Page 2 – the Warranty Certificate with terms and conditions for maintaining its validity; – the range of additional services available to Alfa Romeo Customers. We are confident that these instructions will help you become familiar with your new car and the Alfa Romeo after-sales staff who will be at your service.
Page 3 (that may value (RON) of no lower than 95. otherwise cause the battery to gradually lose power), please consult an Alfa Romeo Authorised Service. They Diesel engines : only use diesel fuel compliant with European can calculate the overall electrical requirement and specification EN590.
Page 4: Table Of Contents
SUMMARY Getting to know your car Safety Starting up and driving In an emergency Care and maintenance Technical data Index...
Page 5 page intentionally left blank...
Page 6: Getting To Know Your Car
GETTING TO KNOW YOUR CAR Dashboard ....................Instrument panel and on-board instruments ........... Display ....................Menu items ....................Trip Computer ................... Symbols ....................Alfa Romeo Code System................The keys ....................Alarm ..................... Ignition device ..................Seats ...................... Head restraints ..................Steering wheel ..................
Page 7 GETTING TO KNOW YOUR CAR Interior fittings ..................Electric sunroof ..................Doors ....................Electric windows ................... Luggage compartment ................Bonnet ....................103 Roof rack/ski rack ................104 Headlights ................... 105 ABS system ..................107 VDC system ..................108 “Alfa dna” system ................. 111 EOBD system ..................
Page 8: Dashboard
GETTING TO KNOW YOUR CAR DASHBOARD The presence and position of controls, instruments and gauges may vary according to different versions. fig. 1 A0J0191m 1. Air vent for side windows - 2. Adjustable air vent - 3. Exterior lighting control lever - 4. Instrument panel - 5. Windscreen wiper/rearscreen wiper/trip computer control lever - 6.
Page 9: Instrument Panel And Onboard Instruments
GETTING TO KNOW YOUR CAR INSTRUMENT PANEL AND ONBOARD INSTRUMENTS A0J0141m fig. 2 VERSIONS WITH MULTIFUNCTIONAL DISPLAY A Speedometer (speed indicator) B Multifunctional display C Rev counter D Fuel level gauge with reserve warning light E Engine coolant temperature gauge and excessive temperature warning light Warning lights supplied in diesel versions only.
Page 10 GETTING TO KNOW YOUR CAR A0J0002m fig. 3 VERSIONS WITH RECONFIGURABLE MULTIFUNCTIONAL DISPLAY A Speedometer (speed indicator) B Reconfigurable multifunctional display C Rev counter D Fuel level gauge with reserve warning light E Engine coolant temperature gauge and excessive temperature warning light Warning lights supplied in diesel versions only.
Page 11 GETTING TO KNOW YOUR CAR A0J0006m fig. 4 SPORT VERSIONS WITH MULTIFUNCTIONAL DISPLAY A Speedometer (speed indicator) B Multifunctional display C Rev counter D Fuel level gauge with reserve warning light E Engine coolant temperature gauge and excessive temperature warning light Warning lights supplied in diesel versions only.
Page 12 GETTING TO KNOW YOUR CAR A0J0084m fig. 5 SPORT VERSIONS WITH RECONFIGURABLE MULTIFUNCTIONAL DISPLAY A Speedometer (speed indicator) B Reconfigurable multifunctional display C Rev counter D Fuel level gauge with reserve warning light E Engine coolant temperature gauge and excessive temperature warning light Warning lights supplied in diesel versions only.
Page 13: General Warnings
Handbrake on (red) gine and contact an Alfa Romeo Authorised Service. This warning light comes on when the ignition key is turned to MAR, but it should go off after a few seconds. The warning light (or sym- bol on the display) comes on when the handbrake is on.
Page 14 ABS system. Drive with caution and visit an Alfa Romeo Authorised Service at your earliest convenience. The display will If, when the key is turned to MAR, the ¬ warning show the dedicated message.
Page 15 ¬ may not indicate a fault in the If you wish to permanently deactivate the S.B.R. (Seat Belt Re- system. Contact an Alfa Romeo Authorised Service im- minder) system buzzer, please contact your nearest Alfa Romeo mediately to have the system checked. Authorised Service.
Page 16 Steering is, however, possi- ble. In this case contact your nearest Alfa Romeo Authorised Ser- vice. The display will show the dedicated message. Oil degraded (Diesel versions) The warning light flashes when the system detects that the en- gine oil has degraded.
Page 17: Bonnet Open
GETTING TO KNOW YOUR CAR Excessive engine coolant Doors not closed correctly (red) ´ temperature (red) The warning light (or symbol on the display) lights up This warning light comes on when the ignition key is when one or more doors or the boot tailgate are not properly closed.
Page 18 Alfa Romeo Authorised Service as soon as possible. exhaust emissions, a possible loss of performance, poor driveabil- ity and high fuel consumption.
Page 19 (on some versions together with a message in the display) to in- driving, contact an Alfa Romeo Authorised Service. On certain ver- dicate the failure of the Alfa Romeo CODE or alarm system (where sions the dedicated message is displayed. If the warning light flash- provided): if this occurs, contact your nearest Alfa Romeo Autho- es when driving, this indicates that the VDC system is active.
Page 20: Diesel Versions
(together with a mes- (Diesel versions) light sage in the display) contact an Alfa Romeo Authorised Ser- vice as soon as possible to bleed the system. Water may If this warning light flashes (on some versions together with a mes-...
Page 21 GETTING TO KNOW YOUR CAR External lights failure Possible presence of ice on the road √ On some versions the display will show a message + On versions equipped with “Reconfigurable multi- symbol if a fault is detected in one of the following functional displays ”...
Page 22 On some versions the display will show a message + symbol if there is a fault in the rain sensor. If the warning light flashes with the vehicle in mo- tion, contact an Alfa Romeo Authorised Service. Parking sensor failure (where provided) Cruise Control (where provided) Ü...
Page 23 GETTING TO KNOW YOUR CAR Particulate trap filter blocked General failure (amber) è (Diesel versions) (amber) (where provided) This warning light comes on (together with a message On some versions, this warning light comes on under the in the display), when the particulate trap filter is blocked. following circumstances: To clean the filter, you should continue driving the vehicle until the warning light goes out.
Page 24 (see the paragraph on “Replacing versions together with a message in the display) this indicates that a wheel” in chapter 4) and contact an Alfa Romeo Authorised Ser- the tyre pressure is below the optimum value recommended to vice as soon as possible.
Page 25 GETTING TO KNOW YOUR CAR Display of selected driving mode Rear fog lights (amber) (“Alfa dna” system) (where provided) This warning light comes on when the rear fog lights On versions equipped with a “Reconfigurable multifunctional Dis- are turned on. play”...
Page 26 GETTING TO KNOW YOUR CAR Main beam headlights (blue) Side lights (green) This warning light comes on when the side lights are This warning light comes on when the main beam head- lights are turned on. turned on. Follow me home (green) Left direction indicator (green) This warning light comes on (together with a message in the dis- This warning light comes on when the direction indi-...
Page 27: Display
GETTING TO KNOW YOUR CAR DISPLAY MULTIFUNCTIONAL DISPLAY “STANDARD” SCREEN fig. 6 The car may be equipped with the multifunctional display/multi- The following information is shown on the display: functional reconfigurable display which, in accordance with the set- A. Date tings made, can display useful information when driving.
Page 28 GETTING TO KNOW YOUR CAR RECONFIGURABLE MULTIFUNCTIONAL DISPLAY On some versions when the “DYNAMIC” driving mode is select- “STANDARD” SCREEN fig. 7 ed, the display shows the turbine pressure fig. 8. The following information is shown on the display: A. Time B.
Page 29 GETTING TO KNOW YOUR CAR WELCOME MOVEMENT Illumination of graphic symbols/display On some versions, when the key is turned to MAR, the following A few seconds after the key is inserted, the gauges, graphic sym- occurs: bols and display light up in sequence. ❍...
Page 30 GETTING TO KNOW YOUR CAR CONTROL BUTTONS Fig. 9 IMPORTANT the “+” and “–” buttons activate different functions according to the following situations: “+” To scroll the displayed menu and the related options upwards ❍ to scroll the menu options upwards and downwards; or to increase the displayed value ❍...
Page 31 GETTING TO KNOW YOUR CAR SETUP MENU The menu includes the following items: – MENU The menu comprises a series of items which can be selected us- ing the + and – buttons to access the different selection and set- –...
Page 32 GETTING TO KNOW YOUR CAR Selecting a main menu item without Selecting a main menu item with submenu: submenu: – briefly press the MENU ESC button to display the first submenu – Briefly press the button MENU ESC to select the main menu option;...
Page 33: Menu Items
GETTING TO KNOW YOUR CAR MENU ITEMS IMPORTANT The speed limit can be set at between 30 and 200 km/h, or 20 and 125 mph depending on the selected unit of mea- surement, see paragraph “Units of measurement”. The setting will Menu increase/decrease by five units each time button +/–...
Page 34 GETTING TO KNOW YOUR CAR Headlight sensor (Automatic headlight sensor Rain sensor (Rain sensor sensitivity sensitivity adjustment) (where provided) adjustment) (where provided) This function is used to adjust the dusk sensor sensitivity to three With this function it is possible to adjust the rain sensor sensitivi- levels (level 1 = minimum, level 2 = medium, level 3 = maxi- ty according to 4 levels.
Page 35 Trip B data (Trip B enablement) Set time (Clock) Through this option it is possible to activate (On) or deactivate With this function it is possible to set the clock through two sub- (Off) the Trip B (partial trip) display. menus: “Time”...
