Philips 200CW8FB/00 Service Manual

20" lcd color monitor

Hide thumbs Also See for 200CW8FB/00:

Specifications (3 pages)

User manual (110 pages)

100

101

102

103

104

105

106

107

108

109

110

111

112

Table of Contents

Quick Links

Chapters

Table of Contents

Summary of Contents for Philips 200CW8FB/00

Page 1: Table Of Contents
20" LCD Color Monitor Chassis: HUDSON 8 Service Service Service 200CW8FB/00 200CWFB/69 200CW8FB/93 Description Page Description Page Table Of Contents........………….1 6.1 Main Board…….……………..….……………………22 Revision List..........…………….2 6.2 Power Board…………………………..…………………27 Important Safety Notice………….........3 6.3 Key Board…….………………………..…………………29 1. Monitor Specifications……........…..4 7. PCB Layout..……......……………………..30 2.
Page 2: Revision List
HUDSON 8 Revision List Version Release Date Revision History Aug.31, 2007 Initial release, Draft Version Sep.25, 2007 Add new BOM in Item17 Oct.22,2007 Add Philips 12NC for Model 200CW8FB/69 and 200CW8FB/93 Nov.25,2007 Add Philips 12NC for 715GT039 A...
Page 3: Important Safety Notice
HUDSON 8 Important Safety Notice Proper service and repair is important to the safe, reliable operation of all Philips Company Equipment. The service procedures recommended by Philips and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose.
Page 4: Monitor Specifications
HUDSON 8 1. Monitor Specifications...
Page 5 HUDSON 8...
Page 6: Lcd Monitor Description
HUDSON 8 2. LCD Monitor Description The LCD monitor will contain a main board, a power board and a key board which house the flat panel control logic, brightness control logic and DDC. The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each voltage.
Page 7: Operation Instructions
HUDSON 8 3. Operating Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control buttons are located at the front of the panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences. The power cord should be connected.
Page 8 HUDSON 8 Rear View...
Page 9: Adjusting The Picture
Description of the On Screen Display On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance or select functions of the monitors directly through an on-screen instruction window. A user friendly on screen display interface is shown as below.
Page 10 HUDSON 8 The OSD Tree Below is an overall view of the structure of the On-Screen Display. You can use this as a reference when you want to work your way around the different adjustments later on.
Page 11: Connecting To The Pc
HUDSON 8 3.4 Connecting to the PC 1) Connect the power cord to the back of the monitor firmly. (Philips has pre-connected VGA cable for the first installation. 2) Connect to PC (a) Turn off your computer and unplug its power cable.
Page 12: Input/Output Specification
HUDSON 8 4. Input/ Output Specification 4.1 Input Signal Connector Analog connectors Pin No. Description Pin No. Description Red video input Green video input Logic Ground Blue video input Ground Sense (GND) Serial data line (SDA) Cable detect (GND) H. Sync Red video ground V.
Page 13: Factory Preset Display Modes
HUDSON 8 4.2 Factory Preset Display Modes...
Page 14: Pixel Defect Policy
HUDSON 8 4.3 Pixel Defect Policy...
Page 15 HUDSON 8...
Page 16 HUDSON 8...
Page 17: Failure Mode Of Panel
HUDSON 8 4.4 Failure Mode Of Panel Quick reference for failure mode of LCD panel this page presents problems that could be made by LCD panel. It is not necessary to repair circuit board. Simply follow the mechanical Polarizer has bubbles instruction on this manual to eliminate failure by replace LCD panel.
