GE JSS28 Installation Instructions Manual

Installation
Instructions
Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: www.GEAppliances.com

BEFORE YOU BEGIN

Read these instructions completely
and carefully.
IMPORTANT
•
instructions for local inspector's use.
IMPORTANT
•
governing codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these
instructions for future reference.
• Skill level – Installation of this appliance
requires basic mechanical skills.
• Completion time – 1 to 3 hours
• Proper installation is the responsibility of
the installer.
• Product failure due to improper installation
is not covered under the Warranty.
WARNING
be properly grounded.
FOR YOUR SAFETY:
CAUTION:
remove house fuse or open circuit breaker
before beginning installation. Failure to do so
could result in serious injury or even death.

TOOLS YOU WILL NEED

"
Drill with 1/8 Bit Straight Edge
Hand or Saber Saw
31-10596-1
(11-04 JR)
— Save these
— Observe all
— This appliance must
— For Personal Safety
Safety Glasses
Tape Measure
Pencil
30" Electric
Slide-In Range
JSS28, JSP39
ANTI-TIP DEVICE
WARNING
of tipping, the appliance must be secured by
properly installed Anti-Tip bracket packed
with this appliance.
If the Anti-Tip device supplied with the range
does not fit this application, use the universal
Anti-Tip device WB2X7909.
If you pull the range out and away from the
wall for any reason, make sure the Anti-Tip
bracket is engaged when the range is pushed
back against the wall.
FOR YOUR SAFETY:
All rough-in and spacing dimensions must be
met for safe use of your range. Electricity to
the range can be disconnected at the outlet
without moving the range if the outlet is in
the preferred location (remove lower drawer).
To reduce the risk of burns or fire when
reaching over hot surface elements, cabinet
storage space above the cooktop should be
avoided. If cabinet storage space is to be
provided above the cooktop, the risk can
be reduced by installing a range hood that
sticks out at least 5" beyond the front of the
cabinets. Cabinets installed above a cooktop
must be no deeper than 13".
Be sure your appliance is properly installed
and grounded by a qualified technician.
1
— To reduce the risk
WARNING
• All ranges can tip
• Injury to persons could result
• Install Anti-Tip bracket packed
with range
• See Installation Instructions
—
