- Page 1 Digital Recorder DN-60 Quick Start Guide www.datavideo-tek.com...
-
Page 2: Table Of Contents
CF Card Slot ..................10 Rear Panel ..................11 Operation Procedures ................. 12 Menu Navigation ................. 13 Remote Control of the DN-60 .............. 29 Connect CF Card to PC ..............30 APPENDIX A ..................32 APPENDIX B ..................33 Specifications ..................39... -
Page 3: Warnings And Precautions
7. This product should only be operated from the type of power source indicated on the marking label of the AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company. - Page 4 13. Unplug this product from the wall outlet and refer to qualified service personnel under the following conditions: When the power cord is damaged or frayed; When liquid has spilled into the unit; When the product has been exposed to rain or water; When the product does not operate normally under normal operating conditions.
-
Page 5: Warranty
DVD Drives, Hard Drives are only covered for the first 10,000 hours, or 1 year (whichever comes first). Any second year warranty claims must be made to your local Datavideo office or one of its authorized Distributors before the extended warranty... -
Page 6: Disposal
It must be handed over to the applicable take back scheme for the recycling of electrical and electronic equipment. For more detailed information about the recycling of this product, please contact your local Datavideo office. -
Page 7: Outline And Features
Outline and Features Portable recorder with Compact Flash memory card (CF card). The CF card is protected under a secured cover to protect from harsh environment such as rain or sand…etc. CF card can be used in any PC with CF card reader, stand-alone as portable media device, or with any of the PC interface adapters offered. -
Page 8: Packing List
Packing List Items Description Q’ty DN-60 IEEE1394 6-4 50CM IEEE1394 6-6 50CM Switching Adaptor DC 12V/500mA DN-60 Instruction Manual... -
Page 9: Front Panel
Front Panel 1. LCD Display There are four lines in the LCD Display. The first line is used to display icons that reflect some of the current settings of the unit. These settings include: Battery Level Loop Play enabled ... - Page 10 Allows On - When DN-60 Recording. Glimmered - 1. No CF card inserted. 2. No signal input. 3. DN-60 set mode and input signal is different. Slowly Glimmered - 1. When DN-60 making media file. 2. When DN-60 format media.
-
Page 11: Cf Card Slot
CF Card Slot 1. CF Card Protection Cover – Lift open this cover to get access to the CF card and the eject button. 2. CF Card Eject Button – Press to eject the CF card. When the slot is empty (no CF card inserted), this button is normally in the depressed position. -
Page 12: Rear Panel
2. DV/HDV IN/OUT: Six-pin IEEE1394B (400Mbps) connector used to send and receive digital signals as well as to connect as an HDD to a computer. Power is not accepted from this connector. 3. RS-232: 3.5mm 4-pin connector used to remotely control the DN-60. -
Page 13: Operation Procedures
VTR MODE (Capturing or Play Back) Formatting the CF card The DN-60 will format a CF card to handle one of three signal types; HDV (all frame rates), or NTSC DV, DVCPro or PAL DV, DVCPro. If an unformatted CF card is inserted, the DN-60 will recognize it and suggest it be formatted to its signal type. -
Page 14: Menu Navigation
Menu Option Action taken RECORD This will take DN-60 into record mode. At this mode, the MODE device checks input signal and ready for recording immediately. Other options are to change to different bin or to return to HOME. - Page 15 RECORD MODE Entering RECORD MODE, DN-60 will start checking the input signal immediately. If there is no signal at input port, it will flash NO INPUT message to alert user. If the input signal is wrong signal type, it will also flash warning message WRONG SIGNAL to alert user.
- Page 16 RECORD Current timecode is displayed on the second line. Third line will display recording status and BINS length in the minimal unit of second. There are three options during RECORD: Menu Option Action taken STOP Select STOP to stop recording. PAUSE Select PAUSE to pause recording.
- Page 17 PLAY MODE DN-60 will display the signal type of the current selected BINS, DV, HDV or DVCPro on the first line. It also displays clip number and timecode on the second line. User can choose the timecode display type (either timecode or frame count) through the system setup in the SETUP MODE.
- Page 18 PLAY During PLAY, DN-60 will display output signal format on the first line, clip number and timecode on the second line. It will pause at the last frame of the playing BINS. Any time during PLAY, user can use the knob to select one of the five play options to achieve the function they want.
- Page 19 TOOLS There are five useful tools available in TOOLS mode. MAKE MEDIA FILES EMPTY CURRENT BINS FORMAT MEDIA UPGRADE FIRMWARE FIRMWARE REVISION Menu Option Action taken MAKE MEDIA Prepares the recorded content to be seen by the FILES computer in the CF card. The operating system environment is previously set to either FAT32 or NTFS.
- Page 20 Updating the Firmware To update the DN-60’s firmware, take a CF card that has undergone the MAKE MEDIA FILES process with FAT-32 file system option selected, and then connect it to your computer. Copy the firmware update file to the root directory, level where all bin folders appear, and rename it flash.bin.
- Page 21 PLAY SETUP This menu provided the options to sets the DN-60 to loop play a track; the track will continuously loop until stopped. RECORD SETUP This menu provide the options to setup RECORDING related features such as record file type, power on auto recording…etc.
- Page 22 SYSTEM SETUP SYSTEM SETUP mode allows user to setup DN-60 for different type of signal, or file system. Menu Option Action taken SET SIGNAL Where to choose HDV, DV-NTSC or DV-PAL signal TYPE to be recorded. When in DV mode, DN-60 will automatically detect...
