PEx16-1: PCI-Express x16 Slot
- PCI-Express 1.0a compliant.
Maximum theoretical realized bandwidth of 4GB/s simultaneously per
-
direction, for an aggregate of 8GB/s totally.
PEx1_1/PEx1_2: PCI-Express x1 slots
- PCI-Express 1.0a compliant.
- Data transfer bandwidth up to 250MB/s per direction; 500MB/s in total.
- PCI-Express supports a raw bit-rate of 2.5Gb/s on the data pins.
- 2X bandwidth over the traditional PCI architecture.
PCI1~PCI4: Peripheral Component Interconnect Slots
This motherboard is equipped with 4 standard PCI slots. PCI stands for
Peripheral Component Interconnect, and it is a bus standard for expansion
cards. This PCI slot is designated as 32 bits.
PEX16-1
PEX1_1
PEX1_2
PCI1
PCI2
PCI3
PCI4
TForce 550 SE
