FOREWORD
This manual explains components, system
operations and functions for the Mazda3,
MAZDASPEED3, Mazda5, Mazda6,
MAZDASPEED6, Mazda MX-5,
Mazda RX-8.
For proper repair and maintenance, a
thorough familiarization with this manual is
important, and it should always be kept in a
handy place for quick and easy reference.
All the contents of this manual, including
drawings and specifications, are the latest
available at the time of printing.
As modifications affecting repair or
maintenance occur, relevant information
supplementary to this volume will be made
available at Mazda dealers.
This manual should be kept up-to-date.
Mazda Motor Corporation reserves the right
to alter the specifications and contents of
this manual without obligation or advance
notice.
All rights reserved. No part of this book may
be reproduced or used in any form or by
any means, electronic or mechanical—
including photocopying and recording and
the use of any kind of information storage
and retrieval system—without permission in
writing.
Mazda Motor Corporation
HIROSHIMA, JAPAN
APPLICATION:
This manual is applicable to vehicles
beginning with the Vehicle Identification
Numbers (VIN),and related materials shown
on the following page.
Mazda3
MAZDASPEED3
Mazda5
Mazda6
MAZDASPEED6
Mazda MX-5
Mazda RX-8
© 2006 Mazda Motor Corporation
PRINTED IN U.S.A., JULY 2006
Form No. 3422–1U–06G
Part No. 9999–95–MODL–07

Advertisement

Table of Contents
loading

Summary of Contents for Mazda 3 2007

  • Page 1 Mazda dealers. This manual should be kept up-to-date. Mazda RX-8 Mazda Motor Corporation reserves the right to alter the specifications and contents of this manual without obligation or advance notice. All rights reserved. No part of this book may ©...
  • Page 2 Mazda MX-5 CONTENTS TITLE SECTION ENGINE BODY & ACCESSORIES...
  • Page 4 2007 Mazda3, MAZDASPEED3, Mazda5, Mazda6, MAZDASPEED6, Mazda MX-5, Mazda RX-8 Service Highlights (3422–1U–06G) ENGINE SECTION Toc of SCT OUTLINE[LF] ....01-00 ON-BOARD DIAGNOSTIC [LF]..... 01-02 CONTROL SYSTEM[LF] .
  • Page 5 2007 Mazda3, MAZDASPEED3, Mazda5, Mazda6, MAZDASPEED6, Mazda MX-5, Mazda RX-8 Service Highlights (3422–1U–06G) OUTLINE [LF] ENGINE SPECIFICATION[LF] id0100e1100300 Specification Specification Item 2007MY MX-5 2006MY MX-5 LF (2.0L) LF (2.0L) MECHANICAL DOHC-16 valves in-line, 4- ← Type cylinder ← Combustion chamber...
  • Page 6 2007 Mazda3, MAZDASPEED3, Mazda5, Mazda6, MAZDASPEED6, Mazda MX-5, Mazda RX-8 Service Highlights (3422–1U–06G) OUTLINE [LF] Specification Item 2007MY MX-5 2006MY MX-5 LF (2.0L) LF (2.0L) ← Type Wax, bottom-bypass Opening ← (°C {°F}) 80—84 {176—183} temperature Thermostat ← Full-open temperature (°C {°F})
  • Page 7 2007 Mazda3, MAZDASPEED3, Mazda5, Mazda6, MAZDASPEED6, Mazda MX-5, Mazda RX-8 Service Highlights (3422–1U–06G) OUTLINE [LF] Specification Item 2007MY MX-5 2006MY MX-5 LF (2.0L) LF (2.0L) STARTING SYSTEM ← Type Coaxial reduction Starter ← Output (kW) : Applied VIN (Assumed) JM1 NC15F*7# 100001—130613 JM1 NC16F*7# 100001—130613...
  • Page 8: Table Of Contents

    ON-BOARD DIAGNOSTIC [LF] 01-02 ON-BOARD DIAGNOSTIC [LF] DIAGNOSTIC TEST MODE[LF] ..01-02–1 DTC DETECTION LOGIC AND Sending Diagnostic Data ... 01-02–2 CONDITIONS[LF] ....01-02–8 Sending Freeze Frame Data .
  • Page 9: Sending Diagnostic Data

    ON-BOARD DIAGNOSTIC [LF] Sending Diagnostic Data PID data monitor • The PID data monitor items are shown below. PID data monitor table Full names Unit Fuel system loop status Refer to list below. LOAD °C °F Short term fuel trim Long term fuel trim Engine speed Vehicle speed...
  • Page 10: Sending Freeze Frame Data