Page 36 GETTING TO KNOW YOUR CAR – when accessing the “Mode” submenu: briefly press MENU ESC: Set date the previously set display format will flash on the display; With this function it is possible to update the date (day - month - –...
Page 37 GETTING TO KNOW YOUR CAR First page (Display of information on the See radio (Repeat audio information) initial screen) (where provided) With this function the display repeats information relevant to the This function allows you to choose the information you would like sound system.
Page 38 GETTING TO KNOW YOUR CAR Autoclose (Automatic door lock operation Units (Set unit of measurement) with car running) This function may be used to set the units of measurement via When activated (On), this function automatically locks the doors three submenus: “Distances”, “Fuel consumption” and “Temper- when the car speed exceeds 20 km/h.
Page 39 GETTING TO KNOW YOUR CAR if the distance unit of measurement is set as “km”, the display en- Language (Selecting the language) ables the setting of the fuel consumption unit (km/l or l/100) Messages on the display can be shown in the following languages: to show the amount of fuel consumed.
Page 40 A buzzer will sound dur- ing the adjustment procedure. Belt buzzer (Buzzer activation for S.B.R. indication) This function can only be displayed after an Alfa Romeo Authorised Service has deactivated the S.B.R. system (see the paragraph on“S.B.R. system” in chapter 2).
Page 41 MAR. Go to an or hold the button down to go back to the standard screen. Alfa Romeo Authorised Service where the “Scheduled Service” op- erations will be performed and the message will be reset.
Page 42 GETTING TO KNOW YOUR CAR Passenger bag (Activation/Deactivation Day lights (D.R.L.) of passenger-side front Air bag and Side bag This function allows you to activate/deactivate the daylight lights. to protect chest/pelvis area) Proceed as follows to switch this function on or off: This function can be used to activate/deactivate the passenger- –...
Page 43: Trip Computer
GETTING TO KNOW YOUR CAR Courtesy lights (Activation/deactivation of TRIP COMPUTER “Courtesy lights”) (where provided) GENERAL FEATURES This function allows the side lights, number plate lights and inter- nal courtesy lights to be lit up for approximately 25 seconds when The “Trip computer”...
Page 44 GETTING TO KNOW YOUR CAR Distance travelled Values displayed This value shows the distance covered from the start of the new Range mission. Approximately indicates the distance the vehicle can travel with the present amount of fuel in the tank. Average fuel consumption The message “- - - -”...
Page 45 GETTING TO KNOW YOUR CAR Information displayed The icons relating to the various parameters are as follows: 7 E K Each time a value is displayed, the following information is shown: ”Range”; ❍ animated icon in the upper part of the display (A-fig. 10); “Average fuel consumption A”...
Page 46 GETTING TO KNOW YOUR CAR TRIP 0.00 button New mission The new mission begins after: This is located on the right-hand lever fig. 12. With the ignition key turned to MAR, this button allows you to view the previously de- –...
Page 47: Symbols
The code is sent only if the Alfa Romeo CODE system control unit has recognised the code transmitted from the key. Each time the ignition key is turned to STOP, the Alfa Romeo CODE system deactivates the functions of the engine management control unit.
Page 48: The Keys
A CODE card fig.13 is provided together with the keys. On the card ❍ If the warning light remains on, contact an Alfa Romeo Au- you will find a mechanical code A and an electronic code B. Keep thorised Service.
Page 49 GETTING TO KNOW YOUR CAR KEY WITHOUT REMOTE CONTROL Press button B-fig. 15 only after moving the key The metal insert A-fig.14 operates: away from your body, especially your eyes, and from objects which could get damaged (e.g. your ❍ the ignition switch; clothes).
Page 50 The system acknowledges up to 8 remote controls. If you ever compartment are not closed correctly, the led and direction indi- require a new remote control, contact an Alfa Romeo Authorised cators start flashing quickly. Service and bring your CODE card (where provided), some ID, and the vehicle ownership documents with you.
Page 51 They should be disposed of as specified by law in Proceed as follows: special containers or taken to an Alfa Romeo Au- thorised Service, which will take care of their disposal. ❍ press button A-fig. 17 and bring the metal insert B into the open position;...
Page 52: Disengaging The System
GETTING TO KNOW YOUR CAR SAFE LOCK DEVICE (where provided) Disengaging the system This safety device inhibits the operation of the interior door han- The system disengages automatically by: dles and the door locking/unlocking button. We recommend that ❍ opening the driver-side door using the metal insert; you activate this device each time you park your car.
Page 53 GETTING TO KNOW YOUR CAR The main functions that can be activated with the keys (with or without remote control) are as follows: Type of key Unlocking Locking the doors flashing Tailgate Windows down Windows up opening (where provided) (where provided) the doors from the outside Safe lock activation...
Page 54: Alarm
IMPORTANT The engine inhibitor function is guaranteed by the Alfa Romeo CODE, which is automatically activated when the ig- nition key is extracted from the ignition switch. IMPORTANT the alarm is configured to comply with the regulations...
Page 55 GETTING TO KNOW YOUR CAR SWITCHING OFF THE ALARM VOLUME SENSING/ ANTI-TILT PROTECTION Ë Press the button. The following operations are performed (ex- To guarantee the correct operation of the protection, close the side cluding some versions for specific markets): windows and any sunroof completely (where provided).
Page 56: Ignition Device
GETTING TO KNOW YOUR CAR IGNITION DEVICE If the ignition switch is tampered with (e.g.: attempted theft), have it checked over by an Alfa The key can be turned to three different positions fig. 21: Romeo Authorised Service as soon as possible. ❍...
Page 57: Seats
GETTING TO KNOW YOUR CAR STEERING COLUMN LOCK SEATS Engagement FRONT SEATS fig. 22 When the key is at STOP, remove the key and turn the steering wheel until it locks. All adjustments must be made with the car sta- Disengagement tionary.
Page 58 GETTING TO KNOW YOUR CAR Height adjustment (where provided) Adjusting backrest inclination Move lever B up or down until the required height is achieved. Rotate knob C until the required position is reached. IMPORTANT Carry out the adjustment whilst seated in the driver’s For maximum safety, keep the back of your seat seat.
Page 59 GETTING TO KNOW YOUR CAR Seat warming (where provided) EASY ENTRY With the key turned to MAR, press buttons A or B-fig. 23 to acti- This function allows easy access to the rear seats. vate/deactivate the function. When the function is enabled, the To reach the rear seats, lift up handle E-fig.
Page 60: Head Restraints
GETTING TO KNOW YOUR CAR HEAD RESTRAINTS To remove the head restraint: ❍ raise the head restraint to its maximum height; FRONT HEAD RESTRAINTS ❍ press buttons A and B-fig. 24 and then remove the head re- straint by sliding it upwards. Head restraints are adjustable in height and they lock automati- cally in the required position.
Page 61: Steering Wheel
GETTING TO KNOW YOUR CAR REAR HEAD RESTRAINTS STEERING WHEEL Two height-adjustable head restraints are provided for the back The steering wheel can be adjusted axially and vertically. seats (to adjust the height see the previous paragraph). On some versions a head restraint is also provided for the central seat. To carry out the adjustment: release lever A-fig.
Page 62: Rearview Mirrors
GETTING TO KNOW YOUR CAR REARVIEW MIRRORS It is absolutely forbidden to carry out any after- market operation involving steering system or INTERNAL MIRROR steering column modifications (e.g.: installation of anti-theft device). This could badly affect performance and Operate lever A-fig. 27 to adjust the mirror into two different po- safety, invalidate the warranty and also result in the non- sitions: normal or antiglare.
Page 63 GETTING TO KNOW YOUR CAR Adjusting the mirror Electric mirror folding (where provided) Door mirrors can be adjusted/folded away only if the ignition key To fold back the mirrors press button C-fig. 28. Press the button is in the MAR position. once again to bring the mirrors back to the driving position.
Page 64: Climatic Comfort
GETTING TO KNOW YOUR CAR CLIMATIC COMFORT A0J0036m fig. 30 VENTS fig. 30 1. Fixed upper vent - 2. Adjustable central vents - 3. Fixed side vents - 4. Adjustable side vents - 5. Lower vents for front seats - 6.
Page 65: Heating/Climate Control System
GETTING TO KNOW YOUR CAR HEATING/CLIMATE CONTROL SYSTEM fig. 31 A0J0074m CONTROLS fig. 31 ß air flow towards driver/passenger and feet area; © A Air temperature adjustment knob air flow towards front and rear feet area; (red = hot/blue = cold); ®...
Page 66: Climate Control
GETTING TO KNOW YOUR CAR PASSENGER COMPARTMENT VENTILATION WARMING THE PASSENGER COMPARTMENT Proceed as follows to adjust the ventilation: Proceed as follows: ❍ turn knob A to the blue section; ❍ turn knob A to the red section; ❍ press button D to disable the air recirculation system (the LED ❍...
Page 67 GETTING TO KNOW YOUR CAR FRONT WINDOW FAST DEMISTING/ Window demisting DEFROSTING In the event of considerable outside moisture and/or rain and/or (WINDSCREEN AND SIDE WINDOWS) considerable differences in temperature inside and outside the pas- Proceed as follows: senger compartment, perform the following preventive demisting procedure: ❍...
Page 68 LOOKING AFTER THE SYSTEM Run the climate control system for at least 10 minutes every month during the winter. Have the system checked by an Alfa Romeo Authorised Service before the summer.
