DS7400XiV4-EXP | Wireless Reference Guide | 5.0
Table 30: Address 0483 to 0538, Zone-to-Address Cross Reference
Zones
Address
Zones 137 & 138
0483
Zones 139 & 140
0484
Zones 141 & 142
0485
Zones 143 & 144
0486
Zones 145 & 146
0487
Zones 147 & 148
0488
Zones 149 & 150
0489
Zones 151 & 152
0490
Zones 153 & 154
0491
Zones 155 & 156
0492
Zones 157 & 158
0493
Zones 159 & 160
0494
Zones 161 & 162
0495
Zones 163 & 164
0496
Zones 165 & 166
0497
Zones 167 & 168
0498
Zones 169 & 170
0499
Zones 171 & 172
0500
Zones 173 & 174
0501
5.2
Program a Zone
Zone Programming (Program Addresses 0167 to 0278) is different when programming keyfobs. Data
Digit 1 is always 0, and Data Digit 2 can only be 1, 2, 3, or 4.
Keyfob function programming starts at Program Address 0167.
Hint: Zone number + 30 = The Program Address (for example: Zone 137 + 30 = Program Address 0167)
•
Addresses: 0167 to 0278
•
Data Digit:
•
Data Digit 1: Must = 0
•
Data Digit 2: ____ (refer to Table 31)
•
Selections: 0 to 4
Bosch Security Systems | 6/05 | 4998154962B
Zones
Zones 175 & 176
Zones 177 & 178
Zones 179 & 180
Zones 181 & 182
Zones 183 & 184
Zones 185 & 186
Zones 187 & 188
Zones 189 & 190
Zones 191 & 192
Zones 193 & 194
Zones 195 & 196
Zones 197 & 198
Zones 199 & 200
Zones 201 & 202
Zones 203 & 204
Zones 205 & 206
Zones 207 & 208
Zones 209 & 210
Zones 211 & 212
Table 31: Zone Programming (Addresses 0167 to 0278,
Data Digit 2)
Select Options
Single Partition No Force Arming Allowed
Single Partition Force Arming is Allowed
All Partitions No Force Arming Allowed
All Partitions Force Arming is Allowed
Adding Keyfobs
Address
Zones
0502
Zones 213 & 214
0503
Zones 215 & 216
0504
Zones 217 & 218
0505
Zones 219 & 220
0506
Zones 221 & 222
0507
Zones 223 & 224
0508
Zones 225 & 226
0509
Zones 227 & 228
0510
Zones 229 & 230
0511
Zones 231 & 232
0512
Zones 233 & 234
0513
Zones 235 & 236
0514
Zones 237 & 238
0515
Zones 239 & 240
0516
Zones 241 & 242
0517
Zones 243 & 244
0518
Zones 245 & 246
0519
Zones 247 & 248
0520
Selections
for Data
Digit 2
1
2
•
•
EN | 21
Address
0521
0522
0523
0524
0525
0526
0527
0528
0529
0530
0531
0532
0533
0534
0535
0536
0537
0538
3
4
•
•