    ON-BOARD DIAGNOSTIC [LF] On-board system readiness test • The items supported by the on-board system readiness test are shown below. Continuous monitoring system — HO2S heater — HO2S — Fuel system — Misfire — CCM Intermittent monitoring system — HO2S heater —...
  • Page 11: Sending Emission-Related Malfunction Code

    ON-BOARD DIAGNOSTIC [LF] Sending Emission-related Malfunction Code • The DTCs are shown below. ×: Applicable N/A: Not applicable DTC No. Self-test Memory Condition Monitor item function 07MY 06MY type* ← B1342 PCM malfunction C, O ← × P0011 CMP timing over-advanced C, R ←...
  • Page 12 ON-BOARD DIAGNOSTIC [LF] DTC No. Self-test Memory Condition Monitor item function 07MY 06MY type* Flash/ ← × P0302 Cylinder No.2 misfire detected 1 or 2 Misfire C, R Flash/ ← × P0303 Cylinder No.3 misfire detected 1 or 2 Misfire C, R Flash/ ←...
  • Page 13 ON-BOARD DIAGNOSTIC [LF] DTC No. Self-test Memory Condition Monitor item function 07MY 06MY type* PCM random access memory (RAM) ← × P0604 C, O, R error ← × P0606 PCM processor C, O, R ← × P0610 PCM vehicle options error C, O, R Throttle actuator control circuit range/ ←...
  • Page 14: Sending Intermittent Monitoring System Test Results

    ON-BOARD DIAGNOSTIC [LF] DTC No. Self-test Memory Condition Monitor item function 07MY 06MY type* ← × P2502 Charging system voltage problem Other C, R ← × P2503 Charging system voltage low Other C, R ← × P2504 Charging system voltage high Other C, R ←...
  • Page 15: Dtc Detection Logic And Conditions[Lf]

    ON-BOARD DIAGNOSTIC [LF] 2-drive cycle type • The code for a failed system is stored in the PCM memory in the first drive cycle. If the problem is not found in the second drive cycle, the PCM determines that the system returned to normal or the problem was mistakenly detected, and deletes the pending code when the ignition switch is turned to the ON position in the next drive cycle.
  • Page 16 ON-BOARD DIAGNOSTIC [LF] P0069 Manifold absolute pressure/atmospheric pressure correlation • PCM monitors differences between intake manifold vacuum and atmospheric pressure. If the difference is below –12 kPa {–90 mmHg, –3.5 inHg} or above 12 kPa {90 mmHg, 3.5 inHg} when the following conditions are met, the PCM determines that there is a MAP sensor performance problem.
  • Page 17 ON-BOARD DIAGNOSTIC [LF] P0126 Coolant thermostat stuck open • If the ECT signal never exceeds 71 °C {160 °F} after engine start for specified period, PCM determines that the coolant thermostat is stuck open. MONITORING CONDITIONS — IAT: above –10 °C {14 °F} —...
  • Page 18 ON-BOARD DIAGNOSTIC [LF] P0138 Rear HO2S circuit high input • The PCM monitors input voltage from rear HO2S. If the input voltage from the rear HO2S sensor is above 1.2 V for 0.8 s, the PCM determines that circuit input is high. P0139 Rear HO2S circuit problem •...
  • Page 19 ON-BOARD DIAGNOSTIC [LF] P0335 CKP sensor circuit problem • If the PCM does not receive the input voltage from the CKP sensor for 4.2 s while the MAF is 1.95 g/s {0.25 lb/ min.} or above, the PCM determines that the CKP sensor circuit has a malfunction. •...
  • Page 20 ON-BOARD DIAGNOSTIC [LF] P0455 Evaporative emission control system leak detected (gross leak) • PCM measures the pump load current (EVAP line pressure) when the specified period has passed after EVAP system is sealed when monitoring conditions are met. If the load does not reach the reference current value within the specified period, PCM determines that the EVAP system has gross leak.
  • Page 21 ON-BOARD DIAGNOSTIC [LF] P0500 VSS circuit problem With ABS/DSC • If an error in the wheel speed signal from the ABS/DSC HU/CM is detected by CAN when the following conditions are met: — Neutral switch and clutch pedal position switch are OFF —...
  • Page 22 ON-BOARD DIAGNOSTIC [LF] P0661 Variable intake air solenoid valve circuit low input • The PCM monitors the variable intake air solenoid valve control signal. If the PCM turns variable intake air solenoid valve off but voltage at PCM terminal still remains low, the PCM determines that variable intake air solenoid valve circuit has malfunction.
  • Page 23 ON-BOARD DIAGNOSTIC [LF] P2123 APP sensor No.1 circuit high input • The PCM monitors the input voltage from APP sensor No.1 when the engine is running. If the input voltage is above 4.8 V, the PCM determines that the APP sensor No.1 circuit input voltage is high. P2127 APP sensor No.2 circuit low input •...
  • Page 24: Koeo/Koer Self-Test[Lf]

