- Page 1 Operator′s manual Please read the operator’s manual carefully and make sure you understand the instructions before using the machine.
-
Page 2: Key To Symbols
Symbols WARNING! Incorrect or careless use of a hedge trimmer can turn it into a dangerous tool that can cause serious or even fatal injury. It is extremely important that you read and understand the contents of this operator’s manual. -
Page 3: Table Of Contents
WARNING! Incorrect or careless use of a hedge trimmer can turn it into a dangerous tool that can cause serious or even fatal injury. It is extremely important that you read and understand the contents of this operator’s manual. -
Page 4: Introduction
If you will sell this machine, make sure that the buyer will get the operator′s manual. Good luck on using your Jonsered machine! Jonsered has a policy of continuous product development and therefore reserves the right to modify the design and appearance of products without prior notice. -
Page 5: What Is What
What is what? 1 Cutter 2 Grease nipple and plug for filling lubricant. 3 Bevel gear 4 Angle adjustment handle 5 Angle adjustment knob 6 Shaft 7 Front handle 8 Throttle control 9 Stop switch 10 Throttle lock 11 Start throttle button 12 Harness support hook 13 Starter handle WHAT IS WHAT? -
Page 6: General Safety Precautions
English Personal protective equipment IMPORTANT! Incorrect or careless use of a hedge trimmer can turn it into a dangerous tool that can cause serious or even fatal injury. It is extremely important that you read and understand the contents of this operator’s manual. -
Page 7: Machine's Safety Equipment
See instructions under the heading Start. Start the hedge trimmer and apply full throttle. Release the throttle trigger and check that the blades stop and remain stationary. If the blades move when the throttle trigger is in the idle position then the carburettor idle setting must be adjusted. - Page 8 GENERAL SAFETY PRECAUTIONS In countries that have a warm and dry climate there is a significant risk of fire. We therefore fit certain mufflers with a spark arrestor mesh. Check whether the muffler on your machine is fitted with this kind of mesh. For mufflers it is very important that you follow the instructions on checking, maintaining and servicing your machine.
-
Page 9: Assembly
Fitting the main body Connect the engine (A) to the tube (B) with four screws (C). Connecting throttle cable and stop switch wires 1 Insert the throttle cable (A) through the carburettor bracket (B), then screw the cable adjuster sleeve (C) into the carburettor bracket fully. -
Page 10: Adjusting The Harness
ASSEMBLY Adjusting the harness You should always use the harness with the machine to give maximum control over the machine and reduce the risk of fatigue in your arms and back. 1 Put on the harness. 2 Hook the machine onto the harness support hook. 3 Adjust the length of the harness so that the support hook is roughly level with your right hip. -
Page 11: Fuel Handling
When working at continuous high revs a higher octane rating is recommended. Two-stroke oil • For best results and performance use JONSERED two- stroke engine oil, which is specially formulated for our air- cooled two-stroke engines. • Never use two-stroke oil intended for water-cooled engines, sometimes referred to as outboard oil (rated TCW). -
Page 12: Fuelling
Mixing • Always mix the petrol and oil in a clean container intended for fuel. • Always start by filling half the amount of the petrol to be used. Then add the entire amount of oil. Mix (shake) the fuel mixture. Add the remaining amount of petrol. •... -
Page 13: Starting And Stopping
STARTING AND STOPPING Check before starting • Inspect the working area. Remove any objects that could be thrown out. • Check the cutting attachment. Never use blades that are dull, cracked or damaged. • Check that the machine is in perfect working order. Check that all nuts and screws are tight. -
Page 14: Working Techniques
General working instructions IMPORTANT! This section takes up the basic safety precautions for working with a hedge trimmer. If you encounter a situation where you are uncertain how to proceed you should ask an expert. Contact your dealer or your service workshop. -
Page 15: Transport Position
Make sure that the tip does not touch the ground. • Do not rush the work, but work steadily until all the branches have been cut back cleanly. Changing the hedge trimmer angle • Undo the knob. WORKING TECHNIQUES •... - Page 16 3 Grip the handle on the cutting unit and angle the cutting unit upwards. At an angle of 48 degrees there is a stop position. To pass the stop position, pull out the lock button. 4 Fold down the cutting unit against the shaft. 5 Tighten the knob.
-
Page 17: Maintenance
Carburettor Your Jonsered product has been designed and manufactured to specifications that reduce harmful exhaust fumes. The engine will be run in after it has used 8-10 tanks of fuel. To ensure that the engine runs at peak performance and... -
Page 18: Cooling System
Cooling system To keep the working temperature as low as possible the machine is equipped with a cooling system. The cooling system consists of: 1 Cooling fins on the cylinder. 2 Cylinder cover (directs cold air over the cylinder). Clean the cooling system with a brush once a week, more often in demanding conditions. -
Page 19: Gear
Gear There are three grease nipples on the gearbox. Use a grease gun to top up with grease. This should be carried out after approximately every 20 working hours. Use Jonsered special grease. Cleaning and lubrication Clean any resin and plant residue from the blades using cleaning agent before and after using the machine. -
Page 20: Maintenance Schedule
Maintenance schedule The following is a list of the maintenance that must be performed on the machine. Most of the items are described in the Maintenance section. The user must only carry out the maintenance and service work described in this Operator’s Manual. More extensive work must be carried out by an authorized service workshop. -
Page 21: Technical Data
Note 2: Reported data for equivalent sound pressure level for the machine has a typical statistical dispersion (standard deviation) of 1 dB (A). Note 3: Reported data for equivalent vibration level has a typical statistical dispersion (standard deviation) of 1 m/s TECHNICAL DATA HTE2123 22,8 32,2 28,0... -
Page 22: Ec-Declaration Of Conformity
Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declare under sole responsibility that the hedge trimmers Jonsered HTE2123 from 2009’s serial numbers and onwards (the year is clearly stated in plain text on the type plate with subsequent serial number), are in conformity with the standards or or other normative documents following the provisions in the COUNCIL’S DIRECTIVES:... - Page 24 Original instructions 1152683-26 ´®z+Td@¶6o¨ ´®z+Td@¶6o¨ 2009-11-17...
