Ford Tourneo Connect Owner's Handbook Manual
  1. Manuals
  2. Brands
  3. Ford Manuals
  4. Automobile
  5. TOURNEO CONNECT
  6. Owner's handbook manual

Ford Tourneo Connect Owner's Handbook Manual

Hide thumbs Also See for Tourneo Connect:

Advertisement

Quick Links

Download this manual
Feel the difference
FordTourneoConnect
FordTransitConnect
Owner's handbook

Advertisement

loading

Related Manuals for Ford Tourneo Connect

Summary of Contents for Ford Tourneo Connect

  • Page 1 Feel the difference FordTourneoConnect FordTransitConnect Owner's handbook...
  • Page 2 This publication, or part thereof, may not be reproduced nor translated without our approval. Errors and omissions excepted. © Ford Motor Company 2010 All rights reserved. Part number: (CG3526en) 09/2010 20101022111434...
  • Page 3 Table of contents Introduction Alarm About this handbook........5 Principle of operation......30 Symbols glossary........5 Arming the alarm........30 Parts and accessories......6 Disarming the alarm........30 Quick start Steering wheel Quick start...........7 Adjusting the steering wheel....31 Audio control..........31 Child safety Voice control..........32 Child seats..........11 Wipers and washers Booster cushions........12 Child seat positioning......13...
  • Page 4 Table of contents Warning lamps and indicators....52 Fuel and refuelling Audible warnings and indicators..54 Safety precautions........83 Fuel quality - Diesel.........83 Information displays Catalytic converter........83 General information........56 Fuel filler flap..........84 Trip computer..........58 Refuelling..........84 Personalised settings......59 Fuel consumption........84 Information messages......60 Technical specifications......84 Climate control Transmission Principle of operation......63...
  • Page 5 Table of contents Repairing minor paint damage....115 Towing Towing a trailer........96 Vehicle battery Using booster cables......116 Driving hints Running-in..........97 Wheels and tyres Cold weather precautions.....97 General information.......117 Changing a road wheel......117 Emergency equipment Tyre care..........122 First aid kit..........98 Using winter tyres........122 Warning triangle........98 Using snow chains........122 Fuses...
  • Page 6 Table of contents Appendices Type approvals........151 Electromagnetic compatibility....151...
  • Page 7 ABOUT THIS HANDBOOK protects the passengers against allergen particles in the outdoor air. Thank you for choosing Ford. We recommend that you take some time to For more information, contact TÜV at get to know your vehicle by reading this www.tuv.com.
  • Page 8 We recommend that you ask your Ford Dealer for advice on parts and accessories suitable for your vehicle.
  • Page 9 Quick start QUICK START Instrument panel overview Left-hand drive E115781...
  • Page 10 Quick start Right-hand drive E115782 Air vent. See Climate control (page 63). Headlamp levelling control. See Headlamp levelling (page 40). Direction indicators. See Lighting (page 38). Instrument cluster. See Gauges (page 50). Information display. See (page 56). Wiper lever. See Wipers and washers (page 34). Hazard warning flasher switch.
  • Page 11 Turn the top of the key towards the front E87379 of the vehicle to unlock the front doors. Unlock Tourneo Connect Lock Turn the top of the key towards the front Luggage compartment lid of the vehicle to unlock the front and unlock sliding doors.
  • Page 12 Quick start Tourneo Connect Press button A once to unlock the front and sliding doors. Press button A twice to unlock all doors. Press button C once to unlock the luggage compartment lid. All vehicles Press button B once to lock all doors and the luggage compartment lid.
  • Page 13 Child safety CHILD SEATS WARNINGS Do not leave unattended children in your vehicle. If your vehicle has been involved in an accident, have the child restraints checked by properly trained technicians. Note: Mandatory use of child restraints E133140 varies from country to country. Only child restraints certified to ECE-R44.03 (or later) have been tested and approved for use in your vehicle.
  • Page 14 Child safety Child safety seat CAUTION When using a child seat on a rear seat, make sure that the child seat rests tightly against the vehicle seat. It may be necessary to lift or remove the head restraint. See Head restraints (page 74).
  • Page 15 Booster cushion (Group 3) CHILD SEAT POSITIONING WARNINGS Please consult your Dealer for the latest details relating to Ford recommended child seats. When using a forward facing child seat on a rear seat, always remove the head restraint from that seat.
  • Page 16 ISOFIX child restraints. At time of publishing the recommended Group O+ ISOFIX baby safety seat is the Britax Romer Baby Safe. Please consult your Dealer for the latest details relating to Ford recommended child seats. At time of publishing the recommended Group 1 ISOFIX child seat is the Britax Romer Duo.
  • Page 17 Child safety ISOFIX ANCHOR POINTS WARNINGS Do not attach a tether strap to Tourneo Connect anything other than the correct tether anchor point. Always use the top tether anchor point at the base of the second row seatback when the third row is occupied.
  • Page 18 Child safety Note: Child safety locks are only fitted to sliding doors. E75766 Lock Unlock...
  • Page 19 Occupant protection Driver and front passenger airbags PRINCIPLE OF OPERATION Airbags WARNINGS Do not modify the front of your vehicle in any way. This could adversely affect deployment of the airbags. Original text according to ECE R94.01: Extreme Hazard! Do not use a rearward facing child restraint on a seat protected by an airbag in front of E74302...
  • Page 20 Occupant protection The side airbags will deploy during Status after a collision significant lateral collisions. Only the airbag WARNING on the side affected by the collision will deploy. The airbags will inflate within a few Seat belts subjected to strain, as a thousandths of a second and deflate on result of an accident, should be contact with the occupants, thus...