    • The KOEO self-test is a powertrain control system self-diagnosis, performed when the ignition switch is turned to the ON position and the engine is stopped. A KOEO self-test begins when the connected Mazda Modular Diagnostic System (M-MDS) sends an execute command to the PCM.
  • Page 25 ON-BOARD DIAGNOSTIC [LF] KOEO/KOER self-test table ×: Applicable N/A: Not applicable DTC No. Test condition Condition 07MY 06MY KOEO KOER ← × B1342 PCM malfunction ← × P0011 CMP timing over-advanced ← × P0012 CMP timing over-retarded ← P0016 CKP-CMP correlation ←...
  • Page 26 ON-BOARD DIAGNOSTIC [LF] DTC No. Test condition Condition 07MY 06MY KOEO KOER ← × × P0443 Purge solenoid valve circuit problem Change over valve (COV) (EVAP system leak detection pump) stuck ← × P0446 close ← × P0455 Evaporative emission control system leak detected (gross leak) ←...
  • Page 27: Pid/Data Monitor And Record[Lf]

    ON-BOARD DIAGNOSTIC [LF] DTC No. Test condition Condition 07MY 06MY KOEO KOER ← P2195 Front HO2S signal stuck lean ← P2196 Front HO2S signal stuck rich ← × × P2228 BARO sensor circuit low input ← × × P2229 BARO sensor circuit high input ←...
  • Page 28 ON-BOARD DIAGNOSTIC [LF] Item definition Unit/Condition terminal 07MY 06MY EQ_RAT11_D ← Target lambda ← ° ETC_ACT Throttle control ← ETC_DSD Throttle control desired ← ° ← EVAPCP Purge solenoid valve duty value ← FAN1 Cooling fan relay No.1 control signal Off/On ←...
  • Page 29 ON-BOARD DIAGNOSTIC [LF] Item definition Unit/Condition terminal 07MY 06MY SELTESTDTC Diagnostic trouble codes ← SHRTFT1 Short term fuel trim (front) ← SHRTFT12 Short term fuel trim (rear) ← ° SPARKADV Ignition timing ← test Test mode Off/On ← TIRESIZE Tire revolution per mile rev/mile ←...
  • Page 30: Simulation Test[Lf]

