FujiFilm FinePix E500 Service Manual

Hide thumbs Also See for FinePix E500:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual

DIGITAL CAMERA

FinePix E500
SERVICE MANUAL
US/CA/EU/EG/GE/AS/CH/JP-Model
WARNING
THE COMPONENTS IDENTIFIED WITH THE MARK "
" ON THE SCHEMATIC
DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR SAFETY.
PLEASE REPLACE ONLY WITH THE COMPONENTS SPECIFIED ON THE SCHEMATIC
DIAGRAM AND IN THE PARTS LIST.
IF YOU USE PARTS NOT SPECIFIED, IT MAY RESULT IN A FIRE AND AN
ELECTRICAL SHOCK.
Ref.No.:ZM00567-103
FUJI PHOTO FILM CO., LTD.
Printed in Japan 2005.10

Advertisement

Table of Contents
loading

Related Manuals for FujiFilm FinePix E500

Summary of Contents for FujiFilm FinePix E500

  • Page 1: Digital Camera

    DIGITAL CAMERA FinePix E500 SERVICE MANUAL US/CA/EU/EG/GE/AS/CH/JP-Model WARNING THE COMPONENTS IDENTIFIED WITH THE MARK “ ” ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR SAFETY. PLEASE REPLACE ONLY WITH THE COMPONENTS SPECIFIED ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST.
  • Page 2 FinePix E500 Service Manual SAFETY CHECK-OUT After correcting the original problem, perform the following safety check before return the product to the customer. 1. Check the area of your repair for unsoldered or poorly CAUTION: FOR CONTINUED soldered connections. Check the entire board surface PROTECTION AGAINST FIRE for solder splasher and bridges.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS FinePix E500 Service Manual TABLE CONTENTS 1.General ............4 4. Adjustment ............ 32 1-1. Product specification ..........4 4-1. Important point Adjustment when Replacing 1-2. Explanation of Terms ..........6 Major Parts ............32 1-3. Names of External Components ......7 4-2.

  • Page 4: General

    1. General FinePix E500 Service Manual 1.General 1-1. Product specification System Model Digital camera FinePix E500 Effective pixels 4.1 million pixels CCD sensor 1/2.5 inch square pixel CCD Number of total pixels: 4.23 million pixels Still image: 2304 × 1728 pixels/1600 × 1200 pixels/1280 × 960 pixels/ Number of recorded pixels 640 ×...
  • Page 5 DPC-16 (16 MB)/DPC-32 (32 MB)/DPC-64 (64 MB)/DPC-128 (128 MB)/ DPC-256 (256 MB)/DPC-512 (512 MB) AC Power Adapter AC-3V Fujifilm Rechargeable Battery 2HR-3UF Fujifilm Battery Charger with Battery BK-NH/BK-NH2 (With Euro type or UK type plug) PictureCradle CP-FXA10 Rechargeable Battery NH-10 Soft Case SC-FXE01...

  • Page 6: Explanation Of Terms

    1. General FinePix E500 Service Manual 1-2. Explanation of Terms Deactivated batteries: Leaving an Ni-MH battery unused in storage for a long period may cause a rise in the level of substances that inhibit current flow inside the battery and result in a dormant battery. A battery in this state is referred to as deactivated.

  • Page 7: Names Of External Components

    1. General FinePix E500 Service Manual 1-3. Names of External Components Power button Mode dial Shutter button Flash Viewfinder window Self-timer lamp Flash control sensor Microphone A/V OUT (Audio / Lens (Lens cover) Visual output) socket (USB) socket Cradle connection...

  • Page 8: Disassembly

    2. Disassembly FinePix E500 Service Manual 2. Disassembly 2-1. Names of internal Components R CABI ASSY BATTERY HLD ASSY TOP CABI ASSY KEY FPC ASSY MODE PWB ASSY LCD CONST MAIN PWB ASSY SUB PWB ASSY ST UNIT MIC ASSY...

  • Page 9: Removing The R Cabi Assy

    2. Disassembly FinePix E500 Service Manual 2-2. Removing the R CABI ASSY (1) Remove the 6 special screws (3ULR BT2PN M1.7 x 5N). (Use the dedicated screwdriver (ZJ00583-100).) (2) Lift off the R CABI ASSY in the direction indicated by the arrow.