Page 18: Block Diagram
HUDSON 8 5. Block Diagram 5.1 Software Flow Chat...
Page 19 HUDSON 8 1) MCU initialize. 2) Is the EPROM blank? 3) Program the EPROM by default values. 4) Get the PWM value of brightness from EPROM. 5) Is the power key pressed? 6) Clear all global flags. 7) Are the AUTO and SELECT keys pressed? 8) Enter factory mode.
Page 20: Electrical Block Diagram
HUDSON 8 5.2 Electrical Block Diagram 5.2.1 Main Board Panel Interface (CN101) Scalar PUMO58CWHJ-LF EEPROM Keypad Interface (Include MCU, ADC, OSD) AF24BC16-SI (CN401) (U401) (U403) H sync D-Data V sync D-Clock Flash Memory Crystal PM25LV010A-100SCE 14.31818MHZ (U402) (X401) D-Sub Connector Connector (CN405) (CN406)
Page 21 HUDSON 8 5.2.2 Inverter/Power Board AC input Bridge Rectifier Transformer Rectifier diodes EMI filter and Filter Start Circuit: R904、R905、R906 Feedback Circuit Control IC ON/OFF Output MOSFET Circuit Transformer Lamp Over ON/OFF Feedback Voltage Control Circuit Control IC...
Page 22: Schematic Diagram
HUDSON 8 6. Schematic 6.1 Main Board 715G2592-1 TSUMU58J SCHEMATIC HDCP_RST HDCP_RST LVDS OUTPUT GNDR GNDR GNDG GNDG GNDB GNDB HSYNC HSYNC VCC1.8 VCC3.3 VSYNC VSYNC DDCA_SDA DDCA_SDA DDCA_SCL DDCA_SCL DDC_WP DDC_WP VCC1.8 Vcc3.3 CLK+ CLK+ CLK- CLK- DDCD_SDA DDCD_SDA DDCD_SCL DDCD_SCL DET_INPUT...
Page 23 HUDSON 8 POWER 600 OHM FB406 +3V3 C710 CN701 A1 C709 100uF/25V R701 CN702 0.1uF 16V 1K 1/16W R705 CN701 C702 D5 1K 1/16W R706 C708 A3 NC/0R05 1/16W C709 A2 +3V3 C710 A2 C708 C711 B3 NC/1000pF Adj_BACKLIGHT 4 C712 C5 Q701 R707...
Page 24 HUDSON 8 CN405 INPUT FB410 30 OHM DB15 CN405 A1 CN406 C1 RED+ R434 56 OHM 1/16W C432 0.047uF C432 A5 C433 A5 RED- FB411 30 OHM R435 56 OHM 1/16W C433 0.047uF C434 A5 C435 A5 GREEN+ GREEN- FB412 C436 A5 C437 A5 BLUE+...
Page 25 HUDSON 8 AVDD_33 VDDC VDDP FB403 SCALER AVDD_18AVDD_MEMPLL_33 VCC3.3 AVDD_MEMPLL_33 VCC3.3 600 OHM VDDP CN401 E5 CN407 E7 VCC3.3 C401 B2 C402 A8 C403 A7 C404 A7 FB405 600 OHM C416 C408 C405 A7 C406 A7 0.1uF 16V 10uF/16V C407 B7 C408 A6 VCC3.3 C409 A7...
Page 26: Panel Interface
HUDSON 8 PA[0..9] PA[0..9] CN101 LVA3P LVA3M LVB0M RXO0- CN101 A4 LVACKP LVB0P RXO0+ C720 C1 LVACKM LVB1M RXO1- C721 C2 LVA2P LVB1P RXO1+ LVA2M LVB2M RXO2- FB701 C1 LVA1P LVB2P RXO2+ R719 C2 LVA1M R720 C1 LVA0P LVBCKM RXOC- R732 C4 LVA0M LVBCKP...
Page 27: Power Board
HUDSON 8 6.2 Power Board 715G2621-1 POWER BD901 B1 CN901 G1 CN902 F7 C900 E5 C901 F2 C902 F1 C903 D1 C905 C2 C906 C4 C907 D4 C908 D4 C909 E4 1/4W R918 L904 C912 B7 C915 C8 +16V 1/4W R919 C917 B7 3.5uH...
Page 28 HUDSON 8 C819 INVERTER 68pF3KV CN801 A7 CN802 A7 CN801 CN803 C7 CN804 C7 CONN C801 B3 C802 B3 C803 C1 C804 C1 +16V R805 C805 C2 C806 C2 C820 1/10W CN802 ON/OFF C807 C3 C808 C3 68pF3KV CONN C809 C4 C810 C4 T801 C811 B4...
Page 29: Key Board
HUDSON 8 6.3 Key Board 715G2844-1 CN001 KEY1 KEY2 POWER LED_G LED_A LED_LF Pitch 1.0mm CONN C001 C002 C003 C004 C005 C006 0.01uF/25V 0.01uF/25V 0.01uF/25V 1uF 16V 0.01uF/25V 0.01uF/25V CN001 A5 C001 A2 C002 A3 C003 A3 C004 A3 C005 A4 KEY1 KEY2 POWER...
Page 30: Pcb Layout
HUDSON 8 7. PCB Layout 7.1 Main Board 715G2592-1 C401 C446 D409 R119 R452 R708 C402 C447 D410 R120 R453 R709 C403 C448 D411 R401 R454 R710 C404 C449 D412 R403 R455 R711 C405 C450 D413 R404 R456 R712 C406 C451 D414 R405...
Page 31 HUDSON 8 C470 R476 R477 R478 R479 R480 R481 R482...