Page 69: Two-Zone Automatic Climate Control System
GETTING TO KNOW YOUR CAR TWO-ZONE AUTOMATIC CLIMATE CONTROL SYSTEM (where provided) fig. 32 A0J0037m CONTROLS fig. 32 E climate control system off button; A button for activating the MONO function (alignment of set tem- F button for activating the MAX-DEF function (fast front window peratures) driver/passenger;...
Page 70 GETTING TO KNOW YOUR CAR H AUTO function activation button (automatic operation) and pas- All these functions can be adjusted manually by operating the sys- senger-side temperature adjustment knob; tem and selecting one or more functions and modifying their pa- rameters.
Page 71 GETTING TO KNOW YOUR CAR SWITCHING ON THE CLIMATE During automatic operation the set temperatures, the air distribu- CONTROL SYSTEM tion and fan speed can be changed at any time using the corre- sponding buttons or knobs: the system will automatically change The system can be switched on in several ways: we recommend the settings to adapt to the new request.
Page 72 GETTING TO KNOW YOUR CAR SETTING THE AIR DISTRIBUTION In FULL AUTO mode the climate control system automatically man- ages the air distribution; the LEDs on the I and M buttons should By pressing these buttons you can manually choose between 7 pos- be off.
Page 73 GETTING TO KNOW YOUR CAR REGULATING THE FAN SPEED IMPORTANT If the system is unable to reach/maintain the required temperature in the various areas of the passenger compartment, Press button L to increase/decrease the fan speed. The fan speed the set temperature will flash and after approximately 1 minute is shown by the lit-up bars on the display: the word AUTO will disappear.
Page 74 GETTING TO KNOW YOUR CAR AIR RECIRCULATION It is advisable not to use the air recirculation func- Air recirculation works according to the following operating logics: tion when the outside temperature is low to pre- vent the windows from rapidly misting up. ❍...
Page 75 GETTING TO KNOW YOUR CAR With climate control compressor off: IMPORTANT the MAX-DEF function remains on for approximately 3 minutes from the moment the engine coolant reaches a suitable ❍ if the outside temperature is higher than the set one, the sys- temperature.
Page 76 GETTING TO KNOW YOUR CAR SWITCHING OFF THE CLIMATE ADDITIONAL HEATER CONTROL SYSTEM (only for diesel versions) (where provided) Press the OFF button. With the climate control system switched off: This device speeds up passenger compartment warming when it is very cold.
Page 77: External Lights
GETTING TO KNOW YOUR CAR EXTERNAL LIGHTS SIDE LIGHTS/DIPPED BEAM HEADLIGHTS With the ignition key turned to MAR, turn selector wheel A to 2. The LEFT-HAND LEVER fig. 33 daylight lights are switched off and the side lights and dipped beam headlights are switched on.
Page 78 GETTING TO KNOW YOUR CAR IMPORTANT the sensor is not able to detect the presence of fog. MAIN BEAM HEADLIGHTS The fog lights must therefore be switched on manually if required. With selector wheel A in position 2 pull the lever towards the When the lights are switched on by the sensor, the front and rear steering wheel (stable position).
Page 79 GETTING TO KNOW YOUR CAR “FOLLOW ME HOME” DEVICE EXTERIOR COURTESY LIGHTS This device allows you to illuminate the area in front of the car This function lights up the vehicle and the space around it when for a certain amount of time. the doors are unlocked.
Page 80: Window Washing
(low speed); restored, even after turning the key and restarting the en- windscreen wiper off; gine, contact an Alfa Romeo Authorised Service. AUTO rain sensor activation (where provided) (the windscreen wipers adapt the operating speed automatically to suit the intensity of the rain) ≤...
Page 81 GETTING TO KNOW YOUR CAR RAIN SENSOR (where provided) fig. 35 If the vehicle is switched off with the lever in the automatic posi- tion, when the vehicle is next started no wiping cycle will take place This is an infra-red LED sensor fitted on the vehicle windscreen. It even if it is raining.
Page 82: Cruise Control
GETTING TO KNOW YOUR CAR REARSCREEN WIPER/WASHER CRUISE CONTROL (where provided) (where provided) GENERAL INFORMATION Activation This is an electronic driving aid that allows you to drive at a speed This only operates with the ignition turned to MAR. The function of above 30 km/h on long and straight dry roads (e.g.
Page 83 GETTING TO KNOW YOUR CAR When travelling downhill with the device engaged, the car may INCREASING THE MEMORISED SPEED slightly exceed the preset speed. When the device is activated Press the accelerator and store the new speed or move the lever the Ü...
Page 84: Courtesy Lights
The switching on/off of the lights is gradual. In the event of defective operation or device fail- ure turn the selector wheel to OFF and contact an Alfa Romeo Authorised Service. A0J0066m fig. 37...
Page 85 GETTING TO KNOW YOUR CAR Switch B works as a spotlight. COURTESY LIGHT TIMING Switch B positions: On certain versions, two different timed switching-on modes have ❍ central position (position 1): lights C and D are always off; been provided to facilitate getting in/out of the car at night or with poor lighting.
Page 86 GETTING TO KNOW YOUR CAR COURTESY LIGHTS (where provided) fig. 38 DOOR LIGHTS fig. 39 On some versions courtesy lights are fitted behind the sun visors. These are located in the doors and are activated when the door is Press switch A to switch on/off the light. opened regardless of the position of the ignition key.
Page 87: Controls
GETTING TO KNOW YOUR CAR GLOVE COMPARTMENT LIGHT CONTROLS fig. 41 HAZARD WARNING LIGHTS fig. 42 This light comes on automatically when the glove compartment is opened and switches off when it is closed. Press switch A to switch on/off the lights. Warning lights Ÿ and Δ...
Page 88 GETTING TO KNOW YOUR CAR Emergency braking REAR FOG LIGHTS fig. 43 In the event of emergency braking the hazard warning lights are Press button to switch on/off the lights. The rear fog lights lit up automatically as well as the Ÿ and Δ warning lights in the are only enabled with the dipped beam headlights on.
Page 89 GETTING TO KNOW YOUR CAR FUEL CUT-OFF SYSTEM To reset car operation, follow this procedure: ❍ turn the ignition key to MAR; This system intervenes in the event of a collision, activating: ❍ activate the right-hand direction indicator; ❍ switch off of fuel supply with resultant engine switch off; ❍...
Page 90: Interior Fittings
GETTING TO KNOW YOUR CAR INTERIOR FITTINGS FRONT ARMREST (where provided) fig. 46 Some versions include an armrest between the front seats. GLOVE COMPARTMENT fig. 45 To bring this to the standard position, push it down as shown in fig. 46. Operate handle A to open the compartment.
Page 91 GETTING TO KNOW YOUR CAR POWER SOCKETS (where provided) If you require the smokers kit , the socket on the central tunnel is replaced with a cigar lighter (see following paragraph). These are located on the central tunnel A-fig. 48 and on the left- hand side of the luggage compartment B-fig.
Page 92 GETTING TO KNOW YOUR CAR ASHTRAY (where provided) fig. 50 FIRE EXTINGUISHER (for versions/markets where provided) fig. 52 The ashtray is a removable plastic box with spring loaded open- ing that can be fitted into the glass/can holder on the central con- This is located on the right-hand side of the luggage compartment.
Page 93: Electric Sunroof
GETTING TO KNOW YOUR CAR ELECTRIC SUNROOF OPENING/CLOSING THE SUN BLINDS fig. 53 (where provided) To open: Grip handle A, release it and move it in the direction of the arrows to the “fully open” position. The large electric sunroof comprises two panes of glass, one of To close: reverse the opening procedure.
Page 94 GETTING TO KNOW YOUR CAR ANTI-PINCH SAFETY SYSTEM With a transverse roof rack fitted, the sunroof The sunroof is fitted with an anti-pinch safety system that detects should remain closed. the presence of an obstacle during the sunroof closing travel and cuts in by stopping and reversing the sunroof travel.
Page 95: Initialisation Procedure
GETTING TO KNOW YOUR CAR INITIALISATION PROCEDURE EMERGENCY OPERATION The sunroof must be re-initialised after disconnecting the battery or In the event of a malfunction of button A-fig. 53, the sunroof can if the relevant protection fuse is blown. also be opened manually. Proceed as follows: Proceed as follows: ❍...
Page 96: Doors
GETTING TO KNOW YOUR CAR DOORS Door unlocking from the outside Press button Ë on the remote control or turn the metal insert (lo- DOOR CENTRAL LOCKING/UNLOCKING cated inside the key) in the driver-side door lock. Locking from the outside Door locking/unlocking from the inside With the doors closed press button Á...
Page 97: Electric Windows
GETTING TO KNOW YOUR CAR Continuous automatic operation ELECTRIC WINDOWS (where provided) These are equipped with an automatic setting to raise and lower This is activated by pressing one of the two buttons for longer than the driver-side front window. half a second.
Page 98 GETTING TO KNOW YOUR CAR IMPORTANT If the anti-pinch protection intervenes 5 times consec- Passenger-side door utively within 1 minute or a system failure is detected, the auto- The passenger-side door is equipped with a button that controls matic window closing function is inhibited. The window can then the opening/closing of the passenger-side window.
Page 99 GETTING TO KNOW YOUR CAR Electric window system initialisation The reset operation should be carried out with the doors closed according to the following procedure: The safety system must be re-initialised after disconnecting the bat- 1. completely lower the driver-side window and keep the button tery or if the relevant protection fuse is blown.
