Summary of Contents for Rockford Fosgate Prime R1653
-
Page 2: Carton Contents
AFETY CAUTION: Before installation, disconnect the battery negative (-) terminal to prevent damage to the unit, fire and/or possible injury. PRACTICE SAFE SOUND™ Continuous exposure to sound pressure levels over 100dB may cause permanent hearing loss. High powered auto sound systems may produce sound pressure levels well over 130dB. -
Page 3: Physical Dimensions
HYSICAL IMENSIONS R152 PRIME Trim Ring Diameter-inch 6.10 (mm) (154.6) Trim Ring Height-inch 0.70 (mm) (17.85) Mounting Diameter-inch 4.78 (mm) (121.0) Mounting Depth-inch 1.91 (mm) (49.5) Screw Hole Diameter-inch 5.41 (mm) (137.5) Specifications subject to change without notice 3.83" (97.23mm) R152 6.10"... -
Page 4: Notes Pour L'installation
Français MISE EN GARDE : avant d'entamer l'installation, déconnectez la broche négative (-) de la batterie pour éviter tout risque de blessures, d’incendie ou de dommages à l'appareil. PRATIQUEZ UNE ÉCOUTE SANS RISQUES Une exposition continue à des niveaux de pression acoustique supérieurs à... - Page 5 Deutsch VORSICHT: Entfernen Sie vor dem Einbau den negative Batteriepol, um Schäden am Gerät, Feuer bzw. mögliche Verletzungen zu vermeiden. PRAKTIZIEREN SIE SICHEREN SOUND Fortgesetzte Geräuschdruckpegel von über 100 dB können beim Menschen zu permanentem Hörverlust führen. Leistungsstarke Autosoundsysteme können Geräuschdruckpegel erzeugen, die weit über 130 dB liegen.
- Page 6 • 0.5" Balanced Dome MYLAR Tweeter • 1.75" Midrange MYLAR Speaker • Mica injected polypropylene cone • Cold Rolled Steel Frame Rockford Corporation Rockford Fosgate 600 South Rockford Drive Tempe, Arizona 85281 U.S.A. In U.S.A., (480) 967-3565 - Customer Service 1-800-669-9899 www.rockfordfosgate.com...
-
Page 7: Mounting Holes
PEAKER OUNTING EMPLATE R1653 Mounting Holes 6.46" (164.0mm) R1653 Hole Cutout 5.81" (147.5mm) Verify Scale Before Using 1.00" (25.40mm) Template 1.00" (25.40mm) - Page 8 6.48" (164.5mm) Verify Scale Before Using 1.00" (25.40mm) Template 1.00" (25.40mm) PEAKER OUNTING EMPLATE R1693 Mounting Holes R152 Mounting Holes 5.41" (137.5mm) R152 Hole Cutout 4.76" (121.0mm) R1693 Hole Cutout 6.02" x 8.74" (153.0mm x 222.0mm) 4.78" (121.5mm)
