Polycom VVX 500 Owner's Manual page 8

Button Description
Voicemail Flashing red light indicates there is a
1
Indicator voicemail on the phone.
The home key returns you to the
2
Home
Screen of the phone. Pressing it
twice returns you to the idle screen.
Color Touch Screen. Touch sen-
Full Color
sitive, full color screen that allows
3
Touch Screen
you to tap to highlight and select, or
scroll using up down left and right
movements.
Headset Key- Light is green with the
use of an analog headset and Blue
4
when using a USB headset.
Speakerphone Key – Glows green
5
when in use.
6 Mute Key- Glows red when in use.
7 Volume up and down key
Transmits sound without using
8 Microphone
the handset, this is an audio input
device.
Transmits sound without using the
9 Speaker
handset, this is for audio output.
Allows entry of numbers, letters and
other characters, also allows for
10 Dial Pad
selection of numbered menu items.
8
