Invacare® Tornado
Electric Wheelchair
Operating Instructions

Advertisement

Table of Contents
loading

Related Manuals for Invacare Tornado

Summary of Contents for Invacare Tornado

  • Page 1 Invacare® Tornado Electric Wheelchair Operating Instructions...
  • Page 2 How can you get in touch with Invacare®? If you have any questions or need support, please contact your authorised Invacare® Dealer, who has the necessary know-how and equipment plus the special knowledge concerning your Invacare® product, and can offer you all-round satisfactory service. Should you wish to contact Invacare® directly, you can reach us in Europe at the following addresses and phone numbers.
  • Page 3 Bridgend Industrial Estate uk@invacare.com Mid Glamorgan - CF31-3PY eire@invacare.com United Kingdom WWW: www.invacare.co.uk Invacare Mecc San s.r.l. +39 - 0445 - 38 00 59 Via Dei Pini, 62 Fax: +39 - 0445 - 38 00 34 I - 36016 Thiene (VI) italia@invacare.com...
  • Page 4 +31 - (0)318 - 69 57 57 Celsiusstraat 46 Fax: +31 - (0)318 - 69 57 58 NL-6716 BZ Ede nederland@invacare.com Nederland WWW: www.invacare.nl Invacare Portugal, Lda +351-225105946 Rua Estrada Velha, 949 Fax: +351-225105739 4465-784 Leça do Balio portugal@invacare.com Portugal WWW: www.invacare.pt...

  • Page 5: Table Of Contents

    Table of Contents Chapter Page Introduction Important symbols in this manual ..................13 Important symbols found on the vehicle ................14 Type classification and permissible use................15 Guarantee ..........................15 Indications..........................16 Life expectancy........................16 Safety Notes General Safety Notes ......................17 Safety Information on Electromagnetic Interference............20 Safety Information on Driving and Freewheel Mode............21 Safety Information on Wheelchairs with a Lifter ..............23 Safety Information on Wheelchairs with Recaro Seats ............24...
  • Page 6 5.2.2 The ”Stability Lock“ System ..................30 5.2.3 The components of the "SureStep" and the "Stability Lock" system......31 5.2.4 Maximum obstacle height .....................31 5.2.5 Safety information when ascending obstacles .............32 5.2.6 Safety information when descending obstacles ............33 5.2.7 The correct way to overcome obstacles ...............34 Driving up and down gradients....................35 Parking and stationary......................36 Pushing the wheelchair in freewheel mode...
  • Page 7 Adjusting the armrests and the joystick box................54 9.2.1 Adapting the remote to the length of the user’s arm ............54 9.2.2 Setting the height of the remote ...................55 9.2.3 Setting the height of the armrests.................56 9.2.4 Adjusting the width of the armrests ................57 Manually adjusting the seat tilt ....................59 Manually adjusting the backrest ....................61 9.4.1...
  • Page 8 10 Adjusting footrests and legrests 10.1 Centre-mounted legrests ......................85 10.1.1 Electric legrest ......................85 10.1.1.1 Lowering the electric legrest completely to assist getting out of the wheelchair..86 10.1.2 Adjustable legrest ......................89 10.1.2.1 Adjusting the angle ....................89 10.1.2.2 Adjusting the length of the legrest ................90 10.1.2.3 Adjusting the calf plate to the calf width of the user ..........91 10.1.2.4...
  • Page 9 10.2.3.5 Adjusting the height of the calf plate ..............116 10.2.3.6 Unlocking and swivelling the calf plate backward when alighting ......117 10.2.3.7 Adjusting the angle adjustable foot plate...............118 10.2.3.8 Adjusting the angle and depth adjustable foot plate ..........119 10.2.4 Electrically height adjustable legrest 80° - 0° with ergonomic length adjustment ..120 10.2.4.1 Swivelling the legrest outward and/or removing............120 10.2.4.2...
  • Page 10 14.1 Transferring the wheelchair to a vehicle................151 14.2 Use of the wheelchair as a seat in a vehicle...............153 14.2.1 How the wheelchair is anchored in a vehicle for use as a vehicle seat .....155 14.2.2 How the user is secured within the wheelchair............156 14.3 Securing the wheelchair for transport without passengers ..........159 15 Refurbishment...

  • Page 11: Introduction

    The decision whether the model is suitable for the user may only be taken by medical specialists with appropriate expertise. Invacare® or their statutory representatives can accept no liability in cases in which the wheelchair has not been adapted to suit the users’ handicaps.
  • Page 12 This manual contains copyrighted information. This manual may not be reproduced or reprinted either partly or completely without previous written consent from Invacare® or its statutory representatives. We reserve the right to make any necessary alterations on the grounds of...

  • Page 13: Important Symbols In This Manual

    Important symbols in this manual WARNING! This symbol warns you of danger! • Always follow these instructions to avoid injury to the user or damage to the product! EXPLOSION HAZARD! This symbol warns you of an explosion hazard, which, for example, can be caused by excessive tyre pressure in a pneumatic tyre! •...

  • Page 14: Important Symbols Found On The Vehicle

    Important symbols found on the vehicle This product has been supplied from an environmentally aware manufacturer that complies with the Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/CE. This product may contain substances that could be harmful to the environment if disposed of in places (landfills) that are not appropriate according to legislation.

  • Page 15: Type Classification And Permissible Use

    Type classification and permissible use This vehicle was designed for persons whose ability to walk is impaired, but who are still physically and mentally able to operate an electric vehicle. It has been classified according to EN 12184 as a class B mobility product (for indoor and outdoor areas).

  • Page 16: Indications

    Indications The use of this mobility product is recommended for the following indications: The inability or a greatly restricted ability to walk within the scope of the basic requirement to be able to move within one’s own four walls. The need to leave the dwelling place in order to get some fresh air during a short walk or to reach those places generally to be found at close distance to the dwelling and where everyday business is carried out.