Page 32: Power Board
HUDSON 8 7.2 Power Board 715G2621-1 BD901 D4 J803 C812 J804 C816 J805 C817 J806 C819 J807 C820 J808 C821 J809 C822 J810 C900 J811 C901 J901 C902 J902 C903 J903 C905 J904 C906 J905 C908 J906 C915 J907 C917 J908 C918 L801...
Page 33 HUDSON 8 C801 R837 C802 R838 C803 R839 C804 R840 C805 R841 C806 R842 C807 R843 C808 R844 C809 R845 C810 R846 C811 R847 C813 R848 C814 R849 C815 R850 C818 R901 C823 R902 C907 R904 C909 R905 C912 R906 C924 R909 C928...
Page 34: Key Board
HUDSON 8 7.3 Key Board 715G2844-1 C001 C002 C003 C004 C005 C006 D001 D002 D003 LED001 A4 LED002 A2 R001 R002 R003 R007 CN001 A1...
Page 35: Wiring Diagram
HUDSON 8 8. Wiring Diagram Lamp Wire Harness Panel Lamp Wire Harness Power Wire Harness CN802 CN902 Panel Interface CN801 CN701 CN101 Power Board CN501 Main Board CN401 CN804 CN901 Board CN803 CN406 CN405 CN502 D-SUB AC-IN CN511 Key Board Wire Board Key Board CN001...
Page 36: Mechanical Instructions
HUDSON 8 9. Mechanical Instructions 1. Back View as Fig1 Place the monitor face down on a smooth surface as Fig 1. Be careful to avoid scratch and injury during the uninstallation. Fig1 2. Remove cable cover as Fig2. Fig2...
Page 37 HUDSON 8 3. Remove the base as Fig3. Fig3 4. Remove the hinge cover as Fig4. Fig4...
Page 38 HUDSON 8 5. Remove the column as Fig5. Remove the four screws remarked in red to remove the column as Fig5. Fig5 6. Remove the bezel as Fig6~Fig9. a. Remove the screw remarked in red as Fig6. Fig6...
Page 39 HUDSON 8 b. Remove the bezel as Fig7~Fig8. Fig7 Fig8...
Page 40 HUDSON 8 Fig9 7. Remove rear cover as Fig10~Fig11 a. Remove the two screws in red in the left of the monitor as Fig10. Fig10 b. Remove the two screws in red in the right of the monitor to remove the rear cover as Fig11. Fig11...
Page 41 HUDSON 8 8. Remove the shielding as Fig12. Remove the five screws remarked in red to remove the shielding. Fig12 9. Remove main board, power board and USB board as Fig13~Fig14 Remove the seven screws remarked in red to remove the main board, power board and USB board. Fig13...
Page 42 HUDSON 8 Fig14 10. Remove main frame as Fig15~Fig16. a. Remove the two screws in red in the left as Fig15. Fig15 b. Remove the two screws in red in the right to remove the main frame as Fig16. Fig16...
Page 43 HUDSON 8 11. The end as Fig17~Fig18. Fig17 Fig18...
Page 44: Trouble Shooting
HUDSON 8 10. Trouble Shooting This page deals with problems that can be corrected by a user. If the problem still persists after you have tried these solutions, contact Philips customer service representative.
Page 45 HUDSON 8...
Page 46: Repair Flow Chart
HUDSON 8 11. Repair Flow Chart 11.1 Main Board (1). No Power No power Press power key and look if the picture is normal Please reinsert and make sure the AC of 100-240 is normal Reinsert or check the Adapter/Inverter section Measure U702 PIN2=3.3V U701 PIN2 =1.8V Check CN701, D704, U701,...
Page 47 HUDSON 8 (2). No Picture No picture The button if X401 oscillate Replace X401 under control waveform is normal Check reset circuit of Check Correspondent component U401 is normal Measure U702 PIN2=3.3V U701 PIN2 =1.8V Replace U401 Check CN701, D704, U701, U702 X401 oscillate waveform is normal...
Page 48 HUDSON 8 (3). White screen White screen Measure Q705 base X401 oscillate waveform is normal is low level? Replace X401 Check Q705, Q704 is broken or CN101 solder? Check reset circuit of U401 is normal Check Correspondent Check Correspondent component. component.
