Telephone Equipment
KX-TG2220BXB
KX-TG2220BXF
KX-TG2220BXS
KX-TGA226BXB
KX-TGA226BXF
KX-TGA226BXS
2.4GHz Digital Cordless Phone
Black Version
Blue Version
Silver Version
(for Asia, Middle Near East and Other areas)