  • Page 17: Safety Notes

    Safety Notes READ WELL BEFORE OPERATION! General Safety Notes Danger of injury if mobility device is used in any other way than the purpose described in this manual! • Only ever use the mobility device in accordance with the instructions in this User's Manual (see chapter "Type classification and permissible use"...
  • Page 18 Danger of injury if the mobility device is switched off while driving, for example by pressing the On/Off Button or disconnecting a cable, due to it coming to an abrupt, sharp stop! • If you have to brake in an emergency, simply release the joystick which will bring you to a halt. (refer to the joystick operating manual for more information).
  • Page 19 Danger of fire or breaking down due to electric devices being connected! • Do not connect any electric devices to your mobility device that are not expressly certified by Invacare® for this purpose. Have all electrical installations done by your authorised Invacare® Dealer.

  • Page 20: Safety Information On Electromagnetic Interference

    Safety Information on Electromagnetic Interference This electric vehicle was successfully tested in accordance with International standards as to its compliance with Electromagnetic Interference (EMI) Regulations. However, electromagnetic fields, such as those generated by radio and television transmitters, and cellular phones, can influence the functions of electric vehicles.

  • Page 21: Safety Information On Driving And Freewheel Mode

    Safety Information on Driving and Freewheel Mode Danger of injury if the wheelchair tips over! • Inclines and declines can only be travelled up to the maximum safe slope (see chapter "Technical Specifications" from page 162). • Always return the backrest of your seat or the seat tilt to an upright position before ascending slopes.
  • Page 22 Danger of breaking down in adverse weather conditions, i.e. extreme cold, in an isolated area! • If you are a user with severely limited mobility, we advise that in the case of adverse weather conditions DO NOT attempt a journey without an accompanying attendant! Danger of injury if your foot slides off the footrest and gets caught underneath the wheelchair when it is in motion! •...

  • Page 23: Safety Information On Wheelchairs With A Lifter

    Safety Information on Wheelchairs with a Lifter IMPORTANT - IF YOUR WHEELCHAIR IS EQUIPPED WITH A LIFTER: Danger of injury if the wheelchair tips over! • Never exceed the maximum permissible load (see chapter "Technical Specifications" from page 162)! • Avoid dangerous driving situations when the lifter is in a raised position, such as trying to overcome obstacles like kerbs or driving up or down steep gradients! •...

  • Page 24: Safety Information On Wheelchairs With Recaro Seats

    Safety Information on Wheelchairs with Recaro Seats Danger of injury if the wheelchair tips over! The centre of gravity of a Recaro seat is higher than that of other seats. The Recaro seat is also heavier than other seating systems. The backrests of RECARO seats can be leaned back 90°.

  • Page 25: Key Features

    Key features 1) Headrest (release handles for adjustment purposes are to be found behind the headrest) 2) Sliding handle 3) Backrest 4) Knob for adjusting the angle of the armrest 5) Releasing handle 6) Drive wheel 7) Armrest 8) Remote 9) Legrest...

  • Page 26: Getting In And Out Of The Wheelchair

    Getting in and out of the wheelchair Important information when side transferring in and out of the wheelchair In order to side transfer it is necessary for the armrest to either be raised or removed completely depending on the model. A skirtguard can be installed as an option in connection with the parallel sliding armrest.

  • Page 27: Raise The Parallel Sliding Armrest / Remove The Skirtguard (Optional)

    Raise the parallel sliding armrest / remove the skirtguard (optional) Swivel up armrest • Swivel armrest up to access from the side. Removing the Skirtguard (option) for access: • Loosen the release handle (1). • Pull the Skirtguard out of the receptacle.
  • Page 28 Getting into the wheelchair: • Position your wheelchair as close as possible to your seat. This might have to be done by an attendant. • Switch your wheelchair off. • Apply the manual wheel lock of your wheelchair (if existing). •...

  • Page 29: Driving

    Driving NOTE The maximum load capacity that is stated in the technical data only states that the system is designed for this mass in total. However, this does not mean that one can sit a person with this body weight in the wheelchair without restrictions. Attention must be paid to the body proportions, such as height, weight distribution, abdominal girth, leg and calf girth and seat depth.

  • Page 30: Taking Obstacles

    5.2.1 The ”SureStep“ System The Invacare® Tornado is fitted with "SureStep" technology. When passing over obstacles, the front steering wheels are lifted by the torque of the drive wheels. This technology provides excellent obstacle climbing ability when driving forward, but it is not designed for driving backward. The maximum obstacle height is considerably reduced when driving backward.

  • Page 31: The Components Of The "Surestep" And The "Stability Lock" System

    5.2.3 The components of the "SureStep" and the "Stability Lock" system The picture below shows the “SureStep“ system components after the side panelling has been removed: (1) Anti-dive spring, (2) walking beam and (3) stability lock. 5.2.4 Maximum obstacle height Your wheelchair can overcome obstacles and kerbs with the following heights.

  • Page 32: Safety Information When Ascending Obstacles

    5.2.5 Safety information when ascending obstacles CAUTION: Danger of Tipping Over! • Never approach obstacles at an angle but at 90 degrees as shown below. • Put your backrest into an upright position before climbing an obstacle. CAUTION: The wheelchair can be damaged if an obstacle is approached at excessive speed.

  • Page 33: Safety Information When Descending Obstacles

    5.2.6 Safety information when descending obstacles WARNING: In certain situations, e.g. when descending inclines and obstacles, the wheelchair user could slip off the seat. • Always fasten the restraining belt when descending from inclines and obstacles. CAUTION: The wheelchair can tip over to the front when descending from an obstacle that is too high as there can be spring deflection of the front swivel wheels.

  • Page 34: The Correct Way To Overcome Obstacles

    5.2.7 The correct way to overcome obstacles CAUTION: If the lifter is raised, the drive wheels can lose ground contact when descending from obstacles or driving on an uneven surface! The "Stability Lock" prevents “Walking Beam“ spring deflection when the lifter is raised! •...