Page 100: Luggage Compartment
GETTING TO KNOW YOUR CAR LUGGAGE COMPARTMENT Emergency opening from the inside Proceed as follows: Luggage compartment unlocking is electrically controlled and is dis- ❍ remove the rear head restraints and completely fold back the abled with the vehicle in motion. seats (see the paragraph on “Expanding the luggage com- partment”);...
Page 101 GETTING TO KNOW YOUR CAR CLOSING LUGGAGE COMPARTMENT INITIALISATION Pull tab A-fig. 61 and lower the tailgate by pressing near the lock IMPORTANT If the battery is disconnected or the protection fuse until a click is heard. blows, the luggage compartment opening/closing mechanism must be reinitialised as follows: IMPORTANT Before closing the luggage compartment make sure ❍...
Page 102 GETTING TO KNOW YOUR CAR EXPANDING THE LUGGAGE COMPARTMENT Folding back the seats Removing the parcel shelf Proceed as follows: ❍ raise the head restraints to the maximum height, press both Proceed as follows: buttons A-fig. 64 to the side of the two supports, then remove ❍...
Page 103 GETTING TO KNOW YOUR CAR ❍ raise backrest levers A-fig. 65 and fold the required cushion for- Repositioning the rear seat ward (when lever A is raised this is indicated by a red strip). Move the seat belts making sure that they are correctly extended with no coils.
Page 104: Bonnet
GETTING TO KNOW YOUR CAR BONNET CLOSING THE BONNET ❍ hold the bonnet up with one hand and with the other remove OPENING THE BONNET rod C-fig. 67 from housing D and fit it back into its catch; Proceed as follows: ❍...
Page 105: Roof Rack/Ski Rack
GETTING TO KNOW YOUR CAR ❍ lower the bonnet to about 20 centimetres above the engine ROOF RACK/SKI RACK compartment and then let it drop. Make sure that the bonnet is closed correctly and not just in the safety position by trying To fit the roof rack/ski rack, raise the special tabs A-fig.
Page 106: Headlights
GETTING TO KNOW YOUR CAR HEADLIGHTS The Lineaccessori Alfa Romeo includes a dedicated roof rack/ski rack for this vehicle. ADJUSTING THE LIGHT BEAM The correct orientation of the headlights is important for the dri- After having travelled several kilometres check that ver’s comfort and safety as well as for all other road users.
Page 107 GETTING TO KNOW YOUR CAR Adjusting headlamp alignment FRONT FOG LIGHTS ALIGNMENT (where provided) Press buttons Ò and  to carry out the alignment (fig. 69). The instrument panel display provides a visual indication of the posi- To check and, if necessary, adjust the alignment contact an Alfa tions during the adjustment operation.
Page 108: Abs System
GETTING TO KNOW YOUR CAR ABS SYSTEM When the ABS intervenes it means that you are ap- proaching the grip limit between tyres and road: slow down to adjust the speed according to avail- The car is fitted with an ABS braking system, which prevents the able grip.
Page 109: Vdc System
GETTING TO KNOW YOUR CAR VDC SYSTEM HILL HOLDER SYSTEM (Vehicle Dynamics Control) This system is an integral part of the VDC system and it is provided to facilitate starting on slopes. This is an electronic system that controls car stability in the event It is activated automatically in the following instances: of tyre grip loss.
Page 110 GETTING TO KNOW YOUR CAR ASR SYSTEM (AntiSlip Regulation) If the spare wheel is used, the VDC system keeps This is an integral part of the VDC system. It automatically cuts in operating. Be aware however that the spare wheel, in the event of one or both drive wheels slipping, loss of grip on being smaller than the original wheel, provides less wet roads (aquaplaning) and acceleration on slippery, snowy or icy...
Page 111: Emergency Braking Assistance
GETTING TO KNOW YOUR CAR BRAKE ASSIST “ELECTRONIC Q2” SYSTEM (“E-Q2”) (emergency braking assistance) The “Electronic Q2” system uses the braking system to create an This system, which cannot be excluded, recognises emergency brak- effect similar to a limited slip differential. ing (on the basis of the brake pedal operation speed) and allows The front braking circuit, when accelerating around a corner, acts the braking system to react more quickly.
Page 112: Alfa Dna" System
GETTING TO KNOW YOUR CAR “ALFA dna” SYSTEM DRIVING MODES (Dynamic vehicle control system) Lever A-fig. 70 is a one-way switch, i.e. it always remains in the cen- tral position. The selected driving mode is indicated by the corre- (where provided) sponding LED coming on in the panel and by an indication on the re- configurable multifunctional display, as illustrated below: This device allows three different driving modes to be selected by...
Page 113 GETTING TO KNOW YOUR CAR ENGAGEMENT/DISENGAGEMENT OF Disengagement “Dynamic” MODE To disengage “Dynamic” mode and return to “Normal”, move the lever as described above once again. In this case, the LED cor- Engagement responding to “Normal” mode will light up and the words “Normal engaged”...
Page 114 GETTING TO KNOW YOUR CAR ENGAGEMENT/DISENGAGEMENT IMPORTANT NOTES OF “All Weather” MODE ❍ It is not possible to go from“Dynamic” mode straight to “All Weather” mode and vice versa. You must always first go back Engagement to “Normal” mode and then select the other mode. Move lever A-fig.
Page 115: Eobd System
IMPORTANT After eliminating a fault, to check the system com- pletely, Alfa Romeo Authorised Services are obliged to run tests and, if necessary, road tests which may also call for a long journey.
Page 116: Radio Wiring System
When connecting a car radio to the radio wiring fig. 71. contact an Alfa Romeo Authorised Service to pre- The radio wiring system is composed of: vent any faults from occurring that might com- ❍...
Page 117: Wiring For Navigation System
Some versions have wiring for the navigation system available from Electrical and electronic devices installed after buying the car by af- e CE the Lineaccessori Alfa Romeo. ter-market services must carry the following label: Insert the Navigation system into the housing shown in fig. 72.
Page 118: Parking Sensors
GETTING TO KNOW YOUR CAR RADIO TRANSMITTERS AND CELLULAR PHONES PARKING SENSORS (where provided) Radio sets (e.g. mobile phones, CB radio systems and the like) cannot be used inside the car unless a separate aerial is mounted on the roof. The parking sensors are located in the rear bumper fig.
Page 119 Side action range: 60 cm For repainting the bumpers or retouching the paint- If several obstacles are detected, the control unit indicates the near- work around the sensors contact an Alfa Romeo est one. Authorised Service. The incorrect application of paint may compromise the operation of the parking sen- sors.
Page 120 GETTING TO KNOW YOUR CAR GENERAL WARNINGS The ultimate responsibility when parking and car- During parking manoeuvres, pay the utmost attention to any ob- rying out other dangerous manoeuvres still rests with the driver. When carrying out such manoeu- stacles that could be located above or below the sensors. Sometimes, objects located close to the rear part of the vehicle vres, always ensure that the manoeuvring area is free of people (particularly children) and animals.
Page 121: System
GETTING TO KNOW YOUR CAR T.P.M.S. SYSTEM (Tyre Pressure Take the greatest of care when checking and top- Monitoring System) ping up the tyre inflation pressure. Excessive pres- sure compromises road holding, increases the stress (where provided) on the suspension and wheels as well as increasing the risk of the tyres wearing out un-evenly.
Page 122 The T.P.M.S. system requires the use of specific equip- inflation pressure losses (for example when a tyre ment. Contact an Alfa Romeo Authorised Service to explodes). In this case stop the car, braking with find out which accessories are compatible with the care and avoiding sharp steering actions.
Page 123 Romeo Authorised Service. Tyre and wheel fit- ting/removal operations require specific precautions; to avoid damaging or fitting the sensors incorrectly, tyre and wheel fitting/removal operations should only be carried out by specialists. Contact an Alfa Romeo Authorised Ser- vice Provider.
Page 124 Wheel change – with others of different size (*) Wheel cross switching – (front/rear) (**) (*) Given as an alternative in the Owner Handbook and available in Lineaccessori Alfa Romeo. (**) Not cross switched (tyres must stay on the same side).
Page 125: At The Filling Station
GETTING TO KNOW YOUR CAR AT THE FILLING STATION DIESEL ENGINES Only use diesel fuel compliant with European specification EN590. Switch off the engine before refuelling. The use of other products or mixtures may damage the engine beyond repair and consequently invalidate the warranty. PETROL ENGINES Operation at low temperatures Only use unleaded petrol.
Page 126: Protecting The Environment
GETTING TO KNOW YOUR CAR FUEL FILLER CAP PROTECTING THE ENVIRONMENT To refuel, open flap A-fig. 74 then use the ignition key to undo The devices for limiting petrol engine emissions are: catalytic con- cap B. The cap is provided with loss-prevention device C which se- verter, Lambda sensors and anti-evaporation system.
Page 127 GETTING TO KNOW YOUR CAR page intentionally left blank...
Page 128: Safety
SAFETY Seat belts ..............128 S.B.R. system............... 129 Pretensioners ............... 131 Carrying children safely ..........134 Fitting “Universal” child seat .......... 135 “Isofix” child restraint assembly setup ......139 Front Airbags ............... 142 Side Air bags (Side bag - Window bag) ......145 “Alcohol Test”...
Page 129: Seat Belts
SAFETY SEAT BELTS Never press button C-fig. 1 when travelling. USING THE SEAT BELTS Wear the belt keeping the chest straight and rested against the back- rest. To fasten the seat belts, hold tongue A-fig. 1 and insert it into The rear seat is fitted with inertia seat belts with three anchor points buckle B, until the locking click is heard.
