ULTRA COMPACT COMPONENT SYSTEM
SISTEMAS DE COMPONENTES ULTRA COMPACTOS
SYSTEME DE COMPOSANTS ULTRA COMPACT
FS-MD9000
REMOTE CONTROL RM-RXFSMD9000
DIMMER
SLEEP
CLOCK
FM MODE TAPE/AUX
AHB.
AUTO
SUPER PRO
PRESET
PROGRAM
RANDOM
BASS
TREBLE
EDIT
/TITLE
UP
<
SET
DOWN
MD
TUNER
BAND
VOLUME
POWER
REPEAT
CANCEL
DISPLAY
/CHARA
>
CD
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
AHB.
PRESET
SLEEP
SUPER PRO
TUNING
DOWN
MULTI CONTROL
UP
CLOCK
OPEN/CLOSE
TUNER
MD/TAPE
BAND
CD
STANDBY
PHONES
ULTRA COMPACT COMPONENT SYSTEM
FS -MD9000
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bot-
tom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT0054-001A
[J]

Advertisement

Table of Contents
loading

Related Manuals for JVC FS-MD9000

Summary of Contents for JVC FS-MD9000

  • Page 1 ULTRA COMPACT COMPONENT SYSTEM SISTEMAS DE COMPONENTES ULTRA COMPACTOS SYSTEME DE COMPOSANTS ULTRA COMPACT FS-MD9000 REMOTE CONTROL RM-RXFSMD9000 DIMMER SLEEP POWER CLOCK FM MODE TAPE/AUX AHB. AUTO SUPER PRO PRESET PROGRAM RANDOM REPEAT BASS TREBLE CANCEL EDIT DISPLAY /TITLE /CHARA <...
  • Page 2 Warnings, Cautions and Others / Mises en garde, précautions et indications diverses (For U.S.A) CAUTION RISK OF ELECTRIC SHOCK CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated...
  • Page 3 For Canada/pour le Canada CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. PRECAUTION: POUR EVITER LES CHOCS ELEC- TRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUAU FOND.

  • Page 4: Table Of Contents

    The controls and operations have been redesigned to make them very easy to use, freeing you to just enjoy the music. • With JVC’s COMPU PLAY you can turn on the System and automatically start the Radio, CD Player, MD Player with a single touch.

  • Page 5: Getting Started

    The Remote Control makes it easy to use many of the functions of the System from a distance of up to 7m (23 feet) away. You need to point the Remote Control at the remote sensor on the System’s front panel. R6P(SUM-3)/AA(15F) STANDBY ULTRA COMPACT COMPONENT SYSTEM FS-MD9000 Remote sensor PHONES...

  • Page 6: Connecting The Fm Antenna

    CAUTION: Make all connections before plugging the System into an AC power outlet. Connecting the FM Antenna OPTICAL SUB WOOFER DIGITAL IN(AUX2) AC IN Connecting the AM Antenna OPTICAL SUB WOOFER DIGITAL IN(AUX2) AC IN Using the Supplied Wire Antenna Using the Coaxial Type Connector (Not Supplied) $ýæèðRKPýDQWHQQDýZLWKýFRD[LDOýW\SHýFRQQHFWRUýVKRXOGýEHýFRQQHFWHG WRýWKHý)0ýæèðRKPý&2$;,$/ýWHUPLQDOï...

  • Page 7: Connecting The Speakers

    CAUTION: Make all connections before plugging the System into an AC power outlet. Connecting the Speakers 1. Open each of the terminals to connect the speaker wire leads. 2. Connect the speaker cords between the Speaker terminals of the Unit and the terminals of the Speakers. Connect the cords with a black line to the (–) terminals and cords without a black line to the (+) terminals.

  • Page 8: Connecting The Ac Power Cord

    OPTICAL DIGITAL IN(AUX2) Connecting a Subwoofer System Connect an (not supplied) signal cord between the SUB WOOFER OUT terminal and an external JVC subwoofer system, etc. SUB WOOFER Connecting the AC Power Cord Firmly insert the supplied AC power cord into the AC inlet on the back of the Unit.

