- Page 1 TOSHIBA 2ST Label Printer DB-EA4D Printer Driver Manual First Edition: April 27, 2012...
- Page 2 Notes: All rights reserved. It is prohibited to use or duplicate a part or whole of this document without the permission of TOSHIBA TEC SINGAPORE PTE LTD. This document is subject to change without prior notice. Microsoft, Windows, Windows NT, Windows 2000, Windows XP and Windows 7 are registered trademarks of Microsoft Corporation in the United States and/or other countries.
-
Page 3: Table Of Contents
Table of Content 1. System Requirement ..............1 2. Driver Installation guide ............2 2.1. Installation for Windows 7(32-bit, 64-bit)............2 2.2. Hardware Wizard ....................20 2.3. Update Driver....................21 3. Printer Properties and Settings ..........25 3.1. Printer Configuration ..................25 3.2. -
Page 4: System Requirement
2ST Label Printer - Windows Driver User’s Manual 1. System Requirement Windows XP Professional (English) / 7(32bit, 64bit)(English) Language: English Printer I/F: USB (Printer Class) LAN (TCP/IP) Parallel (Option) - 1 -... -
Page 5: Driver Installation Guide
Installation on USB I/F Plug printer on USB I/F and turn it on, before running installer. You'll see "Unspecified" icon named "DB-EA4D" as shown below. After this, run your printer driver's package to unpack and start installation. - 2 -... - Page 6 2ST Label Printer - Windows Driver User’s Manual Select "I accept…" and click "Next >". Specify the directory to unpack and click "Next >". - 3 -...
- Page 7 2ST Label Printer - Windows Driver User’s Manual Click "Finish" to start unpacking drivers and "Driver Wizard" will run automatically as shown below. Select "Install printer drivers" and click "Next >". - 4 -...
- Page 8 2ST Label Printer - Windows Driver User’s Manual Select "Install a driver for a Plug and Play printer” and click "Next >" to proceed installation. Specify "Printer name" and select "Do not share…" and click "Next >". - 5 -...
- Page 9 2ST Label Printer - Windows Driver User’s Manual Click "Finish" to begin installation process. - 6 -...
- Page 10 2ST Label Printer - Windows Driver User’s Manual You'll see this warning, please click "Install" to proceed. Printer driver for "TOSHIBA DB-EA4D" is installed, click "Close" to complete. - 7 -...
- Page 11 2ST Label Printer - Windows Driver User’s Manual After installation, you'll see below "TOSHIBA DB-EA4D" icon in the "Devices and Printers" folder. - 8 -...
- Page 12 2ST Label Printer - Windows Driver User’s Manual 2.1.2. Installation on Parallel I/F Run your printer driver's package to unpack and start installation. Select "I accept…" and click "Next >". - 9 -...
- Page 13 2ST Label Printer - Windows Driver User’s Manual Specify the directory to unpack and click "Next >". Click "Finish" to start unpacking drivers and "Driver Wizard" will run automatically as shown below. - 10 -...
- Page 14 2ST Label Printer - Windows Driver User’s Manual Select "Install printer drivers" and click "Next >". Select "TOSHIBA DB-EA4D" and click "Next >". - 11 -...
- Page 15 2ST Label Printer - Windows Driver User’s Manual Select "LPT1:" and click "Next >". Specify "Printer name" and select "Do not share…" and click "Next >". - 12 -...
- Page 16 2ST Label Printer - Windows Driver User’s Manual Click "Finish" to begin installation process. Printer driver for "TOSHIBA DB-EA4D" is installed, click "Close" to complete. - 13 -...
- Page 17 2ST Label Printer - Windows Driver User’s Manual 2.1.3. Installation on Ethernet Follow the same install operation as " Installation on Parallel I/F" until you see the dialog to specify port as shown below. If you have no TCP/IP Port which has same IP Address as printer has, click "Create Port…".
