INSTRUCTIONS
CAMCORDER
GZ-MS130AA
LYT2031-001B-M
Dear Customer
Thank you for purchasing this
camcorder. Before use, please
read the safety information and
precautions contained in pages 2
and 3 to ensure safe use of this
product.
For more details on the
operations, refer to the
GUIDEBOOK in the
supplied CD-ROM.
ENGLISH
EN
Advertisement
Table of Contents
Related Manuals for JVC GZ-MS130AA
Summary of Contents for JVC GZ-MS130AA
- Page 1 LYT2031-001B-M INSTRUCTIONS CAMCORDER GZ-MS130AA Dear Customer Thank you for purchasing this camcorder. Before use, please read the safety information and precautions contained in pages 2 and 3 to ensure safe use of this product. For more details on the operations, refer to the GUIDEBOOK in the supplied CD-ROM.
- Page 2 • Do not disassemble and do not dispose of in fire. Contact your JVC dealer. Do not attempt to repair the malfunction yourself. • To prevent shock, do not open the cabinet. No...
- Page 3 Remember that this camcorder is intended for Do not point the lens directly into the sun. This private consumer use only. can cause eye injuries, as well as lead to the Any commercial use without proper permission malfunctioning of internal circuitry. There is also a is prohibited.
- Page 4 AC Adapter To AC Outlet (110V to 240V) CAUTION Be sure to use JVC battery packs. If you use any other battery packs besides JVC battery packs, safety and performance can not be guaranteed. Grip Adjustment Adjust the strap and fasten.
- Page 5 Date/Time Setting Select [CLOCK SETTING] Open the LCD monitor to CLOCK ADJUST turn on the camcorder CLOCK SETTING AREA SETTING SET FOR DAYLIGHT SAVING TIME Power Button SET THE CITY, DATE AND TIME QUIT Select the city closest to the area where you use the camcorder AREA SETTING LCD monitor...
- Page 6 Video recording CAUTION Before recording an important scene, it is recommended to conduct a trial recording. Slide the mode switch to select ! (video) mode S elect recording mode PLAY/REC The mode changes The auto recording when you press the indicator appears.
- Page 7 To view files on TV ( pg. 25) It is recommended to copy your important recorded data to a DVD or other recording media for storage. JVC will not be responsible for any lost data. CAUTION Don’t forget to make copies after recording! •...
-
