ZXR10 8900
Series 10G Routing Switch
Command Manual (DPI Volume)
Version 2.8.02.C
ZTE CORPORATION
ZTE Plaza, Keji Road South,
Hi-Tech Industrial Park,
Nanshan District, Shenzhen,
P. R. China
518057
Tel: (86) 755 26771900
Fax: (86) 755 26770801
URL: http://ensupport.zte.com.cn
E-mail: support@zte.com.cn

Advertisement

Table of Contents
loading

Related Manuals for Zte ZXR10 8900 Series

Summary of Contents for Zte ZXR10 8900 Series

  • Page 1 ZXR10 8900 Series 10G Routing Switch Command Manual (DPI Volume) Version 2.8.02.C ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, P. R. China 518057 Tel: (86) 755 26771900 Fax: (86) 755 26770801 URL: http://ensupport.zte.com.cn E-mail: support@zte.com.cn...
  • Page 2 The contents of this document are protected by copyright laws and international treaties. Any reproduction or distribution of this document or any portion of this document, in any form by any means, without the prior written consent of ZTE CORPO- RATION is prohibited.

  • Page 3: Table Of Contents

    Contents Preface............... i Overview ............1 Manual Instruction............1 Description of Man-Machine Commands ......1 Auxiliary Function ............2 Command Modes............3 Configuring Signature Entry ......9 Command signature-entry ..........9 Command set content ..........9 Command show signature-entry .........10 Configuring Signature Symbol ......11 Command signature-symbol ........11 Command add signature-entry ........12 Command set hit-limit -num ........12...
  • Page 4 Command add subservice ...........23 Command import subservice ........24 Command bind flow-pool ..........24 Command show service ..........25 Configuring DPI Template ....... 27 Command dpi-template ..........27 Command bind slot .............27 Command bind service ..........28 Command bind sip-addr ..........28 Command bind switchport ..........29 Command show dpi-template ........30 New Commands in DPI Config Mode ....
  • Page 5 Preface This manual is ZXR10 8900 Series (V2.8.02.C) 10G Routing Switch About Manuals Command Manual (DPI Volume). ZXR10 8900 Series (V2.8.02.C) 10G Routing Switch Command Manual has 16 volumes. The details are as follows: Manual Summary ZXR10 8900 Series (V2.8.02.C)
  • Page 6 Unless otherwise specified or when it is specified to ZXR10, the manual applies to all devices. The items about router in the man- ual also apply to switch with routing function. This manual describes DPI-related commands in ZXR10 8900 se- What Is in This Manual ries (V2.8.02.C) 10G routing switch and contains the following...
  • Page 7 This chapter describes configuration of DPI DPI Template template and command used to view DPI Configuration template. Chapter 8 Newly This chapter describes newly added commands in Added Commands DPI config mode. in DPI Config Mode Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 8 ZXR10 8900 Command Manual (DPI Volume) This page is intentionally blank. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 9: Overview

    Manual includes 16 volumes. For details of each volume, please refer to preface of this manual. Commands in ZXR10 8900 Series (V2.8.02.C) 10G Routing Switch Command Manual (Command Index Volume) are listed in se- quence of from letter a to letter z and in form of table. Commands of all other volumes are classified and illustrated according to different function modules.

  • Page 10: Auxiliary Function

    ZXR10 8900 Command Manual (DPI Volume) It describes the mode in which this command can be executed. � Command Format It describes the complete format of this command. If no for- mat is available, list it. � Parameter Description It describes parameters in this command in the form and pre- scribes the range and default value.

  • Page 11: Command Modes

    Use show history command in any mode, and the latest sev- eral commands in this mode will be listed. Command Modes The command modes in this manual are as follows: Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 12 ZXR10 8900 Command Manual (DPI Volume) Mode Prompt Admis- Mode Entry Function sion Command Mode Exec It views ZXR10> Enter this mode simple mode directly information. after system login. Privi- Exec enable It configures ZXR10# leged mode system mode parameters.
  • Page 13 It configures OSPF parameters. router isis It configures IS-IS parameters. router bgp It configures parameters. router It configures pimsm PIM-SM parameters. ipv6 router It configures RIPng parameters. ipv6 router It configures ospf OSPFv3 parameters. Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 14 ZXR10 8900 Command Manual (DPI Volume) Mode Prompt Admis- Mode Entry Function sion Command Mode ZXR10(config- Global ip vrf It configures config- vrf)# config- uration uration parameters. mode mode VFI con- ZXR10(config- Global It configures figu- vfi)# config- VPLS-related ration uration parameters.
  • Page 15 Command Mode IPSec ZXR10(config- Global ipsec It configures config- ipsec)# config- IPv6 IPSec uration uration protection. mode mode Diagno- Privi- diagnose It tests CPU ZXR10(diag)# sis mode leged utilization mode and memory utilization. Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 16 ZXR10 8900 Command Manual (DPI Volume) This page is intentionally blank. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 17: Configuring Signature Entry