  • Page 9: Common Operations

    COMPU PLAY JVC's COMPU PLAY feature lets you control the most frequently used System functions with a single touch. With One Touch Operation you can play a CD, an MD, or turn on the radio with a single press of the play button for that function. One Touch Operation turns the power on for you, then starts the function you have specified.

  • Page 10: Adjusting The Volume

    Adjusting the Volume You can adjust the volume level between 0 and 50. The VOLUME indicator on the display indicates the volume level. VOLUME Press the VOLUME UP button of the Unit to increase the volume or press the VOLUME DOWN button to decrease it. Press the VOLUME + button on the Remote Control to increase the volume or press the VOLUME - button to decrease it.

  • Page 11: Using The Tuner

    Using the Tuner REMOTE CONTROL RM-RXFSMD9000 DIMMER SLEEP POWER CLOCK FM MODE TAPE/AUX FM MODE AHB. AUTO SUPER PRO PRESET AUTO PRESET PROGRAM RANDOM REPEAT BASS TREBLE CANCEL EDIT DISPLAY /TITLE /CHARA < < > > DOWN DOWN TUNER BAND TUNER BAND ¢...

  • Page 12: Using The Cd Player

    5. Press the SET button. "STORED" appears and, after 1 second, the display returns to the broadcast frequency display. 6. Repeat above steps 1 to 5 for each station you want to store in memory with a preset number. To cancel the presetting, press the CANCEL button in step 3 or 4.

  • Page 13: Programming The Playing Order Of The Tracks

    You can place an 8 cm (3'') CD without an adaptor. If the CD cannot be read correctly (because it is scratched, for example), " 0 0:00" appears on the display. You can insert a CD while listening to the other source. Basics of Using the CD Player-Normal Play To Play a CD ————————————...

  • Page 14: Using The Md Player (Listening To An Md)

    2. Press the CD button. The tracks are played in random order. To skip a track during playback, press the to the next track in the random sequence. Press the jump back to the start of a track being played. To exit Random Play mode, press the RANDOM button to light off the "CD RANDOM"...
  • Page 15 To stop playing the MD, press the button. The following in- formation for the MD is displayed. Total track number Total playback time To stop playing and remove the MD, press the MD to eject the MD. To pause, press the MD button.

  • Page 16: Recording Onto An Md

    blank display (back to the beginning) : Repeats one track. ALL : In Normal Play mode, repeats all the tracks. In Program Play mode, repeats all the tracks in the program. In Random Play mode, repeats all the tracks in ran- dom order.

  • Page 17: Using The Md Player (Editing)

    4. Play the record source selected in step 2. 5. Press the MD 38 button to start recording. The MD indicator blinks slowly and the selected source is re- corded on the MD. PAUSE (Source playback) (Track is increased by 1.) 6.

  • Page 18: Title Function

    Erasing all the tracks (ALL ERASE function) All the tracks can be erased at once without recording fresh material over them. Track No. Track A Track B Track C Track D ERASE New tracks can be recorded. REMOTE CONTROL RM-RXFSMD9000 DIMMER SLEEP POWER...

  • Page 19: Join Function

    Note: While “UTOCwriting” is displayed, do not disconnect the power cord or subject the Unit to the vibration to avoid in- correct recording. Joining Tracks (JOIN Function) Use the Remote Control to carry out this function. 1. Insert an MD to be edited with its label side up. 2.

  • Page 20: All Erase Function

    2. Press the MD 38 button and then 7 button to set the function to MD. The track numbers and total playback time are displayed. 3. Press the EDIT/TITLE button until "ERASE ?" is displayed. The "EDIT" indicator appears on the display. DIVIDE JOIN MOVE...
  • Page 21 5. Input a preferred title (up to 32 charac- ters). Use the following buttons to input a title. [Title editing buttons and their functions] (see below) Button Function DISPLAY Changes the type of characters to be input as fol- /CHARA lows.

