s s e e c c o o n n d d a a r r y y h h a a r r n n e e s s s s ( ( H H 2 2 ) ) w w i i r r e e c c o o n n n n e e c c t t i i o o n n g g u u i i d d e e
H H 2 2 / / 1 1 L L I I G G H H T T B B L L U U E E ( ( - - ) ) 2 2 0 0 0 0 m m A A 2 2 n n d d u u n n l l o o c c k k o o u u t t p p u u t t
This wire provides a second unlock output for progressive locks. Refer to document 1041— Door Locking System
Wiring Guide for specific applications.
H H 2 2 / / 2 2 W W H H I I T T E E / / B B L L A A C C K K 2 2 0 0 0 0 m m A A ( ( - - ) ) p p r r o o g g r r a a m m m m a a b b l l e e c c h h a a n n n n e e l l 5 5 o o u u t t p p u u t t
This wire provides 200 mA programmable output. (See Feature Descriptions section of this guide.)
I I M M P P O O R R T T A A N N T T ! ! Never use this wire to drive anything but a relay or a low-current input! This tran-
sistorized output can only supply 200 mA, and connecting directly to a solenoid, motor, or other
high-current device will cause the module to fail.
H H 2 2 / / 3 3 V V I I O O L L E E T T / / B B L L A A C C K K 2 2 0 0 0 0 m m A A ( ( - - ) ) p p r r o o g g r r a a m m m m a a b b l l e e c c h h a a n n n n e e l l 4 4 o o u u t t p p u u t t
This wire provides 200 mA programmable output. (See Feature Descriptions section of this guide.)
I I M M P P O O R R T T A A N N T T ! ! Never use this wire to drive anything but a relay or a low-current input! This tran-
sistorized output can only supply 200 mA, and connecting directly to a solenoid, motor, or other
high-current device will cause the module to fail.
H H 2 2 / / 4 4 G G R R E E E E N N / / W W H H I I T T E E ( ( - - ) ) f f a a c c t t o o r r y y a a l l a a r r m m r r e e a a r r m m
This wire sends a negative pulse every time the remote start shuts down or the doors are locked. This can be used
to pulse the arm wire of the vehicle's factory anti-theft device. Use a relay to send a (-) or (+) pulse to the arm wire.
H H 2 2 / / 5 5 G G R R E E Y Y / / B B L L A A C C K K ( ( - - ) ) d d i i e e s s e e l l w w a a i i t t - - t t o o - - s s t t a a r r t t b b u u l l b b i i n n p p u u t t
Connect this wire to the wire in the vehicle that sends the signal to turn on the WAIT-TO-START bulb in the dash-
board. In most diesels the wire is negative (ground turns on the bulb) and the GRAY/BLACK wire can be directly
connected to the wire in the vehicle. If the vehicle uses a positive wire (12V to turn on the bulb) a relay must
be used to change the polarity. (See Finding the Wires You Need section of this guide.) Here are some common
colors of this wire:
■ Chevrolet and GMC trucks - Light blue or dark blue
■ Ford Trucks - Black/pink
■ Dodge Ram Trucks - Orange/black or black/orange
2 2 2 2
© 2005 Directed Electronics, Inc. Vista, CA