Page 49 HUDSON 8 11.2. Power/Inverter Board (1) No power Check CN902 pin4 = 16V Check AC line volt 110V or 220V Check AC input Check the voltage of C905 (+) Check bridge rectified circuit and F901 circuit Check start voltage for the pin3 of IC901 Check R904, R905, R906 and Change IC901 Check the auxiliary voltage is bigger than 10V and smaller than 20V...
Page 50 HUDSON 8 (2) W / LED, No Backlight Check CN902 pin4 = 16V Check adapter or MB Check ON/OFF signal Check Interface board Check IC801 PIN2=5V Check Q801 and ZD801 Check IC801 PIN1, 15 have the output of square wave at short Change IC801 Check Q805 and Q806 PIN5, 6, 7, 8 have the output of square wave at short time.
Page 51 HUDSON 8 11.3 Key Board OSD is unstable or not working Connect Key Pad Board Is Key Pad Board connecting normally? Replace Button Switch Is Button Switch normally? Replace Key Pad Board Is Key Pad Board normally? Check Main Board...
Page 52: Isp Instruction
HUDSON 8 12. ISP Instruction 1. When do the part, need the tools as follow: a. An i486 (or above) personal computer or compatible. b. Microsoft operation system Windows 95/98/2000/XP. c. “ PORT95NT.exe” program d. Software ISP SN Alignment kits The kit contents: a.
Page 53 HUDSON 8...
Page 54 HUDSON 8...
Page 55 HUDSON 8 Click to complete the installation.
Page 56 HUDSON 8 Note: After installation, you must restart the PC to take the setup to effect. 3. Connect the ISP board as follow: Connect to Connect to the the PC LPT Philips 200CW8...
Page 57 HUDSON 8 4. The process of ISP write is as follows. a. Double-click ，running the program as follows:...
Page 58 HUDSON 8 b. Click icon, running the program as follows: c. Click icon, search the program” 200CW8_MSTAR_LM201WE3_V100_070824.BIN”, and click open:...
Page 59 HUDSON 8 d. Click icon, it will auto run. If burn in success, it will show as the follow picture:...
Page 60: Ddc Instruction
HUDSON 8 13. DDC Instruction General DDC Data Re-programming In case the main EEPROM with Software DDC which store all factory settings were replaced because a defect, repaired monitor’ the serial numbers have to be re-programmed. It is advised to re- soldered the main EEPROM with Software DDC from the old board onto the new board if circuit board have been replaced, in this case the DDC data does not need to be re-programmed.
Page 61 HUDSON 8 2. Install the “WinDDC_ setup” Second, you must install the . The processing as follows:...
Page 62 HUDSON 8...
Page 63 3. Connect the DDC board as follow: Connect to the PC LPT When you write analog EDID, Connect this port to the Philips 200CW8’s When you write digital VGA port EDID, Connect this port to the Philips 200CW8’s DVI port...
Page 64 HUDSON 8 4. Take analog DDC write for example, as follow a. Double-click ，appear as follow Figs：...
Page 65 HUDSON 8 b. Click c. Key 14 numbers in the Serial Number blank, then click “OK”. Now analog DDC Write completes, as follow. Note: The way of digital DDC write is the same as analog DDC write.
Page 66 HUDSON 8 200CW8 EDID Analog 128 bytes EDID Data (Hex): x0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF 00 FF FF FF FF FF FF 00 41 0C 19 C0 03 C4 04 00 10: 0C 0D 01 03 0E 2E 1E 78 2A 85 C5 A4 55 4A 9C 24 20: 14 50 54 BF EF 80 71 4A 71 4F 81 40 81 80 B3 00 30: 01 01 01 01 01 01 21 39 90 30 62 1A 27 40 68 B0...