    ON-BOARD DIAGNOSTIC [LF] SIMULATION TEST[LF] id010245100600 • The simulation items are shown below. Simulation item table ×: Applicable N/A: Not applicable Item Test condition Applicable component Unit/condition PCM terminal 07MY 06MY KOEO KOER ← × × ACCS A/C relay Off/On ←...
  • Page 32 CONTROL SYSTEM [LF] 01-40 CONTROL SYSTEM [LF] FUEL INJECTION CONTROL Determination of Effective OPERATION[LF] ....01-40–1 Injection Time ....01-40–2 Operation .
  • Page 33 CONTROL SYSTEM [LF] Determination of Effective Injection Time • The PCM divides the engine operation conditions into control zones according to engine speed and engine load and determines the effective injection time at each control zone to perform optimum air/fuel ratio control in all engine driving ranges.
  • Page 34 CONTROL SYSTEM [LF] • When the following conditions continue for 10 s or more: — Vehicle is stopped. — Engine speed is 6,500 rpm or more. — Engine coolant temperature is approx. 40 °C {104 °F}. Note • The PCM determines that the driver continues to unintentionally depress the accelerator pedal Determination of fuel injection time •...
  • Page 35 CONTROL SYSTEM [LF] Purpose: Ensures engine speed stability during D-range shifting Correction condition D-range correction • Throttle valve fully-closed and shifted into D range (AT) Correction amount • Low engine coolant temperature→large correction Purpose: Improved engine output, decrease of exhaust gas temperature Correction condition •...
  • Page 36 CONTROL SYSTEM [LF] Dechoke control Purpose • To improve engine starting startability when spark plugs are flooded. Control conditions • When cranking close to fully-open throttle valve Fuel cut during immobilizer system activation Purpose • To prevent vehicle theft Execution conditions •...
  • Page 38 BODY & ACCESSORIES SECTION Toc of SCT GLASS/WINDOWS/ EXTERIOR TRIM ... 09-16 MIRRORS ....09-12 INSTRUMENTATION/ SECURITY AND LOCKS DRIVER INFO.
  • Page 39 GLASS/WINDOWS/MIRRORS POWER WINDOW SYSTEM WIRING DIAGRAM id091200100300 With exterior open function POWER RETRACTABLE P/W CM HARDTOP CM OPEN OPEN RELAY RELAY CLOSE CLOSE RELAY RELAY CLOSE CLOSE KEYLESS CM OPEN OPEN amxuuw0000007 09-12–2...
  • Page 40 GLASS/WINDOWS/MIRRORS Without exterior open function POWER P/W CM RETRACTABLE HARDTOP CM OPEN OPEN RELAY RELAY CLOSE CLOSE RELAY RELAY CLOSE CLOSE OPEN OPEN amxuuw0000007 End Of Sie EXTERIOR OPEN FUNCTION OUTLINE id091200103000 • An exterior open function has been adopted so that the power window system can be operated from outside the vehicle.
  • Page 41 GLASS/WINDOWS/MIRRORS EXTERIOR OPEN FUNCTION STRUCTURAL VIEW id091200103100 POWER WINDOW REGULATOR/MOTOR WITH KEYLESS WITH ADVANCED ENTRY SYSTEM KEYLESS SYSTEM KEYLESS CONTROL MODULE KEYLESS RECEIVER POWER WINDOW MAIN SWITCH amxuun0000000 End Of Sie EXTERIOR OPEN FUNCTION BLOCK DIAGRAM id091200103200 With Advanced Keyless System TRUNK LOCK LINK PUSH...
  • Page 42 GLASS/WINDOWS/MIRRORS EXTERIOR OPEN FUNCTION OPERATION id091200103300 • With the system, door glass can open in conjunction with the UNLOCK operation of the transmitter. • One opening operation fully opens (automatic open) door glass. • The keyless control module sends the signal requiring the open operation to the power window control unit (power window main switch) based on the signals input from the switches.
  • Page 44 • Due to the adoption of the power retractable hardtop, DTC U0207 has been added. End Of Sie ON-BOARD DIAGNOSYS SYSTEM OPERATION[ADVANCED KEYLESS SYSTEM] NG: KEYLESS ENTRY SYSTEM id0914b1111000 DTC Table System malfunction location mazda modular diagnostic system (M-MDS) display U0207 Abnormal message from power retractable hardtop control module End Of Sie 09-14–1...
  • Page 46 EXTERIOR TRIM 09-16 EXTERIOR TRIM EXTERIOR TRIM OUTLINE ..09-16–1 Construction ..... 09-16–13 EXTERIOR TRIM Operation .
  • Page 47: Exterior Trim Outline

    EXTERIOR TRIM POWER RETRACTABLE HARDTOP SYSTEM STRUCTURAL VIEW id091600101100 POWER RETRACTABLE HARDTOP LIMIT SWITCH (POWER RETRACTABLE HARDTOP CLOSE POSITION SWITCH) POWER RETRACTABLE HARDTOP LIMIT SWITCH (POWER RETRACTABLE HARDTOP DECK PANEL LIMIT SWITCH OPEN POSITION SWITCH) (DECK PANEL OPEN POSITION SWITCH) POWER RETRACTABLE HARDTOP...
  • Page 48: Power Retractable Hardtop System Wiring Diagram

    EXTERIOR TRIM POWER RETRACTABLE HARDTOP SYSTEM WIRING DIAGRAM id091600101200 POWER RETRACTABLE HARDTOP OPENED POSITION SWITCH POWER RETRACTABLE HARDTOP CLOSED POSITION SWITCH DECK PANEL OPENED POSITION SWITCH TRUNK OPENER RELAY DECK PANEL CLOSED POSITION SWITCH KEYLESS SYSTEM ROOF MOTOR (LEFT) IGNITION SWITCH DECK PANEL MOTOR (LEFT)
  • Page 49: Power Retractable Hardtop System Operation

