TO MEMORIZE CHANNELS

This TV is equipped with a channel memory feature which
allows channels to skip up or down to the next channel set
into memory, skipping over unwanted channels.
Before selecting channels, they must be programmed into
the TV's memory. In addition to normal VHF and UHF
channels, this TV can receive up to 113 Cable TV channels.
To use this TV with an antenna, set the TV/CATV menu
option to the TV setting. When shipped from the factory, this
menu option is in the CATV setting.
TV/CATV SELECTION
1
Press the MENU button.
2
Press the SET + or – button until the M E N U
CLOCK SET
indicator next to "CH SET UP" ON/OFF TIMER
CH SET UP
begins to flash, then press the
LANGUAGE / IDIOMA
COLOR AUTO
ENTER button.
+ / — / ENTER / MENU
3
Press the SET + or – button until the
indicator next to "TV/CATV" begins
to flash.
CH SET UP
TV CATV
AUTO CH MEMORY
ADD / DELETE
4
Press the ENTER button to select
the TV or CATV mode. The arrow
+ / — / ENTER / MENU
indicates the selected mode.
5
Press the MENU button.
NOTE: Contact your cable company to determine the
type of cable system used in your area.
10
AUTOMATIC CHANNEL MEMORY
1
Press the MENU button.
M E N U
CLOCK SET
ON/OFF TIMER
CH SET UP
2 PICTURE
Press the SET + or – button until the
LANGUAGE / IDIOMA
COLOR AUTO
indicator next to "CH SET UP" begins
+ / — / ENTER / MENU
to flash, then press the ENTER
button.
3 Press the SET + or – button until the
CH SET UP
indicator next to "AUTO CH
TV CATV
AUTO CH MEMORY
MEMORY" begins to flash, then press ADD / DELETE
the ENTER button. The TV will begin
+ / — / ENTER / MENU
memorizing all the channels available
in your area.
4 Press the MENU button.
TO ADD/DELETE CHANNELS
1
Press the MENU button.
M E N U
CLOCK SET
ON/OFF TIMER
CH SET UP
2 PICTURE
Press the SET + or – button until the
LANGUAGE / IDIOMA
COLOR AUTO
indicator next to "CH SET-UP" begins
+ / — / ENTER / MENU
to flash, then press the ENTER
button.
3 Press the SET + or – button until the
CH SET UP
TV CATV
indicator next to "ADD/DELETE"
AUTO CH MEMORY
ADD / DELETE
begins to flash, then press the
ENTER button.
+ / — / ENTER / MENU
4
Select the desired channels to be
added or deleted using the 10-key
pad (0-9) or the CH + or – button.
5
Press the ENTER button to select ADD or DELETE.
If an unmemorized channel was selected (step 4), the
channel indication will be red. Press the CH + or –
button if you wish to ADD the unmemorized channel.
The channel indicator will change from red to green
when a channel is added and the channel will be
memorized. If a memorized channel was selected (step
4), the channel indication will be green.
Press the CH + or – button if you wish to DELETE the
channel from memory. The channel
ADD CH 012
indicator will change from green to
red when a channel is deleted.
Repeat Steps 4 and 5 for each
+ / — / 0-9 / ENTER / MENU
channel to be added or deleted.
6
Press the MENU button after adding or deleting all of
the desired channels, to return to normal TV viewing.

TV BASIC OPERATION

1
Press the POWER button on the front panel to put the
TV into standby mode. The STAND BY indicator will
light.
2
Press the POWER button on the remote control to turn
on the TV.
You can also turn on the TV by pressing the CHAN-
NEL UP or DOWN button on the front panel or on the
remote control when the TV is in standby mode.
3 The VOLUME can be adjusted to a desired level by
pressing the VOL (VOLUME) or button.
Adjust the volume level by
pressing the VOL or
button. The volume level will be
indicated on the screen by
green bar. As the volume level
VOLUME 32
increases, so do the number of
bar. If the volume decreases,
the number of green bar also decreases.
The sound level will be indicated on the TV screen by
green bars and a number. As the sound level in-
creases, so do the number of bars and the number on
the screen. The same is true for decreasing the level.
4
Set the TV/CATV menu option to the appropriate
position. When shipped from the factory, this menu
option is in the CATV setting. See "TO MEMORIZE
CHANNELS".
TV - VHF/UHF channels
CATV - CABLE TV channels
5
CH (CHANNEL) and buttons
Press and release the CH
(CHANNEL) or button.
CH 012
The channel automatically stops
at the next channel set into
memory.
For proper operation, before selecting channels,
they should be set into the TV's memory.
See "TO MEMORIZE CHANNELS".
QUICK VIEW button
Returns to the channel viewed just before the channel
currently onscreen.
CH 012 CH 007
MUTING button
The MUTING button instantly turns the
MUTING
volume down completely when you
press it.
Press MUTING button and the volume
level will instantly go to zero. To restore
the volume to its previous level, press MUTING button again.
10-key pad (0-9)
Press these buttons to select a channel. The channel
number will appear on the upper right corner of the TV
screen. If an invalid channel number is selected, the display
will revert to the original channel.
TV Mode Direct Channel Selection
When the TV/CATV menu option is in the TV position, all
channels can be instantly selected by using two buttons.
(For example, to select channel 2, press "0", then "2". If you
press only "2", channel selection will be delayed for a few
seconds). For channels 10 and above, press the 2 digits in
order.
CATV Mode Direct Channel Selection
When the TV/CATV menu option is in the CATV position,
channels can be selected as follows:
CH. 1-9 Press "0" twice, then 1-9 as needed.
Example, to select channel 2, press
"002".
CH. 10-12 Press "0", then remaining 2 digits.
Example, to select channel 12, press
"012".
CH. 13-99 Press the 2 digits in order.
Example, to select channel 36, press
"36".
CH. 100-125 Press the 3 digits in order.
Example, to select channel 120, press
"120".
NOTE: If the station being viewed stops broadcasting, the
TV will automatically shut off after 15 minutes.