    To enter signature entry configuration mode, execute the following Example commands: ZXR10(config-dpi)#signature-entry 2 ZXR10(config-dpi-signature-entry-2)# Command set content It adds digital decimal KEY into current signature entry. Command Function Signature entry configuration mode with prompt to be Command Mode ZXR10(config- dpi-signature-entry-n)# Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 18: Command Show Signature-Entry

    ZXR10 8900 Command Manual (DPI Volume) set content <0xABCDEF(0xff0000ffff00ff000000000000000000 Command Format )+0x1111+0x222+0x33+0xbbbb> Parameter Description Parameter Description 0xABC- <0xABCDEF(0xff0000 DEF(0xff0000ffff00ff000000000000000000): ffff00ff000000000000 static KEY is the hexadecimal digits 000000)+0x1111+0x with length to be 1-32 characters and 222+0x33+0xbbbb> (0xff0000ffff00ff000000000000000000) is the mask with 32 bits;...

  • Page 19: Configuring Signature Symbol

    1 to 8191. 6144-8191 is reserved and cannot be configured by user. 0 indicates the id is invalid. To enter signature symbol configuration mode, execute the follow- Example ing command: ZXR10(config-dpi)#signature-symbol 2 ZXR10(config-dpi-signature-symbol-2)# Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 20: Command Add Signature-Entry

    ZXR10 8900 Command Manual (DPI Volume) Command add signature-entry This adds one signature entry for current signature symbol. Com- Command Function mand no can be used to delete this signature entry. Signature symbol configuration mode with prompt to be Command Mode...

  • Page 21: Command Show Signature-Symbol

    It is the id of signature symbol, ranging from id> 1 to 6143. To show configuration of signature symbo 2, execute the following Example command: ZXR10(config-dpi)#show signature-symbol 2 signature-symbol-id hit-limit protocol-type signature-entry-num -------------------------------------------------------------------- normal 1 add signature-entry: 2 Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 22 ZXR10 8900 Command Manual (DPI Volume) This page is intentionally blank. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 23: Configuring Policy

    Command upstream-rate- limit This configures parameter upstream of flow pool. Command no Command Function can be used to clear the configuration. Flow pool configuration mode with prompt to be Command Mode ZXR10(config-dpi- flow-pool-n)# Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 24: Command Downstream-Rate-Limit

    ZXR10 8900 Command Manual (DPI Volume) upstream-rate-limit <limit-rate> cbs <cbs-bytes> ebs <ebs-b Command Format ytes> no upstream-rate-limit Parameter Description Parameter Description <limit-rate> It limits rate, ranging from 10 to 1000000, in kbps. <cbs-bytes> It is the number of cbs bytes.

  • Page 25: Command Default-Flow-Pool

    It is id of flow pool entry, ranging from 1 to 8191. To show configuration of flow pool 2, execute the following com- Example mand. ZXR10(config-dpi)#show flow-pool 2 stream-type rate-limit(kbps) cbs(bytes) ebs(bytes) ----------------------------------------------------- downstream 2000 10000 10000 upstream 2000 10000 10000 ----------------------------------------------------- Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 26 ZXR10 8900 Command Manual (DPI Volume) This page is intentionally blank. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 27: Configuring Sub Service

    To enter subservice configuration mode, execute the following Example commands: ZXR10(config-dpi)#subservice 2 ZXR10(config-dpi-subservice-2)# Command add signature-symbol This adds signature symbol relation for current subservice. Com- Command Function mand no can be used to delete this relation. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 28: Command Add Protocol

    ZXR10 8900 Command Manual (DPI Volume) Subservice configuration mode with prompt to be Command Mode ZXR10(config-dpi- subservice-n)# add signature-symbol <signature-symbol-id-relation>[relatio Command Format n-name] no add signature-symbol <signature-symbol-id-relation> Parameter Description Parameter Description <signature-symbol-id It is the relationship among signature symbol, -relation>...

  • Page 29: Command Bind Flow-Pool

    To enter subservice configuration mode and set permit policy for Example subservice 2, execute the following commands: ZXR10(config-dpi)# subservice 2 ZXR10(config-dpi-subservice-2)#action permit Command aging-time This sets aging time for current subservice. Command Function Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 30: Command Show Subservice

    ZXR10 8900 Command Manual (DPI Volume) Subservice configuration mode with prompt to be Command Mode ZXR10(config-sub- service-n)# aging-time <time> Command Format Parameter Description Parameter Description <time> It is aging time, ranging from 1 to 265 (actual range is 2-510), in minutes, 2min by default.

