 • KODAK IMAGELINK Microimager 70 with Advanced Function Module •...

  • Page 3: Software Installation Procedure

    Microimager IL70 * IL70 AFM Scanner IL900 * IL923 Microimager/Scanner DS990 * Scanner DS9500 Mode Setup Software Copyright (c) 1989-1997 Eastman Kodak Company All Rights Reserved Press Any Key to Install, ESCAPE to Exit 3. Press any key. Mode Setup Software...
  • Page 4 4. Enter the desired drive and directory designations and press Enter. Directory Information Drive To Install From: A Drive To Install To: C Directory To Be Installed To: \SETUP ESCAPE to Abort [Press ENTER to Accept, any other key to Edit] 5.
  • Page 5 During the installation procedure, the following window will appear if you don’t have the files and buffers set correctly in the config.sys file: Mode Setup Software INSTALLING Please Wait While Files Are Being Copied ToYour Destination Drive. The CONFIG.SYS File Needs To Be Checked To Make Sure That BUFFERS=40 FILES=40...
  • Page 6 REGISTRATION Please enter the name of the registered user below: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Please Wait While Files Are Being Copied To Your Destination Drive.

  • Page 7: Logon Procedure

    Exit Copyright Eastman Kodak Company MM-DD-YY 1989-1997 4. Select Connect via RS-232 and press Return/Enter. KODAK IMAGELINK (tm) / DIGITAL SCIENCE (tm) Microimager Models 30 & 70 Microimager Model 70/AFM Scanner 900 & 923 Microimager/Scanner DS990 Scanner DS9500 1) Attach RS-232 Cable 2) Turn Operator Power Switch ON 3) Press “ENTER/RETURN”...

  • Page 8: Using The Mode Setup Software

    5. Select Continue. Mainframe Configuration MACHINE STATE Display Machine Accessories Machine ID Number Display Language Measurement System Programmable Function Keys Date Format Time Format Alarm Tone Doc Printer/Film Writer Msg DP-12 Print Template Fixed Field Delimiter Set System Clock Version Numbers User COIN Port Protocol Custom Check Digit OI Hardware Character Set...
  • Page 9 In either instance, contact your Kodak service representative to properly install and/or define the accessory. • If you receive a message that indicates a selection is not available, press the Return/Enter key to continue.

  • Page 10: Logout Procedure

    Logout Procedure Once you have completed the installation, the following sequence of steps may be used to log out of the system. From the Mode Configuration window: 1. Select Save & End Session if you wish to save all of the definitions or Don’t Save &...
  • Page 11 2 Machine Definitions The following section lists the items on the Mainframe Configuration Menu that may be selected for definition. Mainframe Configuration MACHINE STATE Display Machine Accessories Machine ID Number Display Language Measurement System Programmable Function Keys Date Format Time Format Alarm Tone Doc Printer/Film Writer Msg DP-12 Print Template...
  • Page 12 Display Machine Accessories This option displays the status of the various machine accessories and is for viewing only; no selections or entries are made. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Display Machine Accessories. 2.
  • Page 13 Machine ID Number This option establishes a unique identification number for each unit in a multiple-unit installation. The default is 00. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Machine ID Number. 2. Enter a number from 00-99. Mainframe Configuration MACHINE STATE Display Machine Accessories...

  • Page 14: Display Language

    Display Language This option defines the primary display language. The default is English. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Display Language. 2. Select the desired language option. Mainframe Configuration MACHINE STATE Display Machine Accessories Machine ID Number Display Language Measurement System...

  • Page 15: Measurement System

    Measurement System This option defines the primary measurement system. English uses inches as the primary unit of measure. Metric uses millimetres as the primary unit of measure. The default is English. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.
  • Page 16 Programmable Function Keys (P-Keys) This option defines the functions performed by the programmable keys. Refer to Appendix B: Function Codes to determine which function codes and formats to use when programming the P-Keys. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.
  • Page 17 The default values are displayed in the Key Definition table. The following values apply only to the Scanner 9500. Definition Calibrate f98f38 Stop, End of Job f01,01 Change to Mode 1 f01,02 Change to Mode 2 f01,03 Change to Mode 3 f01,04 Change to Mode 4 f01,05...

  • Page 18: P9 F07 Level

    The following default values apply only to the Scanner/Microimager 990: Definition f04,2 Count only, toggle Print test Total document count Last Image Address Calibrate Amount of film remaining Omit printing on next document only Print position Level 0 f98f38 Stop, End-of-Job To enter a function code, type an f (lower case) followed by a two-digit code (i.e., f04).

  • Page 19: Date Format

    Date Format This option defines the date display format, both the date format and delimiter. Refer to Description 1: Date Format Samples for a description of the available formats. The default is mmddyy. The default delimiter is a slash (/). Microimager 70 Microimager 70/AFM Scanner 900...
  • Page 20 Description 1: Date Format Samples Sample Date March 1, 1991 Slash Dash Period Space None mmddyy 03/01/91 03/01/91 03.01.91 03 01 91 030191 mmdd 03/01 03-01 03.01 03 01 0301 ddmmmyy 01/MAR/91 01-MAR-91 01.MAR.91 01 MAR 91 01MAR91 ddmmm 01/MAR 01-MAR 01.MAR 01 MAR...

  • Page 21: Time Format

    Time Format This option defines the time display format. Refer to Description 2: Time Format Samples for a description of the available formats. The default is 12 hour with AM/PM. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.

