Service Manual 6233 RM-145 / 6234 RM-123
Page
CONFIDENTIAL
SERVICE MANUAL
Level 1&2
RM-123
Transceiver characteristics:
Transceiver with BP-6M-S Li-Ion battery pack
Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
1
(14)
Band: Tri-band phone for GSM/EDGE 900/1800/1900MHz and
WCDMA 2100
Camera: Integrated camera 2 Megapixel
Display: Active TFT QVGA color display with 262.144 colors,
resolution 320 x 240 pixel
Bluetooth
IrDA
Stereo FM radio
Vibra Alert: Small round Vibra motor
Connector: Easy Flash connector
Talk time
GSM: Up to 4h
up to 14 days
WCDMA: Up to 3.1h
Environmental characteristics:
•
Lead-free soldered
Approved 3.0
14.May.2007
Standby
Note
Depends on network
parameters
MGR
Advertisement
Related Manuals for Nokia 6233 RM-145
Summary of Contents for Nokia 6233 RM-145
- Page 1 Talk time Standby Note GSM: Up to 4h up to 14 days Depends on network parameters WCDMA: Up to 3.1h Environmental characteristics: • Lead-free soldered Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
- Page 2 Draft 18.Apr.2006 Initial draft Approved 25.Apr.2006 Approval Approved 29.Mrz.2007 Exploded view updated /Chapter Battery Test removed Approved 14.May.2007 Disassy instruction updated - new torque settings Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
-
Page 3: Warnings And Cautions
INTRODUCTION The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it is confidential. - Page 4 Recommendation for the ecologically friendly disposal of components. Colorized components show the different categories. See corresponding ITEM/CIRCUIT REF in the Spare Parts Service Bulletins on NOL. Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
-
Page 5: Component Overview
Page (14) Approved 3.0 CMO Operations & Logistics Training and Vendor Development 14.May.2007 Multimedia Creation & Support CONFIDENTIAL COMPONENT OVERVIEW Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved. - Page 6 SS-45 Camera removal tool. One side is for disassembly, the other side for assembly. CA-53 Service Cable to connect the PC with the Pop-Port™ connector. Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
- Page 7 Wetec tweezers 13 SA-SMD ESD • Wetec tweezers PSF SA-ESD • Wetec ESD brush E1211 • Kaiser Fototechnik airbrush 6315 • Wetec dental tool DEM83266/0 • Components Scissors 323-5732 Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
- Page 8 To use FLS-4S Flash Dongle you have to follow the user guide inside the sales package. Please check always for the latest version of flash software, which is available on NOKIA Online. Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
-
Page 9: Disassembly Instruction
5. Discard the screws and use always new ones because of the 6. This picture shows the position of the holding clips on the left locking compoud. side of the unit. Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved. - Page 10 9. Stick the SRT-6 between the cover and release the four clips. 10. Remove the A-COVER and protect the inner window with a protective film. 11. Protect the LCD MODULE with a protective film. 12. Press out the KEYMAT. Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
- Page 11 17. Unlock the four clips of the C-COVER PLATE ASSY and loosen 18. Flip over the C-COVER PLATE ASSY and pay attention to the flex foil. Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
- Page 12 23. Release the LCD MODULE from the C-COVER ASSY by pushing 24. Remove the MICROPHONE CLAPTON with the dental pick. the edges outwards first. Mind the grounding clips. Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
- Page 13 29. Remove the DC-JACK with a DC-plug. 30. Carefully remove the EARPIECE with the dental tool. Always use a new adhesive tape when replacing the EARPIECE. Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
- Page 14 Page (14) Approved 3.0 CMO Operations & Logistics Training and Vendor Development 14.May.2007 Multimedia Creation & Support CONFIDENTIAL 31. The disassembly procedure is now finished. Service Manual 6233 RM-145 / 6234 RM-123 Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
