- Page 1 REPAIR MANUAL PRODUCT: DRYER MODEL: A 45 V The information included in this Ariston Repair Manual may change without notice. Please see our web site Pages: www.usservicenet.com for updates, corrections or additions. 1 - 11...
- Page 2 Repair Manual. If you have any questions regarding the proper diagnosis, repair or operation of any Ariston Appliance, please contact the Ariston Customer Care Center or your Service Representative SERVICING SAFEGAURDS: To avoid personal injury and/or property damage, it is important that safe servicing practices be observed at all times.
-
Page 3: Table Of Contents
REPAIR MANUAL A 45 V TABLE OF CONTENTS Page 1. Model & Serial Number Locations ....................1 2. Top Panel ............................2 3. Program Selector..........................3 4. Control Panel..........................3 5. Control Panel Components......................4 6. Dryness Sensor Module ......................... 4 7. -
Page 4: Model & Serial Number Locations
• The Model and Serial Number Tag is located behind the door on the upper right hand side (Fig. 1-1). Fig. 1-2 • The Model shown is an A45V with a Serial Number of 404220019. Note: Numbers located below the nine (9) digit Serial Number are not required on the Warranty Claim Form. -
Page 5: Top Panel
REPAIR MANUAL A 45 V 2. TOP PANEL Fig. 2-1 Fig. 2-2 • To remove the Top Panel, first remove the two (2) Phillips screws located at the rear corners of the panel (Fig. 2-1). With the two screws removed lift the rear of the panel up approximately three (3) inches and then slide the panel back, moving it away from the Control Panel (Fig. -
Page 6: Program Selector
REPAIR MANUAL A 45 V 3. PROGRAM SELECTOR Fig. 3-3 Fig. 3-1 Fig. 3-2 • To remove the Program Selector, first remove the Program Selector Knob by using a small screwdriver to pry it off the Selector Shaft (Fig. 3-1), remember to mask the area to prevent damaging the Control Panel. With the Program Selector Knob removed, remove the two (2) Phillips screws (Fig. -
Page 7: Control Panel Components
REPAIR MANUAL A 45 V 5. CONTROL PANEL COMPONENTS Fig. 5-1 Fig. 5-3 Fig. 5-2 • To remove the On / Off Switch and Start Switch (Fig. 5-1) or the LED Indicators (Fig. 5-2) first remove the Control Panel as described in Section 4. -
Page 8: Heater & Thermostat Assembly
REPAIR MANUAL A 45 V 7. HEATER & THERMOSTAT ASSEMBLY Fig. 7-2 Fig. 7-1 • To access the Heating Element or Thermostats remove the Rear Access Panels (Fig. 7-1) in this order; Bearing Cover (1), Panel Support (2) and then the Rear Cover (3). With the Rear Access Panels removed you have access to the following components. A. -
Page 9: Side Panels
REPAIR MANUAL A 45 V 8. SIDE PANELS Fig. 8-2 Fig. 8-1 Fig. 8-3 • To remove the Side Panels, remove the Four (4) Phillips screws that mount the Panel to the Frame. There are three (3) screws located along the rear frame edge and a single screw located in the middle of the bottom panel (Fig. 8-1). When removing the panel note the three (3) alignment pegs along the front frame edge that secure the Side Panel to the Front Frame (Fig.8-2). -
Page 10: Drum Belt
REPAIR MANUAL A 45 V 10. DRUM BELT Fig. 10-1 Fig. 10-2 Fig. 10-3 • To remove Drum Belt, first remove the Right Side Panel as described in Section 8 (Fig. 10-1). Then disengage the Drum Belt from the Pulley Wheels (Fig.10-2). -
Page 11: Schematic
REPAIR MANUAL A 45 V 12. SCHEMATIC Page: 8...
