User Manual
Table of Contents
1. Introduction .........................................................................2
1.1 Before Installation .................................................................... 2
1.2 System Requirements ............................................................. 2
2. Hardware Installation ..........................................................3
2.1 ICA-601 - Indoor Speed Dome Internet Camera ..................... 3
2.1.1 Package Content ............................................................ 3
2.1.2 Physical Installation ........................................................ 4
2.2 ICA-651 - Outdoor Speed Dome Internet Camera .................. 8
2.2.1 Package Content ............................................................ 8
2.2.2 Physical Installation ........................................................ 9
3. Identification of Cables ......................................................10
4. Initial Utility Installation and operation ...............................12
4.1 IPWizard Installation .............................................................. 12
4.2 Wizard function ...................................................................... 15
4.3 Username and Password ...................................................... 16
5. Further Configuration ........................................................16
Advertisement
Table of Contents
Related Manuals for Planet ICA-601
Summary of Contents for Planet ICA-601
-
Page 1: Table Of Contents
1.1 Before Installation ..............2 1.2 System Requirements ............. 2 2. Hardware Installation ............3 2.1 ICA-601 - Indoor Speed Dome Internet Camera ..... 3 2.1.1 Package Content ............3 2.1.2 Physical Installation ............4 2.2 ICA-651 - Outdoor Speed Dome Internet Camera ....8 2.2.1 Package Content ............ -
Page 2: Introduction
1. Introduction Thank you for purchasing the ICA-601 / ICA-651. It is versatile and high image solution of the perfect outdoor surveillance application for day and night. The ICA-601 / ICA-651 is also a stand-alone camera system with a built-in processor and web server that provides highest quality video and system performance. -
Page 3: Hardware Installation
2. Hardware Installation 2.1 ICA-601 - Indoor Speed Dome Internet Camera 2.1.1 Package Content User’s Manual ICA-601 x 1 Quick Guide x 1 and Utility CD x 1 Leaf Spring x 3 Telephone box x 1 Screw x 3 Power Adapter x 1... -
Page 4: Physical Installation
2.1.2 Physical Installation 1. During the installation, please take care and avoid crash. That may cause the de- vice damage. Note 2. Please make sure the hardware had been located on the cell or roof properly. If the hardware drops down, it is possible make someone hurt. Please check the hardware again after the installation. - Page 5 3. Push this outer cover into the ceiling. Check if the leaf springs are clipped to ceiling tight- 4. Find safety hook inside the outer cover. Use the safety hook hanging the inner speed dome cover 5. Have all the cables across the outer cover...
- Page 6 6. Take away 3pcs screws inside the accessory box. Use the screws to fix the inner cover and outer cover. 7. Check speed dome main body. Fit in the pin into pin hole of base plate. Drive 2pcs screws until the speed dome fits the plate tightly and solidly...
- Page 7 8. Follow anti-clockwise to fix the hemisphere cover onto speed dome. 9. Now the ICA-601 is fixed on the ceiling.
-
Page 8: Ica-651 - Outdoor Speed Dome Internet Camera
2.2 ICA-651 - Outdoor Speed Dome Internet Camera 2.2.1 Package Content User’s Manual ICA-651 x 1 Quick Guide x 1 and Utility CD x 1 Cable tube x 1 Telephone box x 1 Wrench x 2 Power Adapter x 1 Software CD x 1... -
Page 9: Physical Installation
2.2.2 Physical Installation 1. During the installation, please take care and avoid crash. That may cause the de- vice damage. Note 2. Please make sure the hardware had been properly locate on the wall. If the hard- ware drops down, it is possible make someone hurt. Please check the hardware again after the installation. -
Page 10: Identification Of Cables
Please use Category 5 “straight through” cable to connect the ICA-601 / ICA-651 to a 100Mbps Fast Ethernet network switch or hub. Note: In case you need to connect the device to PC or notebook directly, you should use cross over cable instead. - Page 11 5. Line in (audio in) Connect an audio input source to the ICA-601 / ICA-651. 6. Line out (audio out) Connect a loud speaker to the ICA-601 / ICA-651. This function is for voice alerting and two-way audio.
-
Page 12: Initial Utility Installation And Operation
4. Initial Utility Installation and operation 4.1 IPWizard Installation 1. Insert the bundled CD into the CD-ROM drive to launch the autorun program. Once com- pleted, a welcome menu screen will appear. 2. Click the “IPWizard” hyperlink; you will see the InstallShield Wizard dialog box as below. Note: If the welcome screen does not appear, click “Start”... - Page 13 4. Please click “Next” to install with original settings, or you may click “Change…” button to modify the install folder then press “Next” to continue. 5. Please click “Install” to start the installation.
- Page 14 6. Please click “Finish” to complete the installation 7. Please double-click the IPWizard icon on the desktop then you will see the utility screen. 8. Press “Search” button. IPWizard will list all IP Cameras in your LAN environment. Please check next section.
-
Page 15: Wizard Function
4.2 Wizard function Note: Please select your camera and press “Wizard”. The utility featured of “Wizard” function to help user to initial camera. User can setup IP address, username and password step by step. Please enter User Name and Password. Default Username is: admin, leave password blank. Then click “Submit”. -
Page 16: Username And Password
4.3 Username and Password You may change the ID and assign a new password to your ICA-601 / ICA-651 or keep the original and press “Next” to continue. You can select “Static IP” and enter the IP settings. Or select “DHCP ON” when there is a DHCP server in your network.
