Summary of Contents for JVC KS-FX460R

Page 1 CASSETTE RECEIVER CASSETTEN-RECEIVER RADIOCASSETTE RADIO/CASSETTESPELER KS-FX463R/KS-FX460R KS-FX463R KS-FX460R For installation and connections, refer to the separate manual. Angaben zu Einbau und Verkabelung entnehmen Sie bitte der gesonderten Anleitung. Pour l’installation et les raccordements, se référer au manuel séparé. Zie de afzonderlijke handleiding voor details aangaande het installeren en verbinden van het toestel.
Page 2: Table Of Contents
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. CONTENTS BASIC OPERATIONS ... 3 RADIO BASIC OPERATIONS ... 4 Listening to the radio ... 4 Storing stations in memory ...
Page 3: Basic Operations
Note: When you use this unit for the first time, set the built-in clock correctly, see page 20. / I /ATT Note on One-Touch Operation: • When you select tuner as a source in step 2 below, the power automatically comes on.
Page 4: Radio Basic Operations
RADIO BASIC OPERATIONS Listening to the radio / I /ATT Note on One-Touch Operation: When you select a band in step 2 below, the power automatically comes on. You do not have to press this button to turn on the power. Note: When a cassette is in the cassette compartment, you cannot select the tuner.
Page 5: Storing Stations In Memory
Storing stations in memory You can use one of the following two methods to store broadcasting stations in memory. • Automatic preset of FM stations: SSM (Strong-station Sequential Memory) • Manual preset of both FM and AM stations FM station automatic preset: SSM You can preset 6 local FM stations in each FM band (FM1, FM2, and FM3).
Page 6: Manual Preset
Manual preset You can preset up to 6 stations in each band (FM1, FM2, FM3 and AM) manually. EXAMPLE: Storing an FM station of 88.3 MHz into preset number 1 of the FM1 band Repeat the above procedure to store other stations into other preset numbers.
Page 7: Tuning Into A Preset Station
Tuning into a preset station You can easily tune into a preset station. Remember that you must store stations first. If you have not stored them yet, see pages 5 and 6. To change the display information while receiving an FM RDS station Press DISP.
Page 8: Rds Operations
RDS OPERATIONS What you can do with RDS EON RDS (Radio Data System) allows FM stations to send an additional signal along with their regular programme signals. For example, the station send their station names, as well as information about what type of programme they broadcast, such as sports or music, etc. Another advantage of RDS function is called “EON (Enhanced Other Networks).”...
Page 9 Mode 1 The AF indicator lights up but the REG indicator does not. Network-Tracking is activated with Regionalization set to “off.” Switches to another station within the same network when the receiving signals from the current station become weak. Note: In this mode, the programme may differ from the one currently received.
Page 10: Using Standby Reception
Using Standby Reception Standby Reception allows the unit to switch temporarily to your favorite programme (PTY: Programme Type) and Traffic Announcement (TA) from the current source — another FM station and Tape or CD changer. Note: Standby Reception will not work if you are listening to an AM station. TA Standby Reception •...
Page 11: Searching Your Favorite Programme
Selecting Your Favorite Programme for PTY Standby Reception You can select your favorite programme for PTY Standby Reception to store in memory. When shipped from the factory, “NEWS” is stored as the programme type for PTY Standby Reception. 1, 4 Searching Your Favorite Programme You can search one of your 6 favorite programme types stored in memory.
Page 12 To store your favorite programme types Press and hold the number button for more than 2 seconds to store the PTY code selected into the preset number you want. The selected code name will flash on the display. 1, 5 Press and hold SEL (select) for more than 2 seconds to enter the general setting mode (see page 22).
Page 13 To search your favorite programme type • If there is a station broadcasting a programme of the same PTY code you selected, that station is tuned in. • If there is no station broadcasting a programme of the same PTY code you selected, the station will not change.
Page 14: Other Convenient Rds Functions And Adjustments
Other convenient RDS functions and adjustments Changing the display mode while listening to an FM station You can change the initial indication on the display to station name (PS NAME), station frequency (FREQ), or clock time (CLOCK) while listening to an FM RDS station. •...
Page 15: Automatic Clock Adjustment
Automatic clock adjustment When shipped from the factory, the clock built in this unit is set to be readjust automatically using the CT (Clock Time) data in the RDS signal. If you do not want to use automatic clock adjustment, follow the procedure below. •...
Page 16: Tape Operations
TAPE OPERATIONS Listening to a tape / I /ATT ¡ To stop play and eject the cassette Press 0. Tape play stops and the cassette ejects from the cassette compartment. You can hear the last received station or CD playback from the CD changer. •...
Page 17: Sound Adjustments
SOUND ADJUSTMENTS Selecting preset sound modes You can select a preset sound adjustment suitable to the music genre. Each time you press SOUND, the sound mode changes as follows. SOUND Indication SCM OFF (Flat sound) BEAT Rock or disco music Light music SOFT Quiet background music...
Page 18: Adjusting The Sound
Adjusting the sound You can adjust the sound characteristics to your preference. Indication Adjust the bass (Bass) Adjust the treble (Treble) Adjust the front and rear speaker (Fader)* balance Adjust the left and right speaker (Balance) balance LOUD Boost low and high frequencies to produce a well-balanced sound at low (Loudness) volume level.