  • Page 22: Alarm Tone

    Alarm Tone This option defines tone or pitch of the audible alarm. The default is High. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Alarm Tone. 2. Select the desired alarm tone pitch. Mainframe Configuration MACHINE STATE Display Machine Accessories Machine ID Number...
  • Page 23 Document Printer/Film Writer Messages This option defines messages that may be printed by a document printer or film writer. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Doc Printer/Film Writer Msg. Messages are limited to thirty-eight (38) characters for Document Printer 1 and 2, and Film Writer, and 12 characters for the DP12, and can include any character that can be input from a standard keyboard (alphabetic, numeric, and special characters).
  • Page 24 Message 0 is predefined and cannot be changed. Messages 1 through 9 are programmable using the following sequence of steps: 1. Select a message number. 2. Press Return/Enter. 3. Enter the desired message text. 4. Press Return/Enter. Definition Diagnostic Message - No Entry Allowed. Prev Previous Menu 2-14...
  • Page 25 Print Template Setup This option defines as many as ten (10) unique print templates. The template definitions are used when programming Document Printer 12 print definitions. The default print template is Print Template 1, which prints Full IA w/No Delimiters on Line 1. Microimager 70 Microimager 70/AFM Scanner 900...
  • Page 26 1. Follow these steps for each line/item to be printed (maximum twelve per template): a. Select the next available item number (or Item 1 if this is the first item). b. Enter a line number corresponding to the line number on the print template master.
  • Page 27 If Check Digit is selected, the following window is displayed: Document Printer 12 Print Template # Check Digit Item Line Print Item Mod 7A - IA Only Mod 11A - IA Only <IA-No Del> <Message 1> Mod 7B - IA Only Mod 7B - Full IA Mod 10 - IA Only Mod 10 - Full IA...
  • Page 28 The master template is designed to assist you in the placement of information printed by the Document Printer 12. Follow these steps to use the master templates: 1. Obtain a sample of the customer’s document(s). 2. Determine the starting print position (how far from the leading edge of the document printed information should appear).

  • Page 29: Table Of Contents

    Dotted line = Starting print position (distance from the leading edge of the document). Line 1 Line 2 Line 3 Line 4 Line 5 Line 6 Line 7 Line 8 Line 9 Line 10 Line 11 Line 12 Line 13 Line 14 Line 15 Line 16...
  • Page 30 Dotted line = Starting print position (distance from the leading edge of the document). Line 1 Line 2 Line 3 Line 4 Line 5 Line 6 Line 7 Line 8 Line 9 Line 10 Line 11 Line 12 Line 13 Line 14 Line 15 Line 16...

  • Page 31: Fixed Field Delimiter

    Fixed Field Delimiter This option defines the fixed field delimiter used in the Image Address Display. The default is a Period (.). NOTE: The Fixed Field Delimiter doesn’t appear on the display; it appears when printing the Image Address. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923...
  • Page 32 Set System Clock This option sets the system clock. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Set System Clock. Mainframe Configuration MACHINE STATE Display Machine Accessories Machine ID Number Display Language Set System Clock Measurement System Set Month Date...
  • Page 33 3. Verify that the terminal time should be downloaded by selecting Yes; or to cancel the download, select No. If the computer being used to program the unit does not have an internal clock or the internal clock is not accurate: 4.

  • Page 34: Version Numbers

    Version Numbers This option displays the current software version(s) installed in the machine and is for viewing only; no selections or entries are made. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Version Numbers. Mainframe Configuration MACHINE STATE Display Machine Accessories...
  • Page 35 User COIN Port Protocol This option enables or disables the user COIN port for communication protocols associated with OCR data, Document Scanning Array / Bar Code Reader, or Customer specified. The default value is Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500...
  • Page 36 If User-Defined Protocol is selected, the following window will be displayed: Mainframe Configuration MACHINE STATE Display Machine Accessories Machine ID Number Display Language User COIN Port Config Measurement System Baud Rate 9600 Programmable Function Keys Parity Bit None Date Format Char.
  • Page 37 5. Select Parity Bit. 6. Select the desired parity. Mainframe Configuration MACHINE STATE Display Machine Accessories Machine ID Number Display Language User COIN Port Config Measurement System Baud Rate 9600 Programmable Function Keys Parity Bit None Date Format Char. Length 8 Bits Time Format Handshaking...
  • Page 38 9. Select Handshaking. 10. Select the handshaking protocol. Mainframe Configuration MACHINE STATE Display Machine Accessories Machine ID Number Display Language User COIN Port Config Measurement System Baud Rate 9600 Programmable Function Keys Parity Bit None Date Format Char. Length 8 Bits Time Format Handshaking None...
  • Page 39 Custom Check Digit This option determines the check digit algorithm to be used when a custom check digit is calculated. NOTE: If a standard check digit algorithm is desired, specify the desired algorithm during Image Address print definitions within each mode setup.
  • Page 40 Custom Check Digit Definition Custom Check Digit Formula [Sum of IA Digits * Attributes] + Constant 1 Check Digit = Constant 2 - Divisor Parameter Current Value Attributes 46231546231 Constant 1 Constant 2 Divisor Left/Right Right LUT Status Lookup Table abcdefghijk Help Previous Menu...
  • Page 41 • Constant1—A constant value in the range 0 through 99. • Divisor—a constant value between 0 and 99. NOTE: The divisor is not used if value specified is zero (0). In addition to the parameters in the equation, there are other user defined parameters which affect check digit processing: •...
  • Page 42 Sample check digit calculation #1 Assume the following: Image Address 123.45.678.912 Attributes 46231546231 Constant 1 Constant 2 Divisor Left/Right Right LUT Status No/off Lookup Table abcdefghijk Then the check digit calculation would be: 1. Set up the equation: Check Digit = 10 - [Calculation 1] + 7 Calculation 1 = (2 x 1) + (1 x 3) + (9 x 2) + (8 x 6) + (7 x 4) + (6 x 5) + (5 x 1) + (4 x 3) + (3 x 2) + (2 x 6) + (1 x 4) 2.
  • Page 43 Sample check digit calculation #2 Assume the following: Image Address 123.45.678.912 Attributes 46231546231 Constant 1 Constant 2 Divisor Left/Right Right LUT Status Yes/on Lookup Table abcdefghijk Then the check digit calculation would be: 1. Set up the equation: Check Digit = 10 - [Calculation 1] + 7 Calculation 1 = (2 x 1) + (1 x 3) + (9 x 2) + (8 x 6) + (7 x 4) + (6 x 5) + (5 x 1) + (4 x 3) + (3 x 2) + (2 x 6) + (1 x 4) 2.
  • Page 44 To program a custom check digit algorithm, use the following sequence of steps: 1. Select the Attributes parameter for definition. 2. Enter the desired attribute values. Custom Check Digit Definition Custom Check Digit Formula Check Digit = Constant 2 - [Sum of IA Digits * Attributes] + Constant 1 Divisor Parameter Current Value...
  • Page 45 5. Select the Constant2 parameter for definition. 6. Enter a value between 00 – 99. Custom Check Digit Definition Custom Check Digit Formula Check Digit = Constant 2 - [Sum of IA Digits * Attributes] + Constant 1 Divisor Parameter Current Value Attributes 46231546231...
  • Page 46 9. Select the Left/Right parameter for definition. 10. Select the digit to be used during calculation of the check digit. Custom Check Digit Definition Custom Check Digit Formula Check Digit = Constant 2 - [Sum of IA Digits * Attributes] + Constant 1 Divisor Parameter Current Value...
  • Page 47 13. Select the Lookup Table parameter for definition. 14. Enter the desired lookup table values. Custom Check Digit Definition Custom Check Digit Formula Check Digit = Constant 2 - [Sum of IA Digits * Attributes] + Constant 1 Divisor Parameter Current Value Attributes 46231546231...