    EXTERIOR TRIM POWER RETRACTABLE HARDTOP SYSTEM OPERATION id091600101300 Operation Conditions • The Power retractable hardtop operates when all of the following conditions are met. — Ignition switch is in the ON position — The trunk lid is in the fully closed position. —...
  • Page 50 EXTERIOR TRIM Open operation 1. When the Power retractable hardtop open switch is turned on with all the Power retractable hardtop operation conditions met, the Power retractable hardtop open request signal is sent to the Power retractable hardtop control module. 2.
  • Page 51 EXTERIOR TRIM 7. When the roof panel link pin contacts the Power retractable hardtop open position switch and the switch is turned on, the roof panel is determined to be fully open and the roof panel motor stops. DECK PANEL POWER RETRACTABLE HARDTOP ROOF MOTOR...
  • Page 52 EXTERIOR TRIM 10. When the deck panel link pin contacts the deck panel close switch and the switch is turned off, the deck panel is determined to be fully closed and the deck panel motor stops. ROOF HOOK FRONT ROOF PANEL LINK A ROOF HOOK ROOF HOOK...
  • Page 53 EXTERIOR TRIM Close operation timing chart DECK PANEL OPEN OPERATION DECK STOP TURN ON PANEL DECK POWER POWER DECK PANEL OPEN PANEL RETRACTABLE RETRACTABLE CLOSE OPERATION DECK PANEL OPERATION OPEN HARDTOP HARDTOP CLOSE COMPLETED START CLOSE OPERATION START OPERATION CLOSE DECK PANEL SWITCH AGAIN START...
  • Page 54 EXTERIOR TRIM Close operation 1. When the Power retractable hardtop close switch is turned on with all the Power retractable hardtop operation conditions met, Power retractable hardtop close request signal is sent to the Power retractable hardtop control module. 2. The Power retractable hardtop control module confirms the operation conditions when it receives the signal, and if all the conditions are met, it sends an operation start beep signal to the instrument cluster.
  • Page 55: Power Retractable Hardtop Control Module Function

    EXTERIOR TRIM 8. When the roof panel link pin contacts the Power retractable hardtop close position switch and the switch is turned on, the roof panel is determined to be fully closed and the roof panel motor stops. DECK PANEL POWER RETRACTABLE HARDTOP FULLY-CLOSE POSITION...
  • Page 56: Fail-Safe Function

    EXTERIOR TRIM FAIL-SAFE FUNCTION • The power retractable hardtop control module monitors each input/output part, and if a malfunction is detected, performs the following actions. Item Detection Condition Action after malfunction detected Recovery condition • Power retractable hardtop not Power supply Power supply voltage is 7.5 V Power supply voltage is operated →...
  • Page 57: Buzzer Operation Function

    EXTERIOR TRIM Item Detection Condition Action after malfunction detected Recovery condition Top lock switch on is detected Close operation can be performed only Top lock switch off is detected. with the Power retractable once. Inhibits the operation after the hardtop open. Power retractable hardtop is fully closed.
  • Page 58: Power Retractable Hardtop Link Construction/Operation

    EXTERIOR TRIM POWER RETRACTABLE HARDTOP LINK CONSTRUCTION/OPERATION id091600101500 Construction • Installed to the inside of the Power retractable hardtop. • The front roof panel is installed to the front roof panel link. • The middle roof panel is installed to the middle roof panel link and roof motor link. •...
  • Page 59: Operation

    EXTERIOR TRIM Operation Open operation 1. After the deck panel is fully opened, the roof motor starts rotating based on the operation signal from the Power retractable hardtop control module. 2. The roof motor link gear and the roof motor link start rotating due to the roof motor rotation, and at the same time, the middle roof panel and the middle roof panel link rotate.
  • Page 60: Deck Panel Link Construction/Operation

    EXTERIOR TRIM DECK PANEL LINK CONSTRUCTION/OPERATION id091600101600 Construction • The links rise according to the rotation of the deck panel links to fully open or close the deck. • The deck panel limit switch is installed to the deck panel link (RH). •...
  • Page 61: Roof/Deck Panel Motor Function

    EXTERIOR TRIM 4. Deck panel link A is pressed upward to fully open the deck panel. DECK PANEL LINK A DECK PANEL MOTOR KNOB amxuun0000005 5. When deck panel link A is fully opened, the sector gear pin shown in the figure presses the deck panel open position switch to stop the deck panel motor rotation.
  • Page 62: Roof/Deck Panel Motor Construction

    EXTERIOR TRIM ROOF/DECK PANEL MOTOR CONSTRUCTION id091600101800 • Consists of a motor, connector, and gear. • Two Hall effect switches are located in the connector. • In the connector, the roof motor has one Hall effect switch and the deck panel motor has two (only one Hall effect switch is used).
  • Page 63: Power Retractable Hardtop Switch Outline

