  • Page 1 RFR-1414 ® ® RFR-1514 Power Systems RFR-1614 Operation & Installation ®...
  • Page 2 Congratulations on your purchase of the world's finest brand of car audio speakers. At Rockford Fosgate we are fanatics about musical reproduction at its best, and we are pleased you chose our product. Through years of engineering expertise, hand craftsman- ship and critical testing procedures, we have created a wide range of products that reproduce music with all the clarity and richness you deserve.
  • Page 3: Table Of Contents

    Installation Section of this manual or refer to the icons listed below. Other information can be located by using the Table of Contents. We, at Rockford Fosgate, have worked very hard to make sure all the information in this manual is current. But, as we are constantly finding new ways to improve our product, this information is subject to change without notice.
  • Page 4: Ontents

    Punch Power Systems. We suggest you save this manual for future reference. We strongly recommend you have your Authorized Rockford Fosgate Dealer install the Punch Power System. If you do choose to install the system yourself, please be sure to read the entire manual before beginning.
  • Page 5: Technical Design Features

    ECHNICAL E S I G N E AT U R E S Titanium Dome The titanium dome used in the Power tweeter allows the voice coil assembly to efficiently dissipate heat. This feature allows the tweeter to be driven at higher operating levels without sacrificing sound quality.
  • Page 6 Midrange Features TPR Rubber Surround TPR (Thermal Plastic Rubber) is resilient to temperature variations and provides a consistent support necessary for the linear motion of the speaker cone. In addition, the inherent damping capabilities elimi- nates the transmission of sonic disturbances between the cone and the frame of the speaker.
  • Page 7 Silver Powder Coat Finish Powder coating has long been the industry standard for durability in protective metal finishes. A dry powder (non-aerosol) is electrostati- cally applied to the metal and “baked” on to provide a hard “shell- like” finish. As an additional benefit, powder coating is the only finishing process that releases no toxic chemicals into our ozone.
  • Page 8 Zobel Network The Zobel network compensate for the impedance rise presented by the driver (speaker). The network flattens out the gradual impedance rise produced by the voice coil which typically results in high frequency rolloff. The Zobel Network compensates for this natural rolloff which allows the driver to produce a more linear response up to the tweeter crossover point.
  • Page 9: Design Features

    ESIGN EATURES ® ® ® ® ACTIVE TWEETER PROTECTION RFR-142x ® 1. Wire Mesh Grille – The Wire Mesh Grille protects the tweeter diaphragm from foreign objects and curious fingers. 2. Input Terminals – The “+” Terminal indicates the positive/plus terminal of the speaker.
  • Page 10: Installation Considerations

    2. For best results, mount the crossover(s) next to the amplifier for a decorative finish to the installation and provide an easy upgrade (no new wires to run) for a bi-amp Rockford Fosgate system in the future. – 7 –...
  • Page 11: Mounting Location

    OUNTING OCATION A solid front stage with a good image is one of the most difficult tasks to achieve in a vehicle. No car has the optimum listening environment. This makes proper sound staging very difficult to accomplish. Most speakers tend to be placed where they will fit easily, as opposed to where they can perform the best.
  • Page 12: Installation

    • Sound radiated from a “point source” has the most optimum stereo imaging because the separation of the acoustical centers between the midrange and tweeter for each channel is at the optimum. Figure 2-A describes a horizontal speaker alignment. In a closed environ- ment such as an automobile, horizontal speaker alignment can cause severe amplitude and phase differences which will degrade not only the imaging, but also the frequency response.
  • Page 13: Front View

    Surface Mount Tweeter (Method #1) ® ® Mounting Baffle Mounting Screw Surface Surface Mount Mount Baseplate Front View Exploded View (twist clockwise to lock) • Use when mounting tweeter to a solid surface (metal, wood, etc.) Surface Mount Tweeter (Method #2) Mounting Baffle Mounting...
  • Page 14 ® ® Flush Mount Tweeter Mounting Mounting Bolt Baffle 2" Cutout Flush Flush Bracket Mount Mount Baseplate Rear View (twist clockwise to lock) Exploded View Crossover Connections HP CROSSOVER LP CROSSOVER TWEETER TWEETER PROTECTION (Rear View) ® “+” “+” – + –...
  • Page 15 ® ® Bandpassing the Midrange RFR-142x Midrange Output – 400µf capacitor – • To bandpass the midrange, it is necessary to add a 400µf capacitor in series with the speaker Tweeter Level Matching (Bottom view of RFR-142x) Cut jumper wire for –3dB •...
  • Page 16 ® ® Horizontal Logo Mounting ® ® ACTIVE TWEETER PROTECTION RFR-142x ® ® • Configure logo into desired position and snap into place Vertical Logo Mounting • Configure logo into desired position and snap into place – 13 –...
  • Page 17: Troubleshooting

    R O U B L E S H O O T I N G Symptom Diagnosis Remedy No sound from Wires between amplifier, Check and repair or replace speakers crossover and speakers wiring as needed. not connected properly. Amplifier has no output. Check system with known working amplifier and re- pair or replace as needed.
  • Page 18 Crossover is mounted Move crossovers away from near radiated noise noise sources. (Refer to the source. (Power cables, Installation Considerations vehicle computers, etc.) section of this manual.) • If noise persists, see your local Authorized Rockford Fosgate Dealer – 15 –...
  • Page 19: Specifications