  • Page 48: Line

    OI Hardware Character Set This option defines non-English character sets which may be used by the Operator Interface, Document Printers and the Film Writer. English characters are contained in both sets. The default OI character set is Anglo/Japanese. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923...

  • Page 49: Line

    Save Configuration to PC This option is used to download a configuration file from the scanner or microfilmer onto diskette. This is useful in creating configuration files which may be transported to other units (see the Load Config from PC option).

  • Page 50: Line

    Load Configuration from PC This option is used to upload a configuration file from diskette to the scanner or microfilmer. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Load Configuration from PC. 2. Enter a file name to upload. Mainframe Configuration MACHINE STATE Display Machine Accessories...

  • Page 51: Line

    3 Selecting the Mode Configuration Window This section lists the Mode Definitions for the Scanner/Microimager. Follow these steps to select the Mode Definition screen. Mainframe Configuration MACHINE STATE Display Machine Accessories Machine ID Number Display Language Measurement System Programmable Function Keys Date Format Time Format Alarm Tone...

  • Page 52: Line

    2. Select a mode to be defined. The Mode Configuration window will be displayed, with the Mode Number you selected for definition displayed at the top. Mode Number: Mode Name: MODE10 Mode Configuration MODE 10 Mode Name Ftswitch Pressed Undef 3 Lvl Index Format Ftswitch Released...

  • Page 53: Line

    Mode Definitions The following section lists the items on the Mode Configuration Menu that may be selected for definition. Unavailable machine types are indicated by hollow boxes. Mode Name This option defines the mode name. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500...

  • Page 54: Line

    Index Format This mode defines the index format used by the application mode. Refer to Description 3: Index Formats for a description of the index formats. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 When using a Microimager 70 without the Advanced Function Module installed, only the index format for Mode 8 and Mode 9 may be defined;...

  • Page 55: Line

    Description 3: Index Formats There are five Index Format options available: Single Level IA 1 IA 2 IA 3 IA 4 (Level 1) (Level 1) (Level 1) (Level 1) Whenever a small image mark is placed next to a document and/or a document is assigned Level 1, the Image Address field associated with Level 1 (Field A) is incremented.

  • Page 56: Line

    Description 3: Index Formats (continued) Three Level IA 1.0.0 IA 1.1.0 IA 1.1.1 IA 2.0.0 (Level 3) (Level 2) (Level 1) (Level 3) Whenever a large image mark is placed next to a document and/or a document is assigned Level 3, the Image Address field associated with Level 3 (Field C) is incremented and the fields associated with Level 2 (Field B) and Level 1 (Field A) are set to zero.

  • Page 57: Line

    Image Address Display Format This mode defines the format of the Image Address display which appears on the control panel. The default is Suppress. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select IA Display Format. Mode Number: Mode Name: MODE10...

  • Page 58: Line

    Image Address Field Widths This mode defines the Image Address field widths. Refer to Description 4: Image Address Fields for a description of proper field definitions. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 When using a Microimager 70 without the Advanced Function Module installed, only the Image Address field widths for Mode 8 and Mode 9 may be defined;...

  • Page 59: Line

    1. Select IA Field Widths. Mode Number: Mode Name: MODE10 Mode Configuration Field Num Fixed Field MODE 10 Mode Name Ftswitch Pressed Undef Field A 3 Lvl Index Format Ftswitch Released Undef Field B Supprs IA Display Format Ftswitch Cnf Tone Field C 4233 IA Field Widths...

  • Page 60: Line

    Description 4: Image Address Fields An Image Address is a unique identifier assigned to each individual document by the Microimager 70, Scanner 900, Scanner 923, Scanner 9500, or Scanner/Microimager 990. An Image Address may contain up to 15 characters, consisting of a maximum of 12 digits Description 4: Image Address Fields.

  • Page 61: Line

    Description 4: Image Address Fields (continued) • Two Level Field A is defined as having a field length greater than zero (1 – 9) Field B is defined as having a field length greater than zero (1 – 9) Field C is defined as having a field length of zero (0) Fixed Field may be defined, if desired (0 –...

