User Manual
Networking & Communication
5 Mega-Pixel 20M IR Vari-Focal Dome IP Camera
This document contains confidential proprietary information and is property of PLANET. The contents of this
document should not be disclosed to unauthorized persons without the written consent of
Change History:
Revision
Version 1.0
Author
Brandon Wang
Reviewed by:
Jonas Yang
Product Specification
ICA-4500V
Version 1.0
Date
2013/3/1
Author
Brandon Wang
Editor:
Brandon Wang
Approved by:
Tom Shih
Product Specification of ICA-4500V
PLANET.
Change List
Initial release
Advertisement
Table of Contents
Related Manuals for Planet ICA-4500V
Summary of Contents for Planet ICA-4500V
-
Page 1: Change History
5 Mega-Pixel 20M IR Vari-Focal Dome IP Camera ICA-4500V Version 1.0 This document contains confidential proprietary information and is property of PLANET. The contents of this document should not be disclosed to unauthorized persons without the written consent of PLANET. -
Page 2: Product Description
The ICA-4500V incorporates the Mega-Pixel Vari-Focal Lens from TAMRON, which has the option of selecting a high millimeter setting for narrow viewing fields or a low millimeter setting for wider viewing fields. The ICA-4500V provides high quality images under all lighting conditions. -
Page 3: Product Features
Gigabit Ethernet Transmission, giving a user the utmost in bandwidth flexibility and storage efficiency. The ICA-4500V is ONVIF-compliant and therefore interoperable with other manufacturer’s products, it’s also included 64-CH central management software; the ICA-4500V is indisputably the top choice for reliable and high performance surveillance. 2. PRODUCT FEATURES Camera 1/3"... -
Page 4: Product Specification
Product Specification of ICA-4500V Networking & Communication Confidential Analog video (BNC) output, works with conventional video devices such as TV Monitors, analog DVRs 3. PRODUCT SPECIFICATION 3.1 COMPOMENT SPECIFICATIONS CPU: Cortex A9 based SoC RAM: 256MB Flash: 16MB LAN Chipset: RTL8211... - Page 5 Product Specification of ICA-4500V Networking & Communication Confidential Streaming over UDP, TCP, HTTP, or HTTPS M-JPEG streaming over HTTP (server push) Supports 3GPP mobile surveillance (MPEG4) Controllable frame rate and bandwidth Constant and variable bit rate (MPEG4/H.264) Audio Audio Streaming Two-Way Audio RTSP: G.711 64kbps, G.726 32kbps...
-
Page 6: Physical Specification
Product Specification of ICA-4500V Networking & Communication Confidential 3.2 PHYSICAL SPECIFICATION Dimension Φ152mm x 109mm (Φ x L) Weight 635g 20M IR LED x 12 F3.3~12mm Vari-Focal Lens Light Sensor Item Description Lens set. Keep this area clean to keep excellent video quality. - Page 7 Product Specification of ICA-4500V Networking & Communication Confidential Descriptions for I/O cable set: Interface Description The input power is DC 12V, 1A. Note：ONLY use package power adapter supplied with the internet. DC Power Otherwise, the product may be damaged. Connect to PC or Hub/Switch.
-
Page 8: Environmental Specification
Product Specification of ICA-4500V Networking & Communication Confidential Terminal block for I/O connectors: Name Cable Color Function 12VDC Brown/White DC 12V (50mA maximum) Blue/White Purple/White RS485 data + Gray RS485 data - Green/White Digital signal input Orange/White Digital signal output 3.3 ENVIRONMENTAL SPECIFICATION... -
Page 9: Appendix A: Default Setting
Product Specification of ICA-4500V Networking & Communication Confidential APPENDIX A: DEFAULT SETTING Default DHCP Client 192.168.0.20 – if no DHCP existed in the network Default IP Address admin Default Login User Name admin Default Login Password Filename: PS-ICA4500V_v1.doc Page 9 of 9...