Page 67 Detailed Timing: FF (Monitor SN) '123231231232' Detailed Timing: FD (Monitor limits) Min. V. rate: 56Hz Max. V. rate: 76Hz Min. H. rate: 30KHz Max. H. rate: 83KHz Max. Pixel Clock: 170MHz Detailed Timing: FC (Monitor Name) 'Philips 200CW' <-x-Detailed Timing Descriptions-x-> Extension Flag: Checksum:...
Page 68 HUDSON 8 200CW8 EDID Digital 128 bytes EDID Data (Hex): x0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF 00 FF FF FF FF FF FF 00 41 0C 19 C0 03 C4 04 00 10: 0C 0B 01 03 80 2E 1E 78 2A 85 C5 A4 55 4A 9C 24 20: 14 50 54 BF EF 80 71 4A 71 4F 81 40 81 80 B3 00 30: 01 01 01 01 01 01 21 39 90 30 62 1A 27 40 68 B0...
Page 69 Detailed Timing: FF (Monitor SN) '231311231232' Detailed Timing: FD (Monitor limits) Min. V. rate: 56Hz Max. V. rate: 76Hz Min. H. rate: 30KHz Max. H. rate: 83KHz Max. Pixel Clock: 170MHz Detailed Timing: FC (Monitor Name) 'Philips 200CW' <-x-Detailed Timing Descriptions-x-> Extension Flag: Checksum:...
Page 70: White Balance, Luminance Adjustment
HUDSON 8 14. White Balance, Luminance Adjustment 1. Apparatuses and program: analyzer CA-210, PC, tool, FGA adjustment program (FGAWB0.15SN), Pattern generator. 2. Equipment installation: a. Connect analyzer CA-210 to PC by USB connector, install drive program CA-SDK Ver4.00 for CA-210 and restart PC after finish installing.
Page 71 HUDSON 8 4. Color Temp confirmation Connect the signal to the monitor, the monitor display white-picture, use CA-210 to measure the Color Temp of the screen center and select the OSD to make sure whether the Color Temps accord with the SPEC.
Page 72: Monitor Exploded View
HUDSON 8 15. Monitor Exploded View...
Page 73: Recommended & Spare Parts List
CUSHION 996510009123 FQ020 Q44GA040 2 CUSHION 996510009124 FQ034 Q44GA040 4 CUSHION 996510009125 FQ021 Q44GA040813 3A 20 LCD PHILIPS CARTON 996510009126 FQ022 Q70G2007813 1A CD MANUAL U401 056G 562182 IC PUMO58CWHJ-LF PQFP-128 996510009132 U701 056G 563 50 IC AP1117D18LA TO252-3L ATC...
Page 74 HUDSON 8 U403 056G1133 89 IC AF24BC16-SI 16K SOIC-8 996510006453 U402 705GQ756079 U402 ASS'Y(CPT) 996510009144 U402 705GQ756077 U402 ASS'Y(LPL) 996510009161 IC903 056G 139 3A IC PC123Y22FZ0F 996510009148 IC901 056G 379 76 IC LD7552BPS SOP-8 996510009148 IC801 056G 608 10 IC OZ9938GN-B SOIC-16 996510009148 IC904 056G 158 12...
Page 75 HUDSON 8 Spare Parts List Service Kit Description Part No. Philips 12NC Remark DDC Kit 715L2005C2 9965 000 43197 for all model OSD SN Kit 715GT033 C 9965 000 43252 for all model for all hudson 7 NOVATEK ISP Kit...
Page 76 996510009121 FQ014 A34G0456ADTA1T0100 BEZEL 200CW8 996510009122 FQ018 Q40G 20N813 1A RATING LABEL FQ019 Q44GA040 1 CUSHION 996510009123 FQ020 Q44GA040 2 CUSHION 996510009124 FQ034 Q44GA040 4 CUSHION 996510009125 FQ021 Q44GA040813 3A 20 LCD PHILIPS CARTON 996510009126 FQ022 Q70G2007813 1A CD MANUAL...
Page 77 HUDSON 8 Board Parts Location Part No. Description Philips 12NC FQ023 CBPC7CMAPHA2 SCALER BOARD ASSY(CPT) 996510009127 C401 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716 C402 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716 C403 067G215Y479 7N LOW ESR EC 4.7 UF 50V NCC...
Page 78 HUDSON 8 C440 065G0402473 12 CHIP 0.047UF 16V X7R 996510005721 C441 065G0402473 12 CHIP 0.047UF 16V X7R 996510005721 C442 065G0402220 31 CHIP 22PF 50V NPO 996510005717 C443 065G0402221 32 MLCC 0402 CAP 220PF J 50V X7R 996510009140 C444 065G0402224 A5 MLCC 0402 CAP 0.22UF K 10V X5R 996510007216 C445...
