JVC TM-A140PN-A Instructions Manual

Colour video monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

COLOUR VIDEO MONITOR
BEDIENUNGSANLEITUNG : FARB-VIDEO-MONITOR
MANUEL D'INSTRUCTIONS : MONITEUR VIDEO COULEUR
MANUALE DI ISTRUZIONI
INSTRUCCIONES
TM-A140PN-A
: MONITOR VIDEO A COLORI
: MONITOR DE VIDEO A COLOR
TM-A140PN-A
INSTRUCTIONS
–
+
B
INPUT SELECT
PHASE
CHROMA
BRIGHT
CONTRAST
MENU
VOLUME/SELECT
A
ON
OFF
POWER

Advertisement

Table of Contents
loading

Related Manuals for JVC TM-A140PN-A

Summary of Contents for JVC TM-A140PN-A

  • Page 1 COLOUR VIDEO MONITOR BEDIENUNGSANLEITUNG : FARB-VIDEO-MONITOR MANUEL D'INSTRUCTIONS : MONITEUR VIDEO COULEUR MANUALE DI ISTRUZIONI INSTRUCCIONES TM-A140PN-A : MONITOR VIDEO A COLORI : MONITOR DE VIDEO A COLOR PHASE CHROMA BRIGHT TM-A140PN-A INSTRUCTIONS – INPUT SELECT CONTRAST MENU VOLUME/SELECT POWER...

  • Page 2: Safety Precautions

    Thank you for purchasing this JVC colour video monitor. Before using it, read and follow all instructions carefully to take full advantage of the monitor's capabilities. SAFETY PRECAUTIONS In order to prevent any fatal accidents caused by misoperation or mishandling the monitor, be fully aware of all the following precautions.

  • Page 3: Table Of Contents

    POWER CONNECTION WARNING Do not cut off the main plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or adapter or consult your dealer.

  • Page 4: Controls And Features

    CONTRAST MENU INPUT SELECT VOLUME/SELECT POWER TM-A140PN-A 1 Phase button [PHASE Press this button to set the picture hue adjustment mode. Adjust the value with the VOLUME/SELECT buttons. Also used as a control button in the menu function mode. 2 Chroma button [CHROMA Press this button to set the picture colour density adjust- ment mode.

  • Page 5: Rear View

    REAR VIEW <Rear Panel> VIDEO Y/C IN To AC outlet (230 V AC, 50/60 Hz) 14 Video A terminals [VIDEO A IN/OUT] Video signal input (IN) and output (OUT) terminals. The output terminal is bridge-connected. : Video signal input terminal OUT : Bridge-connected video signal output terminal Notes: * For corresponding audio signals, use the AUDIO A...

  • Page 6: How To Handle Basic Operations

    HOW TO HANDLE BASIC OPERATIONS BASIC OPERATION 1. Press the POWER switch to turn on the power. _ON : Power turns ON. (Power indicator: lit) —OFF : Power turns OFF. (Power indicator: unlit) POWER 2. Press the INPUT SELECT button to choose input. Selects video/audio signals input to terminals on the rear panel.

  • Page 7: How To Use The Menu Functions

    HOW TO USE THE MENU FUNCTIONS DISPLAY AND SELECTION IN THE <MENU> SCREEN MODE (SETTING) You can set the following menu items. Set them depending on your needs. • SHARPNESS • COLOR SYSTEM 1. Press the MENU button. The <MENU> screen is displayed. MENU 2.
  • Page 8 HOW TO USE THE MENU FUNCTIONS DISPLAY AND SELECTIONS IN THE <SET-UP MENU> MODE (SETTING) You can set the following set-up menu items. ● H. POSITION ● WHITE BALANCE Note: ● Parameters for H. POSITION can be set separately depending on the video input (Input A or Input B) selected by the input select buttons on the front panel.
  • Page 9 Set-up menu items H. POSITION Adjusts the horizontal position of the screen (+ : Horizontal position shifts to the right/–: Horizontal position shifts to the left) WHITE BALANCE Adjusts the white balance DRIVE R.DRIVE Adjusts red level B.DRIVE Adjusts blue level CUT OFF R.

  • Page 10: How To Initialize The Setting

    HOW TO INITIALIZE THE SETTING SCREEN DISPLAY AND SELECTIONS IN THE <SET-UP MENU> RESET MODE You can set <MENU> and <SET-UP MENU> screen items, picture adjustment items and the volume level to their factory-set (initial) values. 1. Press the POWER ( —...

  • Page 11: Basic Connection Example

    BASIC CONNECTION EXAMPLE Notes: ● Before connecting your system, make sure that all units are turned off. ● The illustration below shows some examples of different connections. Terminal connections may differ depending on the component connected. Be sure to refer to the instructions provided with the unit(s) you are connecting. ●...

  • Page 12: Troubleshooting

    TROUBLESHOOTING Solutions to common problems related to your monitor are described here. If none of the solutions presented here solves the problem, unplug the monitor and consult a JVC-authorized dealer or service center for assistance. Problems No power supply. Is the power plug loosened or disconnected?

  • Page 13: Specifications

    * Illustrations used in this manual are for explanatory purposes only. The appearance of the actual product may differ slightly. * Dimensions and weight are approximate. * E. & O. E. Design and specifications subject to change without notice. TM-A140PN-A Colour video monitor PAL, NTSC (3.58) 36 cm measured diagonally, 90°...
  • Page 14 < Front View > – PHASE CHROMA BRIGHT CONTRAST MENU VOLUME/SELECT TM-A140PN-A * Asterisks ( ) are used to indicate front panel dimensions. 7 Y/C (Mini DIN 4 pin) terminal specification Y/C IN Unit : mm < Side View >...
  • Page 16 VICTOR COMPANY OF JAPAN, LIMITED LCT0380-001A © 1999 VICTOR COMPANY OF JAPAN, LIMITED 0199-Tu-U-VP...
