ENTERTAINMENT LOCATION INDEX
2007 Mazda MX-5 Miata Sport
2007 Mazda MX-5 Miata Sport
2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata
2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata
2007 ACCESSORIES & BODY, CAB
Entertainment - MX-5 Miata

Advertisement

loading

Related Manuals for Mazda 2007 MX-5 Miata Sport

Summary of Contents for Mazda 2007 MX-5 Miata Sport

  • Page 1 2007 Mazda MX-5 Miata Sport 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata ENTERTAINMENT LOCATION INDEX...
  • Page 2 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 1: Identifying Location Of Entertainment Components Courtesy of MAZDA MOTORS CORP. CENTER PANEL UNIT REMOVAL/INSTALLATION...
  • Page 3 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata 1. Remove the battery cover. 2. Disconnect the negative battery cable. See BATTERY REMOVAL/INSTALLATION [LF] . 3. Remove the lower panel. See LOWER PANEL REMOVAL/INSTALLATION .
  • Page 4 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 3: Identifying Center Panel Unit Assembly Courtesy of MAZDA MOTORS CORP. 8. Install in the reverse order of removal. CAUTION: When installing the center panel unit, make sure that the wiring ...
  • Page 5 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata 1. Pull the center panel unit outward, detach clip A from the dashboard, and then remove the center panel unit. CAUTION: Verify that bolt has been removed when pulling the center panel ...
  • Page 6 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 5: Exploded View Of Center Panel Unit Components Courtesy of MAZDA MOTORS CORP. 2. Assemble in the reverse order of disassembly. SCREW A ASSEMBLE NOTE...

  • Page 7: Audio Unit Disassembly/Assembly

    2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 6: Tightening Screws A Courtesy of MAZDA MOTORS CORP. AUDIO UNIT DISASSEMBLY/ASSEMBLY 1. Disassemble in the order indicated in Fig. 7 .
  • Page 8 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 7: Exploded View Of Audio Unit Components Courtesy of MAZDA MOTORS CORP.

  • Page 9: Audio Amplifier Removal/Installation

    2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata 2. Assemble in the reverse order of disassembly. AUDIO AMPLIFIER REMOVAL/INSTALLATION EXCEPT POWER RETRACTABLE HARDTOP 1. Remove the battery cover. 2. Disconnect the negative battery cable. (See BATTERY REMOVAL/INSTALLATION [LF] .) 3.
  • Page 10 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 8: Identifying Audio Amplifier (With Torque Specifications) Courtesy of MAZDA MOTORS CORP. 5. Install in the reverse order of removal. POWER RETRACTABLE HARDTOP 1. Remove the battery cover.
  • Page 11 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata 3. Scuff plate (See SCUFF PLATE REMOVAL/INSTALLATION .) 4. Tire house trim (See TIRE HOUSE TRIM REMOVAL/INSTALLATION .) 5. Aeroboard (See AEROBOARD REMOVAL/INSTALLATION .) 6. Front seat back bar garnish (See SEAT BACK BAR GARNISH REMOVAL/INSTALLATION .)
  • Page 12 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 10: Identifying Door Speaker Courtesy of MAZDA MOTORS CORP. 5. Install in the reverse order of removal. DOOR SPEAKER INSTALLATION NOTE...
  • Page 13 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata 1. Remove the speaker with the wiring harness passing through the groove of the front door module. CAUTION: If the speaker is installed with the wiring harness out of the ...
  • Page 14 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 12: Identifying Door Speaker Connector & Terminals Courtesy of MAZDA MOTORS CORP. DOOR UPPER SPEAKER INSPECTION 1. Inspect for resistance between the door upper speaker terminals using an ohmmeter.
  • Page 15 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Courtesy of MAZDA MOTORS CORP. Fig. 14: Identifying Door Upper Speaker Terminals Courtesy of MAZDA MOTORS CORP. REAR SPEAKER REMOVAL/INSTALLATION 1. Remove the battery cover. 2. Disconnect the negative battery cable. (See BATTERY REMOVAL/INSTALLATION [LF] .) 3.
  • Page 16 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 15: Identifying Rear Speaker (With Torque Specifications) Courtesy of MAZDA MOTORS CORP. 5. Install in the reverse order of removal. REAR SPEAKER INSPECTION 1. Inspect for resistance between the rear speaker terminals using an ohmmeter.
  • Page 17 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 16: Rear Speaker Continuity Table Courtesy of MAZDA MOTORS CORP.
  • Page 18 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 17: Identifying Rear Speaker Terminals Courtesy of MAZDA MOTORS CORP. CENTER SPEAKER REMOVAL/INSTALLATION 1. Remove the battery cover. 2. Disconnect the negative battery cable. (See BATTERY REMOVAL/INSTALLATION [LF] .)
  • Page 19 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 18: Identifying Center Speaker Courtesy of MAZDA MOTORS CORP. 4. Install in the reverse order of removal. CENTER SPEAKER COVER REMOVAL NOTE 1. Insert a tape-wrapped flathead screwdriver into the service hole.
  • Page 20 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 19: Inserting Tape-Wrapped Flathead Screwdriver Into Service Hole Courtesy of MAZDA MOTORS CORP. CENTER SPEAKER INSPECTION 1. Verify the resistance between center speaker terminals. If the resistance is not within the specification, replace the center speaker.

