- Page 1 DSM400 Digital Sounder Module Installation Guide www.busse-yachtshop.de | info@busse-yachtshop.de...
- Page 2 Trademarks and registered trademarks Autohelm, HSB, RayTech Navigator, Sail Pilot, SeaTalk and Sportpi- lot are UK registered trademarks of Raymarine UK Limited. Pathfinder and Raymarine are UK registered trademarks of Rayma- rine Holdings Limited. 45STV, 60STV, AST, Autoadapt, Auto GST,...
-
Page 3: Table Of Contents
Location of the sounder module....12 Troubleshooting..........28 What’s in the box ..........13 Common problems and their solutions ..28 Installing the unit..........13 DSM400 Thermocline Troubleshooting ....29 Cable runs ............14 Thermocline Troubleshooting ....... 29 Power cable ..........15 Warnings and errors ........... 30 Transducer cable ..........15... - Page 4 Specifications ........... 35 General............... 35 Features ............. 36 www.busse-yachtshop.de | info@busse-yachtshop.de...
-
Page 5: Safety Notices
NEVER operate the sounder with the to do so within the product handbook. boat out of the water. NEVER remove the DSM400 cover when NEVER touch the transducer face when power is connected. the sounder is powered on. - Page 6 Raymarine DSM400 Digital Sounder Module www.busse-yachtshop.de | info@busse-yachtshop.de...
-
Page 7: Important Information
Intended use product. The intended use for your Raymarine DSM400 Digital Sounder The crossed out wheelie bin symbol, illustrated above, and Module is for leisure marine boats and workboats not covered by... -
Page 8: Conventions
Handbook To the best of our knowledge, the information in this handbook was correct as it went to press. However, Raymarine cannot accept liability for any inaccuracies or omissions it may contain. In addition, our policy of continuous product improvement may change specifications without notice. -
Page 9: Installation
Chapter 1: Installation 1.1 Introduction This chapter deals with the installation of the DSM400 Their design and manufacture conforms to the Digital Sounder Module and covers the following: appropriate Electromagnetic Compatibility (EMC) standards, but correct installation is required to ensure that performance is not compromised. -
Page 10: Cable Suppression Ferrites
EMC performance for the installation. 1.3 Cable suppression ferrites The DSM400 is supplied with a pack of suppression ferrites. These must be fitted correctly to ensure optimum EMC perfor- mance and to comply with applicable EMC regulations. - Page 11 Cable suppression ferrite pack installation DSM400 Cable tie Ferrite Cable tie Cable clip Ethernet Power Speed/Temp Transducer 1 Transducer 2 D11046-1 Note: Cable ties are not required for the Transducer 1 or Transducer 2 ferrites. Installation www.busse-yachtshop.de | info@busse-yachtshop.de...
-
Page 12: Planning The Installation
Interference - the unit should be mounted far enough away Warning: Heavy object from any device that may cause interference such as The DSM400 Digital Sounder Module weighs 27 motors, generators and radio transmitters/receivers. See lbs (12.25 kg). Ensure that the chosen location “EMC installation guidelines”... -
Page 13: What's In The Box
Check that all the correct system components are included as To install the unit: shown in the drawing below. 1. Using tape, secure the mounting template in the required location. DSM400 ti n g te la te (1 .3 4 in Manual (1 .3... -
Page 14: Cable Runs
5. Press the module downwards to engage the key slots in the unit. Before installing the system cables, consider the following points: • Power, transducer and network cables need to be attached to the unit. Raymarine DSM400 Digital Sounder Module www.busse-yachtshop.de | info@busse-yachtshop.de... -
Page 15: Power Cable
Transducer cable Power cable Raymarine does not recommend extending the transducer cable. However, if this is unavoidable contact your local dealer The power cable should be run as a single length of cable from for assistance. - Page 16 Raymarine DSM400 Digital Sounder Module www.busse-yachtshop.de | info@busse-yachtshop.de...
-
Page 17: System And Transducer Connections
Chapter 2: System and transducer connections 2.1 Introduction This chapter deals with connecting the DSM400 Digital • Ultrasonic speed/depth - refer to page 21 Sounder Module to the system and transducers to the transducer unit and covers: • DC power connection - refer to page 21 •... -
Page 18: Transducer Connections
Removing the transducer cable(s) from the unit while powered ON can cause sparks. Only remove a transducer cable after the unit has been powered OFF. The following diagram shows the layout of the transducer connections within your DSM400 Digital Sounder Module: CUSTOM CONFIG. -
Page 19: Non-Diplexed Transducer Cables
T˚ If the cable connections for the transducer you are using with your DSM400 do not include an ‘Orange ID’ wire, you will need to configure the sounder unit manually to match the power and frequency of the transducer. To do this, use one of the four override rotary switches located on the left of the sounder unit printed circuit board (PCB). - Page 20 185 KHz/ 600 W 38 KHz/ 3 kW 185 KHz/ 1 kW 28 KHz/ 600 W 185 KHz/ 2 kW 28 KHz/ 1 kW Reserved 28 KHz/ 2 kW Reserved 28 KHz/ 3 kW Raymarine DSM400 Digital Sounder Module www.busse-yachtshop.de | info@busse-yachtshop.de...