  • Page 10: Removing The Lcd Const

    2. Disassembly FinePix E500 Service Manual 2-3. Removing the LCD CONST (1) Remove the screw (BTS M1.7 x 4.5) (2) Move the LCD CONST in the direction indicated by the arrow. [Notes on assembly] Confirm whether the hook in lower of LCD CONST hangs in EARTH PLATE(F CABI ASSY).

  • Page 11: Removing The Inner Block

    2. Disassembly FinePix E500 Service Manual 2-4. Removing the INNER BLOCK (1) Remove the Connector(Speaker) in the direction indicated by the arrow. (2) Remove the Connector(MIC) in the direction indicated by the arrow. (3) Remove the INNER BLOCK in the direction indicated by the arrow.

  • Page 12: Removing The Lens Const

    2. Disassembly FinePix E500 Service Manual 2-6. Removing the LENS CONST (1) Peel the EMI SHEET in the direction indicated by the arrow. (2) Remove the 2 screw (M1.7 x 4.0) (3) Remove the soldering(18point) of MAIN PWB ASSY. (4) Remove the LENS CONST in the direction indicated by the arrow.

  • Page 13: Removing The Top Cabi Assy And Mode Fpc Assy

    2. Disassembly FinePix E500 Service Manual 2-8. Removing the TOP CABI ASSY and MODE FPC ASSY (1) Remove the connector. (2) Remove the screw (M1.7 x 3.5) (3) Remove the FPC in the direction indicated by the arrow. * Detach FPC carefully because it is pasted with the double-faced tape.

  • Page 14: Removing The Battry Lid Assy

    2. Disassembly FinePix E500 Service Manual 2-10. Removing the BATTRY LID ASSY (1) Push the LOCK BUTTON. (2) Open the BATTERY LID in the direction indicated by the arrow. (3) Remove the BATT SHAFT. 2-11. Location of Sheet Parts. [Attention when Reassemble.] Do not use removed “Sheet Parts”.

  • Page 15: Schematics

    3. Schematics FinePix E500 Service Manual 3. Schematics 3-1. Cautions <Cautions when replacing parts> • Do not reuse removed parts. Always use new parts. • Note that the negative side of tantalum condensers is readily damaged by heat. • Except for chemical condensers and tantalum condensers, voltage is not displayed on condensers with a voltage resistance of 50V or less.

  • Page 16: Functions Of Primary Blocks

    3. Schematics FinePix E500 Service Manual 3-3. Functions of Primary Blocks 3-3-1. Technical Outline Equipped with a 1/2.5-inch square-pixel interline CCD (with 4.1 effective megapixels) and a 3.2x optical zoom lens. Features a new image signal processing LSI chip, called the XCS2_IC (IC202, CSP_IC), built into the MAIN PWB ASSY.

  • Page 17: Block Diagram

    3. Schematics FinePix E500 Service Manual 3-4. Block Diagram LENS CONST MAIN PWB ASSY MIC_IN AU_DA SUB PWB ASSY JTAG D_3.3V LCD_EVR PHOTO TRANSISTOR XCS2 SIP SPEAKER AUDIO MODULE FINDER BEEP,BEEP_VOL,L_MUTE IC202 XCS2 3.3V Operation BP3602 AU_CS IC901 ANALOG DEVICES AFE 3.2xZOOM LENS...

  • Page 18: Overall Connection Diagram

    3. Schematics FinePix E500 Service Manual 3-5. Overall connection Diagram...

  • Page 19: Circuit Diagrams

    3. Schematics FinePix E500 Service Manual 3-6. Circuit Diagrams 3-6-1. MAIN B to B BLOCK...

  • Page 20: Sub Block

    3. Schematics FinePix E500 Service Manual 3-6-2. SUB BLOCK...

  • Page 21: Cam Block

    3. Schematics FinePix E500 Service Manual 3-6-3. CAM BLOCK...

  • Page 22: Jack Block

    3. Schematics FinePix E500 Service Manual 3-6-4. JACK BLOCK...

  • Page 23: Motor Block

    3. Schematics FinePix E500 Service Manual 3-6-5. MOTOR BLOCK...

  • Page 24: Audio Block

    3. Schematics FinePix E500 Service Manual 3-6-6. AUDIO BLOCK 3-6-7. KEY FPC BLOCK...

  • Page 25: Lcd Block

    3. Schematics FinePix E500 Service Manual 3-6-8. LCD BLOCK 3-6-9. MODE FPC BLOCK...

  • Page 26: Strobe Block

    3. Schematics FinePix E500 Service Manual 3-6-10. STROBE BLOCK 3-6-11. XE BLOCK...

  • Page 27: Mounted Parts Diagrams

    3. Schematics FinePix E500 Service Manual 3-7. Mounted Parts Diagrams 3-7-1. MODE FPC ASSY 3-7-2. XE ASSY...

  • Page 28: Main Pwb Assy

    3. Schematics FinePix E500 Service Manual 3-7-3. MAIN PWB ASSY <SIDE A>...
  • Page 29 3. Schematics FinePix E500 Service Manual <SIDE B>...