  • Page 31: Configuring Service

    This adds one subservice to current service. Command no can be Command Function used to delete the subservice. Service configuration mode with prompt to be Command Mode ZXR10(config-service- add subservice <subservice-id> Command Format no add subservice < service-id> Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 32: Command Import Subservice

    ZXR10 8900 Command Manual (DPI Volume) Parameter Description Parameter Description <subservice-id> It is the id of subservice entry, ranging from 1 to 8191. To enter service configuration mode and add subservice 12 to ser- Example vice 2, execute the following command:...

  • Page 33: Command Show Service

    It is the id of service entry, ranging from 1 to 2047. To show configuration of service 2, execute the following com- Example mand: ZXR10(config)#show service 2 service-id flowpool-id sub-service-num ------------------------------------------ add subservice-id: 10 20 27 30 ------------------------------------------ import subservice: ------------------------------------------ Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 34 ZXR10 8900 Command Manual (DPI Volume) This page is intentionally blank. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 35: Configuring Dpi Template

    Bind direction rules of data flow in current DPI-template. Com- Command Function mand no can be used to delete this binding. DPI-template configuration mode with prompt to be Command Mode ZXR10(config- dpi-template-n)# bind slot <slot-id> Command Format Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 36: Command Bind Service

    ZXR10 8900 Command Manual (DPI Volume) no bind slot Parameter Description Parameter Description <slot-id> It is the slot number where DPI card locates, ranging from 1 to 12. To enter dpi-template configuration mode and bind one rule with Example dpi-template 2 (direct data flow to slot 7), execute the following...

  • Page 37: Command Bind Switchport

    To enter dpi-template configuration mode and bind one rule to dpi- Example template 2 (sevice 2 policy is bound to port 12 on interface card locating in slot 1), execute the following commands: ZXR10(config)#dpi-template 2 ZXR10(config-dpi-template-2)#bind switchport gei_1/12 service 2 Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 38: Command Show Dpi-Template

    ZXR10 8900 Command Manual (DPI Volume) Command show dpi-template This shows details of dpi-template configuration. Command Function All modes Command Mode show dpi-template <template-id> Command Format Parameter Description Parameter Description <template-id > It is id of dpi-template entry, ranging from 1 to 4095.

  • Page 39: New Commands In Dpi Config Mode

    1 to 12. <mng-ip-addr> It is management ip address, expressed in dotted decimal notation. It must be IP address of loopback interface. <server-ip-addr> It is server IP address, expressed in dotted decimal notation. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 40: Command Clear Connection-All

    ZXR10 8900 Command Manual (DPI Volume) To bind management IP 1.1.1.1 to DPI card, execute the following Example command: ZXR10(config-dpi)#bind mng-server-ip 2 1.1.1.1 1.1.1.2 Command clear connection-all All entries in the traffic table age out and clear all traffic tables.

  • Page 41: Command Log-File Delete-Dir

    It is directory name. To delete directory 20081126, execute the following command: Example ZXR10(config-dpi)#log-file delete-dir /sata/20081126/ Command log-file delete-file This deletes a file. Command Function DPI configuration mode Command Mode log-file delete-file <slot-id><file-name> Command Format Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 42: Command Set Active -Save-Interval

    ZXR10 8900 Command Manual (DPI Volume) Parameter Description Parameter Description <slot-id> It is the slot number where interface card locates, ranging from 1 to 12. <file-name> It is filename. To delete file 200811260001.dat under directory 20081126, exe- Example cute the following command: ZXR10(config-dpi)# log-file delete-file 4 /sata /20081126/200811260001.dat...

  • Page 43: Command Show Dpi-Vlan-Binding

    All modes Command Mode show dpi-mng-ip Command Format To show management ip and ftp server ip configured on DPI card, Example execute the following command: ZXR10(config-dpi)#show dpi-mng-ip Dpi-slot Mng-ip Server-ip Used ------------------------------------------------ 20.0.0.22 11.1.1.10 Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 44: Command Update Signature-File

    ZXR10 8900 Command Manual (DPI Volume) Command update signature-file This updates signature lib online. Command Function DPI configuration mode with prompt to be Command Mode ZXR10(config-dpi)# update signature-file Command Format To update signature lib online, execute the following command: Example...

  • Page 45: Command Update Dpi-Log

    ZXR10(config-dpi)#update dpi-log 4 / 200811260023.dat /sata /20081126/200811260023.dat Uploading log in batch: To upload local log files 20081126*.dat to files *.dat under root directory of server, execute the following command: ZXR10(config-dpi)#update dpi-log 4 / *.dat /sata/20081126/*.dat Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 46: Command Upload Today-Log

    ZXR10 8900 Command Manual (DPI Volume) Command upload today-log This synchronizes today log, uploads the logs that haven’t been Command Function uploaded or fail to be uploaded. The max synchronized files: 9999. DPI configuration mode Command Mode upload today-log <slot-id>...