  • Page 21: Tweeter Removal/Installation

    2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 20: Identifying Center Speaker Terminals & Connector Courtesy of MAZDA MOTORS CORP. TWEETER REMOVAL/INSTALLATION 1. Remove the battery cover. 2. Disconnect the negative battery cable. (See BATTERY REMOVAL/INSTALLATION [LF] .) 3.

  • Page 22: Tweeter Inspection

    2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 21: Identifying Tweeter/Door Upper Speaker Courtesy of MAZDA MOTORS CORP. TWEETER INSPECTION 1. Inspect for resistance between the tweeter terminals using an ohmmeter. If the resistance is not within the specification, replace the tweeter.
  • Page 23 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Courtesy of MAZDA MOTORS CORP. Fig. 23: Identifying Tweeter Terminals Courtesy of MAZDA MOTORS CORP. CONDENSER REMOVAL/INSTALLATION 1. Remove the battery cover. 2. Disconnect the negative battery cable. (See BATTERY REMOVAL/INSTALLATION [LF] .) 3.
  • Page 24 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata REMOVAL/INSTALLATION .) 10. Rear side trim (See REAR SIDE TRIM REMOVAL/INSTALLATION .) 11. Rear package trim (See REAR PACKAGE TRIM REMOVAL/INSTALLATION .) 4. Remove in the order indicated in Fig. 24 .
  • Page 25 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 25: Identifying Audiopilot Microphone Courtesy of MAZDA MOTORS CORP. 4. Install in the reverse order of removal. MANUAL ANTENNA REMOVAL/INSTALLATION 1. Remove the battery cover.
  • Page 26 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 26: Identifying Manual Antenna (With Torque Specifications) Courtesy of MAZDA MOTORS CORP. 5. Install in the reverse order of removal. MOUNTING NUT REMOVAL NOTE 1. Use snap-ring pliers to remove the mounting nut.
  • Page 27 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 27: Removing Mounting Nut Using Snap Ring Pliers Courtesy of MAZDA MOTORS CORP. MANUAL ANTENNA INSPECTION NOTE: A amplifier is built into the manual antenna.
  • Page 28 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 28: Identifying Manual Antenna Connector Terminal Courtesy of MAZDA MOTORS CORP. FEEDER 1. Remove the battery cover. 2. Disconnect the negative battery cable. (See BATTERY REMOVAL/INSTALLATION [LF] .) 3.

  • Page 29: Antenna Feeder Location

    2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 29: Feeder Continuity Table Courtesy of MAZDA MOTORS CORP. Fig. 30: Identifying Manual Antenna Terminals Courtesy of MAZDA MOTORS CORP. ANTENNA FEEDER LOCATION...
  • Page 30 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 31: Identifying Antenna Feeder Courtesy of MAZDA MOTORS CORP. AM/FM ANTENNA FEEDER NO.1 INSPECTION 1. Verify that the continuity is as indicated in Fig. 32 .
  • Page 31 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 33: Identifying AM/FM Antenna Feeder No. 1 Terminals & Connectors Courtesy of MAZDA MOTORS CORP. AM/FM ANTENNA FEEDER NO.2 INSPECTION 1. Verify that the continuity is as indicated in the table.

  • Page 32: Audio Control Switch Removal/Installation

    2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 34: AM/FM Antenna Feeder No. 2 Continuity Table Courtesy of MAZDA MOTORS CORP. Fig. 35: Identifying AM/FM Antenna Feeder No. 2 Terminals & Connectors Courtesy of MAZDA MOTORS CORP.

  • Page 33: Audio Control Switch Inspection

    2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 36: Removing Driver-Side Air Bag Module Courtesy of MAZDA MOTORS CORP. 6. Install in the reverse order of removal. AUDIO CONTROL SWITCH INSPECTION 1. Verify the resistance and continuity between the audio control switch terminals.
  • Page 34 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 38: Identifying Audio Control Switch Terminals & Connector Courtesy of MAZDA MOTORS CORP. AUDIO CONTROL SWITCH POSITION RESISTANCE Switch position Resistance (ohm) VOL- switch ON...
  • Page 35 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata 3. Remove the console. (See CONSOLE REMOVAL/INSTALLATION .) 4. Remove the side wall. (See SIDE WALL REMOVAL/INSTALLATION .) 5. Remove the console panel. (See CONSOLE PANEL REMOVAL/INSTALLATION .) 6.
  • Page 36 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 40: Removing Accessory Socket Courtesy of MAZDA MOTORS CORP. CAP REMOVAL NOTE 1. While pressing the tabs, pull the cap outwards.
  • Page 37 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 41: Pulling Cap Outwards When Pressing Tabs Courtesy of MAZDA MOTORS CORP. ACCESSORY SOCKET INSPECTION 1. Connect a tester as shown in Fig. 42 and verify that there is continuity.
  • Page 38 2007 Mazda MX-5 Miata Sport 2007 ACCESSORIES & BODY, CAB Entertainment - MX-5 Miata Fig. 42: Identifying Accessory Socket Terminals & Connector Courtesy of MAZDA MOTORS CORP.