  • Page 35: Driving Up And Down Gradients

    Driving up and down gradients For information concerning the maximum safe slope, please see chapter "Technical Specifications" starting on page 162. WARNING: In certain situations, e.g. when descending inclines and obstacles, the wheelchair user could slip off the seat. • Always fasten the restraining belt when descending from inclines and obstacles. WARNING: Danger of tipping over! •...

  • Page 36: Parking And Stationary

    Parking and stationary When parking your vehicle or if your vehicle is stationary for a prolonged period: • Switch the vehicle's power system off (ON-/OFF key). • Activate your anti-theft lock, if existing. Information: If the wheelchair has not been driven for a longer period of time, the solid rubber tyres of the swivel wheels can be pressed flat.

  • Page 37: Pushing The Wheelchair In Freewheel Mode

    Pushing the wheelchair in freewheel mode The motors of the wheelchair are equipped with automatic brakes, preventing that the wheelchair starts rolling out of control when the joystick box is switched off. When pushing the wheelchair manually whilst freewheeling, the magnetic brakes must be disengaged. Disengaging Motors The lever for disengaging the motors is on the rear right side on the wheelchair chassis.

  • Page 38: The Rem 24 Sd Remote

    The REM 24 SD Remote Layout of the remote Upper side Controls Immobilizer "Activate / scroll through drive mode" button Horn Left-hand indicator Joystick "Activate adjustment mode" button ON/OFF button Light Right-hand indicator 10) Hazard warning signal flasher...
  • Page 39 Upper side Displays 11) Battery charger display 12) Status display (in key symbol) 13) Drive mode display 14) Left-hand indicator display 15) Hazard warning signal flasher display 16) Light display 17) Right-hand indicator display...
  • Page 40 Underside 1) Charger socket 2) Programming socket Rear panel Socket for Buddy button 1 (corresponds to "Activate / scroll through drive mode" button). Socket for Buddy button 2 (corresponds to "ON/OFF" button) Socket for Buddy button 3 (corresponds to "Activate / scroll through adjustment mode"...

  • Page 41: On/Off Diode (Status Display)

    ON/OFF diode (status display) INFORMATION The ON/OFF diode (in key symbol) also serves as status or error message display. For error codes please see chapter "Error codes and diagnostic codes" on page 50. Battery charger display • Battery charger display All diodes illuminated: Full range •...

  • Page 42: Activating / Deactivating The Immobilizer

    Immobilizer • Switch on the remote. • Use the end of the magnetic key (Invacare® Logo) to move over the sensor area (1) on the remote (key symbol). The horn will sound briefly once. The remote shuts down automatically. The immobilizer is activated.

  • Page 43: Using The Buddy Buttons With The Remote

    Using the Buddy buttons with the remote What is a Buddy button? A Buddy button is an additional sensing device that can be used to activate a remote function. The sockets for Buddy buttons are to be found at the rear of the remote. Socket 1 (corresponds to the ""Activate / scroll through drive mode""...

  • Page 44: Controlling The Wheelchair Using The Remote

    • Invacare® supplies all electric vehicles from the factory with a standard drive programme. Invacare® can only assume a warranty for the safe vehicle handling of the electric vehicle – in particular tipping stability - for this standard drive programme! Will the wheelchair not drive after switching on? Check the drive-away lock (see chapter "Activating / deactivating the immobilizer "...

  • Page 45: How A Wheelchair With "Indirect Steering" Reacts To Joystick Movements

    7.6.1 How a wheelchair with "Indirect Steering" reacts to joystick movements. "Indirect Steering" occurs by individually applying power to the drive wheels, and is found on wheelchairs with front, rear and middle wheel drive. Travel direction The further the joystick is moved in a particular direction, the more dynamically the wheelchair reacts.

  • Page 46: Operating The Electric Adjustment Options

    Operating the electric adjustment options Electric adjustment options, like electric legrests or an electric backrest, are operated by using the joystick. 7.7.1 Activating adjustment mode • Press the "activate adjustment mode" button (A). The remote switches to the adjustment mode last used. The driving mode display (B) switches to the appropriate symbol (one of the symbols shown below).

  • Page 47: Selecting And Operating The Adjustment Option

    ECU mode (environment control unit). The standard REM 24 SD programming only supports the adjustment function. Please speak to your Invacare dealer if you have any questions in this respect. 7.7.2 Selecting and operating the adjustment option •...

  • Page 48: Changing Back To Driving Mode

    7.7.3 Changing back to driving mode • Briefly press the "Activate / scroll through driving mode" button (A). The remote switches back to the driving mode last used. The driving mode display indicates the drive level (B).

  • Page 49: Error Diagnosis

    Error diagnosis In the event that the electronics should show signs of failure, please consult the following troubleshooting guide in order to locate the error. INFORMATION Before beginning with the diagnosis, please ensure that the drive electronics are switched on. If the status display is OFF: Please check whether the drive electronics are SWITCHED ON.

  • Page 50: Error Codes And Diagnostic Codes

    7.8.1 Error codes and diagnostic codes The drive electronics are capable of rectifying some errors automatically. In this case the status display will cease to flash. Please switch the remote on and off several times. Wait approx. 5 seconds each time before switching the remote on again. If this does not rectify the error, locate the error using the flash codes shown below.
  • Page 51 FLASH FAULT IMMEDIATE MEASURE FURTHER HELP CODE Fault/brake fault on • • Check plug-in Contact your dealer or left-hand motor. connections. wheelchair provider. Connection • Replace motor loose/defective or motor defective. Fault/brake fault on • Check plug-in • Contact your dealer or right-hand motor.

  • Page 52: The G80I Remote (Optional)

    The G80i remote (optional) NOTE: You can find a description of the G80i remote in the appropriate Operating Manual.

