INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MEMORY CAMERA
VIDEOCÁMARA CON MEMORIA
GZ-MS130U
Please read the instruction manual prior to
connecting or operating this product.
Por favor, lea el manual de instrucciones
antes de conectar u operar este producto.
For more details on the
operations, refer to the
GUIDEBOOK in the supplied
CD-ROM.
Para obtener más
información sobre las
operaciones, consulte la
GUÍA incluida en el CD-ROM
suministrado.
LYT2019-001A-M
EN
Dear Customer
Thank you for purchasing
this memory camera. Before
use, please read the safety
information and precautions
contained in pages 2 and 3 to
ensure safe use of this product.
For Future Reference:
Enter the Model No. (located
on the bottom of the memory
camera) and Serial No. (located
on the battery pack mount of the
camcorder) below.
Model No.
Serial No.
Apreciado cliente
Muchas gracias por haber
adquirido esta videocamara con
memoria. Antes de usarla, lea la
informacion de seguridad y las
precauciones contenidas en las
paginas 2 y 3 para garantizar un
uso seguro de este producto.
Para futuras consultas:
Escriba a continuación el número de
modelo (ubicado en la parte inferior
de la videocámara) y el número de
serie (ubicado en el compartimiento
de la batería de la videocámara).
Número de modelo
Número de serie
ENGLISH
ESPANOL
SP

Advertisement

Table of Contents
loading

Summary of Contents for JVC GZ-MS130U

  • Page 1 INSTRUCTIONS MANUAL DE INSTRUCCIONES MEMORY CAMERA VIDEOCÁMARA CON MEMORIA GZ-MS130U Please read the instruction manual prior to connecting or operating this product. Por favor, lea el manual de instrucciones antes de conectar u operar este producto. For more details on the...
  • Page 2: Safety Precautions

    Safety Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 4: Grip Adjustment

    CAUTION Be sure to use JVC battery packs. If you use any other battery packs besides JVC battery packs, safety and performance can not be guaranteed. Grip Adjustment Adjust the strap and fasten.
  • Page 5: Set The Date And Time

    Date/Time Setting Open the LCD monitor to turn on the camcorder Power Button LCD monitor Select [YES] within 10 seconds Slide your finger up and down on the sensor. Then touch OK SET DATE/TIME! • When the message disappears, press the power button for at least 2 seconds to turn off the power, and then press it again for at least 2 seconds.
  • Page 6: Start Recording

    Video recording CAUTION Before recording an important scene, it is recommended to conduct a trial recording. Slide the mode switch to select ! (video) mode S elect recording mode PLAY/REC The mode changes when you press the button. Start recording Press the START/ STOP button to start recording, and press...
  • Page 7: Playing Back

    To view files on TV ( pg. 25) It is recommended to copy your important recorded data to a DVD or other recording media for storage. JVC will not be responsible for any lost data. CAUTION Don’t forget to make copies after recording! •...
  • Page 8: Table Of Contents

    Contents GETTING STARTED Index ... 10 Accessories ... 12 Attaching the core filter ... 12 Preparing the Remote Control ... 12 Indications on LCD Monitor ... 13 Necessary Settings before Use ... 15 Charging the Battery Pack ... 15 Other Settings ... 16 Date/Time Setting ...
  • Page 9: Read This First

    Be sure to use the JVC BN-VF808U/VF815U/ VF823U battery packs. This product includes patented and other proprietary technology and is made to be used with the JVC battery and not with other batteries. JVC cannot guarantee safety or performance of this product when it is operated by other batteries.
  • Page 10: Getting Started

    Index EN10 NOTE • The LCD monitor can rotate 270°. • Be careful not to cover 4, 5, 7 and 8 during shooting.
  • Page 11 Camcorder ! Touch Sensor # OK Button $ MENU Button % Power (1) Button & SD Card Slot ( pg. 18) ( EXPORT Button ) AV Connector * UPLOAD Button ( pg. 36) + PLAY/REC Button ( pg. 19, 20, 22, 23) , Mode Switch [ - DIRECT DVD Button ( pg.
  • Page 12: Accessories

    Accessories AC Adapter AP-V20U USB Cable NOTE Make sure to use the provided cables for connections. Do not use any other cables. Attaching the Core Filter The core filter reduces interference caused when connecting to other devices. Release the stopper. To be connected to the camcorder Preparing the Remote Control...
  • Page 13: Indications On Lcd Monitor