  • Page 22: Using External Equipments

    Using External Equipments REMOTE CONTROL RM-RXFSMD9000 DIMMER CLOCK AHB. SUPER PRO PROGRAM BASS EDIT /TITLE < Listening to External Equipment You can listen to external equipment. First make sure that the external equipment is properly connect- ed to the System. (See page 4). 1.

  • Page 23: Using The Timers

    Using the Timers REMOTE CONTROL RM-RXFSMD9000 DIMMER SLEEP POWER SLEEP CLOCK FM MODE TAPE/AUX AHB. AUTO SUPER PRO PRESET PROGRAM RANDOM REPEAT SUPER PRO BASS TREBLE CANCEL EDIT DISPLAY /TITLE /CHARA CD SYNCHRO < > DOWN TUNER BAND When the System is in use, the display shows other items as well. VOLUME For simplicity, we show here only the items described in this section.

  • Page 24: Information On Mds (Minidiscs)

    6. Press the TIMER/SNOOZE button on the Unit. The timer setting is completed and the display returns to the dis- play before you set the timer. The timer indicator remains lit. 7. Before turning off the System, prepare the music source selected in step 4. TUNER: Tune in to the desired station.

  • Page 25: Md Messages

    ATRAC (Adaptive Transform Acous- tic Coding) Within recordings, there are sounds which cannot be readily heard. For example, as the volume decreases, high-pitched sounds and low-pitched sounds become difficult to hear. also, if a quiet sound comes at the same time as or just after a loud sound, it will not be heard.

  • Page 26: Minidisc Limitations

    Minidisc limitations The minidisc records information in an original format that differs from that of conventional cassette tapes or DATs. Since there are some lim- itations with this recording format, the following types of conditions may arise. These conditions arre not malfunctions. Condition “DISC FULL”...

  • Page 27: Care And Maintenance

    Care And Maintenance +DQGOHý\RXUý&'VýDQGý0'VýFDUHIXOO\ñýDQGýWKH\ýZLOOýODVWýDýORQJýWLPHï Compact Discs ‡ 2QO\ý&'VýEHDULQJýWKLVýPDUNýFDQýEHýXVHGýZLWKý WKLVý6\VWHPïý+RZHYHUñýFRQWLQXHGýXVHýRIýLUUHJXð ODUýVKDSHý&'VýõKHDUWðVKDSHñýRFWDJRQDOñýHWFïôý FDQýGDPDJHýWKHý6\VWHPï ‡ 5HPRYHýWKHý&'ýIURPýLWVýFDVHýE\ýKROGLQJýLWýDWý WKHýHGJHVýZKLOHýSUHVVLQJýWKHýFDVH©VýFHQWHUýKROHý OLJKWO\ï ‡ 'RýQRWýWRXFKýWKHýVKLQ\ýVXUIDFHýRIýWKHý&'ñýRUý EHQGýWKHý&'ï ‡ 3XWýWKHý&'ýEDFNýLQýLWVýFDVHýDIWHUýXVHýWRýSUHYHQWý ZDUSLQJï ‡ %HýFDUHIXOýQRWýWRýVFUDWFKýWKHýVXUIDFHýRIýWKHý&'ý ZKHQýSODFLQJýLWýEDFNýLQýWKHýFDVHï ‡ $YRLGýH[SRVXUHýWRýGLUHFWýVXQOLJKWñýWHPSHUDWXUHý H[WUHPHVñýDQGýPRLVWXUHïý ‡ $ýGLUW\ý&'ýPD\ýQRWýSOD\ýFRUUHFWO\ïý,IýDý&'ý GRHVýEHFRPHýGLUW\ñýZLSHýLWýZLWKýDýVRIWýFORWKýLQýDý VWUDLJKWýOLQHýIURPýFHQWHUýWRýHGJHïý CAUTION: Do not use any solvent (for example, conventional record cleaner, spray thinner, ben- zine, etc.) to clean a CD.