  • Page 21 Occupant protection Rear seat belts SEAT BELT HEIGHT ADJUSTMENT E75564 WARNING In order to ensure that the centre belt works properly, the rear seatback must be correctly E68901 engaged. SEAT BELT REMINDER Make sure that each seat belt uses the correct buckle.
  • Page 22 Occupant protection USING SEAT BELTS DURING PREGNANCY E71313 The key switch and the airbag deactivation lamp are located in the E68587 instrument panel. WARNING If the airbag warning lamp in the Position the seat belt correctly for instrument cluster illuminates your safety and that of your unborn intermittently, it means that there is a child.
  • Page 23 Occupant protection Enabling the passenger airbag WARNING For the adult restraint system to perform as intended, make sure that the airbag is ON. After removing the child restraint from the front, make sure that you turn the key switch to position B.
  • Page 24 Keys and remote controls 2. Turn the ignition to position 0. A tone GENERALINFORMATIONON sounds to indicate that it is now RADIO FREQUENCIES possible to programme the remote controls for ten seconds. CAUTIONS 3. Press any button on a new remote The radio frequency used by your control.
  • Page 25 Keys and remote controls E74386 1. Insert a screwdriver into the recess on the back of the key and remove the key blade. 2. Release the retaining clips with the screwdriver and separate the two halves of the remote control. CAUTION Do not touch the battery contacts or the printed circuit board with the...
  • Page 26 Note: You can only centrally lock the doors if they are all closed. Tourneo Connect Double locking Turn the top of the key towards the front of the vehicle to unlock the front doors WARNING and sliding doors.
  • Page 27 45 seconds of unlocking the doors with the remote Tourneo Connect control. The door locks and the alarm will return to their previous state. Press button A once to unlock the front doors and sliding doors.
  • Page 28 B. If single stage unlocking is enabled all doors will be unlocked. Opening the doors Sliding door Note: On Tourneo Connect, the right-hand sliding door is inhibited from opening fully when the fuel filler flap is unlocked and open.
  • Page 29 Locks Right-hand rear door E74705 Outside Inside Double rear doors WARNING E74707 Close the rear doors properly to Outside prevent them from opening while you are driving. Driving with the rear Inside doors open is extremely dangerous as Left-hand rear door exhaust fumes can be drawn into the vehicle’s interior.
  • Page 30 Locks Opening the doors through 180 and 250 degrees E74709 Push the yellow button located on the door. The check arms will automatically re-engage when the doors are closed. E66517 Luggage compartment lid Outside WARNING Inside Close the luggage compartment lid properly to prevent it opening while you are driving.
  • Page 31 If you lose a key, you can obtain a replacement from your Ford Dealer. If possible, provide them with the key number from the tag provided with the original keys. You can also obtain additional keys from your Ford Dealer.
  • Page 32 Alarm PRINCIPLE OF OPERATION The perimeter alarm is a deterrent against unauthorised access to your vehicle through the doors and the bonnet. It also protects the audio unit. Note: False alarms can also be triggered by the auxiliary heater. See Auxiliary heater (page 67).
  • Page 33 Steering wheel ADJUSTING THE STEERING WARNING WHEEL Make sure that you fully engage the locking lever when returning it to its original position. WARNING Never adjust the steering wheel AUDIO CONTROL when the vehicle is moving. Select radio or CD mode on the audio Note: Make sure that you are sitting in unit.
  • Page 34 Steering wheel Seek Mode E116297 Briefly press the button on the side: • In radio mode, this will locate the next pre-set radio station. • In CD mode, this will select the next CD if a CD changer is fitted. •...
  • Page 35 Steering wheel E116297...
  • Page 36 Wipers and washers WINDSCREEN WIPERS AUTOWIPERS CAUTIONS Do not switch autowipers on in dry weather conditions. The rain sensor is very sensitive and the wipers may operate if dirt, mist or flies hit the windscreen. Replace the wiper blades as soon as they begin to leave bands of water and smears.
  • Page 37 Wipers and washers Adjust the sensitivity of the rain sensor REAR WINDOW WIPER AND using the rotary control. With low WASHERS sensitivity, the wipers will operate when the sensor detects a lot of water on the Intermittent wipe windscreen. With high sensitivity, the wipers will operate if the sensor detects a small amount of water on the windscreen.
  • Page 38 Wipers and washers Rear window washer CHECKING THE WIPER BLADES E71018 WARNING Do not operate the washer for more than 10 seconds at a time, and E66644 never when the reservoir is empty. Run the tip of your fingers over the edge of the blade to check for roughness.
  • Page 39 Wipers and washers E93784 E93785 E93786 Install in the reverse order.
  • Page 40 Lighting Main and dipped beam LIGHTING CONTROL Lighting control positions E71095 Pull the lever fully towards the steering wheel to switch between main and dipped beam. Headlamp flasher E71094 Pull the lever slightly towards the steering wheel. Side and tail lamps Home safe lighting Headlamps You can switch home safe lighting on up...
  • Page 41 Lighting With all doors closed, but within the 30 FRONT FOG LAMPS second delay, opening any door will result in the 3 minute timer starting again. The home safe lights can be cancelled by either turning the headlamp switch ON or by turning the ignition switch ON.
  • Page 42 Lighting Note: You cannot switch the rear fog HEADLAMP LEVELLING lamps on if you have switched autolamps All vehicles HAZARD WARNING FLASHERS Note: Depending on applicable laws and regulations in the country for which your vehicle was originally built, the hazard warning flashers may flash if you brake heavily.
  • Page 43 Lighting Tourneo Connect Load Control position Persons Load in luggage SWB 5 LWB 5 LWB 8 seats seats seats compartment Front Rear max. max. See Vehicle identification (page 126). INTERIOR LAMPS DIRECTION INDICATORS E72170 E71098 Note: Tap the lever up or down to make...