  • Page 30: Sub Assy

    3. Schematics FinePix E500 Service Manual 3-7-4. SUB ASSY <SIDE A>...
  • Page 31 3. Schematics FinePix E500 Service Manual <SIDE B>...

  • Page 32: Adjustment

    4. Adjustment FinePix E500 Service Manual 4. Adjustment 4-1. Important point Adjustment when Replacing Major Parts When replacing the MAIN PWB or LENS CONST or SUB PWB or STROBE or LCD CONST, adjust the items marked with in the table below. (Other part replacements need not be adjusted. )

  • Page 33: Calibration Method Of Pattern Box

    4. Adjustment FinePix E500 Service Manual 4-4. Calibration method of pattern box < Use the pattern box for CAMERA adjustment > Turn on the power supply in the pattern box. Afterwards, wait for about ten minutes so that the source of Pattern BOX light may stabilize.

  • Page 34: Installation Of Dsc Jig Driver

    4. Adjustment FinePix E500 Service Manual <Step3> My Computer The folder named ZJ00827-100 can be made by defrosting without specifying anything <Fig. 4-5-2>. 3.5inch FD(A:) Then, copy the folder named FinePixE500_W in this folder in (C:) C drive <Fig. 4-5-3>.

  • Page 35: Initial Settings Of The Adjustment Software

    4. Adjustment FinePix E500 Service Manual 4-6. Initial Settings of the Adjustment Software * The initial settings are already written in the "FFW.ini" file, therefore perform the following procedure to the letter. Note that, if you change file names, the software will not start up.
  • Page 36 4. Adjustment FinePix E500 Service Manual <Step 3> Select the "EVR & Comm" tab ([1] in Fig. 4-6-3) in the "Customize" dialog box that appears. Set the "EVR" items ([2] in Fig. 8) as follows. Item Details etc (-V2) Check...
  • Page 37 4. Adjustment FinePix E500 Service Manual Cautions When Adjusting *1) FinePix E500 cannot adjust the EVR data reading and writing.(Details are right tables.) Menu Command Details Operation Start Program start *2) End Setting returns the camera from the Jig mode to...

  • Page 38: Starting The Adjustment Software

    <Fig. 4-7-1> —> The [Cautions When Using the Adjustment Software] screen appears. <Step 3> Cautions When Using the FinePix E500 Adjustment Software 1. Adjust as follows after replacing parts. [F1]Battery [F3]LCD [F4]CCD Defect Correction [F5]Camera [F6]AF [F7]Flash [F8]Firmware Download [F11]Video [F12]End Setting | –...
  • Page 39 4. Adjustment FinePix E500 Service Manual <Step 4> FinePix E500 Jig Mode Setup Procedure 1. When execute the LCD adjustment, Set the VIDEO output to the NTSC mode before starting the adjustment software. 2. When adjusting the [battery voltage], supply power (3.0+-0.02V) by using [FX-E500 Battery JIG].
  • Page 40 4. Adjustment FinePix E500 Service Manual <Step 6> FinePix E500_W adjustment item select screen 0. [ R ] : Flash memory reset *Only use for when the MAIN PWB has been replaced. 1. [ F 5 ] : Camera Adjustment 2.

  • Page 41: R] : Flash Memory Reset

    4. Adjustment FinePix E500 Service Manual 4-8. [R] : Flash Memory Reset <Note> Only reset the flash memory when the SUB PWB ASSY has been replaced. When the SUB PWB ASSY has been replaced, always reset the flash memory before making any other adjustments.
  • Page 42 4. Adjustment FinePix E500 Service Manual <Step 2> Flash memory reset (EVR) < Attention > When the SUB PWB ASSY has been replaced, always reset the flash memory before making any other adjustments. Only reset the flash memory when the SUB PWB ASSY has been replaced.