    Indications on LCD Monitor During both Video and Still Image Recording 1/4000 JAN. 1. 2009 4:55 PM ! Selected Operation Mode Indicator pg. 24) : Auto Mode : Manual Mode # Effect Mode Indicator $ Tele Macro Mode Indicator % LED Light Indicator ( pg.
  • Page 14 Indications on LCD Monitor (Continued) During Video Playback JAN. 1. 2009 4:55 PM ! Mode Indicator # Playlist Playback Indicator (Appears when playing back a playlist.) $ Video Quality: (ULTRA FINE), (NORMAL), (ECONOMY) % Counter & Playback Mode : Playback : Pause : Forward Search : Reverse Search...
  • Page 15: Necessary Settings Before Use

    Necessary Settings before Use Charging the Battery Pack Close the LCD monitor to turn off the camcorder. Attach the battery pack, then connect the AC adapter. • With the “ ” (arrow) on the battery pack pointing at the correct direction, slide the battery pack until it locks in place.
  • Page 16: Other Settings

    Other Settings Date/Time Setting Open the LCD monitor to turn on the camcorder. Touch MENU. Select [DISPLAY SETTINGS]. Select [CLOCK ADJUST]. Select [CLOCK SETTING]. Select the city closest to the area where you use the camcorder. Selected area is highlighted Principal city of the selected area Time difference to...
  • Page 17: Language Setting

    Language Setting The language on the display can be changed. Open the LCD monitor to turn on the camcorder. Touch MENU. Select [DISPLAY SETTINGS]. VIDEO WIND CUT AUTO SWITCH REC MEDIA DISPLAY SETTINGS BASIC SETTINGS CONFIGURE ON-SCREEN DISPLAY Select [LANGUAGE]. DISPLAY SETTINGS LANGUAGE CLOCK ADJUST...
  • Page 18: Using An Sd Card

    Clipped Edge It is recommended to copy your important recorded data to a DVD or other recording media for storage. JVC will not be responsible for any lost data. MEDIA SETTINGS REC MEDIA FOR VIDEO REC MEDIA FOR IMAGE...
  • Page 19: Recording/Playback

    Recording Files Video Recording Slide the mode switch to select (video) mode. To stop recording Press the START/STOP again. To view the last recorded scene Select while recording is paused. Selecting during playback deletes that scene. To record a still image during video recording Press SNAPSHOT.
  • Page 20: Still Image Recording

    Recording Files (Continued) Still Image Recording Slide the mode switch to select (still image) mode. To view the last recorded image Select after shooting. Selecting $ during playback deletes that image. To change the picture quality Change the settings in [IMAGE QUALITY].
  • Page 21: Zooming

    Zooming Preparation: • Slide the mode switch to select mode. • Press the PLAY/REC button to select recording mode. Zoom out W: Wide angle You can also zoom out/zoom in by selecting [W] or [T] on the LCD monitor. (On-screen zoom control).
  • Page 22: Playing Back Files

    Playing Back Files Video Playback Slide the mode switch to select (video) mode. To move to the previous or next page Touch [ or [ ] for over a second. To play back a few seconds from each select scene of the recorded videos DIGEST Touch [ Operations during Video Playback...
  • Page 23: Still Image Playback

    Still Image Playback Slide the mode switch to select (still image) mode. To move to the previous or next page Touch [ ] or [ ] for over a second. To delete a still image Select To change the number of thumbnails (6 thumbnails/20 thumbnails) Move the zoom lever to [T] or [W].
  • Page 24: Manual Recording

    Manual Recording Manual recording mode enables you to set the focus and screen brightness etc. manually. Change to Manual Recording Mode Preparation: • Slide the mode switch to select mode. • Press the PLAY/REC button to select recording mode. Select [A/M] twice. To return to the auto recording mode Select [A/M] so that the appears.
  • Page 25: Viewing Files On Tv

    Viewing Files on TV This camcorder is designed to be used with NTSC-type color television signals. It cannot be used with a television of a different standard. Connection with TV To connect using the AV connector. Preparation: Turn off all units. AC Adapter To AC Outlet...
  • Page 26: Managing Files

    Managing Files CAUTION Do not remove the recording medium or perform any other operation (such as turning off the power) while accessing files. Also, be sure to use the provided AC adapter, as the data on the recording medium may be corrupted if the battery becomes exhausted during operation.
  • Page 27: Copying

    You can dub video files recorded on this camcorder onto DVD discs. NOTE It is recommended to use the JVC DVD burner (CU-VD50/CU-VD3). When using CU-VD20 or CU-VD40, the recording time may take approx. 2 times longer than the time that is described in the instruction manual of DVD burner.
  • Page 28 Copying Files (Continued) Backup All Files Preparation: • Connect the camcorder to the DVD burner. • Slide the mode switch to select Select [CREATE FROM ALL]. Select the desired menu. • [ALL SCENES]: All files in the recording medium are copied.
  • Page 29: Creating A Dvd Using A Pc