    P E C I F I C A T I O N S Model RFR-14 RFR-1404 RFR-1405 RFR-1406 Freq. Response 3kHz-20kHz 85Hz-9kHz 70Hz-7kHz 65Hz-6kHz Power Handling 100 Watts* 100 Watts 120 Watts 120 Watts (RMS) Nom. Impedance 4Ω 4Ω 4Ω 4Ω...
  • Page 20: Warranty Information

    • Who is Covered This warranty covers only the original purchaser of Rockford product purchased from an Authorized Rockford Fosgate Dealer in the United States. In order to receive service, the purchaser must provide Rockford with a copy of the receipt stating the customer name, dealer name, product purchased and date of purchase.
  • Page 21: International Information

    – 18 –...
  • Page 22 Es preferible que la instalación de sistema Punch Power sea realizada por un distribuidor autorizado Rockford Fosgate. Si prefiere realizar la instalación usted mismo, asegurese de leer el manual en su totalidad antes de comenzar.
  • Page 23 2. Use los anillos de montaje de plástico como plantilla. Marque la posición de los tornills de anclaje. 3. Quite el anillo y perfore los agujeros con una broca de 1/8". 4. Pase el cable de altavoz a través del agujero. 5.
  • Page 24 ® ® Paso Banda Para del Medio RFR-142x Midrange Output – 400µf capacitor – • Para hacer un paso banda para el medio se ha de añadir un condensador de 400µf en serie con el altavoz Ajuste de Nivel del Tweeter (Vista inferior del RFR-142x) Cut jumper Corte el hilo...
  • Page 25 Punch Power. Nous vous proposons de garder ce manuel pour toute référence future. Nous vous recommandons vivement de faire installaer votre système Punch Power par un dealer agréé Rockford Fosgate. Si vous choisissez d'installer le système vous même, assurez-vous de lire ce manuel entièrement avant de commencer.
  • Page 26 3. Retirer l'anneau. Percer les trous des vis en utilisant une mèche de 3mm. 4. Faire passer les fils dans le trou central. 5. Placer l'anneau de montage au-dessus du trou central. 6. Connecter les fils au haut-parleur en respectant les polarités. Eloigner les fils de toute partie tranchante ou mobile du véhicule.
  • Page 27 Bandpassing the Midrange RFR-142x Midrange Output – 400µf capacitor – • To bandpass the midrange, it is necessary to adda 400µf capacitor in series with the speaker Compensation du Niveau Aigu (Vue d'en bas du RFR-142x) Cut jumper Coupez le pontage au wire for –3dB verso du filtre pour –3dB •...
  • Page 28 Einbau des Punch Power Systems. Wir empfehlen, diese auch für Fragen in der Zukunft sorgfältig aufzubewahren. Es ist empfehlenswert, sich das Punch Power System von einem Autorisierten Rockford Fosgate Fachhändler einbauen zu lassen. Sollten Sie den Einbau jedoch selber vornehmen wollen, so empfehlen wir Ihnen, die Bedienungsanleitung sorgfälitg zu lesen.
  • Page 29 3. Nehmen Sie den Ring wieder ab und bohren Sie dann, mit einem passenden Bohrer, die Schraubenlöcher vor. 4. Führen Sie das Kabel durch das Loch. 5. Plazieren sie den Montagering über dem Loch. 6. Schlieβen Sie die Lautsprecherkabel an. Kontrollieren Sie, ob die Polarität stimmt.
  • Page 30 Bandpa β β β β β für den Mitteltöner RFA-142x Midrange Mitteltöner Ausgang Output – 400µf capacitor – 400µF Kondensator • Um einen Bandpab für den Mittletöner zu bilden, ist es nötig, einen 400mF Kondensator in Reihe zu schalten Pegelanpassung für den Hochtöner (Vorderansicht) Cut jumper wire for –3dB...
  • Page 31 Punch Power. Vi suggeriamo di conservare questo manuale come riferimento futuro. Raccomandiamo fortemente che is sistema sia installato dal vostro rivenditore Rockford Fosgate. Se scegliete di procedere con l'installazione da soli, leggete attentamente tutto il manuale prima di proseguire. OSIZIONAMENTO •...
  • Page 32 3. Togliete l'anello e forate il pannello con una puna da 3,5mm. 4. Passate i cavi attraverso il foro. 5. L'anello della griglia sopra il foro dell'altoplarlante. 6. Collegate i cave assicurandovi di osservare la corretta polarità. Assicuratevi di mantenere i cavi lontano da parti in movimento o strutture taglienti.
  • Page 33 Filtrare passa-banda il midrange RFR-142x Midrange Output – 400µf capacitor – • Per filtrare passa-banda il midrange aggiungere un condensatore da 400µf in serie all'altoparlante. Regolazione del livello di emissione del tweeter (Vista Posteriore del RFR-142x) Cut jumper Tagliare il wire for –3dB ponticello per –3dB •...
  • Page 34 OTES...
  • Page 35 OTES...
  • Page 36 American companies. However, due to the global nature of their manufacturing facilities and the loudspeaker parts industry in general, some parts may be manufactured in other countries. Rockford Fosgate Rockford Corporation 546 South Rockford Drive Tempe, Arizona 85281 U.S.A.