  • Page 43: F5] : Camera Adjustment

    4. Adjustment FinePix E500 Service Manual 4-9. [F5] : CAMERA Adjustment (shutter adjustment, adjustment for reduced aperture sensitivity, ISO sensitivity adjustment, white balance adjustment, AE adjustment, offset level adjustment) <Setup for Camera Adjustment> Maximum 60mm Maximum 5mm Maximum50mm Centerline Pattern box Filter (LB140) <Step 1>...
  • Page 44 4. Adjustment FinePix E500 Service Manual <Step 3> Shutter adjustment (1) Set the distance between the camera and pattern box. (2) The LB140 filter is not placed in front of the lens. When preparations are complete, press the [Enter] key.
  • Page 45 4. Adjustment FinePix E500 Service Manual <Step 5> WB adjustment without filter (1) Set the distance between the camera and pattern box. (2) Remove the LB140 filter from front of the lens. When preparations are complete, press the [Enter] key.

  • Page 46: F4] Ccd Defect Correction Adjustment

    4. Adjustment FinePix E500 Service Manual 4-10. [F4] CCD Defect Correction Adjustment < Setup for CCD defect correction Adjustment> Maximum 30mm Centerline Pattern box <Step 1> Select [F4] CCD Defect Correction Adjustment on the [Adjustment Items Select] screen. —> The [CCD Defect Correction Adjustment Preparation] screen appears.
  • Page 47 4. Adjustment FinePix E500 Service Manual <Step 3> —> Write the adjustment data to the flash ROM when adjustment has been completed correctly. CCD Defect Correction Adjust the distance between the camera and pattern box. When preparations are complete, press the [Enter] key.

  • Page 48: F6] : Af Adjustment

    4. Adjustment FinePix E500 Service Manual 4-11. [F6] : AF Adjustment <Setup for AF Adjustment> (1) Adjust the distance between the Siemens star chart and the lens front of the camera to "614+-5mm" (2) Illuminate the AF chart with a light source. Ensure that the brightness at the surface of the AF chart is between 9.0 and 12.0EV.
  • Page 49 4. Adjustment FinePix E500 Service Manual <Step 3> AF Adjustment (1) Place the Siemens star chart at a distance of 614+-5mm from the lens-face of the conversion lens. (2) Place the conversion lens at a distance of 14+-2mm from the lens-face of the lens.
  • Page 50 4. Adjustment FinePix E500 Service Manual <Step 5> The AF adjustment is completed. Press the [Enter] key to return to the Adjustment Items Select Screen. <Fig. 4-11-4>...

  • Page 51: F7] : Flash Adjustment

    4. Adjustment FinePix E500 Service Manual 4-12. [F7] : Flash Adjustment <Setup for Flash Adjustment> (1) As flash adjustment is readily affected by external light, ensure that the vicinity of the gray chart is very dark. (2) Ensure that distance is measured from the front of the camera during flash adjustment.
  • Page 52 4. Adjustment FinePix E500 Service Manual <Step 3> Flash Adjustment (1) Adjust brightness so that the periphery of the gray chart is as dark as possible. (2) Adjust the camera so that the entire chart is shown on the LCD monitor.

  • Page 53: F1] : Battery Voltage Adjustment

    4. Adjustment FinePix E500 Service Manual 4-13. [F1] : Battery Voltage Adjustment <Setup for Flash Adjustment> (1) When adjusting the battery voltage, supply power (3V) to the camera from the [FxE500 Batt. Jig] before setting the jig mode. (2) Always measure input voltage in the vicinity of the DC IN terminal.
  • Page 54 4. Adjustment FinePix E500 Service Manual <Step 2> Run the adjustment in accordance with the instructions on the screen. Battery Voltage Adjustment <Preparations> 1. Check that the Fx-E500 BATT. JIG and the camera are connected. *If not, return to the Jig Mode Setup screen, and connect the Fx-E500 BATT.
  • Page 55 4. Adjustment FinePix E500 Service Manual <Step 4> Battery Voltage Adjustment (1) Supply 2.32V (+0.02V/-0.00V). When preparations are complete, press the [Enter] key. Result= (2) Supply 2.24V (+0.02V/-0.00V). When preparations are complete, press the [Enter] key. <Fig. 4-13-3> —> The [3.00V Input] screen appears.
  • Page 56 4. Adjustment FinePix E500 Service Manual <Step 6> The BATTERY adjustment is completed. Press the [Enter] key to return to the Adjustment Item selection Screen. <Fig. 4-13-5>...

