- Page 1 WATER BOILER WB-10 -12 Revised 7/04 6913 West Acco Street, Montebello, California 90640 Tel: 800/421-6150 Technical Support Tel: 800/995-0417 Fax: 323/837-2401...
-
Page 2: Installation Instructions
WATER BOILER - WB-10 -12 INSTALLATION INSTRUCTIONS 1. Unpack equipment carefully, inspect for any freight damage. Be sure to promptly put a claim into the freight company if any damage is found. 2. Connect faucet securely to the faucet adapter. -
Page 3: Troubleshooting
TROUBLE SHOOTING PROBLEM: WATER WILL NOT REFILL SOLUTION POSSIBLE CAUSE 1 . Water line closed Check the water system at your facility to make sure the line is or clogged filter open. Replace the water filter. 2 . Valve coil burned Turn machine off. -
Page 4: Possible Cause
TROUBLE SHOOTING CONTINUED: PROBLEM: WATER DOES NOT REACH PROPER TEMPERATURE SOLUTION POSSIBLE CAUSE 2 . Defective thermo- Replace thermostat if contacts are open when knob is fully stat clockwise and water temperature is less than 190º F. You will measure 120 volts (approximately) to ground from both thermo- stat terminals when it is ON and from only one terminal when it is OFF. -
Page 5: Illustrated Parts List
ILLUSTRATED PARTS LIST Water Boiler – WB-10-12... - Page 6 WATER BOILER - WB-10-12 INDEX PART N º DESCRIPTION º WC-3205 KNOB, LID ........WC-5602 LID WITH KNOB .
- Page 7 Water Boiler WB 10 -12 120 VOLTS, 2100 WATTS, 17.5 AMPS, 1Ø 2 - 3.5 KW HEATING THERMOSTAT ELEMENTS RED #10 BLACK WHITE BLUE #10 BLUE INLET VALVE BLACK #18 WATER LEVEL CONTROL WHITE BOARD WHITE ORANGE PROBE Rev. 4/15/98 Single Phase 3 Wire 208 VOLT, 6300 WATT, 30 AMP 220 VOLT, 7000 WATT, 32 AMP...
- Page 8 Curtis equipment that have not been purchased from the Wilbur Curtis Company, Inc. The Wilbur Curtis Company will not accept any responsibility if the following conditions are not met. The warranty does not cover and is void under the following circumstances:...