Page 79 HUDSON 8 D407 093G 64 42 PP BAV70 SOT-23 996500035995 D408 093G 39S 24 T RLZ 5.6B LLDS 996500036079 D409 093G 39S 24 T RLZ 5.6B LLDS 996500036079 D410 093G 39S 24 T RLZ 5.6B LLDS 996500036079 D411 093G 39S 24 T RLZ 5.6B LLDS 996500036079 D412...
Page 80 HUDSON 8 R419 061G0402000 RST CHIPR 0 OHM +-5% 1/16W 996510005699 R420 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701 R421 061G0402000 RST CHIPR 0 OHM +-5% 1/16W 996510005699 R422 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711 R423 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711 R424...
Page 81 HUDSON 8 R463 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700 R464 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700 R465 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700 R466 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700 R467 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700 R468...
Page 82 HUDSON 8 U405 056G1133 84 AF24BC02-S1 996510009133 U701 056G 563 50 IC AP1117D18LA TO252-3L ATC 996510007208 U702 056G 563 52 IC AP1117D33LA TO252-3L ATC 996510005697 X401 093G 2253B J 14.31818MHZ/85C 996510009131 CN405 088G 35315F H D-SUB 15PIN 996500035960 CN406 088G 35424F N DVI 24PIN CONN F 996510005695 FB401...
Page 83 HUDSON 8 C804 065G0805225 12 CHIP 2.2UF 16V X7R 0805 996510006267 C805 065G0603103 12 CHIP 0.01UF 16V X7R 996510007262 C806 065G0603105 12 CHIP 1UF 16VX7R 0603 996510002499 C807 065G0603103 12 CHIP 0.01UF 16V X7R 996510007262 C808 061G0603184 RST CHIPR 180 KOHM +5% 1/10W 996510007252 C809 065G080556131G...
Page 84 L904 073G 253 91 H CHOKE COIL 996500036026 Q801 057G 417 4 PMBS3904/PHILIPS-SMT(04) 996500035966 Q802 057G 763904 TRA FET 2N7002 SOT-23 PHILIPS 996500042651 Q803 057G 763904 TRA FET 2N7002 SOT-23 PHILIPS 996500042651 Q805 057G 600 61 AM4502C-TI-PF S0-8 996510007251 Q806...
Page 85 HUDSON 8 R822 061G0805200 2F RST CHIPR 20 KOHM -1% 1/8W 996500043871 R823 061G0603390 0F RST CHIP 390R 1/10W 1% 996500044263 R824 061G0603330 1F RST CHIP 3K3 1/10W 1% 996500044831 R825 061G0603511 RST CHIPR 510 OHM -5% 1/10W 996500043967 R826 061G0603105 RST CHIPR 1 MOHM -5% 1/10W 996500042216...
Page 86 HUDSON 8 R940 061G0603430 2F RST CHIPR 43 KOHM +-1% 1/10W 996510009156 R942 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955 R943 061G0805471 470&8 1/10W 996500043397 R946 061G152M151 64 RST MOFR 150 OHM +5% 2WS 996510007231 R961 061G1206101 100 1206 996500045142 R962 061G1206101...
Page 87: Different Part List
HUDSON 8 17. Different Part List Diversity of 200CW8FB/00 compared with 200CW8FB/69 200CW8FB/00 200CW8FB/69 Location Part No. Description Philips 12NC Part No. Description Philips 12NC FQ004 089G404A18N IS POWER CORD 32E1818018 FQ005 089G404A18N YH POWER CORD FQ007 095G8014 7D525 WIRE HARNESS 7P-7P 320MM...
Page 88: General Product Specification
PROE FILES REQUIRED 5.3 LOCATION OF PHILIPS LOGO PER PHILIPS MAKE-UP SHEET 5.4 GAP BETWEEN PANEL AND FRONT BEZEL<1.2MM 5.5 LOCATION OF CONTROL ICONS- PER PHILIPS GRAPHIC SHEET 5.6 COLOR FOR RESIN/PAINT PER PHILIPS MAKE-UP SHEET 5.7 RESINS 5.8 IF RAINT IS USED 5.9 PLASITIC MOLD TOOLING...
Page 89 6.3 DISPLAY DISTURBANCES FROM EXTERNAL ENVIRONMENT 6.4 DISPLAY DISTURBANCES TO EXTERNAL ENVIRONMENT RELIABILITY 7.1 MEAN TIME BETWEEN FAILURES QUALITY ASSURANCE REQUIREMENTS 8.1 ACCEPTANCE TEST PHILIPS’ FLAT PANEL MONITORS PIXEL DEFECT POLICY 10. REGULATORY COMPLIANCE 10.1 WORLDWIDE REGULATORY 10.2 EMC REQUIREMENTS 10.3 ROHS 10.4 WEEE...
Page 90: Foreword
