7. Insert the bottom hinge at the left side using

the two screws previously removed in step 6.

NOTE: Do not tighten screws.

8. Stand the cabinet.

9. Replace the door making sure the bottom

socket enters the bottom hinge pin.

Be sure washer is in place.

10. While holding the door in the closed position,

secure the top hinge at the left side using the

two screws previously removed at the

beginning in step 2.

Do not tighten the screws until the top of the

door is leveled with the top cabinet.

11. Replace the hinge cover.

12. Tools required:

-8MM & 10MM socket-ratchet.

-Putty knife or thin-blade screwdriver.

If the supply cord is damaged, it must be replaced by the manufacturer or its service agent

or a simmilary qualified person in order to avoid a hazard.

REFRIGERATOR

INSTRUCTION MANUA

Model No.

FR-063R / FR-093R / FR-153R

CFC-FREE

§ š

Before use, please read this manual carefully.

ß ö

Always remove the drain pan while this refrigerator is running.

ß ö

Removing the drain pan will enhance the cooling power and save your electric cost.

Table of Contents

Page 1 Model No. Be sure washer is in place. FR-063R / FR-093R / FR-153R 10. While holding the door in the closed position, secure the top hinge at the left side using the two screws previously removed at the beginning in step 2.
Page 2: Names Of The Parts
NAMES OF THE PARTS FR-063R ¡á FR-153R 4 10 11 2 1 1. EVAPORATOR The heart of the refrigerator. It evaporates the refrigerant fluid and thereby absorbs heat from the surrounding. Made of pure ¡á FR-093R aluminum. 2. DRAIN PAN (Use of Defrost Only) Discards the water that drips of the evaporator when defrosting.
Page 3: How To Operate
HOW TO OPERATE HOW TO CLEAN Starting your new Refrigerator Cleaners: The cleaners noted below are available. Never use harsh, abrasive cleaners, heavy- duty cleaners, or solvents on any surface. 1. Clean the refrigerator thoroughly. Wipe the outside with a soft dry cloth, the inside with a Exterior: Wipe with damp, sudsy cloth, rinse and dry.
Page 4: Changing The Reversible Door
WHAT TO DO... CHANGING THE REVERSIBLE DOOR This refrigerator has been built with the door hinges on the right. 1. When out of operating for a long time: If you wish to change the opening direction, follow the instruction below: ¦U Remove the power supply cord.