  • Page 62: Line

    Level Rules This mode defines the level of a document based upon the level of the previous document. These definitions are used as defaults when the document level is not determined by another method (i.e., Footswitch, P-Key, Level Key, etc.) Microimager 70 Microimager 70/AFM Scanner 900...

  • Page 63: Line

    1. Select Level Rules. Mode Number: Mode Name: MODE10 Mode Configuration Field Level 0 MODE 10 Mode Name Ftswitch Pressed Undef Level 1 3 Lvl Index Format Ftswitch Released Undef Level 2 Supprs IA Display Format Ftswitch Cnf Tone Level 3 4233 IA Field Widths Patch Reader 1...

  • Page 64: Line

    Batching This mode defines the number of documents of a specified level to process prior to performing a predefined action. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Batching. Mode Number: Mode Number: Mode Name: Mode Name: MODE10 MODE10...

  • Page 65: Line

    Batch Value Defines the number of documents to be counted prior to performing a predefined action. The default value is 99. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Batch Value. Mode Number: Mode Number: Mode Name: Mode Name: MODE10...

  • Page 66: Line

    Start of Batch Function This mode defines the action(s) to be taken prior to processing the document in the batch. The default value is Nothing. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Start of Batch Function. Mode Number: Mode Number: Mode Name:...

  • Page 67: Line

    End of Batch Function This mode defines the action(s) to be taken after processing the document in the batch. The default value is f98, Stop. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select End of Batch Function. Mode Number: Mode Number: Mode Name:...

  • Page 68: Line

    AEC Mode This mode enables or disables Automatic Exposure Control. Fixed Mode disables Automatic Exposure Control. Auto Mode enables Automatic Exposure Control. The default value is Auto Mode. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.

  • Page 69: Line

    Film Mode This mode defines the orientation of documents on film. Refer to Description 5: Film Modes for a description of the available film modes. The default value is Duplex. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.

  • Page 70: Line

    • Simplex Mode Simplex format allows one image to be exposed across the film width. A 24:1 reduction ratio is used for this format. • Duplex Mode Duplex format allows front and back images of the same document to be exposed (at the same time) across the film width. A 40:1 or 50:1 reduction ratio is used for this format.

  • Page 71: Line

    Reduction Ratio This mode defines the level of magnification. The default value is Don’t Care. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Reduction Ratio. Mode Number: Mode Name: Mode Name: MODE10 MODE10 Mode Configuration Reduction Ratio Don't Care MODE 10...

  • Page 72: Line

    Number of Cassettes This mode defines the minimum number of cassettes that must be installed during filming. If Two Cassettes is chosen, you must always use two cassettes. If One Cassette is chosen, you may use one or two cassettes. The default value is One Cassette. Microimager 70 Microimager 70/AFM Scanner 900...

  • Page 73: Line

    Film Writer NOTE: The Film Writing Module must be installed. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Film Writer. Mode Number: Mode Name: MODE10 Mode Configuration Advanced Film Writer Character Orientation MODE 10 Mode Name Ftswitch Pressed Undef...

  • Page 74: Line

    Character Orientation This mode defines the orientation of the information printed by the film writer. The default is Comic. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Character Orientation. Mode Number: Mode Name: MODE10 Mode Configuration Advanced Film Writer Character Orientation...

  • Page 75: Line

    Image Address Print Format This mode defines the format of the Image Address printed on film. The default is Compress. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Image Addr Print Format. Mode Number: Mode Name: MODE10 Mode Configuration...

  • Page 76: Line

    Write Definitions This mode defines the information printed on film next to each document, based upon the document level. The default value for all levels is <FF/IA-All Del>. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 When using a Microimager 70 without the Advanced Function Module installed, a limited number of print items are available.

  • Page 77: Line

    If different information is to be printed next to documents of different levels: 1. Select Print Sequence – Level # for the desired level. FAN Write Sequence Current Print Sequence Display Values Full Image Address Indexed Fields Only Current Field Level <Full IA>...

  • Page 78: Line

    Image Management Code NOTE: The Film Writing Module must be installed. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Image Mgmt Code. Mode Number: Mode Name: MODE10 Mode Configuration Image Management Code Status MODE 10 Mode Name Ftswitch Pressed Undef...

  • Page 79: Line

    Status This mode enables or disables the use of IMC options. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Status. Mode Number: Mode Name: MODE10 Mode Configuration Image Management Code Status MODE 10...

  • Page 80: Line

    IMT Search Program Number This mode defines the IMT search program number. The default value is Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select IMT Search Prg Number. Mode Number: Mode Name: MODE10 Mode Configuration Image Management Code Status MODE 10...

  • Page 81: Line

    Magnification This mode defines for the KODAK IMAGELINK™ Digital Workstation (with Zoom Lens Accessory) the desired level of magnification. The default value is 20. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Magnification. Mode Number:...

  • Page 82: Line

    Splice Definition This mode defines the desired action when a splice is detected. The default value is Ignore. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Splice Definition. Select any of the Sort Criteria and the following screen appears: Mode Number: Mode Name: MODE10...

  • Page 83: Line

    Don't Save & End Session Previous Menu Previous Menu End Configuration 2. Select the desired Image Mark Size option. Custom Setup should only be selected if the Kodak Field Engineer has defined the customer image mark sizes (small, medium, and large). A-61097 May 1997...

  • Page 84: Line

    Image Polarity This mode defines the polarity of the image marks relative to the polarity of the document images. The default value is Same as Image Mark. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Image Polarity. Mode Number: Mode Name: MODE10...