  • Page 28: Troubleshooting

    Troubleshooting ‡ ,Iý\RXýDUHýKDYLQJýDýSUREOHPýZLWKý\RXUý6\VWHPñýFKHFNýWKLVýOLVWýIRUýDýSRVVLEOHýVROXWLRQýEHIRUHýFDOOLQJýIRUýVHUYLFHï ‡ ,Iý\RXýFDQQRWýVROYHýWKHýSUREOHPýIURPýWKHýKLQWVýJLYHQýKHUHñýRUýWKHý6\VWHPýKDVýEHHQýSK\VLFDOO\ýGDPDJHGñýFDOOýDýTXDOLILHGýSHUVRQñýVXFKýDVý \RXUýGHDOHUñýIRUýVHUYLFHï Symptom 1RýVRXQGýLVýKHDUGï 3RRUýUDGLRýUHFHSWLRQ 7KHý&'ýVNLSVï 7KHý&'ýGRHVýQRWýSOD\ï 7KHý0'ýFDQQRWýEHýLQVHUWHGï 5HFRUGLQJýFDQQRWýEHýPDGHýRQý0'ï 7LPHUýIDLOVýWRýVWDUWï 8QDEOHýWRýRSHUDWHýWKHý5HPRWHý&RQWUROï 2SHUDWLRQVýDUHýGLVDEOHGï Possible Cause ‡ &RQQHFWLRQVýDUHýLQFRUUHFWñýRUýORRVHï ‡ +HDGSKRQHVýDUHýFRQQHFWHGï ‡ 7KHýDQWHQQDýLVýGLVFRQQHFWHGï ‡ 7KHý$0ý/RRSý$QWHQQDýLVýWRRýFORVHýWRýWKHý 6\VWHPï ‡ 7KHý)0ý:LUHý$QWHQQDýLVýQRWýSURSHUO\ý H[WHQGHGýDQGýSRVLWLRQHGï 7KHý&'ýLVýGLUW\ýRUýVFUDWFKHGï 7KHý&'ýLVýXSVLGHýGRZQï $Qý0'ýKDVýDOUHDG\ýEHHQýLQVHUWHGï 7KHýDFFLGHQWDOýHUDVXUHýSUHYHQWLRQýNQREýRIýWKHý 0'ýLVýVHWýWRýWKHýRSHQýSRVLWLRQï 3UHVHQWýWLPHýLVýQRWýFRUUHFWï ‡ 7KHýSDWKýEHWZHHQýWKHý5HPRWHý&RQWUROýDQGý WKHýVHQVRUýRQýWKHý8QLWýLVýEORFNHG ‡ 7KHýEDWWHULHVýKDYHýORVWýWKHLUýFKDUJHï...

  • Page 29: Specifications

    Specifications Amplifier 2XWSXWý3RZHU ìêýZDWWVýSHUýFKDQQHOñýPLQïý506ñýDWýéýRKPVýIURPýåíý+]ýWRýëíýN+]ñýZLWKýQRýPRUHýWKDQýìíøý ,QSXWý6HQVLWLYLW\î,PSHGDQFHýõìýN+]ô /,1(ý,1ýõ$8;ýìô èííýP9îçíýNRKPV 2SWLFDOý,Q ¤ëéýG%Pýðý¤ìèýG%P 2XWSXWý6HQVLWLYLW\î,PSHGDQFHýõìýN+]ô /,1(ý287 èííýP9îèýNRKPV 6XEZRRIHU íýðýìééýP9îêíýNRKPV 6SHDNHUýWHUPLQDOV éýðýìçýRKPV 3KRQHV ìçýRKPVýðýìýNRKPV MD Player :RZý$QGý)OXWWHU 8QPHDVXUDEOH CD Player :RZý$QGý)OXWWHU 8QPHDVXUDEOH Tuner )0ý7XQHU 7XQLQJý5DQJH åæïèýðýìíåïíý0+] $0ý7XQHU 7XQLQJý5DQJHý èêíýðýìñæìíýN+] Speaker Specifications õHDFKýXQLWôý6SHDNHUV åýFPýFRQH ,PSHGDQFH éýRKPV 'LPHQVLRQV ìëíý ýìçíý ýìäíýPPýõ:î+î'ôý General 'LPHQVLRQV êåíý...