  • Page 53: Adjusting The Wheelchair To The User's Seating Posture

    Adjusting the wheelchair to the user's seating posture CAUTION: Wheelchair damage and risk of accident! Collisions can occur between the legrest and the chassis or between the foot plates and the ground in the event of varying adjustment option combinations! This occurs in particular on wheelchairs with lifter and a seat angle adjustment range of -10°...

  • Page 54: Adjusting The Armrests And The Joystick Box

    Adjusting the armrests and the joystick box 9.2.1 Adapting the remote to the length of the user’s arm Requirements: • Allen key 3 mm • Loosen the socket head screw (1). • Set remote to the desired length by pushing forward or backward.

  • Page 55: Setting The Height Of The Remote

    9.2.2 Setting the height of the remote • Loosen one or both of the wing screws (1 and 2) that allow height adjustment of the joystick box. • Adjust the joystick box to the desired height. • Re-tighten the screw(s).

  • Page 56: Setting The Height Of The Armrests

    9.2.3 Setting the height of the armrests • Loosen the bolt (1). • Set the armrest at the desired height. • Retighten the bolt.

  • Page 57: Adjusting The Width Of The Armrests

    9.2.4 Adjusting the width of the armrests The distance between the side sections can be adjusted by 5.5 cm on both sides (11 cm in total). Requirements: • Allen key 8 mm Where to find the adjustment screws The picture below shows the position of the screws (1) that permit adjustment to the width of the armrests (only the left side is visible in the picture).
  • Page 58 Doing the adjustment • Loosen screw (1). • Set the armrest to the desired position. • Tighten the screw. • Repeat the procedure for the other armrest.

  • Page 59: Manually Adjusting The Seat Tilt

    Manually adjusting the seat tilt The manual seat angle adjustment has an adjustable range of 0° to 20°. The seat angle is adjusted by means of a spindle, which is to be found at the front underneath the seat frame. When adjusting the seat angle it should be ensured that at least 1cm of the threaded bolt always remains inside the spindle and is not completely unscrewed from the spindle.
  • Page 60 • Loosen the counternut (1) on the spindle. • Set the seat angle by turning the spindle (2). • Tighten the counternut.

  • Page 61: Manually Adjusting The Backrest

    Manually adjusting the backrest 9.4.1 Adjusting the backrest using the gas pressure spring The lever for adjusting the backrest is located on the opposite side from the Joystick Box under the armrest. Adjusting angle of the backrest • Pull lever (1) upward. •...

  • Page 62: Adjust The Backrest Using The Perforated Plate

    9.4.1.1 Adjust the backrest using the perforated plate The angle of the backrest has six positions, from -10° to +30°. • Unscrew the hand screws (1) on both sides. • The backrest is adjusted by choosing a combination of one of the two bore holes in the backrest frame and one of the six bore holes in the fixing plate.

  • Page 63: Flex And Contour Seats

    9.4.2 Flex and Contour seats • Set the angle by turning the hand wheel (1).

  • Page 64: The Lifter

    46. Information regarding operation of the lifter at temperatures of less than 0 °C Invacare® mobility aids are fitted with safety mechanisms that prevent capacity overload of the electronic components. At operating temperatures below freezing point this can, in particular, lead to the lifter actuator being shut down after approx.

  • Page 65: Explanation Of Symbols On Lifter Warning Sticker

    9.5.1 Explanation of symbols on lifter warning sticker. Do not lean out Do not drive up Do not allow any Never drive with Never drive over when the lifter is or down slopes body parts to get two people! uneven surfaces raised! when the lifter is under a raised...

  • Page 66: Adjusting And Removing The Tray

    Adjusting and removing the tray CAUTION: Injury hazard or material damage if an electric wheelchair which is fitted with a table is transported in a vehicle! • If a table is fitted, always remove it before transporting the wheelchair. 9.6.1 Laterally adjusting the tray •...

  • Page 67: Adjusting The Depth Of The Tray / Removing The Tray

    9.6.2 Adjusting the depth of the tray / removing the tray • Loosen the wing-screw (1). • Adjust the table to the desired depth (or remove it entirely). • Re-tighten the screw. 9.6.3 Swinging the tray away to the side CAUTION! Risk of injury! When the tray is raised it does not lock in place in this position! •...

  • Page 69: Child Seat (Option)

    Child seat (option) The child seat consists of the actual seat, a headrest and a laterally-mounted footrest. The following describes how these options can be adapted to the sitting posture of the user. 9.7.1 The headrest of the child seat 9.7.1.1 Adjusting the angle / depth of the headrest •...

  • Page 70: Adjusting The Height Of The Headrest

    9.7.1.2 Adjusting the height of the headrest • Loosen the clamping screw (1). • Move the headrest to the desired height. • Tighten the clamping screw.

  • Page 71: The Armrests / Setting The Angle

    9.7.2 The armrests / setting the angle Pre-requisites: • 13 mm open-ended spanner The adjusting screw for adjusting the angle of the armrest is to be found at the rear end of the armrest (A). • Loosen the counternut (1) using the open-ended spanner.

  • Page 72: The Backrest

    9.7.3 The backrest 9.7.3.1 Adjusting the height of the sliding handles (option) • Loosen the hand wheel (1 or 2). • Move the sliding handle to the desired position. • Tighten the hand wheel.

  • Page 73: Adjusting The Angle Of The Backrest Electrically

    9.7.3.2 Adjusting the angle of the backrest electrically As an option the backrest can be adjusted via an electric actuator. Please see chapter "Operating the electric adjustment options" on page 46. 9.7.3.3 Adjusting the angle of the backrest manually • Loosen the hand wheel (1). •...

  • Page 74: The Legrest Of The Child Seat

    9.7.4 The legrest of the child seat 9.7.4.1 Setting the angle of the footrest Pre-requisites: • 5 mm Allen key • Loosen the Allen screws at both ends of the footrest (1) (only one side is shown in the illustration). •...

