JVC UX-G70J Service Manual

Hide thumbs Also See for UX-G70J:

Advertisement

Quick Links

Download this manual See also: Instruction Manual
SERVICE MANUAL
MICRO COMPONENT SYSTEM
6
MB505
2006
UX-G70J,UX-G70C,UX-G70B,
UX-G70E,UX-G70EN,
UX-G70EV,UX-G70EE
SUPER VIDEO
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-32
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-37
SP-UXG70
CA-UXG70

TABLE OF CONTENTS

COPYRIGHT © 2006 Victor Company of Japan, Limited
SP-UXG70
No.MB505
2006/6
