- Page 1 LYNX Touch L5200/L7000 Series Security Systems Home Automation Guide 800-16091 12/13 Rev. A...
-
Page 2: Table Of Contents
Home Automation Table of Contents Z-Wave Programming ..............................3 General Information ..............................3 Including Z-Wave Devices ............................5 Including Light Switches or Outlet Modules ......................6 Including Door Locks ..............................6 Including Thermostats and Water Valves ......................... 6 Thermostat Energy Saving Mode ..........................6 Edit and Exclude/Delete Z-Wave Devices ........................ -
Page 3: Z-Wave Programming
Z-Wave® Programming General Information The Honeywell LYNX Touch L5200 and L7000 controls are security enabled Z-Wave® devices. The controls feature Z-Wave technology that is designed to automate devices in a home control network. The control allows you to easily add and control multiple devices with the press of a button and supports Z-Wave Network Wide Inclusion (NWI) Mode. - Page 4 Home Automation Z-Wave® Programming Ready To Arm Button Function Switches Provides access to the Switches Screen Switches Water Valves Thermostats Provides access to the Thermostats Screen Locks Provides access to the Locks Screen Thermostats Garages Provides access to control Garage Door operation. Water Valves Provides Access to control Water Valve operation.
-
Page 5: Including Z-Wave Devices
Home Automation Z-Wave® Programming Ready To Arm - Chime Button Function View Enrolled View Z-Wave device information: System Index/name, View Enrolled View Enrolled Devices Secured or Non-Secured, device type, device ID, Devices Controllers manufacturer, node number Pri. Controller Shift Reset Controller View Enrolled View Controller Information: Controller role: (Primary to Secondary... -
Page 6: Including Light Switches Or Outlet Modules
IMPORTANT: Honeywell is not responsible for property damages due to improper setting of the thermostat modes. Notes: • Some thermostats do not update temperature status automatically (i.e., Wayne Dalton). -
Page 7: Edit And Exclude/Delete Z-Wave Devices
Home Automation Z-Wave® Programming Thermostat Energy Saving Mode Step Action At the Home Screen select the “Automation” icon. At the Automation Screen, select “Thermostats”. Select the desired Thermostat from the displayed list. At the Thermostat control screen select the “Saving Off” button OR “Saving On” to activate or deactivate the thermostat’s Energy Saving Schedule Function when a heating or cooling operation is selected. -
Page 8: Z-Wave Operation
Home Automation Z-Wave® Programming ® Z-Wave Operation Scenes are used to control a single or group of devices, by turning them OFF, ON, ON to a preset lighting level, temperature or mode, and/or to lock/unlock a door. The LYNX Touch has 20 Scenes which may each be configured to control up to 10 devices each. -
Page 9: Scenes
Home Automation Scenes General Information Scenes are used to control a single or group of devices together, turning them OFF, ON, ON to a preset lighting level, temperature or mode, or lock/unlocked. The LYNX Touch has 20 Scenes which may each be configured with up to 10 devices each. -
Page 10: Editing/Deleting A Scene
Home Automation Scenes Set the desired options. Typical operations are shown below: Switches/Outlets Set Switch/Outlet On Set Switch/Outlet Off Dim Switch (-/+) Thermostats Set Temperature Mode (Heat, Cool, Off) Set Fan Mode (Auto, On, Circulate) Select Hold Mode (Temperature hold) Setback Select Energy Saving Mode Locks... -
Page 11: Running A Scene
Home Automation Scenes Ready To Arm 3. Select the scene you wish to edit or delete. Scene 1 Scene 2 4. Select the “Edit” or “Delete” button. Burglary Alarm CO Alarm 5. If “Edit” was selected, the system advances to the Scene. Edit as Scene 3 Scene 4 required and proceed to step 6. -
Page 12: Schedules
Home Automation Schedules General Information The Schedules Feature can be used to program the system to automatically perform certain functions (i.e.; automatically arming the system in Stay mode and activating output [Z-Wave] devices) at a scheduled time, day of the week or month, as applicable. Programming a Scheduled Function Ready To Arm 1. -
Page 13: Editing A Scheduled Function
Home Automation Schedules 7. Program the following options based upon the Frequency selected in step 6: Once Date/Start Time/End Time Daily Start Time/End Time Weekday Start Time/End Time Weekly Start Time/End Time/Day of the Week, Monthly Start Time/End Time/Day of the Month 8. -
Page 14: Rules
Home Automation Rules General Information Up to 40 rules can be programmed. Rules 1 through 20 are used for Triggers, Z-Wave Scenes and Follow-Me Messages. Rules 21 through 40 are used for Z-Wave Scenes and for E-mail notification but are only accessible through TotalConnect Service. - Page 15 Home Automation Rules Ready To Arm Select the “Name” key and then enter up to 13 characters of text on the displayed keyboard to assign a name to the Rule. 123!@# Note: Select the “ABC…” key to switch the keyboard between upper/lower case or the “123!@#”...
