Service Manual
Refrigerator
MODEL : FR-15A
FR-15B
Caution :
In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS Corp.
http : //svc.dwe.co.kr
S/M No. : FN15000030
MAR. 2011
Advertisement
Table of Contents
Related Manuals for Daewoo FR-15A
Summary of Contents for Daewoo FR-15A
- Page 1 S/M No. : FN15000030 Service Manual Refrigerator MODEL : FR-15A FR-15B Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
-
Page 2: Table Of Contents
CONTENTS 1. SPECIFICATION .......................2 2. EXTERNAL VIEW .....................3 3. WIRE DIAGRAM .......................4 4. NAME OF PARTS......................5 5. REFRIGERANT CYCLE DIAGRAM ................6 6. MACHINE ROOM VIEW AND PARTS LIST..............7 7. MAIN COMPONENTS ....................8 8. DOOR COLOR SPECIFICATION ................10 9. EXPLODED VIEW AND PARTSLIST ...............11... -
Page 3: Specification
SPECIFICATION 5A/B Refrigerant i l o ì t Roll Bondî type g i r i t a l a r - d l r i a i t n r f e l a r o r f i t a r a t &... -
Page 4: External View
EXTERNAL VIEW... -
Page 5: Wire Diagram
WIRE DIAGRAM FR-15A,FR-15B CAFE TERMOSTATO P-RELAY AZUL AMARILLO COMPRESOR CABLE... -
Page 6: Name Of Parts
NAME OF PARTS r cover e l t i r c f l e d i l... -
Page 7: Refrigerant Cycle Diagram
REFRIGERANT CYCLE DIAGRAM EVAPORATOR DRYER COMPRESSOR... -
Page 8: Machine Room View And Parts List
MACHINE ROOM VIEW AND PART LIST BASE CABINET POWER BOX BRACKET EARTH... -
Page 9: Main Components
MAIN COMPONENTS 1.COMPRESSOR i r f 134a Voltage 127V/60Hz D25BZ Comp model Part Code 3953140750 Start type RSIR 2. RELAY ASSEMBLY i r f R134a 127V/60Hz Voltage Spec QP2-4.7/B58-125 Part Code 3018123210 3.CONTROL SWITCH i r f R134a Voltage 127V/60Hz Spec WPFE18A-L-02SS 3018300870... - Page 10 MAIN COMPONENTS POWER CORD SPECIFICATION SHAPE OF POWER CODE PART CODE DESCRIPTION REMARK 3011300321 CP-2PIN 4017J17101 CP-2PIN 4006D17101 KP-30 3011304520 DKP-301U 401PD17101 KP-211 3011316201 BP-3PIN 3011300971 FOR SWISS #267 3011303020 FOR OTHER CONURTY 3011316101 FOR ISRAEL 3011303901 FOR EUROPEAN&SAUDI 3011303921 FOR SINGAPORE BS-1363A 3011303040...
-
Page 11: Door Color Specification
DOOR COLOR SPECIFICATION 1. ASSEMBLY URETHAN DOOR R134a Refrigerant BLACK WHITE Material Normal PCM GLASS GLASS PFTT00D275 PFTT00D270 PFTT00D260 Part Code... -
Page 12: Exploded View And Partslist
EXPLODED VIEW AND PARTS LIST 1. FR-15A,FR-15B... - Page 13 EXPLODED VIEW AND PARTS LIST CAUTION : In this Service Manual, some parts can be changed for improving their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Part s Price List)in Service information Center(http://svc.dwe.co.kr) PART CODE PART NAME DESCRIPTION...
- Page 14 DAEWOO ELECTRONICS Corp.