Page 130: S.b.r. System
Contact an Alfa Romeo Authorised Service Provider to deactivate this system permanently. The S.B.R. system can only be reactivated via the display Set Up Menu (see chapter “1”).
Page 131: Rear Seats
SAFETY The red and green warning lights work as follows: If the seatbelt is unfastened again while the vehicle is in motion, ❍ off if the seat belts are already fastened when the ignition is the acoustic signal and the warning light flashing are resumed as described previously turned to MAR ❍...
Page 132: Pretensioners
If, due to unusual natural events (floods, sea storms, etc.), the de- by vibrations caused by irregularities of the road surface vice has been affected by water and mud, it must be replaced. or low obstacles such as kerbs, etc. Contact an Alfa Romeo Authorised Service Provider for any assistance.
Page 133 SAFETY GENERAL INSTRUCTIONS FOR USING THE The seat belt must not be twisted. The upper part must cross the SEAT BELTS shoulder and the chest diagonally. The lower part must adhere to the hips (fig. 6), not to the abdomen. Do not use devices (clips, Respect and ensure that all the other occupants of the car respect etc.) to hold the seat belt away from your body.
Page 134 SAFETY Each seat belt may only be used by a single person: Do not carry If the belt has been subjected to heavy stress, for children on your lap with one seat belt protecting both (fig. 7). In example after an accident, it should be changed general, do not place any objects between the passenger and the completely together with the anchors, anchor fas- belt.
Page 135: Carrying Children Safely
When over 1.50 m in height, from the point of view of restraint systems, children are considered as adults and have to wear the standard seat belts. Lineaccessori Alfa Romeo includes child seats for each weight group. These devices are recommended, having been specifically designed for Alfa Romeo cars.
Page 136: Fitting "Universal" Child Seat
SAFETY FITTING “UNIVERSAL” GROUP 1 fig. 9 CHILD SEAT (with seat belts) Children from 9 kg to 18 kg in weight can be carried facing for- wards if the child seat is fitted with a front cushion. Some types of child seat have a front cushion through which the vehicle seat GROUP 0 and 0+ fig.
Page 137 SAFETY GROUP 3 fig. 11 Some child restraint systems for weight groups 0 For children from 22 kg to 36 kg the child’s chest is so small that and 1 have a rear attachment and seat belts for a spacing seat back is no longer required. Figure 11 shows prop- securing the child.
Page 138 SAFETY PASSENGER SEAT COMPLIANCE WITH REGULATIONS ON UNIVERSAL CHILD’S SEAT USE The car complies with the new European Directive 2000/3/EC which governs the arrangement possibilities for child restraints on the various seats of the car as shown in the following table: Passenger Passenger rear Group...
Page 139 SAFETY ❍ only one child is to be strapped to each retaining system; Main safety rules to be followed when carrying children: ❍ always check the seat belts do not rest around the child’s throat; ❍ while travelling, do not let the child sit incorrectly or release the ❍...
Page 140: Isofix" Child Restraint Assembly Setup
SAFETY “ISOFIX” CHILD RESTRAINT WARNING The centre rear seat is not certified for any type of child’s seat. ASSEMBLY SETUP Provision has been made on the car to mount a Universal Isofix child restraint system, a new European standardised system for car- rying children safely.
Page 141 Isofix” child seat, you can only use approved seats with the mark- ing EKE R44/03 “Universal Isofix”. The “Universal Isofix” “Duo Plus” child seat is available from Lineaccessori Alfa Romeo. For any further installation/details on usage, refer to the “Instruction Man- ual”...
Page 142 SAFETY PASSENGER SEAT COMPLIANCE WITH REGULATIONS ON ISOFIX CHILD SEAT USE The table below, according to ECE 16 European Directive, shows the different installation possibilities of Isofix restraint systems on seats fitted with Isofix fasteners. Weight group Orientation Grade Front Rear passenger child seat Isofix size...
Page 143: Front Airbags
SAFETY FRONT AIRBAGS Do not apply stickers or other objects on the steer- ing wheel, passenger side airbag cover or side up- The vehicle is equipped with multi-stage front air bags (“Smart holstery on roof. Do not place objects on the pas- bag”) for the driver and passenger and knee air bag for the dri- senger side dashboard because these could interfere with ver.
Page 144 SAFETY Always drive with your hands on the steering wheel Do not arrange child seats facing backwards if the rim so that the airbag can inflate freely if need- front airbag on the passenger’s side is enabled. De- ed. Do not drive with your body bent forward. ployment of the airbag in an accident could cause Keep your back straight against the back rest.
Page 145 SAFETY KNEE AIRBAG ON DRIVER’S SIDE fig. 17 Deactivating the passenger-side front Air Bag and Side Bag This is located in a dedicated compartment under the steering wheel. It provides additional protection in the event of a frontal impact. When carrying a chid on the front seat, deactivate the passenger- side front Air Bag and Side Bag.
Page 146: Side Airbags (Side Bag - Window Bag)
SAFETY SIDE AIRBAGS HEAD PROTECTION SIDE AIR BAGS (WINDOW BAGS) fig. 19 (SIDE BAG - WINDOW BAG) These are comprised of two “curtain” bags located behind the side cover of the roof and protected by dedicated covers. They protect The car is fitted with front side bags for driver and passenger for the heads of the front passengers in the event of a side impact.
Page 147 Alfa Romeo Authorised Services. Do not rest your head, arms or elbows on the door, If the vehicle is to be scrapped, contact an Alfa Romeo Authorised windows or on the window bag area to avoid in- Services to have the air bags deactivated.
Page 148 Refer to an Alfa Romeo also with the car at a standstill, if it is hit by an- Authorised Services when it’s time to replace them.
Page 149: Alcohol Test" Kit
SAFETY “ALCOHOL TEST” KIT This is located in the passenger-side glove compartment. The kit consists of an envelope (fig. 20) containing all medical products for checking the alcohol level. The envelope also contains instructions the correct use of the kit. Like all medical products, the alcohol test kit has a set shelf life: replace the pack containing the expired product.
Page 150: Starting Up And Driving
STARTING UP AND DRIVING Starting the engine ................Parking ....................Using of the gearbox ................Saving fuel ..................Towing trailers ..................Snow tyres ..................Snow chains ..................Car inactivity ..................
Page 151: Starting The Engine
Use the car normally if the engine starts and contact an out the emergency starting procedure (see “Emergency Start- Alfa Romeo Authorised Services provider as soon as pos- up” in chapter 4) and contact an Alfa Romeo Authorised Ser- sible. vice Provider.
Page 152 STARTING UP AND DRIVING In the initial period of use, it is advisable to avoid Avoid jump starting the engine by pushing, towing placing the car under excessive stress (for instance or driving downhill. These manoeuvres may dam- excessive acceleration, extended travel at maxi- age the catalytic converter.
Page 153: Parking
If the Y warning light in the instrument panel remains on con- Switch off the engine and pull up the handbrake. Engage a gear stantly, contact an Alfa Romeo Authorised Service Provider. if the car is facing uphill or reverse if it is facing downhill) and leave the wheels steered to one side.
Page 154: Using Of The Gearbox
STARTING UP AND DRIVING IMPORTANT Carry out these manoeuvres with the brake pedal pressed. USING THE GEARBOX IMPORTANT For vehicles equipped with a front armrest, lift this To engage reverse gear from neutral, lift the ring A-fig. 2 under the up to ensure that it does not interfere with the action of the hand- knob and, at the same time, move the lever to the left and then brake.
Page 155: Saving Fuel
STARTING UP AND DRIVING SAVING FUEL Press the clutch pedal fully to change gears cor- rectly. For this reason, there must be no obstacles Here are some suggestions which may help you to save fuel and on the floor under the pedals: ensure that any rub- lower the amount of toxic emissions released into the atmosphere.
Page 156 STARTING UP AND DRIVING Electric devices Unnecessary actions Use electric devices only for the amount of time needed. The heat- Avoid revving up when starting at traffic lights or before stopping ed rear windscreen, additional headlights, windscreen wipers and the engine. The latter action, like double-declutching, is unneces- heater fan require a considerable amount of energy;...
Page 157: Towing Trailers
STARTING UP AND DRIVING CONDITIONS OF USE TOWING TRAILERS Cold starting IMPORTANT NOTES Short distances and frequent cold start-ups will prevent the en- The vehicle must be provided with a type-approved tow hook and gine from reaching optimal running temperature. Consequently, adequate electrical system to tow caravans or trailers.
Page 158: Snow Tyres
Contact an Alfa Romeo Authorised Services to install a tow hook. Use snow tyres of the same size as the normal tyres provided with the car: an Alfa Romeo Authorised Services will be able to advise you on the best tyres for your requirements.
Page 159: Snow Chains
STARTING UP AND DRIVING SNOW CHAINS CAR INACTIVITY The use of snow chains should be in compliance with local regu- If the car is to be left inactive for longer than a month, the following lations. The snow chains may be applied only to the front wheel precautions should be noted: ❍...
Page 160: In An Emergency
IN AN EMERGENCY In an emergency we recommend that you call the freephone number found in the Warranty Booklet. You can also consult www.alfaromeo.com to find Alfa Romeo Authorised Services your nearest Starting the engine ..............160 Replacing a wheel ............... 161 “Fix&Go Automatic”...