  • Page 75: Swivelling The Footrest Upward / Removing The Legrest

    9.7.4.2 Swivelling the footrest upward / removing the legrest In order to simplify getting into the vehicle and alighting, the footrest can be swivelled upward. The footrest must also be swivelled upward so that the width of the legrest can be adjusted or the legrest dismantled.
  • Page 76 • Press the release button (1) and swivel the legrest outward. • Remove the legrest in an upward direction.

  • Page 77: Adjusting The Width Of The Legrest

    9.7.4.3 Adjusting the width of the legrest Pre-requisites: • Flat screwdriver • 5 mm Allen key • 3 mm Allen key • 13 mm open-ended spanner • Swivel the footrest upward and dismantle the legrest (see section "Swivelling the footrest upward / "...
  • Page 78 • Remove the plastic studs carefully using a flat screwdriver. • Remove the rubber mat.
  • Page 79 • Remove the screws (1) using the 3 mm Allen key. • Adjust the footrest bracket (2) to the desired width. • Re-position and tighten the screws.
  • Page 80 • If the width of the footrest has been altered, the width of the legrest brackets (1) on the wheelchair frame must be adapted appropriately. • Loosen the four screws (2) using the 13 mm open- ended spanner.
  • Page 81 • Swivel the footrest slightly upward so that the legrest halves can be turned inward without colliding. • Hang the legrest halves on the left and right and turn inward until the locking mechanisms on both sides lock in place. •...
  • Page 82 • Tighten the screw (1). • Re-close the belt with the Velcro® fastener (2) .

  • Page 83: Adjusting The Length Of The Legrest

    9.7.4.4 Adjusting the length of the legrest Pre-requisites: • 5 mm Allen key • Loosen the screw (1). • Adjust the lower leg length. • Tighten the screw.

  • Page 84: Adjusting The Angle Of The Legrest

    9.7.4.5 Adjusting the angle of the legrest Pre-requisites: • 6 mm Allen key • Metal pin 3 mm ∅, approx. 10 cm long • Hammer • Loosen the screw (1). • Insert the metal pin into the hole (2) and knock lightly with the hammer in order to loosen the halves of the plastic jacket.

  • Page 85: Adjusting Footrests And Legrests

    Adjusting footrests and legrests 10.1 Centre-mounted legrests 10.1.1 Electric legrest The electric legrest is operated via the remote. Please see chapter "Operating the electric adjustment options" on page 46. The electric legrest can be lowered completely to assist getting out of the wheelchair. To do so, move your seat into the correct position by lowering the lifter or by means of a negative seat angle (tilted slightly to the front).

  • Page 86: Lowering The Electric Legrest Completely To Assist Getting Out Of The Wheelchair

    10.1.1.1 Lowering the electric legrest completely to assist getting out of the wheelchair Warning! Misuse may destroy the legrest. • Please read and carefully follow the instructions below. Getting in/out of the wheelchair • Set the lifter and tilt to a comfortable position. •...
  • Page 87 Lifting up the footplates • You are sitting in the wheelchair. • Put your feet beside the footplates. • Pull the lever (1). The footplates rise up automatically. • Let go the lever (1) and put your feet on the footplates.
  • Page 88 Warning! Danger of damage to the legrest! • Always make sure that the footplates are fully raised to the uppermost position before adjusting the angle of the legrest! • Disregarding this advice will cause damage to your legrest. Adjusting the legrest •...

  • Page 89: Adjustable Legrest

    10.1.2 Adjustable legrest 10.1.2.1 Adjusting the angle Prerequisites: • 1x 10 mm open-ended spanner • Use the open-ended spanner to loosen the counternut (1). • Move the legrest to the desired position by turning the spindle (2). • Tighten the counternut.

  • Page 90: Adjusting The Length Of The Legrest

    10.1.2.2 Adjusting the length of the legrest Prerequisites: • 1x 5 mm socket head spanner • Use the socket head spanner to loosen the fastening screws (1). • Slide the foot support to the desired height. • Tighten the fastening screws.

  • Page 91: Adjusting The Calf Plate To The Calf Width Of The User

    10.1.2.3 Adjusting the calf plate to the calf width of the user The calf plate of the legrest can be adapted to the user’s calf width by bending apart or together. • Bending the calf plate to the desired width.

  • Page 92: Adjusting The Angle Of The Foot Plate

    10.1.2.4 Adjusting the angle of the foot plate Prerequisites: • 1x 5 mm socket head spanner • Fold up the foot plates in order to access the adjusting screws. • Use the socket head spanner to adjust the adjusting screws (1). •...

  • Page 93: Laterally Mounted Legrests

    10.2 Laterally mounted legrests 10.2.1 Standard footrest with pre-set angle 10.2.1.1 Swivelling the footrest outward and/or removing The small unlocking button is located on the upper section of the footrest. When the footrest is unlocked, it can be swivelled inward or outward when getting into the wheelchair as well as being removed completely.

  • Page 94: Setting The Angle

    10.2.1.2 Setting the angle PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that neither the legrests nor the steering wheels contact the ground! Pre-requisites: •...
  • Page 95 • Loosen the screw (1) using the Allen key. • Set the desired angle. • Re-tighten the screw.

  • Page 96: Setting The End Stop Of The Footrest

    10.2.1.3 Setting the end stop of the footrest Pre-requisites: • 1x 6 mm Allen key • 1x 10 mm open-ended spanner The end position of the footrest is determined by means of a rubber stop (1). The rubber stop can be screwed in or out (A) or pushed up or down (B).
  • Page 97 • Use the Allen key to loosen the screw (1) and swivel the footrest upward in order to access the rubber stop. • Use the open-ended spanner to loosen the counternut (1).
  • Page 98 • Move the rubber stop to the desired position • Re-tighten the counternut • Move the footrest to the desired position. • Re-tighten the screw.

  • Page 99: Adjusting The Length Of The Footrest

    10.2.1.4 Adjusting the length of the footrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that neither the legrests nor the steering wheels contact the ground! Pre-requisites: •...