  • Page 57: F11] : Video Adjustment

    4. Adjustment FinePix E500 Service Manual 4-14. [F11] : Video Adjustment <Setup for Video Adjustment> (1) Set up the PCI-2764C board in the computer as explained in the instructions for the video adjustment jig. (2) If the waveform of the brightness signal (Y) or color signal (C) does not appear in the “WAVE No. 0” window during adjustments, check the connections of the video adjustment jig.
  • Page 58 4. Adjustment FinePix E500 Service Manual <Step 2> Run the adjustment in accordance with the instructions on the screen. VIDEO Adjustment < VIDEO Adjustment Preparations > (1) Connect the camera and video adj. jig with the video cable. (2) Confirm Video jig is connected with the video cable.

  • Page 59: F3] : Lcd Adjustment

    4. Adjustment FinePix E500 Service Manual 4-15. [F3] : LCD Adjustment <Setup for LCD Adjustment> (Set up the PCI-2747C board in the computer as explained in the instructions for the LCD adjustment Jig. FinePix E500/E510 PCI-2747C AC-5VW DC JACK * Confirm the VIDEO output is NTSC mode before starting the adjustmen.
  • Page 60 4. Adjustment FinePix E500 Service Manual <Step 3> LCD Adjustment < LCD Adjustment Preparations > (1) Confirm the VIDEO output is NTSC mode before starting the adjustment. (2) Adjust so that the center of the camera LCD monitor is in the LCD adjustment jig the sensor.

  • Page 61: F8] : Firmware Download

    4. Adjustment FinePix E500 Service Manual 4-16. [F8] : Firmware Download Attention : When the download of the firmware is needed, FUJI SERVICE BULLETIN is contacted from FTYO/QA. Till then, disregard this item. <Setup for Firmware Download> FinePix E500/E510 DC JACK <Step 1>...
  • Page 62 4. Adjustment FinePix E500 Service Manual <Step 2> Run the adjustment in accordance with the instructions on the screen. Firmware Download LED lights to orange while downloading the firmware. Do not turn off the power while downloading the firmware. c:\FinePixE500_W\Firmwear\SU541.bin Press the ENTER Key to start download.

  • Page 63: F12] : End Setting

    3. USB ID write details 1) USB ID write requires that the USB device (in this case FinePix E500) be unique throughout the world. For this reason, each device has a unique ID as determined by the USB standard. If multiple devices with the same USB ID are connected to a single PC, the PC will be unable to identify each USB device, thus preventing operation.
  • Page 64 4. Adjustment FinePix E500 Service Manual <Step 1> Select [F12] End Setting on the [Adjustment Items Select] screen. —> The [End Setting Description] screen appears. <Step 2> Run the adjustment in accordance with the instructions on the screen. End Setting...
  • Page 65 4. Adjustment FinePix E500 Service Manual <Step 4> Destination setting The destination is selected from an undermentioned list, according to third character from left side of the serial number. The third character <A> FinePix E500 J-model 0 to 9 <B> FinePix E500 US/CA-model A to H,J,K <C>...
  • Page 66 <Step 6> USB ID Selected USA. Press the [Enter] key! <Fig. 4-17-5> —> The [FinePix E500 Adjustment End] screen appears. <Step 7> FinePix E500 Adjustment completed. 1) Remove USB cable from the camera. 2) Press the [Enter] key. --> The adjustment software returns to the Jig mode setup screen after press the [Enter] key.

  • Page 67: Inspection

    5. Inspection FinePix E500 Service Manual 5. Inspection 5-1. Required Measuring Equipment Measuring equipment Remarks Power supply AC adapter (AC-3V), Regurated power supply Digital voltmeter For general use Ammeter For general use (able to measure 1mA or less) FX-E500 Batt. Jig...

  • Page 68: Inspection And Factory Settings

    5. Inspection FinePix E500 Service Manual 5-3. Inspection and Factory Settings Sequemnce Item Mode Preparations for adjustment Method of adjustment Measuring Measurement points (measurement points, subject, other) (VRs, waveforms, required values) equipment and jigs (VRs, positions) Check appearance Visual check of camera No dents exterior of camera.
  • Page 69 5. Inspection FinePix E500 Service Manual Sequemnce Item Mode Preparations for adjustment Method of adjustment Measuring Measurement points (measurement points, subject, other) (VRs, waveforms, required values) equipment and jigs (VRs, positions) Battery low check Auto (1) Connect FX-E500 Batt. jig...

  • Page 70: Parts List

    6. Parts List FinePix E500 Service Manual 6. Parts List 6-1. Packing and Accessories 6-1-1. US-model A111 A110 A112 A118 A119 A123 A121 A122 A114 A120 A113 A103 A105 A104 A101 A117 A115 A106 A116 A107 A108 A109 A102 Ref No.