  • Page 44 Lighting The courtesy lamp will also come on when Note: The following instructions describe you switch off the ignition. It will go off how to remove the bulbs. Fit automatically after a short time or when replacements in the reverse order unless you start or restart the engine.
  • Page 45 Lighting Headlamp main and dipped beam Side lamp E76060 E76060 Note: When installing the cover, make Note: When installing the cover, make sure the arrow faces up. sure the arrow faces up. 1. Turn the cover anti-clockwise and 1. Turn the cover anti-clockwise and remove it.
  • Page 46 Lighting Front fog lamps 3. Remove the bulb. Side repeaters E76063 1. Carefully remove the side repeater. E76064 2. Hold the bulb holder, turn the housing Note: You cannot separate the fog lamp anti-clockwise and remove it. bulb from the bulb holder. 3.
  • Page 47 Lighting Rear lamps 2. Remove the rear lamp and unclip the bulb holder. 3. Gently press the bulb into the bulb holder, turn it anti-clockwise and remove it. Central high mounted brake lamp E76065 E76067 1. Remove the screws. 2. Remove the lamp. 3.
  • Page 48 Lighting Number plate lamp Interior lamp Front Vehicles with double rear doors E71074 1. Remove the lens. E76068 2. Remove the bulb. Rear Vehicles with a tailgate E76070 1. Carefully prise out the lamp. 2. Remove the bulb. Reading lamps E71075 1.
  • Page 49 Lighting 1. Carefully prise out the lamp. 2. Remove the bulb. BULB SPECIFICATION CHART Lamp Specification Power (watt) Headlamp main and dipped beam 55/60 Front fog lamp Front direction indicator PY21W Side lamp Side repeater WY5W Brake and tail lamp P21/5W 21/5 Central high mounted brake lamp...
  • Page 50 Windows and mirrors Manual folding mirrors ELECTRIC WINDOWS Folding WARNING Push the mirror towards the door window Do not operate the electric windows glass. unless they are free from obstruction. Unfolding Make sure that you fully engage the mirror Note: If you operate the switches often in its support when returning it to its during a short period of time, the system original position.
  • Page 51 Windows and mirrors The electric exterior mirrors are fitted with The auto-dimming mirror will adjust a heating element that will defrost or automatically when hit by glaring light from demist the mirror glass. See Climate behind. It will not work when you have selected reverse gear.
  • Page 52 Instruments GAUGES Type 1 E74268 Tachometer Engine coolant temperature gauge Fuel gauge Speedometer Clock set button Information display Tripmeter reset button...
  • Page 53 Instruments Type 2 E115885 Tachometer Engine coolant temperature gauge Fuel gauge Speedometer Information display Message indicator CAUTION Engine coolant temperature Do not restart the engine until the gauge cause of overheating has been resolved. All vehicles Shows the temperature of the engine coolant.
  • Page 54 Instruments ABS warning lamp If the needle enters the red section, the engine is overheating. Stop the engine, If a warning or indicator lamp switch the ignition off and determine the does not illuminate when the cause once the engine has cooled ignition is switched on, this down.
  • Page 55 Instruments Engine warning lamps Glow plug indicator See Starting a diesel engine Malfunction indicator lamp (page 81). Headlamp indicator Powertrain warning lamp It will illuminate when you switch the headlamp dipped beam or the side and tail lamps on. All vehicles Ignition warning lamp If either lamp illuminates when the engine WARNING...
  • Page 56 Instruments Oil pressure warning lamp Shift indicator It will illuminate for a short period CAUTION of time to inform you that Do not resume your journey if the oil shifting to a higher gear may pressure warning lamp comes on give better fuel economy and lower CO2 despite the oil level being correct.
  • Page 57 Instruments Frost WARNING Even if the temperature rises to above +4ºC there is no guarantee that the road is free of hazards caused by inclement weather. A warning chime will sound in the following conditions: • +4ºC or lower: frost warning •...
  • Page 58 Information displays • to scroll through the trip computer GENERAL INFORMATION displays • to scroll through and highlight the WARNING options within a menu. Do not operate the information display controls when the vehicle is moving. Note: The information display will remain on for several minutes after you switch off the ignition.
  • Page 59 Information displays Menu structure Clock Setting Vehicle Settings Remote unlocking Approach lights Lane change indicators Radio display Hazards on heavy braking Chimes Hill start ENGLISH MLS Select Language ENGLISH KM DEUTSCH ITALIANO FRANCAIS ESPAÑOL TÜRKÇE РУССКИЙ NEDERLANDS POLSKI SVENSKA PORTUGUES Press Set to Exit Menu Exit E116081...
  • Page 60 Information displays 1. Press the clock set button until the TRIP COMPUTER time flashes in the display. Type 1 information display 2. Press the clock set button to set the time. Type 2 information display E91003 Distance to empty or clock Tripmeter E115886 Odometer...
  • Page 61 Information displays Distance to empty Note: The position of the trip computer display may vary depending on the Indicates the approximate distance the information shown in the display. vehicle will travel on the fuel remaining in the tank. Changes in driving pattern may PERSONALISED SETTINGS cause the value to vary.
  • Page 62 Information displays 7. Press the SET/RESET button to confirm the setting. 8. Press the SET/RESET button to exit the menu. Vehicle settings Language settings, chimes, approach lights, lane change indicators, radio display, hazards on heavy braking, remote E73266 unlocking, hill start. Press the SET/RESET button to 1.
  • Page 63 Information displays Message Warning lamp System Locks. Vehicle is moving. Stop the Passenger door open vehicle as soon as safely possible and close. Locks. Vehicle is moving. Stop the Bonnet open vehicle as soon as safely possible and close. Locks. Vehicle is moving. Stop the Sliding doors open vehicle as soon as safely possible and close.
  • Page 64 Information displays Lighting Message Warning lamp System A left-hand side indicator bulb has Left indicator bulb failure amber failed. See Changing a bulb (page 42). A right-hand side indicator bulb Right indicator bulb failure amber has failed. See Changing a bulb (page 42).
