INSTALLATION AND OPERATING INSTRUCTIONS FOR AUTOMATIC
INSTANTANEOUS TYPE WATER HEATERS FOR USE WITH NATURAL AND
LIQUEFIED PETROLEUM GAS
MODEL 125X LP and 125X NG (Flow Modulated with Electronic Ignition)
Intended for variable flow applications with steady cold water inlet temperatures
WARNING
adjustment, alteration, service or maintenance can
cause injury or property damage. Refer to this manual.
For assistance or additional information consult a
qualified installer, service agency or the gas supplier.
Upon completion of the installation, these instructions
should be handed to the user of the appliance for
future reference.
FEATURING: Automatic Variable Power Modulating Gas
Valve and Electronic Ignition
Suitable for heating potable water only
Not approved for space heating purposes
: Improper installation,
WARNING
If the information in this manual is not followed
exactly, a fire or explosion may result causing property
damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable,
combustible or corrosive vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch; do not use any
phone in your building.
- Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
- If you cannot reach your gas supplier, call the fire
department.
- Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
TABLE OF CONTENTS
Specifications .................................................... Page 2
Rules for safe operation .................................... Page 4
Locating the Heater ............................................ Page 4
Combustion Air Requirements ............................ Page 5
Mounting the Heater ........................................... Page 5
Venting the Heater ............................................. Page 6
Gas Connections ............................................... Page 7
Water Connections ............................................ Page 8
Safety before turning on the heater ..................... Page 8
Operating instructions ........................................ Page 9
Trouble Shooting .............................................. Page 10
Microswitch Adjustment .................................... Page 11
Electrical Diagram ............................................ Page 12
Diagram of AquaStar ......................................... Page 13
Interior components diagram ............................ Page 14
Parts List ......................................................... Page 15
