Benefits You Can Depend On
• Quiet, comfortable warmth delivered with a large
fan that gently circulates air
• Safe for you and your family
Peace of mind with automatic high temperature
shutoff feature
• Improve air circulation and add comfort to your
home in off-season with a fan only switch
• Common sense components designed with you in
mind
1. NO sharp edges
2. Corrosion resistant
3. Easy to install
• Your Cadet heater has been thoroughly tested
and is guaranteed with a 2 year extended
warranty
Wall Can Top
14
/
"
1
8
35.88cm
15"
38.1cm
Side
Grill Front
16¾"
/
"
13
16
42.54cm
2.06
www.cadetheat.com
4"
10.16cm
Wall Can Side
21"
/
19
"
1
8
53.34cm
48.58cm
SAVE THESE INSTRUCTIONS
Tel: 360-693-2505
NLW Heater
Owner's Guide
http://www.cadetheat.com/products/wall-heaters/NLW
Model w/
Line
Thermostat and
Voltage
Fan Switch
NLW208T
208
NLW308T
NLW408T
NLW202T
NLW302T
(2)
240
NLW402T
NLW452T
(1) Standard built-in thermostat is double pole and provides "OFF" position.
(2) 240 volt models can be used at 208 volts. Wattage equals 75% of 240v rated
wattage.
New installation requires wall can (sold separately): Model Numbers NLWC
Recess Mount or NLWCS Surface Mount.
NLW with Thermostat
Wall Thermostat Not Required
Built-in Thermostat
Rating Label
TOOLS REQUIRED:
• Phillips Screwdriver
• Straight Screwdriver
• Wire Strippers
PO Box 1675 Vancouver, WA
NLW Models
Watts
(1)
2000
3000
4000
2000/1500
3000/2250
4000/3000
4500/3375
• Utility Knife
• (4) 1 1/2" Wood Screws
• Insulated Wire Connectors
• (1) Strain Relief Connector
98668-1675
Amps
9.62
14.42
19.23
8.33/7.21
12.5/10.82
16.67/14.42
18.75/16.23
Reset Button
Page 1