  • Page 65 Climate control The fresh air filter removes most PRINCIPLE OF OPERATION potentially harmful particles such as pollen, industrial fallout and road dust from the Outside air air entering the vehicle’s interior. Keep the air intakes forward of the windscreen free from obstruction (snow, AIR VENTS leaves etc.) to allow the climate control system to function effectively.
  • Page 66 Climate control Heated exterior mirrors Temperature control Electric exterior mirrors are fitted with a heating element that will defrost or demist the mirror glass. They will switch on automatically when you switch the heated rear window on. MANUAL CLIMATE CONTROL Blower Note: If you switch the blower off, the windscreen may mist up.
  • Page 67 Climate control Rapid heating of vehicle interior E74662 Ventilation E74663 Set the air distribution control to position A or B. Set the blower to any position. E74660 Open the air vents to suit individual requirements. Face level Defrosting and demisting the Face level and footwell windscreen Footwell...
  • Page 68 Climate control Air conditioning Defrosting and demisting the windscreen Switching the air conditioning on and off Note: For the air conditioning to operate the engine must be running. E74666 Press the A/C switch to turn the air Set the air distribution control to position conditioning on and off.
  • Page 69 Climate control • Programmable blower operation AUXILIARY HEATER begins when the coolant reaches a certain temperature. In this mode, General information ambient temperature has no effect. WARNINGS • In continuous heater operation, the unit senses the ambient temperature. Do not operate the programmable If this is above 5°C (41°F) the fuel fired heater at filling stations, programmable fuel fired heater heater...
  • Page 70 Climate control Setting the clock time Note: The heating duration for pre-set times and the timed heating mode can be set between 10 and 120 minutes. Press and hold button A for more than three seconds, until the time flashes in the display.
  • Page 71 Climate control Continuous heater operation Programming the pre-set heating start times E71350 E71351 WARNING Press button A repeatedly, until the The heater will continue to operate symbol (1, 2 or 3) for the desired pre-set after the ignition is switched off. time is displayed.
  • Page 72 Climate control Press button A repeatedly, until the symbol (1, 2 or 3) for the desired pre-set time is displayed. Press button C. The ON symbol will appear in the display. To deactivate a pre-set time, press button C again.
  • Page 73 Seats • hold the steering wheel with your arms SITTING IN THE CORRECT slightly bent. POSITION • bend your legs slightly so that you can press the pedals fully. • position the shoulder strap of the seat belt over the centre of your shoulder and position the lap strap tightly across your hips.
  • Page 74 Seats Adjusting the lumbar support E80778 Adjusting the angle of the E74817 seatback Adjusting the height of the seat E74819 E74818...
  • Page 75 Seats Adjusting the armrest Transit Connect E74820 Folding the front passenger seat WARNINGS Make sure that the seats and the E74821 seatbacks are secure and fully engaged in their catches. Do not place objects on the seatback when the vehicle is moving.
  • Page 76 Seats E74823 1. Pull the release strap and fold the seat cushion forwards. 2. Fold the head restraint forwards. 3. Pull the release lever. 4. Fold the seatback forwards. E81584 5. Pull the release lever. Adjusting the head restraint 6. Push the seatback down. WARNING HEAD RESTRAINTS Raise rear head restraint when the...
  • Page 77 Seats Third row WARNINGS Make sure the red indicator is not showing when you engage the seat rear legs and the third row seatback catches. Do not place objects on a folded seat. Do not pull on the second row seat when the entire seat is folded forwards.
  • Page 78 Seats E74846 1. Fully lower the head restraints. 2. Pull the levers on the side of the E74833 seatback. 1. Remove the centre head restraint. 3. Fold the seatback forwards. 2. Fully lower the outer head restraints. 4. Pull the locking levers up. 3.
  • Page 79 Seats 1. Pull the locking levers down. 2. Fold the seat down. 3. Raise the seatback. 4. Install the centre head restraint. Third row E75768 E74849 The seat heating will operate only when 1. Push the release levers down. the ignition is switched on. 2.
  • Page 80 Convenience features When connecting appliances, use only INSTRUMENT LIGHTING specified connectors from the Ford DIMMER Accessory range or connectors for use with SAE standard sockets. AUXILIARY POWER SOCKETS CAUTION If you use the socket when the engine is not running, the battery may discharge.
  • Page 81 Convenience features STORAGECOMPARTMENTS Overhead storage compartment WARNING Do not place heavy objects in the overhead storage compartment. E74677 CUP HOLDERS WARNING Do not place hot drinks in the cup holders when the vehicle is moving. Seat back trays WARNING E74681 Do not use the trays when the vehicle is moving.
  • Page 82 Convenience features MAP POCKETS AUXILIARY INPUT (AUX IN) SOCKET E74686 E115675 See separate audio instructions. FLOOR MATS WARNING When using the floor mats, always make sure the floor mat is properly E80718 secured using the appropriate fixings and positioned so that it does not interfere with the operation of the pedals.
  • Page 83 Starting the engine II The ignition is switched on. All electrical GENERAL INFORMATION circuits are operational. Warning lamps and indicators illuminate. This is the key General points on starting position when driving. You must also If the battery has been disconnected the select it when being towed.
  • Page 84 Starting the engine Release the accelerator pedal. Wait until If you drive only short distances or your the engine has reached idle speed and journeys contain frequent stopping and then switch it off. starting, where there is increased acceleration and deceleration, occasional trips with the following conditions could DIESEL PARTICULATE assist the regeneration process:...
  • Page 85 Do not push-start or tow-start your vehicle. Use booster cables. See Note: The use of additives or other Using booster cables (page 116). engine treatments not approved by Ford is not recommended. Do not switch the ignition off when driving.
