2 2 - - 1 1 1 1 C C H H A A N N N N E E L L 5 5 V V A A L L I I D D I I T T Y Y / / L L A A T T C C H H E E D D / / L L A A T T C C H H E E D D R R E E S S E E T T W W I I T T H H I I G G N N I I T T I I O O N N / / 3 3 0 0 - - S S E E C C O O N N D D T T I I M M E E D D / / 6 6 0 0 - - S S E E C C O O N N D D T T I I M M E E D D / / 9 9 0 0 - - S S E E C C O O N N D D
T T I I M M E E D D : : Channel Four can be programmed for these output configurations. The unit is set to the default validity output.
To change the configuration, use the two-chirp setting to toggle through the different configurations.
m m e e n n u u # # 3 3 - - r r e e m m o o t t e e s s t t a a r r t t o o p p t t i i o o n n s s
3 3 - - 1 1 E E N N G G I I N N E E C C H H E E C C K K I I N N G G O O N N / / O O F F F F : : In the default setting the remote start will monitor either the vehicle's tach wire
or voltage depending on the programming of feature 3-2. If programmed OFF the vehicle will crank for the pro-
grammed crank time (feature 3-5) and will not verify with tach or voltage that the car is running. In the OFF
setting, if the vehicle fails to start, the ignition can stay on for the entire run duration. Using tach or voltage
check is always recommended if possible.
3 3 - - 2 2 C C H H E E C C K K I I N N G G T T Y Y P P E E T T A A C C H H / / V V O O L L T T A A G G E E : : Selects the method of engine monitoring. If set to TACHOMETER the unit will
reference the learned tach signal to disengage the starter. In addition it will monitor the RPM and shut down if
the engine RPM is too high or too low. When set to VOLTAGE, the unit will crank the starter for the programmed
time and then attempt to sense that the engine is running by detecting an increase in voltage. The threshold
for the voltage check is selectable in feature 3-6.
3 3 - - 3 3 R R U U N N T T I I M M E E 1 1 2 2 , , 2 2 4 4 , , 6 6 0 0 M M I I N N U U T T E E S S : : Selects the time in minutes that the system will operate the engine
until the system "times out". This is the maximum operation period and the system may be shut down
using a shutdown at any time. Using the Bitwriter, the run time can be programmed for any duration from 1-60
minutes.
3 3 - - 4 4 P P A A R R K K I I N N G G L L I I G G H H T T S S F F L L A A S S H H I I N N G G / / C C O O N N S S T T A A N N T T : : In the default setting, the unit will flash the vehicle's parking lights
(if connected) while remote started. The constant setting will turn the parking lights on solid for the entire run
duration.
3 3 - - 5 5 C C R R A A N N K K T T I I M M E E 0 0 . . 6 6 / / 0 0 . . 8 8 / / 1 1 . . 0 0 / / 1 1 . . 2 2 / / 1 1 . . 4 4 / / 1 1 . . 6 6 / / 1 1 . . 8 8 / / 2 2 . . 0 0 / / 4 4 . . 0 0 S S E E C C O O N N D D S S : : If the unit is programmed for no engine check-
ing or voltage sense, the crank time must be set to the appropriate duration. The default setting is 0.6 second.
If a different crank time is desired, select feature 3-5 and select either 0.6 second by using the one-chirp setting
or toggle through the higher settings by using the two-chirp settings.
3 3 - - 6 6 V V O O L L T T A A G G E E C C H H E E C C K K H H I I / / L L O O W W : : This feature only functions when programmed for voltage sense. Some vehicles have
many accessories, which are turned on when remote started. In these vehicles, the variation of voltage between
the engine off and the car running is very small and the remote start unit may "think" the vehicle has not started.
This can cause the remote start to shut-down after the car has been started. If this happens program this feature
to the LOW position.
3 3 - - 7 7 S S H H O O R R T T R R U U N N / / T T U U R R B B O O : : When the
vehicle will start for the programmed short run time. The factory default is 1 minute.
5 5 0 0
and
buttons on the transmitter are pressed simultaneously, the
