Ricoh GXe3300N Installation Manual

Hide thumbs Also See for GXe3300N:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
Ricoh GXe3300N
ICC Profile

INSTALLATION GUIDE

MAC OS X

CAUTION
DO NOT INSTALL THE RICOH (OEM) INKS THAT WERE PROVIDED WITH THE PRINTER.
DO NOT POWER ON THE PRINTER BEFORE INSTALLING SAWGRASS SUBLIJET-R INK CARTRIDGES.
DURING DOWNTIME, IT IS HIGHLY RECOMMENDED TO LEAVE THE PRINTER POWERED ON TO
ALLOW THE RICOH AUTOMATIC MAINTENANCE UTILITIES TO KEEP THE PRINT HEAD NOZZLES
CLEAR.

Advertisement

Table of Contents
loading

Related Manuals for Ricoh GXe3300N

Summary of Contents for Ricoh GXe3300N

  • Page 1: Installation Guide

    MAC OS X CAUTION DO NOT INSTALL THE RICOH (OEM) INKS THAT WERE PROVIDED WITH THE PRINTER. DO NOT POWER ON THE PRINTER BEFORE INSTALLING SAWGRASS SUBLIJET-R INK CARTRIDGES. DURING DOWNTIME, IT IS HIGHLY RECOMMENDED TO LEAVE THE PRINTER POWERED ON TO ALLOW THE RICOH AUTOMATIC MAINTENANCE UTILITIES TO KEEP THE PRINT HEAD NOZZLES CLEAR.

  • Page 2: Operating System

    Ricoh GXe3300N ICC Profile — Installation Guide Mac OS-X Operating System Before you begin, you will need to verify what version of Operating System you are using on your Mac. This is important when deciding which drivers to download. You should only download those drivers, which are compatible with your version of Operating System.
  • Page 3 (Continued; Page 3:14) Ricoh (OEM) Printer Driver Installation The following instructions will demonstrate how to install the Ricoh (OEM) printer driver on Mac OS X. Before installing the SubliJet-R ICC Profile, you will need to install the Ricoh (OEM) printer driver.
  • Page 4 FIGURE 3 Finally, locate the RPCS Raster Driver for your Operating System and click the Download Icon (see FIGURE 4). The Ricoh (OEM) printer driver should now begin downloading to your computer. FIGURE 4 Once the driver download has completed, click the download icon in the bottom right corner of your desktop (see FIGURE 5 >...
  • Page 5 Ricoh GXe3300N — Mac OS-X SubliJet-R ICC Profile - Installation Guide (Continued; Page 5:14) Click Continue to allow the program to determine if the software can be installed (see FIGURE 7). FIGURE 7 In the Introduction window, click Continue (see FIGURE 8).
  • Page 6 Ricoh GXe3300N — Mac OS-X SubliJet-R ICC Profile - Installation Guide (Continued; Page 6:14) If you agree with the terms of the Software License Agreement, click Agree (see FIGURE 10). FIGURE 10 10.) In the Destination window, select the Hard Drive on which the printer driver will be installed and click Continue (see FIGURE 11).
  • Page 7 ON to allow the Ricoh Automatic Main- tenance Utilities to keep the print head nozzles clear. The Ricoh GelSprinter has been engineered to perform automatic maintenance at various times in an effort to keep the print head nozzles in top condition. If this maintenance cannot be automatically performed, it is possible that the nozzles may suffer permanent effects.
  • Page 8 The following instructions will demonstrate how to install the SubliJet-R GXe3300N ICC Profile on Mac OS X. In this example, we show how to download and install the GXe3300N ICC Profile on systems with 10.6.4 OS. There- fore, if your printer model or OS version is different, you will need to substitute your printer model or OS version for every instance that GXe3300N or 10.6.4 is used.
  • Page 9 On the SubliJet-R ICC Profile Download page, scroll down to ICC PROFILES FOR MAC OS and select the link that corresponds with your printer model (see FIGURE 2). The SubliJet-R GXe3300N ICC Profile should now begin downloading to you computer.
  • Page 10 Ricoh GXe3300N — Mac OS-X SubliJet-R ICC Profile - Installation Guide (Continued; Page 10:14) Click Continue to allow the program to determine if the software can be installed and to begin the installation process (see FIGURE 5). FIGURE 5 Before installation can begin, you will need to register the SubliJet-R ICC Profile. A Registration...
  • Page 11 Ricoh GXe3300N — Mac OS-X SubliJet-R ICC Profile - Installation Guide (Continued; Page 11:14) On the Product Registration web page, fill in the required information and click Submit when complete (see FIGURE 7). Your Registration Code will now be sent to the e-mail address used during registration.

  • Page 12: Finished (See Figure

    Ricoh GXe3300N — Mac OS-X SubliJet-R ICC Profile - Installation Guide (Continued; Page 12:14) You should receive the following screen informing you that registration completed successfully (see FIGURE 9). Click OK to continue. FIGURE 9 10.) In the Introduction window, click Continue (see FIGURE 10).

  • Page 13: If You Agree With The Terms Of The Software License Agreement, Click Agree (See Figure

    Ricoh GXe3300N — Mac OS-X SubliJet-R ICC Profile - Installation Guide (Continued; Page 13:14) 12.) If you agree with the terms of the Software License Agreement, click Agree (see FIGURE 12). FIGURE 12 13.) In the Destination window, click Install to place the SubliJet-R ICC Profile in the specified folder (see FIGURE 13).
  • Page 14 (Continued; Page 14:14) 14.) You should receive the following screen informing you that installation has completed successfully. Click Close to finalize installation of the SubliJet-R GXe3300N ICC Profile (see FIGURE 14). FIGURE 14 Congratulations! The SubliJet-R GXe3300N ICC Profile has successfully been installed. Please proceed to the Print Setup Guide that corresponds with your version of graphics software.