  • Page 100: Manually Height Adjustable Legrest 90° - 0

    10.2.2 Manually height adjustable legrest 90° - 0° 10.2.2.1 Swivelling the legrest outward and/or removing The small unlocking button is located on the upper section of the legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into wheelchair as well as being removed completely.

  • Page 101: Setting The Angle

    10.2.2.2 Setting the angle PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that neither the legrests nor the steering wheels contact the ground! •...

  • Page 102: Setting The End Stop Of The Legrest

    10.2.2.3 Setting the end stop of the legrest Pre-requisites: • 1x 10 mm open-ended spanner The end position of the legrest is determined by means of a rubber stop (A). The rubber stop can be screwed in or out (A) or pushed up or down (B).
  • Page 103 • Disengage the release handle (1) and swivel the legrest upward in order to access the rubber stop. • Use the open-ended spanner to loosen the counternut (1).
  • Page 104 • Move the rubber stop to the desired position • Re-tighten the counternut • Move the footrest to the desired position. • Re-tighten the release handle.

  • Page 105: Adjusting The Length Of The Legrest

    10.2.2.4 Adjusting the length of the legrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that neither the legrests nor the steering wheels contact the ground! Pre-requisites: •...

  • Page 106: Adjusting The Depth Of The Calf Plate

    10.2.2.5 Adjusting the depth of the calf plate The depth of the calf plate can be adjusted via the holding plate. The holding plate hole combinations allow 5 different depth settings. Pre-requisites: • 1x 10 mm open-ended spanner • Use the open-ended wrench to loosen the nut (1) and remove.

  • Page 107: Adjusting The Height Of The Calf Plate

    10.2.2.6 Adjusting the height of the calf plate Pre-requisites: • 1x 4 mm Allen key • Use the Allen key to loosen the screws (1). • Adjust to the desired position. • Re-tighten the screws.

  • Page 108: Unlocking And Swivelling The Calf Plate Backward When Alighting

    10.2.2.7 Unlocking and swivelling the calf plate backward when alighting • Press the calf plate straight down. • Unlock the legrest and swivel outward. The calf plate swivels backward on its own.

  • Page 109: Adjusting The Angle Adjustable Foot Plate

    • Lift leg over the heel strap and place on the ground. 10.2.2.8 Adjusting the angle adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen both set screws on the foot plate. •...

  • Page 110: Adjusting The Angle And Depth Adjustable Foot Plate

    10.2.2.9 Adjusting the angle and depth adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the set screw on the foot plate (1). • Adjust the foot plate to the desired angle or depth. •...

  • Page 111: Manually Height Adjustable Legrest 80° - 0° With Ergonomic Length Adjustment

    10.2.3 Manually height adjustable legrest 80° - 0° with ergonomic length adjustment 10.2.3.1 Swivelling the legrest outward and/or removing The small unlocking button is located on the upper section of the legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into wheelchair as well as being removed completely.

  • Page 112: Setting The Angle

    10.2.3.2 Setting the angle PLEASE NOTE: Danger of crushing! • Do not reach inside the swivelling range of the legrest! PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that neither the legrests nor the steering wheels contact the ground! •...
  • Page 113 • Lowering: Keep the legrest in the foot plate area, pull the lateral adjusting lever (1) and lower the legrest slowly.

  • Page 114: Adjusting The Length Of The Legrest

    10.2.3.3 Adjusting the length of the legrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that neither the legrests nor the steering wheels contact the ground! Pre-requisites: •...

  • Page 115: Adjusting The Depth Of The Calf Plate

    10.2.3.4 Adjusting the depth of the calf plate The depth of the calf plate can be adjusted via the holding plate. The holding plate hole combinations allow 5 different depth settings. Pre-requisites: • 1x 10 mm open-ended spanner • Use the open-ended wrench to loosen the nut (1) and remove.

  • Page 116: Adjusting The Height Of The Calf Plate

    10.2.3.5 Adjusting the height of the calf plate Pre-requisites: • 1x 4 mm Allen key • Use the Allen key to loosen the screws (1). • Adjust to the desired position. • Re-tighten the screws.

  • Page 117: Unlocking And Swivelling The Calf Plate Backward When Alighting

    10.2.3.6 Unlocking and swivelling the calf plate backward when alighting • Press the calf plate straight down. • Unlock the legrest and swivel outward. The calf plate swivels backward on its own.

  • Page 118: Adjusting The Angle Adjustable Foot Plate

    • Lift leg over the heel strap and place on the ground. 10.2.3.7 Adjusting the angle adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen both set screws on the foot plate. •...

  • Page 119: Adjusting The Angle And Depth Adjustable Foot Plate

    10.2.3.8 Adjusting the angle and depth adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the set screw on the foot plate (1). • Adjust the foot plate to the desired angle or depth. •...

  • Page 120: Electrically Height Adjustable Legrest 80° - 0° With Ergonomic Length Adjustment

    10.2.4 Electrically height adjustable legrest 80° - 0° with ergonomic length adjustment 10.2.4.1 Swivelling the legrest outward and/or removing The small unlocking button is located on the upper section of the legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into wheelchair as well as being removed completely.

  • Page 121: Setting The Angle

    10.2.4.2 Setting the angle PLEASE NOTE: Danger of crushing! • Do not reach inside the swivelling range of the legrest! PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that neither the legrests nor the steering wheels contact the ground! The electrically height adjustable legrest is operated via the remote.

  • Page 122: Adjusting The Length Of The Legrest

    10.2.4.3 Adjusting the length of the legrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that neither the legrests nor the steering wheels contact the ground! Pre-requisites: •...

  • Page 123: Adjusting The Depth Of The Calf Plate

    10.2.4.4 Adjusting the depth of the calf plate The depth of the calf plate can be adjusted via the holding plate. The holding plate hole combinations allow 5 different depth settings. Pre-requisites: • 1x 10 mm open-ended spanner • Use the open-ended wrench to loosen the nut (1) and remove.