Page 161: Starting The Engine
If after several attempts the engine will not start, contact an Alfa Romeo Authorised Service Provider. If the Y warning light in the instrument panel remains on con- stantly, contact an Alfa Romeo Authorised Service Provider imme- IMPORTANT Never connect the negative terminals of the two bat- diately.
Page 162: Replacing A Wheel
IN AN EMERGENCY REPLACING A WHEEL Indicate that the car is stationary according to the laws in force: emergency lights, refracting warn- GENERAL INSTRUCTIONS ing triangle, etc. Passengers should leave the car, particularly if it is heavily loaded, and wait for the wheel The vehicle is equipped with the“Fix&Go automatic kit”: to use to be changed away from on-coming traffic.
Page 163 IN AN EMERGENCY Vehicle handling is modified with the small spare The jack may only be used to replace wheels on wheel fitted. Avoid violent accelerations and brak- the car to which it is fitted or other cars of the same ing, sharp steering and fast cornering.
Page 164 IN AN EMERGENCY JACK Replace the wheel as follows: ❍ stop the car in a position where it does not endanger on-com- Important notes: ing traffic and where you can replace the wheel safely. The ❍ the jack weight is 1.76 kg; ground must be flat and compact;...
Page 165 IN AN EMERGENCY ❍ for versions with steel wheels: insert the screwdriver into open- ing A-fig. 4 to release clip B retaining the hub cap. ❍ use wrench A-fig. 5 to loosen the retaining bolts by one turn; ❍ for versions with alloy wheels: rock the vehicle to facilitate the detachment of the rim from the wheel hub.
Page 166 IN AN EMERGENCY ❍ operate device A-fig. 7 to extend the jack, until the upper part ❍ make sure that the contact surfaces on the small spare wheel B-fig. 8 inserts correctly into device C; are clean and free of impurities which may subsequently cause the retaining bolts to loosen;...
Page 167 IN AN EMERGENCY ❍ use wrench A-fig. 5, to fully tighten the retaining bolts, tight- REMOVING THE SUBWOOFER (versions with ening first one bolt and then the diametrically opposite bolt, HI-FI bose system, where provided) following the sequence shown in fig. 9; IMPORTANT The following procedure only applies to vehicles ❍...
Page 168 IN AN EMERGENCY ❍ rest the Subwoofer to one side in the luggage compartment, Subwoofer and “Fix&Go Automatic Kit” remove the container and take out the small spare wheel; fig. 12 ❍ replace the wheel as described previously. Locating the Fix&Go Automatic Kit: ❍...
Page 169 IN AN EMERGENCY REFITTING THE WHEEL After tyre replacement: stow the small spare wheel in the space provided in the boot; place the jack and other tools Following the procedure described previously, raise the car and re- into their container; place the container, complete with tools on move the small spare wheel.
Page 170: Fix&Go Automatic" Kit
IN AN EMERGENCY “Fix&Go Automatic” KIT IMPORTANT The sealing fluid is effective with external tempera- tures between –20 °C and +50 °C. The sealing fluid also has an expiry date. This is located in the luggage compartment. The Kit container al- so contains a screwdriver and the ring.
Page 171 IN AN EMERGENCY The kit cannot be used to repair damage to the tyre The cylinder contains ethylene and latex: may sidewall. Do not use the fast repair kit on tyres cause an allergic reaction. Harmful if swallowed. damaged by the vehicle running with a flat tyre. Irritates the eyes.
Page 172 IN AN EMERGENCY ❍ make sure that switch A-fig. 18 on the compressor is in posi- INFLATION PROCEDURE tion 0 (off), start the motor, insert pin A-fig. 17 into the cur- rent socket/cigar lighter on the central tunnel and switch on Wear the gloves provided in the kit.
Page 173 ❍ if a pressure value of at least 1.8 bars is detected, restore the tribute the sealant fluid in the tyre and repeat the inflation correct pressure (with the engine running and the handbrake procedure; engaged), and drive with care to an Alfa Romeo Authorised Services. A0J0114m fig. 18...
Page 174 IN AN EMERGENCY CHECKING AND RESTORING TYRE PRESSURE REPLACING THE CYLINDER The compressor can also be used to check and if necessary top Proceed as follows: up the tyre pressure. Release quick coupling A-fig. 19 and con- ❍ release coupling A-fig. 20 and disconnect pipe B; nect it directly to the tyre to be inflated.
Page 175: Changing A Bulb
IN AN EMERGENCY CHANGING A BULB GENERAL INSTRUCTIONS ❍ Before changing a bulb check the contacts for oxidation; ❍ blown bulbs must be replaced with others of the same type and power: ❍ After replacing a headlight bulb, always check its alignment; ❍...
Page 176 IN AN EMERGENCY Bulb Type Power Ref. figure Front side lights/Daylight lights W21/5W 5/21W Rear side lights – – Dipped beams Main beams Dipped beams/Main beams (versions with – Bi-xenon headlights) (where provided) Front direction indicators WY21W Rear direction indicators P21W Side direction indicators Brake light...
Page 177: Replacing Exterior Bulbs
IN AN EMERGENCY REPLACING EXTERIOR BULBS SIDELIGHTS/DAYLIGHT LIGHTS To change the bulb, proceed as follows: FRONT LIGHT CLUSTERS fig. 22 ❍ remove cover A-fig. 22; These contain the bulbs for the side lights, dipped beams, main beams ❍ withdraw lamp holder B-fig. 23, remove the bulb and and direction indicators.
Page 178: Dipped Beam Headlights
❍ remove the bulb and replace it; ❍ refit the lamp holder making sure it is correctly secured; ❍ refit cover B-fig. 22. With gas discharge bulbs (Bi-xenon) (where provided) Contact an Alfa Romeo Authorised Service Provider to replace these bulbs. A0J0040m A0J0144m fig. 24...
Page 179 ❍ turn the bulb holder anticlockwise FRONT FOG LIGHTS (where provided) ❍ remove the bulb and replace it; Contact an Alfa Romeo Authorised Services to replace these bulbs. Side indicators REAR LIGHT CLUSTERS To change the bulb, proceed as follows: To access the light cluster, move the luggage compartment side ❍...
Page 180 To replace the rear fog lights A-fig. 28 or reversing lights B con- These are located in the tailgate and are LED lights. Contact an tact an Alfa Romeo Authorised Services. Alfa Romeo Authorised Services to replace these lights. NUMBER PLATE LIGHTS To change the bulb proceed as follows: ❍...
Page 181: Replacing An Interior Bulb
IN AN EMERGENCY REPLACING AN INTERIOR BULB LUGGAGE COMPARTMENT COURTESY LIGHT To change the bulb, proceed as follows: FRONT COURTESY LIGHT ❍ open the luggage compartment and remove courtesy light A-fig. To change the bulb, proceed as follows: 33, by applying leverage at the points shown by the arrows; ❍...
Page 182 IN AN EMERGENCY ❍ open cover B-fig. 34 and replace the bulb; GLOVE COMPARTMENT LIGHT ❍ re-close the protective cover B on the lens; To change the bulb, proceed as follows: ❍ refit courtesy light A-fig. 33, inserting it into the correct posi- ❍...
Page 183 IN AN EMERGENCY ❍ refit protective cover B by inserting it between tabs C; SUN VISOR COURTESY LIGHT (where provided) ❍ refit the courtesy light by inserting into side E-fig. 37 and then pressing the other side until hearing the locking click of tab F. To change the bulb, proceed as follows: ❍...
Page 184: Replacing Fuses
IN AN EMERGENCY DOOR LIGHTS REPLACING FUSES To change the bulb, proceed as follows: INTRODUCTION ❍ open the door and remove the light by pushing on tab A-fig. 38 with a screwdriver; Fuses protect the electric system: they blow in the event of a fault in the system.
Page 185 IN AN EMERGENCY If the fuse blows again contact an Alfa Romeo If a general protection fuse blows contact an Alfa Authorised Services. Romeo Authorised Services. Never replace a blown fuse with anything other Before replacing a fuse, make sure you have re- than a new fuse.
Page 186 IN AN EMERGENCY FUSE LOCATION When washing the engine compartment, take care Fuses are grouped together in three junction units located in the not to spray water jets directly at the fuse box. engine compartment, dashboard and luggage compartment Fuse box in engine compartment This is located next to the battery: to access the fuses undo bolts A-fig.
Page 187 IN AN EMERGENCY Fuse box on dashboard To access the fuses, lower the flap A-fig. 42 and undo the bolts inside the actual flap. The fuses are located in the fuse box shown in fig. 43. A0J0128m fig. 42 A0J0129m fig.
Page 188 IN AN EMERGENCY Luggage compartment fuse box To gain access to the fuse box located on the left side of the luggage compartment open the relevant inspection lid (as shown in fig. 44). A0J0264m fig. 44 A0J0175m fig. 45...
Page 189 IN AN EMERGENCY FUSE SUMMARY TABLE LIGHTS FUSE AMPERE FIGURE Main beams Right hand dipped beam headlight Left hand dipped beam headlight Headlight gas discharge system (right side) Headlight gas discharge system (left side) Fog lights Brake light Reversing light Front courtesy light, luggage compartment light, Sun visor courtesy light, Door lights, Glove compartment light...
Page 190 IN AN EMERGENCY CONSUMERS FUSE AMPERE FIGURE Passenger compartment fan Headlight washer pump Two-tone horn Waste gate solenoid, Shut off solenoid, Canister solenoid, Lambda Sensor Heater, VGT solenoid, EGR cooling bypass solenoid, Swirl solenoid, Throttle solenoid, Glow plug preheating control unit Headlight alignment adjustment system Additional heater (PTC 1) Engine management control unit...
