7" TFT LCD Monitor
TLM-700HD
Quick Start Guide
www.datavideo-tek.com

Advertisement

Table of Contents
loading

Related Manuals for Datavideo TLM-700HD

Summary of Contents for Datavideo TLM-700HD

  • Page 1 7" TFT LCD Monitor TLM-700HD Quick Start Guide www.datavideo-tek.com...

  • Page 2: Table Of Contents

    Table of Contents Warnings and Precautions............2 What's in the Box...............4 Introduction................4 Features ..................4 Connections & Control...............5 Front Panel ................5 Rear Panel.................7 Menu Options ................8 Support Format................ 11 Specification ................12 Service & Support..............13...

  • Page 3: Warnings And Precautions

    This product should only be operated from the type of power source indicated on the marking label of the AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company.
  • Page 4 10. Make sure that the total amperes of all the units that are plugged into a single wall outlet do not exceed 15 amperes. 11. Never push objects of any kind into this unit through the cabinet ventilation slots, as they may touch dangerous voltage points or short out parts that could result in risk of fire or electric shock.

  • Page 5: What's In The Box

    Switching Adaptor DC 12V/1.5A User’s Manual Introduction The Datavideo TLM-700HD is designed for outdoor field side for user; it can be dust-proof, drop-proof, sunshade and carry easy, TLM-700HD is a standard V-Mount enabling you to power the monitor using a universal battery from a range of manufacturers, prefect for use in the field.

  • Page 6: Connections & Control

    Connections & Control Front Panel Power Switch Switches the power On / Off. Stereo mini jack plug For stereo headphones. The headphone volume is controlled by the Audio Level Adjustments. N.B. Audio source from HDMI or SDI audio embedded audio. Audio Level Adjustments Allow you to adjust the headphones volume.
  • Page 7 BLUE The BLUE button is set blue only enable, Press this button to eliminate the red and green component of input signals. Only the blue component of an input is displayed on the screen. This facilitates adjustments of chroma and phase. (Phase adjustment is effective only for NTSC signals).

  • Page 8: Rear Panel

    Rear Panel HD/SD - SDI input BNC connector for SDI Input. YUV input BNC connectors for analog (Component) video inputs. Composite video input BNC connectors for analog (Composite) video inputs. HDMI in interface HDMI digital signal input connecter. Support HDMI 1.1 Tally In Send in red and yellow colour tally signal to tally LED.

  • Page 9: Menu Options

    Menu Options 1. Picture - Press the MENU button into the system Picture setting mode. - Press ENTER button into the Picture setting position. - Press UP / DOWN button moving to the Brightness setting. - Press ENTER button into the Brightness setting position. - Press UP / DOWN button to setting the Brightness values from 0~100 - Press MENU button return to the Picture setting menu.
  • Page 10 4. Setup - Press the MENU button four times into the Setup setting mode. - Press ENTER button into the Setup setting position. - Press UP / DOWN button moving to the OSD Timer setting. - Press ENTER button into the OSD Timer setting position. - Press UP / DOWN button to select the OSD display on screen time (value from 5~60 SEC).
  • Page 11 5. Advance - Press the MENU button five times into the Advance setting mode. - Press ENTER button into the Advance setting position. - Press UP / DOWN button moving to the LCD L/R Scan setting. - Press ENTER button, the LCD screen will reversed (Left to Right). - Press ENTER button again, the LCD screen will return to normal.

  • Page 12: Support Format

    Support Format • HDMI YUV - 720 x 576i x 50 Hz - 720 x 480i x 60 Hz - 1280 x 720p x 50 Hz - 1280 x 720p x 60 Hz - 1920 x 1080i x 50 Hz - 1920 x 1080i x 60 Hz •...

  • Page 13: Specification

    Specification 1x HD/SD-SDI input (SMPTE 272M-C 1.5Gbps, 270Mbps with Embedded Audio) 1x Component Y.U.V Sony Betacam Spec Interface 1x CV input 1x HDMI input 1x D-Sub 15 Pin Plug (Tally Light Signal) SDI/HD-SDI Specifications Standard SMPTE 259M-C (270Mbps - 525/625 Component Video) and SMPTE 292M (1.485/1.001 Gbps) Connector BNC (IEC 169-8) Impedance 75 Ω...

  • Page 14: Service & Support

    It is our goal to make your products ownership a satisfying experience. Our supporting staff is available to assist you in setting up and operating your system. Please refer to our web site www.datavideo-tek.com for answers to common questions, support requests or contact your local office below.
