TABLE OF CONTENTS INTRODUCTION DIMENSIONS LISTING APPROVALS GENERAL INSTRUCTIONS LOCATING APPLIANCE UNPACKING AND TESTING APPLIANCE GROUNDING APPLIANCE INSTALLATION MINIMUM CLEARANCE TO COMBUSTIBLES MINIMUM MANTEL CLEARANCES NEW CONSTRUCTION OR RENOVATION INSTALLING THE APPLIANCE THERMOSTAT AND THERMAL SENSOR INSTALLATION HARD-WIRE INSTALLATION FRAMING FINISHING HEARTH COLD CLIMATE INSTALLATION...
1.0 INTRODUCTION WARNING • THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED. • Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fi re or injury. •...
United States and Canada. If you need assistance during installation, please contact your local dealer. NOTE: This appliance must be electrically wired and Model Number EF30G grounded in accordance with local codes or, in the absence Description Electric Appliance...
GENERAL INSTRUCTIONS WARNING READ THESE INSTRUCTIONS COMPLETELY BEFORE BEGINNING INSTALLATION. FAILURE TO FOLLOW THEM COULD CAUSE AN APPLIANCE MALFUNCTION RESULTING IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. ALL ELECTRIC APPLIANCES HAVE HOT AND ARCING OR SPARKING PARTS INSIDE. DO NOT USE IT IN AREAS WHERE GASOLINE, PAINT OR FLAMMABLE LIQUIDS ARE PRESENT.
2.0 LOCATING APPLIANCE WARNING DUE TO HIGH TEMPERATURES, THIS ELECTRIC APPLIANCE SHOULD BE LOCATED OUT OF TRAFFIC. KEEP COMBUSTIBLE MATERIALS SUCH AS FURNITURE, PILLOWS, BEDDING, PAPERS, CLOTHES AND CURTAINS AT LEAST 3 FEET (0.9M) FROM THE FRONT OF THE APPLIANCE. NEVER LOCATE THIS ELECTRIC APPLIANCE WHERE IT MAY FALL INTO A BATHTUB OR OTHER WATER CONTAINER.
GROUNDING APPLIANCE This appliance is for use on 120 Volts. The cord has a plug GROUNDING METHODS as shown in (A). An adapter as shown in (C) is available for connecting three-blade grounding type plugs to two-slot receptacles. The green grounding lug extending from the adapter must be connected to a permanent ground such as METAL SCREW a properly grounded outlet box.
3.0 INSTALLATION WARNING RISK OF FIRE! THE POWER CORD MUST NOT BE PINCHED AGAINST A SHARP EDGE. SECURE CORD TO AVOID TRIPPING OR SNAGGING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL INJURY. DO NOT RUN CORD UNDER CARPETING. DO NOT COVER CORD WITH THROW RUGS, RUNNERS OR THE LIKE.
MINIMUM CLEARANCE TO COMBUSTIBLES WARNING THIS APPLIANCE MUST REMAIN REMOVABLE FROM THE ENCLOSURE. THE APPLIANCE MAY BE HARD WIRED, BUT IT IS RECOMMENDED THAT IT BE PLUGGED INTO A STANDARD OUTLET USING THE SUPPLIED POWER CORD. THIS APPLIANCE MUST NOT BE SEALED AROUND THE FRONT FACING. APPLIANCE VENTS LOCATED ON THE FRONT AND BACK OF THIS ELECTRIC APPLIANCE CANNOT, IN ANY WAY, BE COVERED AS IT MAY CREATE A FIRE HAZARD.
Placing the sensor too close to the heater area of the appliance will cause unwanted cycling of the heater. Second is the option of a wall-mounted thermostat. Napoleon Part # W690-0001, W660-0081, or an equivalent low voltage thermostat.