    EXTERIOR TRIM Deck panel motor construction view CONNECTOR HALL EFFECT SWITCH 1 MAGNET SHAFT HALL EFFECT SWITCH 2 HALL EFFECT SWITCH SEC. A—A GEAR amxuun0000004 End Of Sie POWER RETRACTABLE HARDTOP SWITCH OUTLINE id091600101900 • The power retractable hardtop electric open/close operation is performed by the power retractable hardtop open and close switches.
  • Page 64: On-Boad Diagnostic Outline

    DTCs; a display function, which indicates system malfunctions by DTC display; and a PID/data monitoring function, which reads out specific input/output signals. • Using the mazda modular diagnostic system (M-MDS), DTCs can be read out and cleared, and the PID/data monitoring function can be activated.
  • Page 65 EXTERIOR TRIM Malfunction indication Mazda modular Power retractable Description diagnostic system (M- Buzzer sound hardtop indicator MDS) display light flashing Flashing pattern for a Operation reject B293C Deck panel motor pulse signal error (RH) power retractable sound hardtop malfunction Flashing pattern for a...
  • Page 66: Pid/Data Monitor Function

    • The PID/data monitor function is used for optionally selecting input/output signal monitor items preset in the power retractable hardtop control module and reading them out in real-time. • Use the mazda modular diagnostic system (M-MDS) to read the PID/data monitor. PID/data monitor table...
  • Page 68: Instrument Cluster Outline

    INSTRUMENTATION/DRIVER INFO. 09-22 INSTRUMENTATION/DRIVER INFO. INSTRUMENT CLUSTER POWER RETRACTABLE HARDTOP OUTLINE ......09-22–1 WARNING ALARM INSTRUMENT CLUSTER CONSTRUCTION/OPERATION .
  • Page 69: Power Retractable Hardtop Warning Alarm Construction/Operation

    INSTRUMENTATION/DRIVER INFO. POWER RETRACTABLE HARDTOP WARNING ALARM CONSTRUCTION/OPERATION id092200110300 System Wiring Diagram INSTRUMENT CLUSTER MICROCOMPUTER BUZZER CAN CONTROL CIRCUIT POWER RETRACTABLE HARDTOP CONTROL MODULE amxuun0000003 Operation Operation start sound • A buzzer in the instrument cluster sounds if both of the following two conditions are met: —...
  • Page 70: Controller Area Network (Can) System Outline

    — Instrument cluster — Power retractable hardtop control module (with power retractable hardtop) • With an on-board diagnostic function included for each multiplex module, display of DTCs using the Mazda Modular Diagnostic System (M-MDS) has improved serviceability. End Of Sie...
  • Page 71: Can System Wiring Diagram

    CONTROL SYSTEM CAN SYSTEM WIRING DIAGRAM id094000101200 WITHOUT POWER RETRACTABLE HARDTOP KEYLESS STEERING CONTROL MODULE ANGLE DSC HU/CM ABS HU/CM (WITH ADVANCED SENSOR (WITH DSC) (WITH ABS) KEYLESS SYSTEM) (WITH DSC) INSTRUMENT CLUSTER CAN_H TCM (AT) DLC-2 TWISTED PAIR CAN_L STEERING KEYLESS CONTROL MODULE...
  • Page 72: On-Board Diagnostic Function

    — ABS HU/CM (with ABS) — Keyless control module — Steering angle sensor (with DSC) — Instrument cluster — Power retractable hardtop control module (with power retractable hardtop) • Using the Mazda Modular Diagnostic System (M-MDS), DTCs can be read out and deleted. 09-40–3...
  • Page 73 CONTROL SYSTEM Block diagram WITHOUT POWER RETRACTABLE HARDTOP KEYLESS STEERING CONTROL MODULE ANGLE DSC HU/CM ABS HU/CM (WITH ADVANCED SENSOR (WITH DSC) (WITH ABS) KEYLESS SYSTEM) (WITH DSC) INSTRUMENT CLUSTER CAN_H TCM (AT) DLC-2 TWISTED PAIR CAN_L KEYLESS STEERING ANGLE CONTROL MODULE WITH POWER RETRACTABLE HARDTOP (WITH ADVANCED...
  • Page 74 Self-malfunction diagnostic function • The self-malfunction diagnostic function determines that there is a malfunction, and outputs a signal, as a DTC, to the DLC-2. The DTC can be read out using the Mazda Modular Diagnostic System (M-MDS). DTC table Malfunction location DTC output module •...