  • Page 85: Line

    Duplex Front Location The mode defines for the KODAK IMAGELINK™ Digital Workstation where the front side image is located. The default value is Same as IM Channel. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Duplex Front Location.
  • Page 86 Film Image Orientation The mode defines where the top of the image is located for the KODAK IMAGELINK™ Digital Workstation. The default value is Leading Edge Up. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Film Image Orientation.
  • Page 87 Image Offset This mode defines the position of the image marks relative to the leading edge of the document. The default value is 0. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Image Offset. Mode Number: Mode Name: MODE10...

  • Page 88: Length Monitor

    Length Monitor NOTE: The Advanced Document Controller must be installed. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Length Monitor. Mode Number: Mode Name: MODE10 Mode Configuration Length Monitor Status MODE 10 Mode Name Ftswitch Pressed Undef Max Document Length...
  • Page 89 Status This mode enables or disables length monitoring. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Status. Mode Number: Mode Name: MODE10 Mode Configuration Length Monitor Status MODE 10 Mode Name Ftswitch Pressed...
  • Page 90 Maximum Document Length This mode defines the maximum document length accepted. The default value is 13.000 inches/325 mm. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Max Document Length. Mode Number: Mode Name: MODE10 Mode Configuration Length Monitor Status...
  • Page 91 Minimum Document Length This mode defines the minimum document length accepted. The default value is 02.500 inches/63 mm. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Min Document Length. Mode Number: Mode Name: MODE10 Mode Configuration Length Monitor Status...
  • Page 92 Length Error Response This mode defines the action taken if a document is smaller than the minimum length specified or larger than the maximum length specified. The default value is Display and Beep. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.

  • Page 93: Skew Monitor

    Skew Monitor Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 NOTE: The Advanced Document Controller must be installed. 1. Select Skew Monitor. Mode Number: Mode Name: MODE10 Mode Configuration Skew Monitor Skew Detect Status MODE 10 Mode Name Ftswitch Pressed Undef...
  • Page 94 Skew Threshold This mode defines the amount of tolerable skew. If 5 Degrees is selected, an error will be reported if the amount of document skew is between 5 and 30 degrees. If 10 Degrees is selected, an error will be reported if the amount of document skew is between 10 and 30 degrees.
  • Page 95 Skew Error Response This mode defines the action taken if the amount of document skew is greater than the threshold specified. The default value is Display and Beep. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.
  • Page 96 Check Stacker NOTE: The Check Stacker must be installed. This mode defines when the check stacker is activated. Continuous will activate the check stacker whenever the side panel switch is on. Documents in Transport will activate the check stacker only when there are documents exiting the transport.
  • Page 97 Endorser NOTE: The Endorser must be installed. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Endorser. Mode Number: Mode Name: MODE10 Mode Configuration Endorser Status MODE 10 Mode Name Ftswitch Pressed Undef Mode 3 Lvl Index Format Ftswitch Released Undef...
  • Page 98 Endorser Status Enables or disables the endorser. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Status. Mode Number: Mode Name: MODE10 Mode Configuration Endorser Status MODE 10 Mode Name Ftswitch Pressed Undef...
  • Page 99 Endorser Mode This mode defines whether the endorser will print continually or only once per document. Continuous will activate the Endorser continually. Single Stamp will activate the Endorser only once per document. The default value is Continuous. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990...
  • Page 100 Endorser Print Position This mode defines how far from the leading edge of the document the endorsement will appear: The default value is 0000.250 inch/ 6.350 mm. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Print Position. Mode Number: Mode Name: MODE10...
  • Page 101 Footswitch Pressed NOTE: The Footswitch accessory must be installed. This mode defines the action which results when the footswitch is pressed. The default is Undefined. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 When using a Microimager 70 without the Advanced Function Module installed, a limited number of actions are available.
  • Page 102 Footswitch Released NOTE: The Footswitch accessory must be installed. This mode defines the action which results when the footswitch is pressed. The default is Undefined. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Ftswitch Pressed. Mode Number: Mode Name: MODE10...
  • Page 103 Footswitch Confirmation Tone NOTE: The Footswitch accessory must be installed. This mode enables or disables the footswitch press confirmation tone. The default is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Ftswitch Cnf Tone. Mode Number: Mode Name: MODE10...

  • Page 104: Patch Reader

    Patch Reader 1 NOTE: A Patch Reader accessory or Document Scanning Array must be installed. Enables or disables the primary patch reader. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.
  • Page 105 Patch Reader 2 NOTE: A Patch Reader accessories or Document Scanning Array must be installed. Enables or disables the secondary patch reader. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.
  • Page 106 Patch Definition NOTE: At least one Patch Reader accessory or Document Scanning Array must be installed. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Patch Definition. Mode Number: Mode Name: MODE10 Mode Configuration Patch Definition Transfer Patch Definition MODE 10 Mode Name...

  • Page 107: Transfer Patch Definition

    Transfer Patch Definition This mode defines which level should be assigned to the next document when a transfer patch is used. The default value is Level 2. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Transfer Patch Definition. Mode Number: Mode Name: MODE10...
  • Page 108 Film Transfer Patches This mode defines whether or not a document containing a transfer patch is to be filmed. The default value is Transfer Patch Filmed. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Film Transfer Patches. Mode Number: Mode Name: MODE10...
  • Page 109 Patch Recognition This mode defines which patch codes will be recognized by the system. The default value is 2, 3, & T. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Patch Recognition. Mode Number: Mode Name: MODE10 Mode Configuration...

  • Page 110: Bar Code

    Bar Code NOTE: A Bar Code Reader must be installed. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Bar Code. Mode Number: Mode Name: MODE10 Mode Configuration Bar Code Reader Bar Code Reading Status MODE 10 Mode Name Ftswitch Pressed...
  • Page 111 Bar Code Reading Status Enables or disables bar code reading. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Bar Code Reading Status. Mode Number: Mode Name: MODE10 Mode Configuration Bar Code Reader Bar Code Reading Status...