HARD-WIRE INSTALLATION WARNING ENSURE ALL POWER IS TURNED OFF BEFORE HARD WIRING THIS APPLIANCE. HARD WIRING CONNECTION If it is necessary to hard wire this appliance, a qualifi ed electrician may remove the cord connection, and wire the appliance directly to the house hold wiring. This appliance must be electrically connected and grounded in accordance with local codes, if hard wired.
Page 12
Power Cord Remove 2 screws on cover plate. Hot Wire Common Wire Connector Ground Wire Final Connection W415-0760 / C / 12.21.11...
4.0 FRAMING WARNING RISK OF FIRE! IN ORDER TO AVOID THE POSSIBILITY OF EXPOSED INSULATION OR VAPOUR BARRIER COMING IN CONTACT WITH THE APPLIANCE BODY, IT IS RECOMMENDED THAT THE WALLS OF THE APPLIANCE ENCLOSURE BE “FINISHED” (IE: DRYWALL / SHEETROCK), AS YOU WOULD FINISH ANY OTHER OUTSIDE WALL OF A HOME.
5.0 FINISHING WARNING RISK OF FIRE! NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE. DO NOT STRIKE, SLAM OR SCRATCH GLASS. DO NOT OPERATE APPLIANCE WITH GLASS REMOVED, CRACKED, BROKEN OR SCRATCHED. FACING AND/OR FINISHING MATERIAL MUST NEVER OVERHANG INTO THE APPLIANCE OPENING. HEARTH A hearth is NOT necessary but is recommended for aesthetic purposes.
6.0 OPERATING INSTRUCTIONS The controls are located on the bottom right corner of the appliance. Plug in your electric appliance. Main ON/OFF Power Switch and LED: This switch is located on the right side of the control panel. The "|" indicates ON and "O" indicates OFF.
OPERATING BY REMOTE CONTROL Once the appliance has been plugged in to a grounded electrical outlet, it is ready to operate. Plug in your electric appliance. Make sure the appliance's main power button is at the ON position! The remote control will NOT work if the main Power button is at the OFF position.
7.0 MAINTENANCE WARNING ALWAYS DISCONNECT THE POWER AND ALLOW THE ELECTRIC APPLIANCE TO COOL BEFORE PERFORMING ANY CLEANING, MAINTENANCE OR RELOCATION OF THIS ELECTRIC APPLIANCE. TURN CONTROLS TO OFF AND REMOVE PLUG FROM OUTLET OR TURN OFF THE HOUSE CIRCUIT BREAKER TO ELECTRIC APPLIANCE RECEPTACLE.
FLAME GENERATION LAMP REPLACEMENT Remove the 7 screws from the bottom half of the BACK PLATE back of appliance illustrated. Remove back plate. Mantel Locate the fl ame generation cylinder drum. It is constructed of two removable halves. They are two (2) matte black sheet metal pieces with holes Back View of Appliance in them, either of which can be removed from the...
EMBER BED LAMP REPLACEMENT Remove the 7 screws from the bottom half of the back BACK PLATE Mantel of appliance as illustrated. Remove back plate. Locate the ember bed lamps which are underneath the fl ame generation cylinder drum. Back View of Appliance Remove spring clip.
9.0 REPLACEMENT PARTS Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally all parts can be ordered through your Authorized dealer / distributor. FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM.
10.0 TROUBLE SHOOTING WARNING TURN OFF THE APPLIANCE COMPLETELY AND LET COOL BEFORE SERVICING. ONLY A QUALIFIED SERVICE PERSON SHOULD SERVICE AND REPAIR THIS ELECTRIC APPLIANCE. SYMPTOM PROBLEM TEST SOLUTION Dim or no fl ame Bulb(s) are burnt out Inspect the bulbs inside the fl ame generation cylinder drum and replace them if necessary Ember bed is not Bulb(s) are burnt out...
NAPOLEON® warrants its products against manufacturing defects to the original purchaser only. Registering your warranty is not necessary. Simply provide your proof of purchase along with the model and serial number to make a warranty claim. NAPOLEON® reserves the right to have its representative inspect any product or part thereof prior to honouring any warranty claim.