- Page 23 SAVE SETUP Menu Option Action taken SAVE AS Save current setup into USER setup #1 USER #1 SAVE AS Save current setup into USER setup #1 USER #2 Table 10 SAVE SETUP RECALL SETUP Menu Option Action taken USER #1 Recall USER setup #1 to be loaded into current setup USER #2...
- Page 24 STATUS Press STATUS will display DN-60 current status information. It displays the selected recording signal type, recording file format, recording file system, and the selected recording media type. It also displays the recording setup such as sync to tape is ON or OFF, time-lapse recording information, pre-trigger and power on auto recording feature setup.
- Page 25 Set the CF Card volume ID When connecting as a CF card created by DN-60, the volume name is DATAVIDEO xx. If your application calls for multiple CF card to be connected to the computer at the same time, it becomes helpful to have the volume name be different for each CF card.
- Page 26 A choice must be made for the eventual file type of choice should you want to connect the DN-60 CF card in your computer and drag and drop your video content as files. The choices for DV are Microsoft .avi type II, Canopus .avi type II, both commonly used in PCs, .mov, the QuickTime...
- Page 27 See the command protocol in Appendix B. Pausing The DN-60 will pause recording if time code is not moving and ST:ON is set, otherwise it will record. When the video source is digital the time code is embedded in the stream and it is always the time code recorded.
- Page 28 Warning: If power is interrupted while the recording is paused, all clip numbers added during the current record session will be lost. No content however will be lost. Future firmware upgrades may fix this behavior. Note: If power is interrupted while recording, up to two seconds of the last video may be lost.
- Page 29 Use Record Pre-trigger When this option is enabled the DN-60 is always in a record-ready mode when it is not playing. In this mode it is continuously storing live data in its internal buffer which is 8 seconds in length. In this manner, when a recording is started 8 seconds of history prior to the trigger already exists and is then captured to disk.
-
Page 30: Remote Control Of The Dn-60
Note: The acquisition of video in the DN-60 is instantaneous so requires to pre-roll. This limits the random access of an early frame in a batch capture by an editor that is setup to ask for a minimum pre-roll greater than zero. -
Page 31: Connect Cf Card To Pc
Connect CF Card to PC General Preparation Prior to removing the CF card in DN-60 and seeing your video as files instead of clips, the MAKING MEDIA FILES process must be undertaken. MAKE MEDIA FILES This operation prepares the recorded content to be seen by a computer by building the file wrappers around the recorded content and emulating the computer’s operating file system. - Page 32 File Organization After the media conversion is made, all bins that contained video will appear to the computer as folders named BINxx where xx represents the BIN number ranging from 01 to 99. Inside each folder, each clip will be represented as a file with an extension name .avi, .mov e.g.
-
Page 33: Appendix A
APPENDIX A I/O CONNECTORS PIN-OUT... -
Page 34: Appendix B
APPENDIX B Datavideo 232 Controller Command Set Rev 3.1 July 29, 2006 Communication format: Mode : no synchronization Character Length : 1 start bit + 8 data bits + 1 parity bit + 1 stop bit Data Rate : 38,400 BAUD... - Page 35 Summary List of Commands: Command Name Response Name System Control 00h, 11h, 11h Device Type Request 12h, 11h, 00, Device 00, 23h Type 00h, F1h, F1h Next Bin 10h, 01h, 11h 00h, F2h, F2h Previous Bin 10h, 01h, 11h 00h, F4h, F4h Disable Loop Play 10h, 01h, 11h 00h, F5h, F5h...
- Page 36 System Control 00h, 11h Device Type request The response is 00, 00 indicating QuickCapture 00h, F1h Next Bin When this command is issued from the Idle state the next bin is selected. If the present bin is 99 then the next bin is 1. 00h, F2h Previous Bin When this command is issued from the Idle state the previous bin is selected.
- Page 37 Transport Control 20h, 00h, Stop The unit enters the idle state. In the A2D, the outputs reflect the video source as selected by the Front Panel. 20h, 01h Play Content of the present bin is played at 1x speed. This command may be issued from the idle state or any other Play state.
- Page 38 Sense Request 61h, 0Ch, 04h Current Time Sense Requests the Time code data. The unit responds with 4 bytes indicating the present time code in Binary-Coded-Decimal. The first byte hold the frame number, the second byte holds the seconds, the third the minutes and the fourth the hour. In the play state, the time code returned is the time associated with the current frame being played, in the record state, the time code returned represents the elapsed time recorded in the present bin.
- Page 39 61h, F0h, 04h Current Frame Offset Requests the current Frame Offset number. Unit responds with 4 bytes indicating the present frame offset in Binary-Coded format with the least significant byte first. 61h, F1h, 01h Current Bin Requests the current bin number. The single byte answer is in Binary-Coded format.
-
Page 40: Specifications
Idle: 4.3W, Play/Record: 6W, HDD mode: 5.3W Size (W x H x D): 4.0” x 1.9” x 7.0” (101.6mm x 48.3mm x 177.8mm) Weight: DN-60: ??oz (500g), CF card: 6oz (170g) Temperature Operating: +40°F to +104°F (+4°C to +40°C) Non-Operating -40°F to +149°F (-40°C to +65°C) -