-
Page 21: Ultrasonic Speed/Temperature Transducer
OFF. Your DSM400 Digital Sounder Module is intended for use on DC power systems rated from 10.7 V to 32V. The power connection to the sounder unit should be made at Br Gr Wh T˚... -
Page 22: Ground Connection
2.7 Ground connection Power input cable Your DSM400 Digital Sounder Module is designed for use on POWER boat’s with a ‘negative’ ground system and is not intended for GROUND use on boat’s with a ‘positive’ ground system. Br Wh Gr It is important that an effective RF ground is connected to the system. -
Page 23: Display Connection
D10983-1 D10994-1 2.8 Display connection Your DSM400 Digital Sounder Module can be connected to either E-Series or G-Series display units. How you configure the sounder module depends on the type of display to which it is going to be connected. Full details will be found in the relevant documentation for your display. -
Page 24: Connecting To Multiple E-Series Displays
DSM digital sounder RANGE CANCEL C/lines for plugs/sockets SeaTalk hs Power E series display SeaTalk hs Transducer PAGE ACTIVE WPTS SeaTalk switch DATA DXXXXX-1 MENU RANGE CANCEL SeaTalk SeaTalk SeaTalk SeaTalk D10984-1 Raymarine DSM400 Digital Sounder Module www.busse-yachtshop.de | info@busse-yachtshop.de... -
Page 25: Maintenance And Troubleshooting
Chapter 3: Maintenance and troubleshooting 3.1 Introduction 3.2 Maintenance This chapter deals with maintenance and troubleshooting for the DSM400 Digital Sounder Module, WARNING: High voltage and covers the following: This equipment contains high voltages. Unless otherwise instructed in this handbook DO NOT remove the covers or •... -
Page 26: Routine Checks
The paddle wheel mechanism may become jammed by dirt, grit or barnacles. Work the contaminant out of the mechanism, then The DSM400 Digital Sounder Module is a sealed unit. clean the unit with soap and water or IPA. Maintenance is therefore limited to the following periodic checks: •... -
Page 27: Resetting The System
3.3 Resetting the system Using the reset function will return your DSM400 Digital Sounder Unit to its factory default values. The reset function also clears any sonar depth offset and speed and temperature calibrations that have been set. To perform a factory reset: 1. -
Page 28: Troubleshooting
All Raymarine products are, prior to packing and shipping, If there is still a problem after referring to the table, contact your subject to comprehensive test and quality assurance programs. -
Page 29: Dsm400 Thermocline Troubleshooting
This problem occurs when fishfinder sonars (including the DSM400) interpret the thermocline as the bottom of the seabed, returning an incorrect depth reading. To overcome this problem, you must configure the DSM400 to operate in a different... -
Page 30: Warnings And Errors
If you are using the DSM400 at depths greater than 100 feet, and displaying high frequencies only, the Range Shift function If you are using the DSM400 at depths of less than 100 feet, has no impact, as the high frequencies mean that it is less likely thermoclines are always penetrated correctly by the sonar, that a thermocline will be detected as a bottom in any range. -
Page 31: Contacting Raymarine
Using the website Amber Solid DSM has rebooted For the latest information on Raymarine products visit the website at www.raymarine.com. Amber Transducer sense failure Click on the region that you are located in and go to the Amber... -
Page 32: Worldwide
Anchorage Park Product repair and service Portsmouth Hampshire In the unlikely event that your Raymarine unit should develop a England problem, please contact your authorized Raymarine dealer for PO3 5TD assistance. The dealer is best equipped to handle your service... - Page 33 Fax: +44 (0) 23 9266 1228 Parts and accessories Raymarine parts and accessory items are available through your authorized Raymarine dealer. Please refer to the lists of component part numbers and optional accessories in the Installation chapter of this handbook and have the numbers ready when speaking with your dealer.
- Page 34 Raymarine DSM400 Digital Sounder Module www.busse-yachtshop.de | info@busse-yachtshop.de...