Page 191 IN AN EMERGENCY CONSUMERS FUSE AMPERE FIGURE Braking system control unit (control unit and solenoid unit) Electric steering control unit (power supply + Key), Brake system control unit (power supply + Key), Yaw sensor on tunnel INT/A key exhaust relay coils on engine fuse box Radio, Blue&Me control unit, Climate control unit,...
Page 192 IN AN EMERGENCY CONSUMERS FUSE AMPERE FIGURE Parking sensors control unit, Tyre pressure detection control unit, Rain/dusk sensor on rear-view mirror, Electro-chrome sensor on rear-view mirror, Seat belts fastened warning light display on rear-view mirror, Control panel illumination (Central control panel, Driver-side control panel, Steering wheel control panel, Blue&Me control panel),...
Page 193 IN AN EMERGENCY CONSUMERS FUSE AMPERE FIGURE Fuse wiring – Luggage compartment power socket Suspension control unit Power socket on tunnel Passenger/driver-side door mirror demister, Demister on front jets, Heated windscreen relay coil...
Page 194: Recharging The Battery
LIFTING THE CAR IMPORTANT The battery recharging procedure is provided as an ex- If you need to lift the car contact an Alfa Romeo Authorised Services, ample only. Contact an Alfa Romeo Authorised Services to carry which will be equipped with a workshop lift.
Page 195: Towing The Car
IN AN EMERGENCY TOWING THE CAR ATTACHING THE TOW HOOK Release cap A, remove tow ring B from its housing in the tool box The tow ring provided with the car is housed in the tool box in and tighten it fully on to the front (fig. 46) or rear (fig. 47) thread- the luggage compartment.
Page 196 IN AN EMERGENCY The power brakes and the electrical power steer- The front and rear tow hooks must only be used ing will not work while the car is being towed. More for emergency situations on the road. THE vehi- effort on the brake pedal and steering wheel will cle may be towed for short distances when a ded- therefore be required.
Page 197 page intentionally left blank...
Page 198: Care And Maintenance
CARE AND MAINTENANCE Scheduled maintenance ..............198 Scheduled servicing plan ..............199 Periodic checks .................. 203 Demanding use of the car ..............203 Checking fluid levels ................204 Air filter/pollen filter/diesel filter ............210 Battery....................210 Wheels and tyres ................212 Windscreen/rearscreen wipers .............
Page 199: Scheduled Maintenance
❍ Scheduled Service operations are required by the manufactur- Alfa Romeo has prepared a series of checks and service opera- er. Failure to carry them out may invalidate the warranty. tions to be carried out every 30,000 kilometres (for petrol ver- ❍...
Page 200: Scheduled Servicing Plan
CARE AND MAINTENANCE SCHEDULED SERVICING PLAN PETROL VERSIONS Thousands of kilometres ● ● ● ● ● ● Check tyre condition/wear and adjust pressure if required Check lighting system operation (headlights, direction indicators, hazard lights, passenger ● ● ● ● ● ●...
Page 201 - adhere strictly to the spark plug replacement intervals detailed in the Scheduled Service Plan; - it is advisable to have this carried out by an Alfa Romeo Authorised Services. 2 If the car is mainly used in cities or travels less than 10,000 km a year, change the engine oil and filter every...
Page 202 CARE AND MAINTENANCE DIESEL VERSIONS Thousands of kilometres ● ● ● ● ● Check tyre condition/wear and adjust pressure if required Check lighting system operation (headlights, direction indicators, hazard lights, ● ● ● ● ● passenger compartment lights, boot lights, instrument panel warning lights, etc.) ●...
Page 203 CARE AND MAINTENANCE Thousands of kilometres ● Replace auxiliary drive belt/s ● Replace toothed timing drive belt (*) ● ● Replace fuel filter ● ● ● ● ● Replace air filter cartridge Change engine oil and replace oil filter (**) ●...
Page 204: Periodic Checks
We recommend the use of FL Selenia products, designed and pro- ❍ check front disc brake pad condition and wear; duced specifically for Alfa Romeo cars (see “Consumables” table ❍ check cleanliness of bonnet and boot locks, and cleanliness and in chapter 6).
Page 205: Checking Fluid Levels
CARE AND MAINTENANCE ❍ check battery charge and fluid level (electrolyte); CHECKING FLUID LEVELS ❍ visually inspect the condition of auxiliary drivebelts; ❍ check and if necessary change engine oil and oil filter; Be careful not to confuse the various types of flu- ❍...
Page 206 CARE AND MAINTENANCE A0J0230m fig. 1 - 1.4 Petrol versions...
Page 207 CARE AND MAINTENANCE A0J0201m fig. 2 - 1.4 Turbo Petrol versions...
Page 208 CARE AND MAINTENANCE A0J0200m fig. 3 - 1.6 JTD versions...
Page 209 If this accidentally 1000 km. During the initial period of use the engine oil consumption occurs, do not start the engine. Contact an Alfa Romeo conditions should be considered as having stabilised after the first Authorised Services.
Page 210 CARE AND MAINTENANCE WINDSCREEN/REARSCREEN/HEADLIGHT BRAKE FLUID WASHING FLUID Check that the fluid is at the maximum level. If the level is too If the level is too low undo reservoir cap D-fig. 1-2-3 and add the low undo reservoir cap E-fig. 1-2-3 and add the fluid described in fluid described in chapter 6.
Page 211: Air Filter/Pollen Filter/Diesel Filter
The battery (F-fig. 1-2-3) does not require top ups of distilled water to replenish the electrolyte. A periodic check carried out at an Contact an Alfa Romeo Authorised Services to replace these Alfa Romeo Authorised Services is, however, necessary to check ef- filters. ficiency.
Page 212 (alarm etc.) or accessories that mobile phone, etc.): they will be able to suggest the most require large amounts of power, please consult an Alfa Romeo suitable devices and advise you if a higher capacity bat- Authorised Services.
Page 213: Wheels And Tyres
CARE AND MAINTENANCE WHEELS AND TYRES IMPORTANT NOTES Take the following precautions to prevent damage to the tyres: Before embarking on a long trip check the tyre inflation pressure ❍ avoid braking suddenly, racing starts and violent knocks against (and small spare wheel); check the pressure with the tyres cold. the curb, potholes or other obstacles and driving for extended Incorrect pressure causes abnormal tyre wear fig.
Page 214: Windscreen/Rearscreen Wipers
CARE AND MAINTENANCE WINDSCREEN/REARSCREEN WIPERS If the pressure is too low the tyre will get over- heated, with the risk of serious damage to the tyre. Driving with worn wiper blades is a serious haz- ard, because visibility is reduced in bad weather. Avoid changing over the tyres from the right side of the vehicle to the left side and vice versa.
Page 215 CARE AND MAINTENANCE Replacing the windscreen wiper blades SPRAY NOZZLES Proceed as follows: Windscreen washer fig. 7 ❍ lift the windscreen wiper arm and position the blade so that it The windscreen washer jets are fixed. forms an angle of 90° with the arm; ❍...
Page 216 CARE AND MAINTENANCE If the jet of fluid is inadequate, firstly check that there is fluid in the HEADLIGHT WASHERS (where provided) fig. 9 reservoir: see “Checking fluid levels” in this chapter). These are located within the front bumper. They are activated when Then check that the nozzle holes are not clogged, if necessary us- the dipped beam and/or main beam headlights are on and the ing a needle.
Page 217: Bodywork
CARE AND MAINTENANCE BODYWORK BODY AND UNDERBODY WARRANTY PROTECTION FROM Your car is covered by warranty against perforation due to rust of ATMOSPHERIC AGENTS any original element of the structure or body. For the general terms of this warranty, refer to the Warranty Booklet. The vehicle is equipped with the best available technological solu- tions to protect the bodywork against corrosion.
Page 218: Front Headlights
CARE AND MAINTENANCE When drying take care to dry the least exposed parts where the Windows water could collect most easily. Do not wash the car after it has Use specific detergents and clean cloths to prevent scratching. been parked in the sun or when the engine is bonnet is hot: this could take the shine off the paint.
Page 219: Interiors
CARE AND MAINTENANCE INTERIORS LEATHER SEATS (provided on request for versions/markets where available) Periodically check for water puddles under the mats that could cause Remove the dry dirt with a buckskin or slightly damp cloth, with- the panels to rust. out exercising too much pressure.
Page 220 CARE AND MAINTENANCE LEATHER PARTS (provided on request Don’t keep aerosol cans in the vehicle: risk of ex- for versions/markets where available) plosion. Aerosol cans must not be exposed to tem- Use only water and neutral soap to clean these parts. Never use peratures exceeding 50°C.
Page 221 CARE AND MAINTENANCE page intentionally left blank...
Page 222: Technical Data
TECHNICAL DATA Identification data ..............222 Engine codes - bodywork versions ..........224 Engine ................... 225 Fuel system ................226 Transmission ................226 Brakes..................227 Suspension ................227 Steering ................. 228 Wheels .................. 229 Dimensions ................233 Performance ................234 Weights .................
Page 223: Identification Data
TECHNICAL DATA IDENTIFICATION DATA IDENTIFICATION PLATE fig. 1 This plate is applied to the engine compartment front beam and The vehicle identification details are: shows the following identification data: ❍ Identification plate (located in the engine compartment, next A. Space reserved for national type approval to the upper attachment for the right-hand shock absorber);...