    Creating a DVD using a PC Please read the “JVC SOFTWARE LICENCE AGREEMENT” in the CD-ROM instruction before you install software. You can copy the data from the camcorder and create a DVD using a PC. Q Installing the software to the PC...
  • Page 30 Copying Files (Continued) R Making Backup on the PC Preparation: • Install the software to the PC. • Make sure that enough free space is left in the PC’s HDD. • Close the LCD monitor to turn off the camcorder. AC Adapter To AC Outlet...
  • Page 31 S Making User Lists to Arrange the Files You can make a user list of a certain subject (such as Travel, Athletic meet) and put the files related to the subject into the user list. Preparation: Make backup on the PC. Double-click icon and open the calendar.
  • Page 32 Copying Files (Continued) T Copying Files to a DVD Preparation: Use a recordable DVD disc (It is recommended to use a DVD-R disc.) Select the user list and click [Create Disc]. Click [Select files individually] and click [Next]. To add all the files onto DVD discs, click [Select all files displayed], then go to step 4.
  • Page 33 Customer Support Information Use of this software is authorized according to the terms of the software licence. When contacting the nearest JVC office or agency in your country (refer to the JVC Worldwide Service Network at http://www.jvc-victor.co.jp/english/worldmap/index-e.html) about this software, please have the following information ready.
  • Page 34: Dubbing Files To A Vcr/Dvd Recorder

    Copying Files (Continued) Dubbing Files to a VCR/DVD Recorder Preparation: • Create a playlist. • Turn off all units. To connect using the AV connectors (analog dubbing) Adapter To AC Outlet AV Connector AV Cable VCR/DVD Recorder AV Connector EN34 Connector Adapter (Input)
  • Page 35: Using With A Portable Media Player

    Using with a Portable Media Player Turning on the Export Mode You can easily transfer videos recorded ® in export mode to iTunes . All the files with the export setting turned on are transferred to PC. For details on transferring, refer to the operation guide of MediaBrowser in the CD-ROM.
  • Page 36: Uploading Files To Websites

    Uploading Files to Websites Turning on the Upload Mode You can upload the file to video sharing websites (You Tube ) quickly after recording. For more information on YouTube™, visit YouTube™ website: http://www.youtube.com/ Preparation: • Slide the mode switch to select •...
  • Page 37: Changing The Menu Settings

    Before requesting service, consult the following chart. If the solutions indicated in the chart do not solve the problem, consult your nearest JVC dealer or JVC service center for instructions. Refer also to the FAQ of new products on JVC’s website.
  • Page 38 Troubleshooting (Continued) Trouble Recording cannot be performed. Recording stops by itself. Sound or video are interrupted. Cannot find a recorded video/image. The lamp does not flash during battery pack charging. Cannot upload the file ™ to YouTube Cannot export the file ®...
  • Page 39: Warning Indications

    Set the clock. If the message still appears after setting the clock, the battery for the clock has been depleted. Consult your nearest JVC dealer. • Be sure to use JVC battery packs. • Select [OK] and select [YES] to perform formatting. •...
  • Page 40: Specifications

    Specifications Camcorder For general Power supply DC 11 V (Using AC adapter) DC 7.2 V (Using battery pack) Power consumption Approx. 1.8 W* * When the LED light is off and the monitor backlight is set to [STANDARD] mode. Dimensions (W x H x D) 54.5 mm x 65 mm x 112.5 mm (2-1/8”x2-9/16”x4-7/16”) Weight...
  • Page 41: Remote Control

    Remote Control Power supply DC 3 V Battery life Approx. 1 year (depending on the frequency of use) Operating distance Within 5 m (16.4 ft) Operating temperature 0°C to 40°C (32 F° to 104° F) Approximate recording time (for video) Recording medium 256 MB 512 MB...
  • Page 42: Cautions

    AC wall outlet other than American National Standard C73 series type use an AC plug adapter, called a “Siemens Plug”, as shown. For this AC plug adapter, consult your nearest JVC dealer. Battery Packs The supplied battery pack is a lithium-ion battery.
  • Page 43 Changes or modifications not approved by JVC could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 44: Terms

    Terms AC Adapter ... 15, 42 AV Connection ... 25, 34 Backlight Compensation ... 24 Battery Pack ... 15, 42 Built-In Memory ... 18, 39 CD-ROM ... 12, 29 Clock Adjust ... 16 Date/Time Setting ... 5 Daylight Saving Time ... 16 Deleting Files ...