  • Page 86 E75775 the accessories fitted and towing etc. Your Ford dealer can give you advice on Open improving your fuel consumption. Close TECHNICAL SPECIFICATIONS...
  • Page 87 Fuel and refuelling Tourneo and Kombi Connect Fuel consumption figures CO2 emis- Urban Extra-urban Combined sions Variant l/100 km l/100 km l/100 km g/km (mpg) (mpg) (mpg) 1.8 l Duratorq-TDCi Turbo diesel (75 PS), Stage IV, 7.8 (36.2) 5.5 (51.4) 6.3 (44.8) Axle ratio: 4.06 1.8 l Duratorq-TDCi Turbo...
  • Page 88 Transmission MANUAL TRANSMISSION CAUTION Do not engage reverse gear when the vehicle is moving. This can cause damage to the transmission. Note: Fully depress the clutch pedal and wait for three seconds before you select first gear. Selecting reverse gear E72455...
  • Page 89 Brakes PRINCIPLE OF OPERATION PARKING BRAKE Disc brakes Applying the parking brake Wet brake discs result in reduced braking efficiency. Dab the brake pedal when driving from a car wash to remove the film of water. WARNING E66567 The ABS does not relieve you of your responsibility to drive with due WARNING care and attention.
  • Page 90 Stability control Stability control (ESP) warning lamp PRINCIPLE OF OPERATION The ESP warning lamp will flash when the Electronic stability programme system is operating. See Warning (ESP) lamps and indicators (page 52). WARNING Emergency brake assist ESP does not relieve you of your WARNING responsibility to drive with due care and attention.
  • Page 91 Traction control PRINCIPLE OF OPERATION The traction control system improves traction when one wheel starts to spin at vehicle speeds up to 40 km/h (25 mph). If a wheel starts to spin, the traction control system varies the pressure to the brake of that wheel until is stops spinning.
  • Page 92 Hill start assist You can activate the system only if the PRINCIPLE OF OPERATION following conditions have been met: The system makes it easier to pull away • The engine is running. when the vehicle is on a slope without the •...
  • Page 93 Hill start assist • Wait for two to three seconds until the system deactivates automatically. • If the system is active in a forward gear, select reverse gear. • If the system is active in neutral, release the clutch pedal. •...
  • Page 94 Parking aid Note: The parking aid may emit false PRINCIPLE OF OPERATION tones if it detects a signal using the same frequency as the sensors or if the vehicle WARNING is fully laden. The parking aid does not relieve you Note: The outer sensors may detect the of your responsibility to drive with side walls of a garage.
  • Page 95 Parking aid Note: If a high pitch tone is heard for three seconds, this indicates a malfunction. The system will be disabled. Have the system checked by a properly trained technician.
  • Page 96 Load carrying GENERAL INFORMATION CAUTION Do not exceed the maximum WARNINGS permissible roof load of 100 kilogrammes (220 pounds) (including Use load securing straps to an the roof rack). approved standard, e.g. DIN. Make sure that you secure all loose items properly.
  • Page 97 Load carrying E81954 The 3 telescopic bars can be moved to allow up to 5 cargo net positions.
  • Page 98 Towing TOWING A TRAILER WARNING Do not exceed the maximum gross train weight stated on the vehicle identification plate. See Vehicle identification (page 126). CAUTION Do not exceed the maximum permissible nose weight, i.e. vertical weight on the tow ball, of 75 kilogrammes (165 pounds).
  • Page 99 Driving hints RUNNING-IN Tyres WARNING New tyres need to be run-in for approximately 500 kilometres (300 miles). During this time, you may experience different driving characteristics. Brakes and clutch WARNING Avoid heavy use of the brakes and clutch if possible for the first 150 kilometres (100 miles) in town and for the first 1 500 kilometres (1 000 miles) on motorways.
  • Page 100 Emergency equipment FIRST AID KIT Space is provided under the driver's seat. WARNING TRIANGLE Space is provided in the left-hand side wall of the load area.
  • Page 101 Fuses Central fuse box FUSE BOX LOCATIONS Left-hand drive E75782 Engine compartment fuse box E75783 Central fuse box Engine compartment fuse box E75784 E75785 Right-hand drive WARNING Have MAXI fuses (Fuses 1–9 in the auxiliary fuse box) replaced by a properly trained technician.
  • Page 102 Fuses 1. Press the sides inwards and allow the CAUTION glove box to pivot downwards. Fit a replacement fuse with the same rating as the one you have removed. Note: You can identify a blown fuse by a break in the filament. Note: All fuses, except high current fuses, are a push fit.
  • Page 103 Fuses FUSE SPECIFICATION CHART Engine compartment fuse box Fuse Ampere Circuits protected rating Central fuse box Engine cooling fan - secondary fuse (110 PS) Central fuse box Heated windscreen Engine cooling fan - primary fuse (75 PS/90 PS) Engine cooling fan - primary fuse (110 PS) Glow plugs Central fuse box Ignition switch...
  • Page 104 Fuses Fuse Ampere Circuits protected rating Glow plug monitoring (diesel engines) Main beam right-hand side Air conditioning clutch solenoid Sensors, Actuators, Relay coils Foglamps Dipped beam (via main beam relay) Heater blower motor Heated windscreen Central fuse box Fuse Ampere Circuits protected rating GEM flasher power...
  • Page 105 Fuses Fuse Ampere Circuits protected rating Not used Not used Front wiper motor Heated front seats GEM VBAT, Recirc / ICL (30-) Not used Not used Radio (memory and power), BTVC module A/C, parking aid Interior lamps and battery saver Not used Not used Side lamps right-hand side...
  • Page 106 Fuses Fuse Ampere Circuits protected rating Not used Not used Not used Not used Rear power point, Transco hand wash Side lamps left-hand side Not used Not used Heated rear window Cluster, PATS, accelerator pedal Wiper front and rear Not used Not used...