  • Page 124: Adjusting The Height Of The Calf Plate

    10.2.4.5 Adjusting the height of the calf plate Pre-requisites: • 1x 4 mm Allen key • Use the Allen key to loosen the screws (1). • Adjust to the desired position. • Re-tighten the screws.

  • Page 125: Unlocking And Swivelling The Calf Plate Backward When Alighting

    10.2.4.6 Unlocking and swivelling the calf plate backward when alighting • Press the calf plate straight down. • Unlock the legrest and swivel outward. The calf plate swivels backward on its own.

  • Page 126: Adjusting The Angle Adjustable Foot Plate

    • Lift leg over the heel strap and place on the ground. 10.2.4.7 Adjusting the angle adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen both set screws on the foot plate. •...

  • Page 127: Adjusting The Angle And Depth Adjustable Foot Plate

    10.2.4.8 Adjusting the angle and depth adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the set screw on the foot plate (1). • Adjust the foot plate to the desired angle or depth. •...

  • Page 128: Electrical System

    Electrical System 11.1 Electronics Protection System The vehicle's electronics are equipped with an overload-protection system. If the motors are put under considerable strain for a longer period of time (for example, when driving up a steep hill) and especially when the ambient temperature is high, then the electronic system could overheat.

  • Page 129: The Main Fuse

    NOTE A defective main fuse may be replaced only after checking the entire electric system. An Invacare® specialised dealer must perform the replacement. You can find information on the fuse type in chapter "Technical Specifications" starting on page 162. The entire wheelchair electrical system is protected against capacity overload by means of the main fuse.

  • Page 130: Batteries

    11.2 Batteries 11.2.1 What you need to know about batteries Power is supplied by two 12V batteries. The batteries are maintenance-free and only need regular charging. New batteries should always be fully charged once before their first use. New batteries will be at their full capacity after having run through approx.
  • Page 131 The batteries cannot be overcharged with the specified charger. Please use only charging devices in Class 2. This class of chargers may be left unattended during charging. All charging devices which are supplied by Invacare® comply with these requirements.

  • Page 132: Charging The Batteries

    • Only ever use the battery charger supplied with your vehicle, or a charger that has been approved by Invacare®. Danger of electric shock and damage to the battery charger if it is allowed to get wet! • Protect the battery charger from water.
  • Page 133 Charging the batteries • Switch off the wheelchair at the Joystick Box. • Connect the battery charger to the Joystick Box - the charging socket is located on the bottom of the Joystick Box (1). • Connect battery charger to the mains outlet and switch on if necessary.

  • Page 134: Removing And Fitting Batteries

    11.2.3 Removing and fitting batteries WARNING: Danger of injury if the batteries are not handled correctly during assembly and maintenance work! • New batteries should be installed by authorised technicians! • Observe the warnings on the batteries! • Take into account the heavy weight of the batteries! •...

  • Page 135: Removing The Batteries

    11.2.3.1 Removing the batteries CAUTION: Risk of fire and burns if battery poles are bridged! • When replacing the batteries the battery poles MUST NOT come into contact with metal parts of the wheelchair causing bridging. • Be sure to replace the battery pole caps after the batteries have been replaced. WARNING: Risk of fire and burns due to damage to the battery cables! •...
  • Page 136 If a lifter is available the seat unit must be pulled in an upward direction. To do this the piston head on the actuator must be released and pulled out of its guideway in the lifter unit. • Pull the actuator piston head forward in order to release the piston head, at the same time pulling the lifter upward until the engaging mechanism (1) is heard to lock in place.
  • Page 137 • Pull cover to the front and remove. • Remove the locking clip (1) using the needle-nosed pliers and pull out the retaining pin of the actuator or spindle retainer (on manual seat angle adjustment) (2)
  • Page 138 • Use the 5mm Allen key to loosen and remove the screws (1) on both sides. • Pull the holding plate to the front and remove. • Pull out the actuator or spindle (on manual seat angle adjustment) (1) to the front.
  • Page 139 • Release and remove the battery cable on the battery poles. • Remove batteries by pulling to the front.
  • Page 140 NOTE Installation of new batteries is carried out in reverse order. When installing new batteries, make sure there are no cables between the front batteries and the actuator of the lifter! They could get damaged when the lifter is operated! WRONG! RIGHT!
  • Page 141 Releasing the lifter locking mechanism • If lifter is fitted raise the piston rod of the actuator carefully on the remote until the piston head (1) interlocks in the retainer track (2). The lifter is now supported by the actuator. •...

  • Page 142: How To Handle Damaged Batteries Correctly

    • Only ever transport damaged batteries in an appropriate acid-resistant receptacle. • Wash all objects that have come into contact with acid with lots of water. Disposing of dead or damaged batteries correctly Dead or damaged batteries can be given back to your dealer or directly to Invacare®.

  • Page 143: Care And Maintenance

    Care and maintenance NOTE: Have your vehicle checked once a year by an authorised Invacare® dealer in order to maintain it's driving safety and roadworthiness. Cleaning the vehicle When cleaning the vehicle, pay attention to the following points: • Only use a damp cloth and gentle detergent.
  • Page 144 Maintenance Jobs Seat and backrest padding: - Check for perfect condition. Side part and armrest: - Are all fastening elements installed? - Can armrests / side parts be removed and installed without too much physical effort? - Are armrests secured in their positions? Legrests: - Do legrests lock into place without any problem? (Only applies to detachable legrests)
  • Page 145 - Clean all parts carefully. When necessary Have your vehicle inspected and serviced once a year by your authorised dealer. A complete checklist of necessary maintenance work can be found in the Service Manual, which can be obtained from Invacare®.

