COLOR VIDEO MONITOR
TM-H1375SU
For Customer Use:
Enter below the Serial No. which is located on the rear of
the cabinet. Retain this information for future reference.
TM-H1375SU
Model No. :
Serial No.
:
INSTRUCTIONS
–
PHASE
CHROMA
BRIGHT
CONTRAST
MENU
VOLUME/SELECT
TM-H1375SU
+
B
A
_ON
—OFF
UNDER
SCAN
INPUT SELECT
POWER
Advertisement
Table of Contents
Related Manuals for JVC TM-H1375SU
Summary of Contents for JVC TM-H1375SU
- Page 1 COLOR VIDEO MONITOR TM-H1375SU For Customer Use: Enter below the Serial No. which is located on the rear of the cabinet. Retain this information for future reference. TM-H1375SU Model No. : Serial No. INSTRUCTIONS – UNDER SCAN INPUT SELECT PHASE...
-