30 minutes that brightness stability is optimal, and follow strictly after panel specification. 2. PRODUCT PROFILE This display monitor unit is a color display monitor enclosed in PHILIPS styling cabinet which has an integrated tilt base. 2.1 LCD Priority : 1.
Page 91: Scanning Frequencies
HUDSON 8 Color gamut : >=72% (typ) Gate IC : Novatek NT39615C4H-C1477A Source IC : Novatek NT3929H-C1478A Response time : 5 ms 2.2 Scanning frequencies Hor. : 30 – 83 K Hz Ver.: 56 - 76 Hz < Video dot rate: 165 MHz Power input: 90-264 V AC, 50/60 ±...
Page 92: Interface
HUDSON 8 3.2 Interface 3.2.1 D-Sub Cable Length : 1.8 M +/- 50 mm Fix with monitor when packing, with transplant pin protective cover. Connector type : D-Sub male with DDC2B pin assignments. Blue connector thumb-operated jack screws Pin No. Signal Green/ SOG Blue...
Page 93 HUDSON 8 3.2.2 DVI Cable The input signals are applied to the display through DVI-D cable. Length. : 1.8 M +/- 50 mm Connector type : DVI-D male with DDC-2B pin assignments White connector thumb-operated jackscrews With transplant pin protective cover. Pin Assignment: Pin No.
Page 94: Timing Requirement
HUDSON 8 3.2.3 USB Cable (High Full Speed) Length : 1.8 M +/- 50 mm (Max.) Connector type : USB- B Plug (Input) USB- A Plug (Output) Pin Assignment: Pin No. Description VBUS Data+ Data- 3.3 Timing requirement Factory Preset mode definition : 1.
Page 95 HUDSON 8 44.75 960x720 48.363 VESA 1024x768 60.004 56.476 VESA 1024x768 70.069 60.023 VESA 1024x768 75.029 61.08 IBM XGA-2 1024x768 75.781 CVT 2.3MA 1280 x768 60.289 CVT 2.3MA 1280 x768 54.1 1152x864 63.851 VESA 1152x864 70.012 67.5 VESA 1152x864 68.7 MACINTOSH 1152x870 61.845...
Page 96: Horizontal Scanning
HUDSON 8 OSD Tree 3.4 Horizontal scanning Sync polarity : Positive or Negative Scanning frequency : 30 – 83 K Hz 3.5 Vertical scanning Sync polarity : Positive or Negative Scanning frequency : 56 - 76 Hz...
Page 97: Power Input Connection
In accordance with VESA DDC/CI and MCCS ver.2.0, the monitor should be workable with Protrait Display Tune at least. 3.12 EDID 1 User visible strings on .inf file Philips 200CW (20inch WIDE LCD MONITOR 200CW8) 2 Manufacturer ID ( EDID data) 3 Product ID, "xxxx" 4 codes MSB(byte 12): C0...
Page 98: Smart Contrast (Dynamic Contrast Ratio)
HUDSON 8 3.14 Smart contrast (Dynamic contrast ratio) Smart Contrast is a kind of dynamic backlight control. This function changes the panel backlight dynamically according to the frame brightness histogram. The contrast ratio has to be 3000:1. (typical) 3.15 Smart Image 3.15.1Smart Image OSD outlook 3.15.1.1 Position Pressing the “Smart Image”...
Page 99 HUDSON 8 3.15.1.5Linkage between Smart Image OSD and main OSD A. Settings within main OSD have linkage with Smart Image OSD. Brightness Contrast iii. Color Temperature B. Because each preset profiles will define default setting of these 3 parameters. Users can understand what is the value of that in preset profile by open the main OSD.
Page 100: Visual Characteristics
HUDSON 8 D. Economy i.Purpose: Adjust brightness level for reducing power consumptions ii.No optimization by Smart Image. iii.Design: 1. Brightness level set to 70%, a little higher brightness level than laptop PC, fine tune brightness level before DVT exit. 2. Color temperature set to 6500K. 3.
Page 101: Brightness Uniformity
HUDSON 8 4.4 Brightness uniformity Set contrast at 100% and turn the brightness at 100%. Apply the Fig 1, it should comply with the following formula: B_min X 100% >75% B_max Where B_max =Maximum brightness, B_min = Minimum brightness 4.5 Check Cross talk (S) Apply Pattern 2.