- Page 18 2ST Label Printer - Windows Driver User’s Manual Click "Next >". Specify the IP address with which printer is configured and click "Next >". - 15 -...
- Page 19 2ST Label Printer - Windows Driver User’s Manual Click "Next >". Click "Finish" to complete the wizard. - 16 -...
- Page 20 2ST Label Printer - Windows Driver User’s Manual Click "Close". Make sure the new port is created and click "Next >". After this, follow the same operations as "Installation on Parallel I/F". - 17 -...
- Page 21 2ST Label Printer - Windows Driver User’s Manual 2.1.4. Install by Plug-N-Play by Parallel Connect your printer with Parallel cable and turn it on, then restart your PC. You'll see the "Unspecified" icon is created in "Devices and Printers" folder. After this, please proceed your installation process as shown in "2.1.2".
- Page 22 2ST Label Printer - Windows Driver User’s Manual You'll see below dialog during your installation process. Click "Next >" to proceed your installation on this dialog. After installation completes, the "Unspecified" icon is removed and "TOSHIBA DB-EA4D" icon is created as shown below. - 19 -...
-
Page 23: Hardware Wizard
USB or parallel I/F. Please ignore this wizard and proceed your installation with printer driver package or "DriverWizard.exe" extracted from the package. After installation, you'll see "TOSHIBA DB-EA4D" in the "Printers and Faxes" folder as shown below. - 20 -... -
Page 24: Update Driver
2ST Label Printer - Windows Driver User’s Manual 2.3. Update Driver To update printer driver, run your new printer driver package to start installation process as shown in "2.1 Installation for Windows 7(32-bit, 64-bit)". When you see below dialog, please select "Upgrade printer drivers" and click "Next >"... - Page 25 2ST Label Printer - Windows Driver User’s Manual Make sure the version installed and to be update as shown above. Click "Next >". Click "Finish" to complete the Wizard and start updating printer driver. - 22 -...
- Page 26 2ST Label Printer - Windows Driver User’s Manual Click "Restart". After restarting your system, update of printer driver completes. Click "Close" to complete. - 23 -...
- Page 27 2ST Label Printer - Windows Driver User’s Manual To confirm the printer version, open "About" tab of printer's properties as shown below and click "Version…” - 24 -...
-
Page 28: Printer Properties And Settings
*1 Available only if "Labels With Black Marks" is selected. *2 Available only if "variable print speed" is enabled. In order to configure printer's option, click right button and select "Printer properties" on the "TOSHIBA DB-EA4D" icon to open printer's properties. - 25 -... - Page 29 2ST Label Printer - Windows Driver User’s Manual "Printer Properties" will open as shown below. Click "Preferences…". - 26 -...
- Page 30 2ST Label Printer - Windows Driver User’s Manual "Printing Preferences" will open as shown below. Click "Configure…" Below window will be shown during communicating with printer. - 27 -...
- Page 31 2ST Label Printer - Windows Driver User’s Manual 3.1.1. Media Settings "Printer Configuration" will open and you'll see current "Media Settings" as shown below. In order to change its configurations, please follow the operations below. 5 options are available for "Media Type" as shown above. - 28 -...
- Page 32 2ST Label Printer - Windows Driver User’s Manual 4 options are available for "Form Width" as shown above. About "Form Length", you can input in the text box shown above. - 29 -...
- Page 33 2ST Label Printer - Windows Driver User’s Manual If you select "Labels With Black marks" for "Media Type", you can define the "Cut Offset" which is the distance between black mark and the cut position. After you finish your setup, click "Apply" to change printer's configuration. - 30 -...
- Page 34 2ST Label Printer - Windows Driver User’s Manual 3.1.2. Print Speed and Darkness Select "Options" tab and you'll see current configuration of "Print Speed" and "Darkness" as shown below. In order to change those configurations, please follow the operations below. In case "Variable Print Speed"...
