2. With the applied load force at location A, begin
to slowly loosen the lock nut until the lever
can barely rotate to the full downward (stop)
position.
Adjusting Governor Lever
To adjust the governor lever, the air box has to be
installed and tightened on the carburetor studs to hold
the carburetor in its normal position.
1. Loosen the governor lever hex flange nut. Push
and hold the governor lever in the direction
indicated in Figure 23. Continue holding in this
direction throughout this procedure. Turn the
governor shaft clockwise until it stops. Tighten
the hex flange nut on the governor lever clamp
bolt to lock the lever on the shaft. Torque the nut
to 10 N·m (89 in. lb.).
Push Lever
Governor Shaft
Figure 23. Governor Lever Adjustment.

Fuel Filter

Replace the in-nipple fuel filter every 100 hours of
operation, with a genuine Kohler filter. Remove the air
box cover, retractable starter cover, and engine cover
to access the fuel line. See Figure 24.
Fuel Tank Nipple
In-Nipple Fuel Filter
Fuel Line
Figure 24. In-Nipple Fuel Filter.
8
Governor Lever
Hex Flange Nut
1. Remove the fuel line to access the fuel filter. The
fuel filter may remain in the fuel line when the
fuel line is removed. Pull the fuel filter out of the
fuel tank nipple or the fuel line and discard.
2. Insert a new fuel filter into the fuel tank nipple
and push the fuel line onto the fuel tank nipple.
Check Spark Plug
Every 100 hours of operation, remove the spark plug,
check condition, and reset the gap or replace with
a new plug as necessary. The original spark plug is
a Champion® XC12YC. Equivalent alternate brand
plugs can also be used. Refer to the CH270 service
manual for instructions to service the spark plug.
Electronic Ignition System and Stator
Ignition Module
Spark
Plug
Ground
Stop/Run Key
Ground
Figure 25. Wiring Diagram.
Check Oil Level
The importance of checking and maintaining
the proper oil level in the crankcase cannot be
overemphasized. Check oil BEFORE EACH USE as
follows:
1. Make sure the engine is stopped, level, and is
cool so the oil has had time to drain into the
sump.
2. Clean the area around and beneath the dipstick
before removing it. This will help keep snow, ice,
and other foreign matter out of the engine. See
Figure 26.
Stator
18 Watt
Terminal
Control Lever Switch
Ground