  • Page 107 Front towing eye E93106 Transit Connect Your towing eye is located in the bag behind the driver’s seat. Tourneo Connect Your towing eye is located in the left-hand sidewall of the load area. TOWING THE VEHICLE ON FOUR WHEELS WARNINGS Switch the ignition on when your vehicle is being towed.
  • Page 108 Vehicle recovery CAUTIONS Too much tension in the tow rope could cause damage to your vehicle or the vehicle that is towing. Do not use a rigid tow bar on the front towing eye. Drive off slowly and smoothly without jerking the vehicle that is towing.
  • Page 109 • Brake fluid level. See Brake and resale value. There is a large network of clutch fluid check (page 111). Ford Authorised Repairers that are there to help you with their professional • Washer fluid level. See Washer fluid servicing expertise. We believe that their check (page 112).
  • Page 110 Maintenance E78141 E78142 E78143 Closing the bonnet Note: Make sure that the bonnet is closed properly. Lower the bonnet and allow it to drop from under its own weight for the last 20 – 30 centimetres (8 - 12 inches).
  • Page 111 Maintenance ENGINE COMPARTMENT OVERVIEW - 1.8L DURATORQ-TDCI (LYNX) DIESEL/1.8L DURATORQ-TDDI (LYNX) DIESEL E75516 Power steering fluid reservoir : See Power steering fluid check (page 112). Engine oil filler cap : See Engine oil check (page 110). Brake and clutch fluid reservoir : See Brake and clutch fluid check (page 111).
  • Page 112 Do not top up further than the MAX engine. mark. Note: The oil consumption of new Top up with fluid that meets the Ford engines reaches its normal level after specification. See Technical approximately 5 000 kilometres (3 000 specifications (page 112).
  • Page 113 CAUTION Top up with a 50/50 mixture of coolant Make sure that the level is between and water using fluid that meets the Ford the MIN and the MAX marks. specification. See Technical specifications (page 112). Note: Coolant expands when it is hot.
  • Page 114 CHECK Do not top up further than the MAX mark. WARNING Top up with fluid that meets the Ford Do not allow the fluid to touch your specification. See Technical skin or eyes. If this happens, rinse specifications (page 112).
  • Page 115 Maintenance E115472 Capacities Variant Item Capacity in litres (gallons) Power assisted steering MAX-mark fluid Windscreen washer system 4.3 (1.0) Fuel tank 60 (13.2) 1.8 l Duratorq-TDdi/ Cooling system incl. heating 7.0 (1.5) Duratorq-TDCi 1.8 l Duratorq-TDdi/ Engine oil - with filter 5.6 (1.2) Duratorq-TDCi 1.8 l Duratorq-TDdi/...
  • Page 116 Vehicle care Cleaning the chrome trim CLEANING THE EXTERIOR CAUTION WARNING Do not use abrasives or chemical If you use a car wash with a waxing solvents. Use soapy water. cycle, make sure that you remove the wax from the windscreen. Body paintwork preservation CAUTIONS CAUTIONS...
  • Page 117 You should repair paintwork damage caused by stones from the road or minor scratches as soon as possible. A choice of products is available from your Ford Dealer. Read and follow the manufacturer’s instructions.
  • Page 118 Vehicle battery 4. Connect the negative (-) terminal of USING BOOSTER CABLES vehicle B to the engine block or the engine mount of vehicle A (cable 2). CAUTIONS CAUTIONS Connect batteries with only the same nominal voltage. Do not connect to the negative (–) terminal of the flat battery.
  • Page 119 5. Remove the jack. reference number certificate. 6. Install in the reverse order. Vehicle jack Tourneo Connect WARNINGS Your jack and wheelbrace are located in Before using the vehicle jack, check the left-hand sidewall of the load area.
  • Page 120 Wheels and tyres E93301 Emergency use only Maintenance Small arrow-shaped marks on the sills A show the location of the jacking points. E93302...
  • Page 121 Wheels and tyres Spare wheel E76071 Lower the spare wheel by inserting the E76072 hexagonal end of the wheelbrace into the Detach the first cable by unscrewing and guide hole. Turn the wheelbrace sliding back the cap. Turn the nipple at anticlockwise until the wheel rests on the the end of the cable through 90 degrees.
  • Page 122 Wheels and tyres WARNINGS If your vehicle has a manual transmission, select first or reverse gear. If it has an automatic transmission, select park. Have the passengers leave the vehicle. Secure the diagonally opposite wheel with an appropriate block or wheel chock.
  • Page 123 Wheels and tyres 5. Remove the wheel nuts and the wheel. Installing a road wheel WARNINGS Use only approved wheel and tyre sizes. Using other sizes could damage the vehicle and will make the National Type Approval invalid. See Technical specifications (page 123). Do not fit run flat tyres on vehicles that were not originally fitted with them.
  • Page 124 Wheels and tyres TYRE CARE USING WINTER TYRES CAUTION Make sure that you use the correct wheel nuts for the type of wheel the winter tyres are fitted to. If winter tyres are used, make sure that the tyre pressures are correct. See Technical specifications (page 123).
  • Page 125 Wheels and tyres TECHNICAL SPECIFICATIONS Transit Connect Wheel nut torque Wheel type Nm (Ib-ft) Steel - type 1 90 (66.4) Steel - type 2 135 (99.6) Alloy 120 (88.5) Type 2 - Open end, one piece wheel Type 1 - Closed end, two piece wheel nut E131504 E131503...