Page 224 TECHNICAL DATA CHASSIS MARKING fig. 3 BODYWORK PAINT IDENTIFICATION PLATE fig. 3 This is printed on the passenger compartment floor panel near the front right seat. Move flap A forwards to access it. This plate is applied inside the bonnet and shows the following data: The chassis marking includes: A Paint manufacturer.
Page 225: Engine Codes - Bodywork Versions
TECHNICAL DATA ENGINE CODES - BODYWORK VERSIONS Engine code Bodywork version 1.4 Petrol (*) 955A1000 955AXB1B 01 ( ) 955AXB1B 01B ( ) 1.4 Turbo Petrol 199A8000 955AXA1B 00 ( ) 955AXA1B 00B ( ) 1.6 JTD 955A3000 955AXC1B 02 ( ) 955AXC1B 02B ( ) (*) Version for specific markets ( ) 4 seater version...
Page 226: Engine
TECHNICAL DATA ENGINE GENERAL 1.4 Petrol (*) 1.4 Turbo Petrol 1.6 JTD Engine code 955A1000 199A8000 955A3000 Cycle Otto Otto Diesel Number and layout of cylinders 4 in line 4 in line 4 in line Piston bore and stroke 72.0 x 84.0 72.0 x 84.0 79.5 x 80.5 Total displacement...
Page 227: Fuel System
TECHNICAL DATA FUEL SYSTEM 1.4 Petrol 1.4 Turbo Petrol 1.6 JTD Fuel system Phased sequential electronic Electronically-controlled Multijet “Common Rail” direct Multipoint injection Multipoint phased electronic injection with turbo with detonation control sequential electronic injection and intercooler with turbo and intercooler TRANSMISSION 1.4 Petrol - 1.4 Turbo Petrol - 1.6 JTD Six forward gears plus reverse with synchronisers for forward gears...
Page 228: Brakes
TECHNICAL DATA BRAKES 1.4 Petrol - 1.4 Turbo Petrol - 1.6 JTD Service brakes: – front Self ventilating discs – rear Disc Parking brake Controlled by hand lever, acting on rear brakes IMPORTANT Water, ice and salt sprinkled on the roads may deposit themselves on the brake discs, reducing braking efficiency the first time the brakes are applied.
Page 229: Steering
TECHNICAL DATA STEERING 1.4 Petrol - 1.4 Turbo Petrol - 1.6 JTD Type Rack and pinion with electric steering Turning circle (between pavements) 11.0...
Page 230: Wheels
TECHNICAL DATA WHEELS READING TYRE MARKINGS fig. 4 Example: 195/55 R 16 91 V RIMS AND TYRES 195 = Nominal width (S, distance in mm between sidewalls). Pressed steel or alloy rims. Tubeless radial carcass tyres. All ap- 55 = Height/width ratio (H/S) in percentage. proved tyres are listed in the Log Book.
Page 231 TECHNICAL DATA Load rating (capacity) Maximum speed rating 60 = 250 kg 84 = 500 kg Q = up to 160 km/h. H = up to 210 km/h. 61 = 257 kg 85 = 515 kg R = up to 170 km/h. V = up to 240 km/h.
Page 232 TECHNICAL DATA Versions Rims Tyres Spare wheel Provided Snow tyres Tyre 1.4 Petrol 7Jx16 ET 39 195/55 R16 87 H 195/55 R16 87 H (M+S) 7Jx17 ET 39 205/45 R17 88W XL 205/45 R17 88 H (M+S) 135/70 R16 4B x 16 ET 15 7Jx17 ET 39 215/45 R17 87W (*) 215/45 R17 87 H (M+S)
Page 233 TECHNICAL DATA COLD TYRE INFLATION PRESSURES (bar) Versions Size PROVIDED TYRES Medium load Full load Front Rear Front Rear 1.4 Petrol 195/55 R16 87H 205/45 R17 88W XL 215/45 R17 87W 215/40 R18 89W XL 1.4 Turbo 195/55 R16 87V Petrol 205/45 R17 88W XL 215/45 R17 87W...
Page 234: Dimensions
TECHNICAL DATA DIMENSIONS Dimensions are expressed in mm and refer to the vehicle fitted with standard tyres. The height refers to the vehicle unladen. Luggage compartment capacity Unladen luggage compartment capacity (V.D.A. standards) 270 dm A0J0202m fig. 5 2511 1446 1477 ( ) 1720 1469 ( )
Page 235: Performance
TECHNICAL DATA PERFORMANCE Versions Top speed (km/h) Acceleration from 0-100 km/h (sec.) 1.4 Petrol 12.3 1.4 Turbo Petrol 1.6 JTD...
Page 236: Weights
TECHNICAL DATA WEIGHTS Weights (kg) 1.4 Petrol 1.4 Turbo Petrol 1.6 JTD 4 seater 5 seater 4 seater 5 seater 4 seater 5 seater Unladen weight (with all fluids, fuel tank filled to 90% and without optional equipment): 1080 1080 1145 1145 1205...
Page 237: Consumables
TECHNICAL DATA CONSUMABLES 1.4 Petrol 1.6 JTD Recommended fuels 1.4 Turbo Petrol and original lubricants litres litres Fuel tank: – 45 ( ) – Unleaded petrol not less than 95 R.O.N including a reserve of: – – (Specification EN228) ( ) Diesel fuel for motor vehicles (Specification EN590) Mixture of 50% demineralised water Engine cooling system...
Page 238: Fluids And Lubricants
ACEA C2; are acceptable. If this is the case, the best engine performance is not guaranteed. We recommend replacing the lubricant as soon as possi- ble at an Alfa Romeo Authorised Service Provider. The use of products with characteristics that are not up to ACEA C3 and ACEA C2 standard could cause engine damage not covered by the warranty.
Page 239 TECHNICAL DATA Fluid qualitative specifications and lubricants Fluids and lubricants Interval for correct vehicle operation original replacement Synthetic-based oil, grade SAE 75W-85. TUTELA CAR TECHNYX Manual gearboxes and Exceeds API GL-4 PLUS specifications. Contractual Technical differentials FIAT 9.55550-MX3 qualification Reference N° F010.B05 differentials Synthetic-based oil, grade SAE 75W-85.
Page 240: Fuel Consumption
TECHNICAL DATA ❍ combined fuel consumption: calculated based on about 37% FUEL CONSUMPTION of urban cycle consumption and about 63% of extra urban con- sumption. The fuel consumption figures given in the table below are deter- mined on the basis of the homologation tests set down by specif- IMPORTANT The type of route, traffic situations, weather conditions, ic European Directives.
Page 241 TECHNICAL DATA EMISSIONS The CO emission levels at the exhaust given in the following tables refer to combined consumption. EMISSIONS ACCORDING TO 2004/3/EC DIRECTIVE (g/km) 1.4 Petrol 1.4 Turbo Petrol 1.6 JTD...
Page 242: Index
Fix&Go Automatic kit ....169 emissions ......240 Alfa “dna” (system) ....111 Flashing the headlights ....77 CODE card ........47 Alfa Romeo CODE (system) ..46 Fluids and lubricants ....237 Compliance for use ....... 137 Ashtray ........91 Fog lights Control buttons ......
Page 243 INDEX Supplementary heater....75 Radio wiring system ..... 115 dentification data ....... 222 Suspension ......... 227 Rear fog lights In an emergency ......159 Symbols ........46 – activation ......87 Installing a navigation – bulb replacement ....179 system (wiring) ......116 Rear screen wiper .P.M.S.
Page 244 RIGHT HAND DRIVE VERSION DASHBOARD The presence and position of controls, instruments and gauges may vary according to different versions. fig. 1 A0J0291m 1. Air vent for side windows - 2. Adjustable air vent - 3. Passenger front air bag - 4. Adjustable air vents - 5. Hazard warning lights, door lock/unlock button - 6.
Page 245: Instrument Panel And Onboard Instruments
RIGHT HAND DRIVE VERSION INSTRUMENT PANEL AND ONBOARD INSTRUMENTS fig. 2 A0J0292m fig. 3 A0J0293m VERSIONS WITH MULTIFUNCTIONAL DISPLAY VERSIONS WITH RECONFIGURABLE MULTIFUNCTIONAL DISPLAY A Speedometer (speed indicator) A Speedometer (speed indicator) B Multifunctional display B Reconfigurable multifunctional display C Rev counter C Rev counter D Fuel level gauge with reserve warning light D Fuel level gauge with reserve warning light...
Page 246 AT THE END OF ITS LIFE-CYCLE For years now Alfa Romeo has been developing its global commitment towards the safeguarding and protection of the En- vironment through the continuous improvement of its production processes and the making of increasingly more “eco friend- ly”...
Page 249: Engine Oil Change
ENGINE OIL CHANGE 1.4 Petrol -1.4 Turbo Petrol 1.6 JTD litres litres Engine sump 2.75 Engine sump and filter 2.9(*)/3.3(**) 2.6(*)/2.95(**) (*) 1.4 Petrol (**) 1.4 Turbo Petrol REFUELLING (litres) 1.4 Petrol -1.4 Turbo Petrol 1.6 JTD Fuel tank capacity Reserve 5 - 7 For cars with petrol engine, only use unleaded petrol with over 95 R.O.N.

Alfa Romeo MiTo Owner's Manual

Table of Contents

Safety

Starting up and Driving

In an Emergency

Care and Maintenance

Technical Data

Quick Links

Chapters

Related Manuals for Alfa Romeo MiTo

Summary of Contents for Alfa Romeo MiTo

Table of Contents