Page 102: Mechanical Characteristics
5.1 Cosmetic - Philips ID 5.2 Mechanical data files - ProE files required 5.3 Location of Philips logo - Per Philips make-up sheet 5.4 Gap between panel and front bezel < 1.2 (typ) mm 5.5 Location of Control icons - Per Philips Graphic sheet 5.6 Color for resin/paint -...
Page 103: Plastics Flammability
(bezel, back cover, base). Plastic resin type selection should be referred to “TY R83-2-9002-1”s. 5.11 Texture/Glossing of housing The texture area and texture no should follow Philips make-up sheet. The exterior surfaces shall have a uniform texture. Philips must approve the mold texturing.
Page 104: Transportation
HUDSON 8 5.16 Transportation Transportation standards refer to TYE-M0002. 5.16.1 Transportation packages Packaging and wrapping shall be sufficient to protect the product against damage or loss during shipment from the supplier to the destination specified in the purchase order. All packaging materials are subject to test and evaluation per TYE-M0002.
Page 105: Pallet/Container Loading
HUDSON 8 5.17 Pallet / Container loading Transportation standards refer to TYE-M0002 and UAW-0309. Air shipment - Sea container 20'(pallet/slip sheet) Sea container 40'(pallet/slip sheet) Sea container 40' High Cube (pallet/slip sheet) Truck shipment- Transportation request for all region except China/India A.
Page 106: Acceptance Test
Control II level AQL: 0.4 (major) 1.5 (minor) (Please also refer to annual quality agreement) Customer acceptance criteria: UAW0377/00 9. Philips’ Flat Panel Monitors Pixel Defect Policy Philips’ Flat Panel Monitors Pixel Defect Policy BRIGHT DOT DEFECTS ACCEPTABLE LEVEL MODEL...
Page 107 HUDSON 8 Fig 1: Measurement locations of Brightness Uniformity Fig 2: Cross talk pattern Gray level 46 (64 Gray level) Fig 3: Cross talk Pattern Center at Gray level 0 (Black)
Page 108 HUDSON 8 SEPARATE SYNC. VIDEO HORIZONTAL VIDEO VERTICAL COMPOSITE SYNC. VIDEO HORIZONTAL FIG-4 TIMING CHART -1...
Page 109: Regulatory Compliance
HUDSON 8 10. REGULATORY COMPLIANCE 10.1 Worldwide Regulatory SAFETY / EMC / ERGONOMICS / COUNTRY DOMAIN DOCUMENTS STANDARDS IEC60950-1:2001. Group -and national CB Report INTERNATIONAL differences of all countries listed in CB and CB certificate Bulletin No. 107A European Low Voltage Directives Declaration of Conformity 73/23/EEC and 93/68/EEC European Electromagnetic Compatibility...
Page 110 HUDSON 8 UL 60950-1: 2003 UL certificate FCC Part 15 Class B FCC ID grant Energy Star EPA registration CSA C22.2 No 60950 CSA certificate CANADA ICES-003 issue 3 Statement on label MEXICO NOM-019-SCFI-1994 NOM certificate Korean Safety Control law IEC 60950 eK certificate KOREA Regulations laws: EMI 1996-78, 80.
Page 111: Emc Requirements
10.2 EMC Requirements Supplier DVT EMI test result must be submitted prior to DVT samples delivery, and PVT EMI test result must be submitted again prior to PVT samples delivery, which also has to meet Philips' immunity testing specification. 10.3 RoHS Restriction on the use of certain hazardous substances.
Page 112 4. When the HV circuitry is operating properly there is no possibility of an x- tube must be the same type as the original, including suffix letter, or a Philips radiation problem. High voltage should always be kept at the manufacturer's approved type.
