Plantronics RIG User Manual

Gaming headphones
Hide thumbs Also See for RIG:
Table of Contents

Advertisement

Quick Links

RIG
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Plantronics RIG

Summary of Contents for Plantronics RIG

  • Page 1 User Guide...

  • Page 2: Table Of Contents

    Contents Welcome What's in the box System overview Be safe Headset basics Installing a microphone Using the inline microphone PC setup Xbox 360 setup Xbox 360 optical cable setup Xbox 360 component setup Xbox 360 HDMI setup* Sony Playstation setup PS3 optical cable setup PS3 component setup PS4 setup...

  • Page 3: Welcome

    RIG was designed from the ground up for deeply immersive game audio but without losing your connection to the world. When connected to a mobile device, RIG blends game and chat with mobile audio, apps, and alerts—and best of all—enables you to take calls without pausing the game.

  • Page 4: What's In The Box

    What's in the box Headset Mixer Boom microphone/cable Optional in-line microphone/ ® Xbox LIVE chat cable RCA piggyback cable cable...

  • Page 5: System Overview

    System overview Headset Headband adjustment Microphone port Right ear indicator Mixer Power on/off Game/chat sound balancer Master volume dial Call button Mobile microphone Equalizer button Game microphone Master mute button Game/mobile sound balancer...

  • Page 6: Be Safe

    Boom microphone/cable Boom Optional inline microphone/cable Call button Mute switch Be safe Please read the safety guide for important safety, charging, battery and regulatory information before using your new headset.

  • Page 7: Headset Basics

    Designed to connect and mix audio from your mobile device with a game console or PC, the mixer shines when integrated with a mobile device. This next section enables you to get the most out of everything RIG can do for your game.

  • Page 8: Using The Inline Microphone

    Using the inline Use the stealth inline microphone for the occasions when connecting directly to a mobile microphone device. The controls are easy to use and perfect for mobile calls, gaming and music on-the-go. Use the boom microphone for gaming sessions. 1.

  • Page 9: Pc Setup

    PC setup Make sure the boom microphone is attached properly to the headset. Insert the headset 3.5mm plug into the headset jack on the front of the mixer located under the RIG logo tab, on the left side. Attached to the mixer is a set of cables that includes a long cord with a 3.5mm audio and USB connectors.

  • Page 10: Xbox 360 Setup

    Make sure the boom microphone is attached properly to the headset. Insert the 3.5mm plug into the headset jack on the front of the mixer located under the RIG logo tab, on the left side. Insert the included Xbox Live chat cable into the 2.5mm jack (smaller of the two) located to the right of the headset jack on front of the mixer.

  • Page 11: Xbox 360 Component Setup

    Make sure the boom microphone is attached properly to the headset. Insert the 3.5mm plug into the headset jack on the front of the mixer located under the RIG logo tab, on the left side. Connect the USB cable from the mixer into a USB port on the Xbox 360. For proper function: make sure that the USB connector is plugged into the Xbox 360 itself and not an external USB power source.

  • Page 12: Xbox 360 Hdmi Setup

    Make sure the boom microphone is attached properly to the headset. Insert the 3.5mm plug into the headset jack on the front of the mixer located under the RIG logo tab, on the left side. Connect the USB cable from the mixer into a USB port on the Xbox 360 (For proper function: make sure that the USB connector is plugged into the Xbox 360 itself and not an external USB power source.

  • Page 13: Sony Playstation Setup

    Make sure the boom microphone is attached properly to the RIG headset. Insert the 3.5mm plug into the headset jack on the front of the mixer located under the RIG logo tab, on the left side. Attach a Toslink digital optical cable to the appropriate port on your Playstation 3, HDTV, A/V Receiver, or other audio device.

  • Page 14: Ps3 Component Setup

    Make sure the boom microphone is attached properly to the headset. Insert the 3.5mm plug into the headset jack on the front of the mixer located under the RIG logo tab, on the left side. Connect the USB cable from the mixer into an available USB port on the PS3.

  • Page 15: Ps4 Setup

    Make sure the boom microphone is attached properly to the headset. Insert the 3.5mm plug into the headset jack on the front of the mixer located under the RIG logo tab, on the left side. Connect an TOSlink optical cable (sold separately) from the optical input on the rear of the mixer to the optical output on the back of the PS4.

  • Page 16: Ps Vita Setup

    PS Vita setup Insert the 3-pole connector of the inline microphone cable into the port located on the bottom of the left ear cup of the headset. Insert the 4-pole connector into the 3.5mm jack on the PS Vita.

  • Page 17: The Mixer

    The mixer Powering up PRO TIP The mixer must be connected via USB to the platform that you are using it with for proper operation. External USB power adapters will NOT function correctly. Do not shake or taunt the mixer. Rotate the outer Master volume dial to the right (clockwise) to turn on the mixer.

  • Page 18: Mic Rocker Switch

    CAUTION Do not use headsets at high volumes for an extended period of time. Doing so can cause hearing loss. Always listen at moderate levels. See for more information on headsets and hearing. Mic rocker switch In the center of the mixer, the large, glossy paddle controls many elements of the audio experience.

  • Page 19: Game/Mobile Sound Balancer

    Skype video chat via connected tablet, and listening and playing along with walkthroughs on YouTube instead of pausing gameplay to watch the video. RIG enables a dedicated mobile channel for audio and chat - take advantage! Play more. Pause less.

  • Page 20: Take Calls. Keep Playing

    Take calls. Keep playing. To answer a call from your mobile device while in a game, flip the Mic rocker switch to the Mobile mode (blue) and tap the Call button . The mixer enables toggling back-and-forth between game chat and mobile calls without disconnecting either conversation.

  • Page 21: Combo Chat

    If you press the EQ button you'll hear and this will happen once 1 tone PURE The Pure mode has only minor audio corrections that enable audio played through the headset as flat and accurate as possible. Use this mode if high-fidelity to the source material is important or preferred.

  • Page 22: Faq

    The Mute LED won't turn off. Make sure 3.5 mm cable is firmly plugged into the mixer. Callers can't hear me when I Make sure the Mic rocker switch is deployed to Mobile mode answer a phone call. (blue). I can't hear the person on the other Make sure that the game/mobile sound balancer (the left slider) end of the phone call.

  • Page 23: Support

    2132 LR Hoofddorp, Netherlands © 2014 Plantronics, Inc. All Rights Reserved. Bluetooth is a registered trademark of Bluetooth SIG, Inc. and any use by Plantronics is under license. All other trademarks are the property of their respective owners. US Patents Pending...