  • Page 112: Bar Code Type

    Bar Code Type Identifies the type of bar code which is to be read. The default value is Code 39. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Bar Code Type. Mode Number: Mode Name: MODE10 Mode Configuration Bar Code Reader...
  • Page 113 Number of Bar Code Characters This mode defines the minimum bar code length allowed (in terms of the number of characters encoded). The default value is 3. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select # of Bar Code Characters. Mode Number: Mode Name: MODE10...
  • Page 114 Bar Codes per Document This mode defines the number of bar codes per document to be decoded. The default value is One Code. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Bar Codes per Document. Mode Number: Mode Name: MODE10...
  • Page 115 Distance Between Codes This mode defines the minimum bar code height allowed. The height of the tallest bar code determines the distance between codes. The default value is 1.000 inch/25.400 mm. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.

  • Page 116: Scan Direction

    Scan Direction This mode defines whether the bar codes may be read in only one direction (from left to right) or in either direction (from left to right or from right to left). The default value is Unidirectional (from left to right only). Microimager 70 Microimager 70/AFM Scanner 900...

  • Page 117: Image Processing

    Image Processing Enables or disables image processing; indicates whether or not image processing is required to enhance the overall quality of the bar codes used. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.
  • Page 118 Partial Read Enabled Enables or disables partial bar code reading. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Partial Read Enabled. Mode Number: Mode Name: MODE10 Mode Configuration Bar Code Reader Bar Code Reading Status MODE 10...
  • Page 119 Minimum Partial Characters NOTE: Partial Reading must be enabled or this definition will be ignored. This mode defines the minimum number of characters which must be properly decoded to constitute a partial read. The default value is 5-80. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923...
  • Page 120 DSA Patch Reading Status Enables or disables patch reading using the Document Scanning Array. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select DSA Patch Reading Status. Mode Number: Mode Name: MODE10 Mode Configuration...
  • Page 121 Patch Horizontal Location This mode defines the position of patches on the document(s) in terms of the distance from the left side of the transport. The default value is 5.12 inches/130.048 mm. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.
  • Page 122 End Fed Patch Reading Status Enables or disables end fed patch reading using the Document Scanning Array. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select End Fed Patch Read Status. Mode Number: Mode Name: MODE10...
  • Page 123 Level Change via Bar Code Enables level changes based upon detection of a bar code. The default value is Undefined. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Level Change via Bar Code. Mode Number: Mode Name: MODE10 Mode Configuration...

  • Page 124: Confirmation Tones

    Confirmation Tones NOTE: The tones must have been enabled during machine configuration; otherwise, these definitions will be ignored. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Confirmation Tone. Mode Number: Mode Name: MODE10 Mode Configuration Confirmation Tone Patch Detected Tone MODE 10...
  • Page 125 Patch Detected Tone NOTE: Patch reading must be enabled. In addition, the confirmation tones must have been enabled during machine definitions; otherwise, this definition will be ignored. This mode enables or disables a confirmation tone issued when a patch document is detected. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900...
  • Page 126 Bar Detected Tone NOTE: Bar Code reading must be enabled. In addition, during machine definitions the confirmation tones must have been enabled; otherwise, this definition will be ignored. Enables or disables a confirmation tone issued when a bar code document is detected. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900...
  • Page 127 Bar Code/Patch Tone NOTE: Patch reading and Bar Code reading must be enabled. In addition, the confirmation tones must have been enabled during machine definitions; otherwise, this definition will be ignored. Enables or disables a confirmation tone issued when a bar code and a patch are both recognized.
  • Page 128 OCR Status NOTE: The OCR accessory must be installed. Enables or disables Optical Character Recognition. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select OCR Status. Mode Number: Mode Name: MODE10 Mode Configuration...
  • Page 129 COIN User Channel NOTE: If the machine definition User COIN Port Protocol was disabled, these definitions will be ignored. Enables or disables the COIN2 user channel. If a standard form of output was chosen during machine definition (Bar Code/KDIS Protocol or OCR Data Protocol), this definition should be set to Enabled which will produce default/standard data output via the COIN2 port.
  • Page 130 Transmit Data This mode defines the data output via the COIN2 port when a user- defined protocol (User-Defined KDIS Format or User-Defined Protocol) is chosen during machine definition. The default values are FF/IA for all levels. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990...
  • Page 131 If different information is to be transmitted for documents of different levels: 1. Select Define Level # for the desired level. Transmit Items Current Transmit Sequence Full Image Address Indexed Field(s) Only Current Field Value <FF/IA> Current Day Current Date Current Time Document Counter Roll Number...