Page 19: Storing Your Own Sound Adjustments
Storing your own sound adjustments You can adjust the sound modes (BEAT, POP, SOFT: see page 17) to your preference and store your own adjustments in memory. SOUND Within 5 seconds Within 5 seconds Within 5 seconds SOUND Repeat the same procedure to store other settings. To reset to the factory settings Repeat the same procedure and reassign the preset values listed in the table on page 17.
Page 20: Other Main Functions
OTHER MAIN FUNCTIONS Setting the clock You can also set the clock system either to 24 hours or 12 hours. 2, 3, 4 Press and hold SEL (select) for more than 2 seconds to enter the general setting mode. 1, 5 2, 3, 4 Set the hour.
Page 21 To check the current clock time (changing the display mode) Press DISP repeatedly. Each time you press the button, the display mode changes as follows. During tuner operation: • For FM RDS stations See page 14. • For AM and other FM stations Frequency Clock Set the clock system.
Page 22: Changing The General Settings
Changing the general settings You can change the items listed on the next page to your preference. Basic Procedure 1, 4 Press and hold SEL (select) for more than 2 seconds to enter the general setting mode. Select the item you want to adjust. (See page 23.) Select or adjust the item selected above.
Page 23 Select. CLOCK H Hour adjustment CLOCK M Minute adjustment 24H/12H 24/12-hour time display AUTO ADJ Automatic setting of the clock DISPMODE Display mode CH DISP Changer display PTY STBY PTY standby PTY SRCH PTY search TA VOL Traffic announcement volume Audio mute for cellular phone system Back...
Page 24: Selecting The Telephone Muting
Selecting the initial CD information display You can select what type of the CD playback information to be initially shown on the display when you start playing a CD. When shipped from the factory, the disc number and track number information is selected to be shown. •...
Page 25: Detaching The Control Panel
Detaching the control panel You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. How to detach the control panel Before detaching the control panel, be sure...
Page 26: Cd Changer Operations
When used with a JVC CD automatic changer (separately purchased). We recommend that you use one of the CH-X series with your unit. If you have another CD automatic changer, consult your JVC IN-CAR ENTERTAINMENT dealer for connections. • For example, if your CD automatic changer is one of the KD-MK series, you need a cord (KS-U15K) for connecting it to this unit.
Page 27: To Fast-Forward Or Reverse The Track
To fast-forward or reverse the track Press and hold track. Press and hold 4 track. To go to the next tracks or the previous tracks Press beginning of the next track. Each time you press the button consecutively, the beginning of the next tracks is located and played back.
Page 28: Selecting Cd Playback Modes
Selecting CD playback modes To play back tracks at random (Random Play) MO/RND Mode RND Indicator RND1 Lights RND2 Flashes MO/RND Each time you press MO/RND (mono/random) while playing a CD, CD random play mode changes as follows: RND1 RND2 (Random1) (Random2) All tracks of the current disc, then the tracks of...
Page 29: Maintenance
To extend the lifetime of the unit This unit requires very little attention, but you will be able to extend the life of the unit if you follow the instructions below. To clean the heads To keep the tape clean CAUTIONS: •...
Page 30: Troubleshooting
TROUBLESHOOTING What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms • A cassette tape cannot be inserted. • Cassette tapes become hot. • Tape sound is at very low level and sound quality is degraded.
Page 31: Specifications
AUDIO AMPLIFIER SECTION Maximum Power Output: Front: 40 W per channel Rear: 40 W per channel Continuous Power Output (RMS): Front: 16 W per channel into 4 , 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion.
Page 32 VICTOR COMPANY OF JAPAN, LIMITED 0800HISFLEJES EN, GE, FR, NL...
Page 33 • Die folgende Abbildung zeigt einen typischen Einbau. Dennoch müssen Sie entsprechend Ihrem jeweiligen Auto Anpassungen vornehmen. Bei irgendwelchen Fragen oder wenn Sie Informationen hinsichtlich des Einbausatzes brauchen, wenden Sie sich an ihren JVC Autoradiohändler oder ein Unternehmen das diese Einbausätze vertreibt. Vor dem Einbau: (Schalttafel-Freigabetaste) zum Lösen der Schalttafel drücken.
Page 34 • When using the optional stay • Beim Verwenden der Anker-Option • Lors de l'utilisation du hauban en option Washer Unterlegscheibe Dashboard Rondelle Armaturenbrett Tableau de bord Sleeve Halterung Manchon Removing the unit • Before removing the unit, release the rear section. Remove the control panel.
Page 35: Electrical Connections
12 volts à masse NEGATIVE . Si votre véhicule n’offre pas ce type d’alimentation, il vous faut un convertisseur de tension, que vous pouvez acheter chez un revendeur d’autoradios JVC. • Remplacer le fusible par un de la valeur précisée. Si le fusible saute souvent, consulter votre revendeur d’autoradios JVC.
Page 36 Remote lead Fernbedienungsleitung Fil d'alimentation à distance Rear speakers JVC Amplifier Hintere Lautsprecher Verstärker von JVC Haut-parleur arrière Amplificateur JVC FEHLERSUCHE • Die Sicherung brennt durch. * Sind die roten und schwarzen Leitungen richtig angeschlossen? • Stromversorgung kann nicht eingeschaltet werden.
