FIG. 40 ELECTRICAL 2
REF.
PART NO. DESCRIPTION
NO.
1 3C1–H591A–10 ENGINE CONTROL UNIT ASSY
2 3C1–H5546–00 BAND
3 3C1–H2540–00 NEUTRAL SWITCH ASSY
4 90430–10148 GASKET
5 1S7–H5790–00 THERMOSENSOR ASSY
6 90430–12801 GASKET
7 3C1–H1960–00 RECTIFIER & REGULATOR ASSY
8 95807–06020 BOLT, FLANGE
9 5TP–H1940–00 STARTER RELAY ASSY
10 3RS–H3936–00 BAND, SWITCH CORD
11 3C1–H2576–00 SENSOR, LEAN ANGLE
12 97707–40012 SCREW, TAPPING
13 90201–04804 WASHER, PLATE
14 3C1–H1950–00 RELAY ASSY
15 3C1–H1965–00 CONDENSER, SMOOTHING
16 90464–36800 CLAMP
17 3C1–H2599–00 COVER, CONNECTER
18 3C1–H2589–00 PROTECTER, WIRE HARNESS
19 2D5–H3350–00 FLASHER RELAY ASSY
20 3C1–H3371–00 HORN
21 97007–06012 BOLT
22 92907–06600 WASHER, PLATE
23 3C1–H5130–00 REAR REFLECTOR ASSY
24 95602–05100 NUT, U
25 90201–05725 WASHER, PLATE
50
REMARKS
1
1
1
1
1
1
1
2
1
2
1
2
2
2
1
6
1
1
1
1
1
1
1
1
1
