Service Manual 6233 RM-45 / 6234 RM-23
Page
CONFIDENTIAL
SERVICE MANUAL
Level &2
RM-23
Transceiver characteristics:
Transceiver with BP-6M-S Li-Ion battery pack

(9)
Band: Tri-band phone for GSM/EDGE 900/1800/1900MHz and
WCDMA 2100
Camera: Integrated camera 2 Megapixel
Display: Active TFT QVGA color display with 262.144 colors,
resolution 320 x 240 pixel
Bluetooth
IrDA
Stereo FM radio
Vibra Alert: Small round Vibra motor
Connector: Easy Flash connector
Talk time
GSM: Up to 4h
WCDMA: Up to 3.1h
Environmental characteristics:
•
Lead-free soldered
Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved .0
25.Apr.2006
Standby
Note
up to 14 days
Depends on network
parameters
MGR

Advertisement

Table of Contents
loading

Related Manuals for Nokia 6233

Summary of Contents for Nokia 6233

  • Page 1 Talk time Standby Note GSM: Up to 4h up to 14 days Depends on network parameters WCDMA: Up to 3.1h Environmental characteristics: • Lead-free soldered Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 2: Table Of Contents

    SPARE PARTS LIST SERVICE TOOLS SW-UPDATE DISASSEMBLY INSTRUCTION GONOGO TEST BATTERY TEST CHANGE HISTORY Status Version No. Date Comments Draft 18.Apr.2006 Initial draft Approved 25.Apr.2006 Approval Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 3: Introduction

    INTRODUCTION The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it is confidential.

  • Page 4: General Repair Information

    Common Software Service Bulletins etc,… Use General SB-217 as a reference or overview. Please also check NOKIA Online (NOL) for latest news and files on a regular basis. Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 5: Pathfinder For Workshop Staff

    Videos – Disassembly/Assembly NOKIA Online Care Services Training Phone Models Level 1&2 e-learning courses offer a quick overview of the NOKIA phone and support for how to repair and use the phone: Overview & Guides Disassembly & Assembly Troubleshooting Basic information about the phone,...

  • Page 6: Exploded View And Component Disposal

    Recommendation for the ecologically friendly disposal of components. Colorized components show the different categories. See corresponding ITEM/CIRCUIT REF in the Spare Parts Service Bulletins on NOL. Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 7: Component Overview

    Page (9) Approved .0 CMO Operations & Logistics Training and Vendor Development 25.Apr.2006 Multimedia Creation & Support CONFIDENTIAL COMPONENT OVERVIEW Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 8: Spare Parts List

    (spare parts, SWAP units and service tools) from NOL! This will ensure, that you are using up-to-date order codes only. Therefore Service Bulletins have to be checked from NOL on daily basis. Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 9: Service Tools

    SS-45 Camera removal tool. One side is for disassembly, the other side for assembly. CA-53 Service Cable to connect the PC with the Pop-Port™ connector. Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 10: Service Manual 6233 Rm-45 / 6234 Rm-23

    Wetec tweezers 13 SA-SMD ESD • Wetec tweezers PSF SA-ESD • Wetec ESD brush E1211 • Kaiser Fototechnik airbrush 6315 • Wetec dental tool DEM83266/0 • Components Scissors 323-5732 Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 11: Sw-Update

    To use FLS-4S Flash Dongle you have to follow the user guide inside the sales package. Please check always for the latest version of flash software, which is available on NOKIA Online. Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 12: Disassembly Instruction

    5. Discard the screws and use always new ones because of the 6. This picture shows the position of the holding clips on the left locking compoud. side of the unit. Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 13: Service Manual 6233 Rm-45 / 6234 Rm-23

    9. Stick the SRT-6 between the cover and release the four clips. 10. Remove the A-COVER and protect the inner window with a protective film. 11. Protect the LCD MODULE with a protective film. 12. Press out the KEYMAT. Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 14: Service Manual 6233 Rm-45 / 6234 Rm-23

    17. Unlock the four clips of the C-COVER PLATE ASSY and loosen 18. Flip over the C-COVER PLATE ASSY and pay attention to the flex foil. Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 15: Service Manual 6233 Rm-45 / 6234 Rm-23

    23. Release the LCD MODULE from the C-COVER ASSY by pushing 24. Remove the MICROPHONE CLAPTON with the dental pick. the edges outwards first. Mind the grounding clips. Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 16: Service Manual 6233 Rm-45 / 6234 Rm-23

    29. Remove the DC-JACK with a DC-plug. 30. Carefully remove the EARPIECE with the dental tool. Always use a new adhesive tape when replacing the EARPIECE. Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 17: Service Manual 6233 Rm-45 / 6234 Rm-23

    Page (9) Approved .0 CMO Operations & Logistics Training and Vendor Development 25.Apr.2006 Multimedia Creation & Support CONFIDENTIAL 31. The disassembly procedure is now finished. Service Manual 6233 RM-45 / 6234 RM-23 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 18: Service Manual 6233 Rm-45 / 6234 Rm-23

    Training and Vendor Development 25.Apr.2006 Multimedia Creation & Support CONFIDENTIAL GONOGO TEST To test the Camera, Bluetooth and IRDA functionality refer to the 6233/6234 User`s guide. The User´s Guide is available on www.nokia.com. Before starting the GoNoGo test, check that camera window is clean.

  • Page 19: Battery Test

    Training and Vendor Development 25.Apr.2006 Multimedia Creation & Support CONFIDENTIAL BATTERY TEST A battery tester lets you test the capacity of NOKIA batteries. Please refer to the actual information on NOKIA Online. http://www.astratec.co.uk/ http://www.cadex.com/ Service Manual 6233 RM-45 / 6234 RM-23...