  • Page 71: Ca-Model

    6. Parts List FinePix E500 Service Manual 6-1-2. CA-model A111 A110 A112 A122 A123 A120 A121 A114 A118 A119 A113 A103 A105 A104 A101 A117 A115 A106 A116 A107 A108 A109 A102 Ref No. Parts No. Description Comment A101 FZ05967-100 UNITARY U.BOX...

  • Page 72: Eu-Model

    6. Parts List FinePix E500 Service Manual 6-1-3. EU-model A111 A110 A112 A124 A125 A126 A121 A122 A123 A114 A118 A119 A120 A113 A103 A105 A104 A101 A117 A115 A106 A116 A107 A108 A109 A102 Ref No. Parts No. Description Comment Ref No.

  • Page 73: Eg-Model

    6. Parts List FinePix E500 Service Manual 6-1-4. EG-model A111 A110 A112 A118 A121 A120 A114 A119 A113 A103 A105 A104 A101 A117 A115 A106 A116 A107 A108 A109 A102 Ref No. Parts No. Description Comment A101 FZ05967-100 UNITARY U.BOX...

  • Page 74: Ge-Model

    6. Parts List FinePix E500 Service Manual 6-1-5. GE-model A111 A110 A112 A120 A119 A114 A118 A113 A103 A105 A104 A101 A117 A115 A106 A116 A107 A108 A109 A102 Ref No. Parts No. Description Comment A101 FZ05967-100 UNITARY U.BOX A102...

  • Page 75: As-Model

    6. Parts List FinePix E500 Service Manual 6-1-6. AS-model A111 A110 A112 A120 A119 A114 A118 A113 A103 A105 A104 A101 A117 A115 A106 A116 A107 A108 A109 A102 Ref No. Parts No. Description Comment A101 FZ05967-100 UNITARY U.BOX A102...

  • Page 76: Ch-Model

    6. Parts List FinePix E500 Service Manual 6-1-7. CH-model A111 A110 A112 A114 A118 A113 A103 A104 A101 A115 A106 A107 A108 A109 A102 Ref No. Parts No. Description Comment A101 FZ05967-500 UNITARY BOX CH A102 FZ05955-100 SHEET MOLD A103...

  • Page 77: Jp-Model

    6. Parts List FinePix E500 Service Manual 6-1-8. JP-model A112 A111 A110 A116 A119 A118 A114 A117 A113 A103 A104 A101 A115 A106 A105 A107 A108 A109 A102 Ref No. Parts No. Description Comment A101 FZ05954-100 UNITARY BOX J A102...

  • Page 78: Cabi Front Block

    6. Parts List FinePix E500 Service Manual 6-2. Cabi Front block 6-2-1. US/CA/EU/EG/GE/AS/CH-model M227 M231 M222 M230 M223 M215 M237 M229 M224 M232 M233 M225 M216 M245 M243 M240 M226 M234 M235 M229 M228 M241 M221 M221 M242 M220 M214...

  • Page 79: Jp-Model

    6. Parts List FinePix E500 Service Manual 6-2-2. JP-model M227 M231 M222 M230 M223 M215 M237 M229 M224 M232 M233 M225 M216 M245 M243 M240 M226 M234 M235 M229 M228 M241 M221 M221 M242 M220 M214 UL TAPE2 M221 M219...

  • Page 80: Electrical Parts

    6. Parts List FinePix E500 Service Manual 6-3. Electrical parts [NOTE] The components indicated by mark are critical for safety. * Due to standardization, replacement in the parts list may be different from the When indicated parts by reference number, please include parts list specified in the circuit or the components used on the set.

  • Page 81: Appendix

    7. Appendix FinePix E500 Service Manual 7. Appendix 7-1. Function of display for Firmware Version The function to display the version is installed in FinePix E500. The version the camera equipped with of the firmware can be displayed only by operating the main body of the camera.

  • Page 82: List Of Related Technical Updates Issued

    7. Appendix FinePix E500 Service Manual 7-2. List of Related Technical Updates Issued To ensure that after-sales srevice is performed accuratety, keep a record here of the technical updates issued that cover this device. Technical Update No. Date Title Details/Other...
  • Page 83 FUJI PHOTO FILM CO., LTD. 26-30, Nishiazabu 2-chome, Minato-ku, Tokyo 106-8620, Japan.
