Page 1: Spray Gun
® Spray Gun IRLESS ERVICE PERATION ANUAL AIRLESSCO Prolight Contractor Series Flat Handle Spray Gun 001-664 OCT 08... -
Page 2: Table Of Contents
NOTE - Identifies essential procedures or extra information. All Service Procedures to be performed by an Authorized Airlessco Service Center ONLY. NO MODIFICATIONS or alterations of any AIRLESSCO Equipment or part is allowed. -
Page 3: Introduction Safety Warnings
NEVER use Airlessco tip guard on other attachments. • Tell the doctor you suspect an injection injury. Airlessco’s tip guard is designed for use with standard • Tell him what kind of material you were spraying with spray tips only. When using other than standard spray tips,... -
Page 4: Pressure Relief Procedure
WHENEVER YOU STOP SPRAYING, OR WHEN YOU ARE INSTRUCTED TO RELIEVE THE PRESSURE. RELIEVING PRESSURE WILL BE DIFFERENT FOR EVERY BRAND OF AIRLESS PAINT SPRAYER, REFER TO THE MANUAL THAT CAME WITH YOUR MACHINE TO RELIEVE PRESSURE. FOR AIRLESSCO BRANDED MACHINES, USE THE PROCEDURE BELOW. -
Page 5: Airless Spray Gun Operation
AIRLESS SPRAY GUN OPERATION SPRAY FIG. 1 Attach spray gun to airless unit and tighten fittings securely. Set the gun safety latch. (Also may be called gun safety lock, or trigger lock) TRIGGER LOCK * The gun safety latch should always be set when the gun is not being triggered. -
Page 6: Airless Spray Technique
SPRAY TECHNIQUE Good Spray Gun Technique is at the core of any spray If you are not familiar with spraying techniques, we paint operation. Operator skill and efficiency is as important recommend that you study this section of your manual and as good equipment and good paint. -
Page 8: Tip Selection Guide
TIP SELECTION GUIDE Your airless spray gun can be used to spray a wide REV-TIP FOR STRIPING 562-XXXST range of coatings. These coatings fall into three general FAN WIDTH catagories: architectural/industrial, line striping, and fine (6” FROM SURFACE) ORIFICE SIZE (INCHES) finishing. - Page 9 TIP SELECTION GUIDE SPRAY TIP - ORIFICE SIZE (INCHES) REV-TIP for Painting (560-XXX) Fan Width (12” from surface) .029 .007 .009 .011 .013 .015 .017 .019 .021 .023 .025 .027 .031 .035 .039 .041 102-152 152-203 8-10 203-254 10-12 254-305 12-14 305-356 14-16...
-
Page 10: Airless Spray Gun Assembly
AIRLESS SPRAY GUN FIG. 5 PARTS LIST FIGURE 5 Item No. Part No. Description 120-530 Gun Seat Assembly 120-535 Gasket-Seat 120-520 Needle Assembly 120-529 Gun Seat Adapter 120-562 Trigger Guard 120-539 Trigger Pin 120-109 Gun Head 120-540 Actuator Pin (2) 120-536 Gun Plate 120-038... -
Page 11: Troubleshooting & Repairs
TROUBLESHOOTING & REPAIRS DEFECTS CAUSE CORRECTION Coarse spray Low pressure Increase the pressure Excessive fogging High pressure Reduce the pressure to satisfactory pattern distribution (overspray) Material too thin Use less thinner Patten too wide Spray angle too large Use smaller spray angle tip Pattern too narrow Spray angle too small Use wider spray angle tip... -