  • Page 126 195/65 R 15 2.3 (33) 2.7 (39) 2.5 (36) 3.4 (49) T230 195/65 R 15 2.3 (33) 2.7 (39) 2.5 (36) 3.4 (49) Tourneo Connect Short wheelbase Tyre pressures Normal load Full load Front Rear Front Rear Variant Tyre size (lbf/in²)
  • Page 127 Wheels and tyres Long wheelbase Tyre pressures Normal load Full load Front Rear Front Rear Variant Tyre size (lbf/in²) (lbf/in²) (lbf/in²) (lbf/in²) K220 195/65 R 15 2.3 (33) 2.7 (39) 2.3 (33) 3.4 (49) K230 195/65 R 15 2.3 (33) 2.7 (39) 2.3 (33) 3.4 (49)
  • Page 128 Vehicle identification VEHICLE IDENTIFICATION VEHICLE IDENTIFICATION PLATE NUMBER (VIN) Note: The vehicle identification plate design may vary to that shown. Note: The information shown on the vehicle identification plate is dependant upon market requirements. E93897 The vehicle identification number is E85610 stamped into the floor panel in front of the right-hand seat.
  • Page 129 Technical specifications TECHNICAL SPECIFICATIONS Vehicle dimensions Short wheelbase E76188...
  • Page 130 Technical specifications Item Dimension description Dimension in mm (inches) Overall length 4324 (170.2) Overall width including exterior mirrors 2113 (83.2) Overall height 1804-1837 (71.0-72.3) Wheelbase 2665 (104.9) Track - Front 1505 (59.3) Track - Rear 1552 (61.1)
  • Page 131 Technical specifications Long wheelbase E76189...
  • Page 132 Technical specifications Item Dimension description Dimension in mm (inches) Overall length 4571 (180.0) Overall width including exterior mirrors 2113 (83.2) Overall height 1970-1982 (77.5-78.0) Wheelbase 2912 (114.6) Track - Front 1505 (59.3) Track - Rear 1552 (61.1)
  • Page 133 Technical specifications Towing equipment dimensions E76190 Item Dimension description Dimension in mm (inches) Bumper – end of towball Min 90 (3.5) Attachment point – centre of towball 91.1 (3.6)
  • Page 134 Centre of towball – side member 460 (18.1) Outer side of side member 920 (36.2) Centre of towball – centre 1. attachment point 413.3 (16.3) Centre of towball – centre 2. attachment point 566.3 (22.3) All measurements refer to towing equipment officially released by Ford.
  • Page 135 E87992 system performance. To avoid this Office situation, only recommended phones should be used. E87993 Please visit the website www.ford- mobile-connectivity.com for full E87994 details. Making a phone an active TELEPHONE SETUP phone When using the system for the first time, Phonebook no phone is connected to the system.
  • Page 136 Bluetooth connection. 2. In the Bluetooth menu on your phone, search for Ford Audio and select it. Phones stored in the system are 3. Enter the code number shown on the accessible by using the phone list on the vehicle display using the phone audio unit.
  • Page 137 Telephone Making a call TELEPHONE CONTROLS Dialling a number using voice Remote control control Phone numbers can be dialled using voice control. See Telephone commands (page 146). Dialling a number using the address book You can access your phone address book via Bluetooth.
  • Page 138 Telephone 3. Select the CALL OUT list or the Rejecting a second incoming call CALL IN list. On some audio units, Second incoming calls can be rejected by select the MISSED, INCOMING or pressing the call reject button. Units OUTGOING calls list. without a telephone keypad can also Note: If the active phone does not reject a second incoming call by pressing...
  • Page 139 Telephone 3. Select the ACTIVE PHONE option Ending a call on the audio unit. Calls can be ended by pressing either the 4. Scroll through the different stored END button, the MODE button on the phones by using the seek buttons to remote switch or the ON/OFF button on display the bonded phones.
  • Page 140 Telephone Rejecting a second incoming call Second incoming calls can be rejected by pressing either the call reject button, or one of the following buttons on the unit: CD, AM/FM. Muting the microphone During a call, it is possible to mute the microphone.
  • Page 141 Voice control Do not try to give any commands until the PRINCIPLE OF OPERATION beep tone has been heard. The voice control system will repeat each spoken CAUTION command back to you. Using the system with the engine off If you are not sure how to continue say will drain the battery.
  • Page 142 Voice control • radio: "TUNE NAME" • Store up to 20 name tags per function. • SD card: "TRACK". • The average recording time for each name tag is approximately 2-3 Start communicating with the seconds. system Before you can start talking to the system AUDIO UNIT COMMANDS you first have to press the VOICE or MODE button for each operation and...
  • Page 143 Voice control Track You can choose a track on your CD directly. Steps User says System answer "CD PLAYER" "CD PLAYER" "TRACK NUMBER PLEASE" "TRACK" "TRACK <number>" "<a number between 1 and 99>" * Can be used as a shortcut. ** Additionally, numbers can be spoken as up to four single digits (for example "2", "4", "5"...
  • Page 144 Voice control "RADIO" "STORE NAME" "PLAY" * Can be used as a shortcut. Tune frequency This function allows you to tune your radio by voice commands. Steps User says System answer "RADIO" "RADIO" "AM" "AM FREQUENCY PLEASE" "FM" "FM FREQUENCY PLEASE" "TUNE <frequency>"...
  • Page 145 Voice control Steps User says System answer "<name>" "STORING NAME" "<name> STORED" Tune name This function allows you to call up a stored radio station. Steps User says System answer "RADIO" "RADIO" "NAME PLEASE" "TUNE NAME" "<name>" "TUNE <name>" * Can be used as a shortcut. Delete name This function allows you to delete a stored radio station.
  • Page 146 Voice control Steps User says System answer "PLAY DIRECTORY" "PLAY <DIRECTORY>" Delete directory This function allows you to delete all stored radio stations at once. Steps User says System answer "RADIO" "RADIO" "DELETE DIRECTORY" "DELETE DIRECTORY" "CONFIRM YES OR NO" "YES"...