  • Page 132: Printer Control

    Printer Control NOTE: The Document Printer Controller must be installed Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Printer Control. Mode Number: Mode Name: MODE10 Mode Configuration Printer Control IA Print Format MODE 10 Mode Name Ftswitch Pressed Undef...
  • Page 133 Print Position This mode defines how far from the leading edge of the document(s) the information printed by the document printer(s) will appear. The default value is 00.250 inch/6.25 mm. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1.
  • Page 134 Special Character Set This mode defines the size font to be printed. Select either the smaller or larger font size when using the Document Printer 12. The default value is Use Smaller Font. NOTE: This selection is not available if the wrong printer driver board is installed.
  • Page 135 Primary Document Printer 1 NOTE: A Document Printer 1 accessory must be installed. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Primary DP-1. Mode Number: Mode Name: MODE10 Mode Configuration Primary Document Printer Document Printer Status MODE 10 Mode Name Ftswitch Pressed...
  • Page 136 Fonts/Orientation This mode defines the size and orientation of the characters printed by the primary Document Printer 1. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Fonts/Orientation. Mode Number: Mode Name: MODE10...
  • Page 137 Print Definitions This mode defines the information printed on each document, based upon the document level. The default values are Nothing Printed for Level 0 documents; Full Image Address with all delimiters for Level 1, Level 2, and Level 3 documents <FF/IA All Del>.
  • Page 138 If Spaces between items is selected, you must select the desired number of spaces. If Check Digit is selected, the following window is displayed: Check Digit Current Print Sequence Display Values Mod 7A IA Only Mod 11A IA Only Mod 7B IA Only Mod 7B Full IA...
  • Page 139 If different information is to be printed on documents of different levels: 1. Select Print Sequence - Level # for the desired level. Print Items Current Print Sequence Display Values Full IA w/No Delimiters Full IA w/FF Delimiter Full IA w/All Delimiter Fixed Field Only Indexed Fields Only Current Field Level...
  • Page 140 Secondary Document Printer 1 NOTE: Two Document Printer 1 accessories must be installed. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Secondary DP-1. Mode Number: Mode Name: MODE10 Mode Configuration Second Document Printer Document Printer Status MODE 10 Mode Name Ftswitch Pressed...
  • Page 141 Document Printer Status Enables or disables the secondary Document Printer 1. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Document Printer Status. Mode Number: Mode Name: MODE10 Mode Configuration Second Document Printer Document Printer Status...
  • Page 142 Fonts/Orientation—DP2 This mode defines the size and orientation of the characters printed by the secondary Document Printer 1. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Fonts/Orientation. Mode Number: Mode Name: MODE10...
  • Page 143 Print Definitions—DP2 This mode defines the information printed on each document, based upon the document level. The default values are Nothing Printed for Level 0 documents; Full Image Address with all delimiters for Level 1, Level 2, and Level 3 documents. Microimager 70 Microimager 70/AFM Scanner 900...
  • Page 144 If Check Digit is selected, the following window is displayed: Check Digit Current Print Sequence Display Values Mod 7A IA Only Mod 11A IA Only Mod 7B IA Only Mod 7B Full IA Mod 10 IA Only Mod 10 Full IA Mod 11B IA Only Mod 11B...
  • Page 145 If Message Number is selected, the following window is displayed: Message Number Current Print Sequence Display Values Message Number 1 Message Number 2 Message Number 3 Message Number 4 Message Number 5 Message Number 6 Message Number 7 Message Number 8 New Print Sequence Display Values Message Number 9 Previous Menu...