- Page 16 Home Automation Rules Ready To Arm Select “Stop Zone Type” OR “Zone Type Restore” (if Scene was selected in the Type field). The system displays the same Name options as the previous step. Type Action Note: If a Rule is being used to trigger a Z-Wave door lock, when the system is Armed Stay or Armed Away, it is recommended that “End of Exit Delay”...
-
Page 17: Editing Or Deleting Rules
Home Automation Rules Editing or Deleting Rules Ready To Arm 1. At the Rules Programming Screen, select the Rule that you wish to edit or delete. Device 1 Device 2 System Armed Follow Me Note: Rules 21-40 are only accessible through TotalConnect Service. Device 3 Device 4 2. -
Page 18: Garage Door Opener Operation
Home Automation Garage Door Opener Operation General Information If your system has been equipped with a 5877 Relay Receiver and 5822T Tilt Sensor or Door/Window Transmitter (i.e.; 5616), it can be used to remotely operate and/or view the status of up to three Garage Doors. The System can be armed when the garage door is open, and once the garage door has been closed, the zone will be monitored as part of the system without providing burglary protection. -
Page 19: Operate Garage Door From Lynx Touch Control Panel
Home Automation Garage Door Opener Operation Button or Icon Function Ready To Arm Edit Used to modify description of Garage Door Close in Provides access to keypad used to set a specific period of time (up to 12 hours and 59 minutes) before an open garage door closes automatically. -
Page 20: Advanced Z-Wave Operations
Home Automation Advanced Z-Wave Operations View Enrolled Z-Wave Devices or Controllers To View a list of the enrolled devices perform the following: Step Action At the Dashboard screen or Security Home Screen select the “Automation” icon. At the Automation Screen, select “Tools”. At the “Device Management”... -
Page 21: Z-Wave Glossary
Home Automation Z-Wave® Glossary Controller The Primary Controller is the main device used to set up and control your Z-Wave network. There can only be one primary controller and it must be used to add or delete devices. A primary controller can be a portable device like a hand-held remote, a static controller (permanently installed and never moved), a Z-wave enabled PC or a Z-Wave enabled Ethernet router/bridge. -
Page 22: Z-Wave Compatibility
Leviton/ViziaRF+ switches Kwikset Smartcode Deadbolt Lock Leviton/ViziaRF+ dimmers Thermostats Leviton/ViziaRF+ plug in modules Honeywell ECC GE wireless lighting control dimmers Wayne Dalton Zwave Thermostat GE wireless lighting control Switches Trane Zwave Thermostat GE wireless lighting control plug in lamp modules... -
Page 23: Important Notes
Home Automation Important Notes Wireless Range This device complies with the Z-Wave® standard of open-air, line of sight transmission distances of 100 feet. Actual performance in a home depends on the number of walls between the controller and the destination device, the type of construction and the number of Z-Wave enabled devices installed in the control network. - Page 24 Z-Wave devices are identified by the Z-Wave logo and can be purchased from your local retailer. Z-Wave and Z-Wave Plus are registered trademarks of Sigma Designs and its subsidiaries in the United States and other countries 2013 Ê800-16091/Š 800-16091 12/13 Rev. A...