  • Page 147 Voice control SD Card Overview The overview below shows the available These voice commands support the voice commands. The following lists will functionality of an SD card which has give further information about the suitable audio files written to it. complete command menu in selected examples.
  • Page 148 Voice control Steps User says System answer "TRACK NUMBER PLEASE" "TRACK" "TRACK <number>" "<a number between 1 and 99>" * Can be used as a shortcut. ** Additionally, numbers can be spoken as up to four single digits (for example "2", "4", "5"...
  • Page 149 Voice control Phone functions Phone numbers can be dialled after giving the name tag voice command. Dial number Steps User says System answer "PHONE" "PHONE" "NUMBER PLEASE" "DIAL NUMBER" "<phone number>" "<phone number> CONTINUE?" "DIAL" "DIALLING" "CORRECTION" "<repeat last part of number> CONTINUE?"...
  • Page 150 Voice control Steps User says System answer "REDIAL" "REDIAL" "CONFIRM YES OR NO" "YES" "DIALLING" "NO" "COMMAND CANCELLED" * Can be used as a shortcut. Mobile name This function allows you to access phone numbers stored with a name tag in your mobile phone.
  • Page 151 Voice control Steps User says System answer "PHONE" "PHONE" "STORE NAME" "STORE NAME" "NAME PLEASE" "<name>" "REPEAT NAME PLEASE" "<name>" "STORING NAME" "<name> STORED" "NUMBER PLEASE" "<phone number>" "<phone number>" "STORE" "STORING NUMBER" "<phone number>" "NUMBER STORED" Delete name Stored names can also be deleted from the directory.
  • Page 152 Voice control Delete directory This function allows you to delete all entries in one go. Steps User says System answer "PHONE" "PHONE" "DELETE DIRECTORY" "DELETE DIRECTORY" "CONFIRM YES OR NO" "YES" "DIRECTORY DELETED" "NO" "COMMAND CANCELLED" Main settings Reject calls Calls can be set to be automatically rejected using voice control.
  • Page 153 The Bluetooth word mark and logos are modules and airbags. owned by the Bluetooth SIG, Inc. and any use of such marks by Ford Motor Note: Only fit antennas in the positions Company is under license. Other shown to the roof of your vehicle.
  • Page 154 Appendices E100566 Frequency Maximum output power Watt Antenna Positions Band MHz (Peak RMS) 1 – 30 50 W 1, 2, 3 30 – 54 50 W 1, 2, 3 68 – 87.5 50 W 1, 2, 3 142 – 176 50 W 1, 2, 3 380 –...
  • Page 155 Appendices Check that electromagnetic fields generated inside the vehicle cabin by the transmitter installed do not exceed applicable human exposure requirements.
  • Page 157 Index Bluetooth setup........134 See: Climate control........63 Handling of phones........134 About this handbook........5 Requirements for Bluetooth connection..........134 See: Brakes...........87 Bonnet lock ABS driving hints See: Opening and closing the bonnet..107 Booster cables See: Hints on driving with ABS....87 Accessories See: Using booster cables......116 Booster cushions........12 See: Parts and accessories......6 Adjusting the steering wheel....31...
  • Page 158 Checking the wiper blades....36 Electromagnetic compatibility....151 Child safety..........11 Emergency equipment......98 Child safety locks........15 Engine compartment overview - 1.8L Duratorq-TDCi (Lynx) Diesel/1.8L Tourneo Connect..........15 Child seat positioning......13 Duratorq-TDDi (Lynx) Diesel.....109 Child seats..........11 Engine coolant check......111 Child restraints for different mass Checking the coolant level......111 groups............11...
  • Page 159 Instrument lighting dimmer....78 See: Transmission........86 Instruments..........50 General information on radio Interior lamps..........41 frequencies..........22 Reading lamps..........42 Introduction..........5 ISOFIX anchor points.......15 Tourneo Connect..........15 Handbrake See: Parking brake........87 Hazard warning flashers......40 Headlamp levelling........40 Jump starting All vehicles.............40 See: Using booster cables......116 Recommended headlamp levelling switch positions............40...
  • Page 160 Index Locking and unlocking......24 Automatic relocking........25 Central locking..........24 Occupant protection.......17 Double locking..........24 Principle of operation........17 Double locking the doors with the Oil check key..............24 See: Engine oil check........110 Locking and unlocking confirmation..24 Locking and unlocking the doors from See: Opening and closing the bonnet..107 inside............26 Locking and unlocking the doors with the remote control..........25...
  • Page 161 Sitting in the correct position....71 Towing points.........105 Snow chains Front towing eye.........105 See: Using snow chains......122 Rear towing eye..........105 Stability control........88 Tourneo Connect........105 Principle of operation........88 Transit Connect...........105 Stability control Towing the vehicle on four See: Using stability control......88 wheels..........105 Starter switch Towing............96...
  • Page 162 Index Traction control Using the telephone - Vehicles Without: Navigation System......135 See: Using traction control......89 Transmission..........86 Changing the active phone......136 Trip computer..........58 Debonding a bonded phone....137 Average fuel consumption......59 Making a call..........135 Average speed..........59 Muting the microphone......136 Distance to empty........59 Receiving an incoming call......136 Menu..............59 Receiving a second incoming call....136...
  • Page 163 Index Warning lamps and indicators....52 ABS warning lamp........52 Airbag warning lamp........52 Brake system warning lamp.......52 Direction indicator........52 Door open warning lamp......52 Engine warning lamps.........53 Front fog lamp indicator......53 Glow plug indicator........53 Headlamp indicator........53 Ignition warning lamp........53 Low fuel level warning lamp.......53 Main beam indicator........53 Message indicator........53 Oil pressure warning lamp......54...
  • Page 166 Feel the difference...

This manual is also suitable for:

Transit connect