- Page 35 2ST Label Printer - Windows Driver User’s Manual In case "Variable Print Speed" is enabled, printer will automatically adjust its printing speed. But you can specify printer's "Maximum Print Speed" from 3.00in/sec to 6.00in/sec as shown above. About "Darkness" option, move the slider to left/right to change its configuration.
-
Page 36: Printer Status
2ST Label Printer - Windows Driver User’s Manual 3.2. Printer Status To check printer's status, please configure "Status Monitoring". Open printer's property and select "Tools" tab as show below. - 33 -... - Page 37 2ST Label Printer - Windows Driver User’s Manual Here, select "Continuous" as shown above to see how this feature works. For the details of each option, please refer to help. An icon is shown in taskbar notification area and you can open "Status Windows"...
- Page 38 2ST Label Printer - Windows Driver User’s Manual With regard to the other printer's status, please see below table for the details. Table 3-2 Printer's status and message Printer's Status Message shown on Windows Paper Jam Error Paper Jam Cutter Jam Error Cutter Error Head Temperature Error Head Temperature High...
-
Page 39: Device Setting
2ST Label Printer - Windows Driver User’s Manual 3.3. Device Setting To configure your media to print, open "Printer Properties" as shown below. Click "Preferences…". - 36 -... - Page 40 2ST Label Printer - Windows Driver User’s Manual In this configuration, the media to print is called as "Stock" as shown above, and we'll give you the example how to configure your "media" with "USER (4.00in x 4.00in)" stock. * "USER (4.00in x 4.00in)" is the only configurable stock by default but you can create any new stock on this "Page Setup"...
- Page 41 2ST Label Printer - Windows Driver User’s Manual Input the "Width" of your media. Input the "Height" of your media. - 38 -...
- Page 42 2ST Label Printer - Windows Driver User’s Manual If your media is "Label" type and has "Liner", please set below sizes. Input the "Width(Left)" of exposed liner. Input the "Width(Right)" of exposed liner. - 39 -...
- Page 43 2ST Label Printer - Windows Driver User’s Manual Note) If your printer works with perforation paper (with hole), please see below how to configure. Switch to "Stock" tab on "Printing Preferences". Select "Labels With Perforation". - 40 -...
- Page 44 2ST Label Printer - Windows Driver User’s Manual Click "Apply" or "OK" to finish. - 41 -...
-
Page 45: Document Printing
2ST Label Printer - Windows Driver User’s Manual 3.4. Document Printing Please refer to below operations to print with "Word" document. Open a document with "Microsoft Word". - 42 -... - Page 46 2ST Label Printer - Windows Driver User’s Manual Point "File" menu and "Print" option. Select "TOSHIBA DB-EA4D" and click "Printer Properties". - 43 -...
- Page 47 2ST Label Printer - Windows Driver User’s Manual Select the stock type with which your printer works. Click "OK" to close. - 44 -...
- Page 48 2ST Label Printer - Windows Driver User’s Manual Click "Print" to print the document. - 45 -...
- Page 49 2ST Label Printer - Windows Driver User’s Manual Below is print result. - 46 -...
- Page 50 2ST Label Printer - Windows Driver User’s Manual - 47 -...
-
Page 51: Un-Installation Of Printer Driver
2ST Label Printer - Windows Driver User’s Manual 4. Un-installation of Printer Driver To uninstall printer driver, run your new printer driver package to start installation process as shown in "2.1 Installation for Windows 7(32-bit, 64-bit)". When you see below dialog, please select "Remove printer drivers" and click "Next >"... - Page 52 2ST Label Printer - Windows Driver User’s Manual Select "Automatically remove all Drivers by Seagull" and click "Next > " to proceed. Click "Finish" to complete the Wizard and start removing printer driver. - 49 -...
- Page 53 2ST Label Printer - Windows Driver User’s Manual Click "Restart". After restarting your system, removal of printer driver completes. Click "Close" to complete. - 50 -...