  • Page 146: Repair Instructions

    "Technical Specifications" on page 162, or consult the Service Manual, available from Invacare® (in this connection please see the addresses and phone numbers in section "How can you get in touch with Invacare®?" on page 2). In case you require assistance, please contact your Invacare® Dealer.

  • Page 147: Repairing Punctures (Drive Wheel With Conventional Motor And Pneumatic Tyres)

    13.1.1 Repairing punctures (drive wheel with conventional motor and pneumatic tyres) Injury hazard! If the wheel has been insufficiently tightened during assembly, it can become loosened during driving! • When reassembling the drive wheels, tighten the Allen screws at a torque of 30 Nm! •...
  • Page 148 Removing the wheel • Block up the vehicle (place wooden blocks under frame). • Unscrew 4 screws (1). • Remove the wheel from the hub. NOTE: Re-assembly is done in reverse order. Ensure that the tyre is replaced on the same side and in the same travel direction as it was previously mounted.
  • Page 149 Repairing the flat tyre EXPLOSION HAZARD! The wheel will explode if the pressure is not released from the tyre before disassembling the wheel rim! • Always make sure to completely release the air pressure by pressing the pin in the centre of the valve! •...
  • Page 150 • Insert the wheel rim halves from outside into the tyre. • Pump a little air into the inner tube. • Insert the cylinder head screws in the rim and tighten to 10 Nm. Make sure the inner tube does not get pinched between the rims halves! •...

  • Page 151: Transport

    Transport CAUTION: Injury hazard or material damage if an electric wheelchair which is fitted with a table is transported in a vehicle! • If a table is fitted, always remove it before transporting the wheelchair. 14.1 Transferring the wheelchair to a vehicle WARNING: Danger of tipping over, if the wheelchair is transferred to a vehicle using a ramp that exceeds the maximum safe slope, or if the backrest is not in an upright position during transfer!
  • Page 152 • Drive or push your wheelchair into the transport vehicle using a suitable ramp.

  • Page 153: Use Of The Wheelchair As A Seat In A Vehicle

    (UK for example), but may also be obtained from Invacare® as an option in other countries. This electric wheelchair complies with the requirements of ISO 7176-19:2001 and may be used as a vehicle seat in connection with an anchoring system that has been checked and approved in accordance with ISO 10542.
  • Page 154 Caution: There is a danger of injury if the wheelchair is not properly secured during use as a vehicle seat! • If possible, the user should always leave the wheelchair to use a vehicle seat and the safety belts provided with the vehicle. •...

  • Page 155: How The Wheelchair Is Anchored In A Vehicle For Use As A Vehicle Seat

    14.2.1 How the wheelchair is anchored in a vehicle for use as a vehicle seat The electric wheelchair is fitted with four anchoring points, which are labelled with the symbol shown on the right. Snap hooks or belt loops can be used for fixation.

  • Page 156: How The User Is Secured Within The Wheelchair

    14.2.2 How the user is secured within the wheelchair CAUTION: There is a danger of injury if the user is not properly secured within the wheelchair! • Even if the wheelchair is fitted with a postural belt, this is no substitute for a proper safety belt which complies with ISO 10542 in the transport vehicle.
  • Page 157 This can cause the neck to be hyperextended during collisions! • A headrest must be installed! The headrest optionally supplied for this mobility device by Invacare® is perfectly suitable for use during transport. • The headrest must be adjusted to the user's ear height.
  • Page 158 Seat belts may not be held at a distance The pelvic belt should be positioned in the from the user's body using parts of the area between the user's pelvis and thighs wheelchair such as armrests or wheels. so that it is unobstructed and not too loose. The ideal angle of the pelvic belt to the horizontal is between 45°...

  • Page 159: Securing The Wheelchair For Transport Without Passengers

    14.3 Securing the wheelchair for transport without passengers CAUTION: Injury hazard! • If you are unable to fasten your electric wheelchair securely in a transport vehicle, we recommend that you do not transport it! • Before transporting your wheelchair, make sure the motors are engaged and that the Joystick Box is switched off.

  • Page 160: Refurbishment

    • Cleaning and disinfection. Please see chapter "Care and maintenance" on page 143. • Inspection according to service plan. Please consult service instructions, available from Invacare®. • Adaptation to the user. Please see chapter "Adjusting the wheelchair to the user's seating...

  • Page 161: Disposal

    • Electric components and printed circuit boards are disposed of as electronic scrap. • Exhausted or damaged batteries can be returned to your medical equipment supplier or Invacare®. • Disposal must be carried out in accordance with the respective national legal provisions.

  • Page 162: Technical Specifications

    Technical Specifications Permissible Operating and Storage Conditions Temperature range for operation • -25 … +50 °C according to ISO 7176-9: Temperature range for storage • -40 … +65 °C according to ISO 7176-9: Electrical system 6 kmh version 8 kmh version Motors •...
  • Page 163 Drive features 6 kmh version 8 kmh version Max. negotiable obstruction • 6 cm • 6 cm height (only applies to driving forward) Turn radius • 60 cm • 60 cm Range in compliance with ISO • 25 km • 25 km 7176 *** Dimensions Standard...
  • Page 164 Dimensions Standard Kontur Recaro Flex Junior Seat height **** • 38 cm (+30 cm with lifter) • 45 cm • 45 cm (+30 cm with lifter) (+30 cm with lifter) • 45 cm • 45 cm • 47 cm • 47 cm Seat width (Adjustable •...
  • Page 165 **** Measured without seat cushion. ***** The actual kerb weight depends on the fittings your mobility aid has been supplied with. Every Invacare® mobility aid is weighed when leaving the works. Please refer to the nameplate for the kerb weight (including batteries) measured.

  • Page 166: Inspections Performed

    It is confirmed by stamp and signature that all jobs listed in the inspection schedule of the Service and Repair Instructions have been properly performed. The list of the inspection jobs to be performed can be found in the Service Manual which is available through Invacare®. Delivery Inspection...

This manual is also suitable for:

Typhoon

Table of Contents
