LCCS VIDEO MONITOR
TM-L450TU
-
+
VO LU
M E( C
H AN N
EL )
TV
VI D EO
A
VI D EO
B
M EN
U
BL U E
C H EC
K
SI ZE
SE LE
C T
PO W
ER
For Customer Use:
Enter below the Serial No. which is located on the
bottom of the cabinet. Retain this information for future
reference.
TM-L450TU
Model No.
:
Serial No.
:
Contents
INSTRUCTIONS
Page
2
6
6
8
9
10
10
11
12
12
13
14
14
15
16
16
17
18
20
21
Advertisement
Table of Contents
Related Manuals for JVC TM-L450TU
Summary of Contents for JVC TM-L450TU
-
Page 1: Table Of Contents
LCCS VIDEO MONITOR TM-L450TU – VO LU M E( C H AN N EL ) VI D EO VI D EO M EN BL U E C H EC SI ZE SE LE PO W For Customer Use: Enter below the Serial No. which is located on the bottom of the cabinet. -
Page 2: Important Safety Precautions
Thank you for purchasing this JVC LCCS video monitor. Before using, read and follow all instructions carefully to take full advantage of the monitor’s capabilities. Retain these instructions for future reference. * LCCS = Liquid Crystal Color Shutter IMPORTANT SAFETY PRECAUTIONS CAUTION: To reduce the risk of electric shock. - Page 3 IMPORTANT SAFEGUARDS CAUTION: Please read and retain for your safety. Electrical energy can perform many useful functions. This Appliance has been engineered and manufactured to assure your personal safety. But improper use can result in potential electrical shock or fire hazards. In order not to defeat the safeguards incorporated in this Appliance, observe the following basic rules for its installation, use and servicing.
- Page 4 7 An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
- Page 5 14 An Appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the Appliance and cart combination to overturn. SERVICE 15 Unplug this Appliance from the wall outlet and refer servicing to qualified service personnel under the following conditions: A.
-
Page 6: Controls And Features
CONTROLS AND FEATURES PRODUCT: FRONT & RIGHT VIEW FRONT VIEW – VOLUME(CHANNEL) VIDEO A VIDEO B MENU BLUE SIZE POWER – CHECK SELECT VOLUME(CHANNEL) VIDEO A VIDEO B MENU BLUE SIZE POWER CHECK SELECT RIGHT VIEW PHONE... - Page 7 FRONT VIEW Carrying Handle Used to carry the monitor. Can be removed when the monitor is mounted in a rack. Screen A removable shield protecting the liquid crystal shutter is provided. Feet Can be removed when the monitor is mounted in a rack.
-
Page 8: Rear View
CONTROLS AND FEATURES PRODUCT: REAR VIEW AC IN VHF/UHF DC IN 12V ANT. IN VIDEO A VIDEO B AUDIO IN AC IN (AC Power Input) Terminal Power input terminal. Connect the provided power cord to the terminal. AC Adapter Can be removed when a commercial DC power supply (DC 12 V) is used. -
Page 9: Basic Connection Examples
BASIC CONNECTION EXAMPLES Before connecting your system, make sure that all units are turned off. If you are not connecting any equipment to one of the bridged video output (VIDEO OUT) terminals, be sure NOT to connect any cables to the terminal as this will cause the terminating resistance switch to open (auto terminate function). -
Page 10: Preparing Power Supply
PREPARING THE POWER SUPPLY Precautions Use one of the following power supplies: AC power supply (120 V AC, 60 Hz): Use the provided power cord. DC power supply (12 V DC): Use any brand of external DC battery pack (commercial) or other DC power supply. -
Page 11: Outdoor Usage (Dc Power Supply)
OUTDOOR USAGE (DC Power Supply) Connect any commercial brand of external DC battery pack or other DC power supply to DC IN 12 V (DC power input) terminal with the exclusive power cord. Connection example: using an external DC battery pack Before performing the following, be sure to unplug the power cord. -
Page 12: Basic Operations
BASIC OPERATIONS MONITORING THE PICTURE – VOLUME(CHANNEL) Precautions Connect video components properly to the connection terminals on the rear of the monitor. ( and 9) Press the power button to turn the power ON. The power indicator lights in green. POWER Select a video input with the VIDEO A or VIDEO B button. -
Page 13: Watching Tv
WATCHING TV 3, 4 – VOLUME(CHANNEL) Precautions Connect the TV antenna cable. ( Set TV channels. ( pages 14, 15 and 17) Press the power button to turn the power ON. The power indicator lights in green. POWER Press the TV button to select The TV button blinks in green for about 8 seconds. -
Page 14: Settings And Adjustments
SETTINGS AND ADJUSTMENTS BASIC MENU OPERATION 2, 3 – VOLUME(CHANNEL) Press the MENU button to select the desired item to adjust (set). MENU The selected item changes each time the MENU button is pressed. The currently selected item is displayed on the monitor. * Some items may not be displayed depending on which input mode is –... -
Page 15: Menu Contents
MENU CONTENTS You can adjust (set) the following items on the menu screen. Each adjusted (set) value is automatically memorized. The values inside [ ] are the factory presets. CONTRAST (Picture Contrast) Adjusts the picture contrast. Decreasing the value lowers the contrast, and increasing the value raises it. -
Page 16: Screen Size Adjustments
SETTINGS AND ADJUSTMENTS – VOLUME(CHANNEL) SCREEN SIZE ADJUSTMENTS Adjust the screen size to get the desired picture. Press the SIZE SELECT button. SIZE SELECT The screen size changes in the following order each time the SIZE SELECT button is pressed. OVER 16:9 OVER... -
Page 17: Setting Tv Channels
Adjust CHROMA (picture chroma) or PHASE (picture phase). When an NTSC color bar signal is input: 1 Adjust CHROMA (picture chroma) so that the blue bars on the left and right side of the screen have the same brightness. 2 Adjust PHASE so that the two blue bars at the center of the screen have the same brightness. -
Page 18: Troubleshooting
TROUBLESHOOTING Before requesting repair, check the following points. Problems No power supply. Is the power plug loosened or disconnected? Is the battery charged properly? (when a DC power supply is used) No picture with the Is the signal output from the connected power on. - Page 19 Problems The screen size is Is the screen size set to UNDER? small. There is no TV Is an antenna connected to the reception. monitor? Was the monitor moved to an area that receives different channels after CH SEARCH START (initiate channel search) was performed? There may not be a solution to the following problems, although adjusting the antenna or taking measures against interfering equipment may improve the situation somewhat.
-
Page 20: Characteristics Of Lccs Video Monitor System
CHARACTERISTICS OF LCCS VIDEO MONITOR SYSTEM PRINCIPLE BEHIND LCCS VIDEO MONITOR OPERATION The LCCS Video Monitor is a combination of a black-and-white cathode-ray tube and liquid crystal color shutter (LCCS), which are used together to reproduce color images. The video signal input to the monitor is demodulated into RGB primary color signals which are then stored in the field memory. -
Page 21: Specifications
SPECIFICATIONS Type : LCCS video monitor Color System : NTSC/PAL RF Reception : U.S.A. Channels VHF: 2 – 13, UHF: 14 – 69 Picture Tube : 4.5" measured diagonally, black and white Effective Screen Size : Width : 3-3/4" (94.2 mm) Height : 2-13/16"... - Page 22 SPECIFICATIONS (cont’d) Dimensions Unit : inch (mm) 11-1/2 (291.8) 9-7/8 (250) 5-3/4 (146) – VOLUME(CHANNEL) VIDEO A VIDEO B MENU BLUE SIZE POWER CHECK SELECT...