  • Page 146: Document Printer

    Document Printer 12 NOTE: The Document Printer 12 accessory must be installed Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Doc. Printer 12. Mode Number: Mode Name: MODE10 Mode Configuration Document Printer 12 Document Printer Status MODE 10 Mode Name Ftswitch Pressed...
  • Page 147 Document Printer Status—DP12 Enables or disables the Document Printer 12. The default value is Off or Disabled. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Document Printer Status. Mode Number: Mode Name: MODE10 Mode Configuration Document Printer 12 Document Printer Status MODE 10...
  • Page 148 Fonts/Orientation—DP12 This mode defines the size and orientation of the characters printed by the Document Printer 12. The default value is Comic Orientation. Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 1. Select Fonts/Orientation. Mode Number: Mode Name: MODE10 Mode Configuration...
  • Page 149 Print Definitions—DP12 This mode defines the information printed on each document, based upon the document level. The default values are No Print Template for Level 0 documents; Print Template for Level 1, Level 2, and Level 3 documents. The default is IA-No Del. Microimager 70 Microimager 70/AFM Scanner 900...
  • Page 150 When using a Microimager 70 with the Advanced Function Module installed, all of the print templates defined during machine configuration are available for selection. 2. Select the print template which contains the information to be printed on all documents. 3. Select Print Sequence—Level # for the desired level. Mode Number: Mode Name: MODE10...
  • Page 151 Document Sorter OFF Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 Select Document Sorter and the following screen appears: Mode Number: Mode Name: MODE10 Sort Criteria Document Sorter Status Default Stopper Upper Error Response Level 0 Docs Default Sort Criteria Level 1 Docs...
  • Page 152 If 4 selections have been set and you choose a 5th option, the following screen appears: Mode Number: Mode Name: MODE10 Mode Configuration ** ERROR ** Maximum number of sorting MODE 10 Mode Name Ftswitch Pressed Undef criteria has been reached 3 Lvl Index Format Ftswitch Released...
  • Page 153 Film Definition This mode enables or disables filming. This option is set as follows: Microimager 70 F (film) Scanners 900, 923, 9500 NoF (no film) Scanner/Microimager 990 F (film) Microimager 70 Microimager 70/AFM Scanner 900 Scanner 923 Scanner/Microimager 990 Scanner 9500 Mode Number: Mode Name: MODE10...
  • Page 154 4 Installation Questionnaire General Information CUSTOMER NAME: __________________________________________________________________ CUSTOMER ADDRESS: _______________________________________________________________ __________________________________________________________________________________ CUSTOMER CONTACT: _________________________________PHONE: _______________________ SALES REPRESENTATIVE: ______________________________PHONE: _______________________ TRAINER: ____________________________________________PHONE: _______________________ MACHINE ID NUMBER ______________ MODE NUMBER/NAME APPLICATION(S) 1_____________________ ________________________________________________________ 2_____________________ ________________________________________________________ 3_____________________ ________________________________________________________ 4_____________________ ________________________________________________________ 5_____________________ ________________________________________________________ 6_____________________ ________________________________________________________ 7_____________________...
  • Page 155 Machine Definitions Accessory Status Messages Definition _____________ Adv. Doc. Controller Diagnostic Message - No entry Allowed. _____________ Bar Code Reader _____________ Doc Scanning Array _____________ Check Feeder _____________ Check Stacker _____________ Document Sorter _____________ Endorser _____________ Footswitch _____________ Film Writing Module 10.0 Doc.
  • Page 156 Print Template # Print Template # Print Template # ITEM LINE PRINT ITEM ITEM LINE PRINT ITEM ITEM LINE PRINT ITEM Print Template # Print Template # Print Template # ITEM LINE PRINT ITEM ITEM LINE PRINT ITEM ITEM LINE PRINT ITEM Print Template # Print Template #...
  • Page 157 Mode Definitions MODE 1 Original Setup Update (enter date) __________ 31.1 Length Monitor Filename: _____________.cfg 31.1 _______ Status May be linked with Mode(s): ________________ 31.2 _______ Max. Doc. Length 31.3 _______ Min. Doc. Length __________ 19.0 Mode Name 31.4 _______ Error Response __________ 20.0 Index Format 32.0...
  • Page 158 Mode Definitions MODE 1 44.0 COIN User Channel 44.1 Transmit Data ________ Level 0 ________ Level 1 ________ Level 2 ________ Level 3 45.0 Printer Control 45.1 _______ IA Print Format 45.2 _______ Print Position 45.3 _______ Special Char Set 46.0 Primary Document Printer 1 46.1 _______ Status...
  • Page 159 A PPEN D IX A : System Map Mainframe Configuration MACHINE STATE Display Machine Accessories Machine ID Number Display Language Measurement System Programmable Function Keys Date Format Time Format Alarm Tone Doc Printer/Film Writer Msg DP-12 Print Template Fixed Field Delimiter Set System Clock Version Numbers User COIN Port Protocol...
  • Page 160 Mode Number: Mode Name: MODE10 Mode to Mode Copy Copy From Mode: Copy Mode 1 Copy Mode 2 Copy Mode 3 Copy Mode 4 Copy Mode 5 Copy Mode 6 Copy Mode 7 Copy Mode 8 Copy Mode 9 Copy From Copy Mode 10 Mode: Copy Mode 11...
  • Page 161 A PPEN D IX B : Function Codes P-Key Definition Input Code Function Code Name/Description Required Optional Select Mode 2-digit mode number Allows you to select one of the eighteen (18) application modes. Restore Mode Allows you to restore the current application mode to its default status (as it was defined at installation), provided that mode overrides are not saved.
  • Page 162 P-Key Definition Input Code Function Code Name/Description Required Optional † Level 2 Count Allows you to display the total number of documents assigned Level 2. Also allows you to reset the count to zero. † Level 3 Count Allows you to display the total number of documents assigned Level 3.
  • Page 163 P-Key Definition Input Code Function Code Name/Description Required Optional F26* AEC Fixed Adjust Allows you to adjust the AEC exposure setting when the AEC is in Fixed Mode (OFF). † Film Advance Allows you to advance the film in six (6) inch [150 mm] increments, or by a specific amount input in inches or millimetres.
  • Page 164 P-Key Definition Input Code Function Code Name/Description Required Optional Primary DP1 On/Off off/disable Allows you to turn the primary document printer 1 on on/enable or off. F42*** Secondary DP1 On/Off off/disable Allows you to turn the secondary document printer 1 on/enable on or off.
  • Page 165 P-Key Definition Input Code Function Code Name/Description Required Optional Endorser Print Position Allows you to specify how far from the leading edge of the document the endorsement will appear. F60*** Bar Code Reading 1 On/Off off/disable Allows you to turn bar code reading on or off. on/enable F62*** Bar Code/Patch Reading Confirmation Tone...
  • Page 166 P-Key Definition Input Code Function Code Name/Description Required Optional F76 ‡ OCR On/Off off/disable Allows you to turn OCR on or off. on/enable Document Sorter On/Off off/disable Allows you to turn the document sorter on or off. on/enable † Sort Next Document to Specified Hopper Allows you to specify the hopper (default, upper, or lower) in which the next document only will be deposited.
  • Page 167 A PPEN D IX C : Recommended Entries Item Description Values Item Description Values Accessory Status PRES (Present) 14.0 User COIN Port NO (Not used) NOTPRES (Not Present) Protocol YES (Used) Machine ID Number 00 – 99 Baud rate Display Language ENG (English) 1200 FREN (French)
  • Page 168 Item Description Values 22.0 Image Address 0 – 9 30.5 Image Mark Sizes CUST (Custom) Field Widths KOD (Kodak Standard) 30.6 Image Polarity OPP (Opposite of IM) 23.0 Level Rules Level 0 SAME (Same as IM) Level 1 Level 2 30.7...
  • Page 169 Item Description Values Item Description Values 36.0 Footswitch OFF (Undefined) 41.12 End Fed Patch ON (Enabled) Released Level 0 OFF (Disabled) Level 1 41.13 Level Change Level 0 Level 2 Level 1 Level 3 Level 2 INC (Increment) Level 3 OFF (Undefined) 37.0 Footswitch...
  • Page 170 Item Description Values 47.3 Print Definitions Enter item(s) 48.0 Document Printer 12 48.1 Status ON (Enabled) OFF (Disabled) 48.2 Font/Orientation COM (Comic) COM180 (Comic 180) 48.3 Print Definitions Enter template 49.0 Document Sorter 49.1 Status ON (Enabled) OFF (Disabled) 49.2 Error Response DISP (Display) BEEP (Display and Beep)
  • Page 171 EASTMAN KODAK COMPANY Business Imaging Systems Rochester, New York 14650 Kodak, Digital Science, the ds monogram symbol, and Imagelink are trademarks of Eastman Kodak Company. Printed on recycled paper. BUSINESS A-61097 5/97 I M AG I N G © Eastman Kodak Company, 1997 SYSTEMS Printed in U.S.A.

This manual is also suitable for:

Digital scienceImagelink

Table of Contents
