Omron E5CN-H Instruction Manual

E5CN-H
Digital Controller
EN
Instruction Manual
Thank you for purchasing the OMRON E5CN-H Digital Controller.
This manual describes the functions, performance,
and application methods needed for optimum use of
the product.
Please observe the following items when using the product.
• This product is designed for use by qualified personnel with
a knowledge of electrical systems.
• Before using the product, thoroughly read and understand
this manual to ensure correct use.
• Keep this manual in a safe location so that it is available for
reference whenever required.
OMRON CORPORATION
©All Rights Reserved
For detailed operating instructions, please refer to the E5CN-H/E5AN-H/E5EN-H
Digital Controllers User's Manual Advaced Type (Cat. No. H157).
Significance of WARNINGs and CAUTIONs
Safety Precautions
Key to Warning Symbols
Indicates a potentially hazardous situation which, if
not avoided, is likely to result in minor or moderate
injury or property damage. Read this manual
CAUTION
carefully before using the product.
5307507- 4D
CH1
Wiring
Dimensions
Dimensions (mm)
6 91
48
78
1.5
Watertight Adapter
Terminal
packing cover
* The main unit can be removed for maintenance without disconnecting the terminal wiring.
* Do not remove the terminal block. Doing so may result in failure or malfunction.
* A Setup Tool port is provided on the bottom of the product. Use this port to connect a personal computer to the
product when using the Setup Tool. E58-CIFQ1 USB-Serial Conversion Cable is required to connect the personal
computer to the product. (Do not use the product with the USB-Serial Conversion Cable left permanently connected.)
Refer to the instruction manual provided with the USB-Serial Conversion Cable for details on connection methods.
Names of parts on front panel
•
Level key
Use this key to change levels:
•
Press the key and the key
together for at least 3 seconds to
switch to protect level.
• Mode key
Press this key to change the
contents of the display.
Press this button for 1 s or
longer for reverse scroll.
Operation menu
Input type
Input Setting range
Input type Input Setting
0 -200.0 to 850.0(°C) / -300.0 to 1500.0 (°F)
Platinum Pt100 1 -199.9 to 500.0(°C) / -199.9 to 900.0 (°F)
resistance
2 0.0 to 100.0(°C) / 0.0 to 210.0 (°F)
thermometer
3 -199.9 to 500.0(°C)
/ -199.9 to 900.0 (°F)
JPt100
4
0.0 to 100.0(°C) / 0.0 to 210.0 (°F)
K 5 -200.0 to 1300.0(°C) /-300.0 to 2300.0 (°F)
6 -20.0 to 500.0(°C) / 0.0 to 900.0 (°F)
Thermocouple
7 -100.0 to 850.0(°C) /-100.0 to 1500.0 (°F)
J
-20.0 to 400.0(°C)
8 / 0.0 to 750.0 (°F)
T 9 -200.0 to 400.0(°C) /-300.0 to 700.0 (°F)
10 -199.9 to 400.0(°C) /-199.9 to 700.0 (°F)
11 -200.0 to 600.0(°C) /-300.0 to 1100.0 (°F)
E
12 -100.0 to 850.0(°C) /-100.0 to 1500.0 (°F)
L
13 -200.0 to 400.0(°C)
U /-300.0 to 700.0 (°F)
14
-199.9 to 400.0(°C) /-199.9 to 700.0 (°F)
15
N -200.0 to 1300.0(°C) /-300.0 to 2300.0 (°F)
16 0.0 to 1700.0(°C) / 0.0 to 3000.0 (°F)
R
17 0.0 to 1700.0(°C) / 0.0 to 3000.0 (°F)
S
18 100.0 to 1800.0(°C)
B / 300.0 to 3200.0 (°F)
19 0.0 to 2300.0(°C)
/ 0.0 to 3200.0 (°F)
W
20
0.0 to 1300.0 (°C) / 0.0 to 2300.0 (°F)
PLII
21 -50.00 to 200.00(°C) / -50.00 to 200.00(°F)
K
22 -50.00 to 200.00(°C) / -50.00 to 200.00(°F)
J
23 -50.00 to 200.00(°C) / -50.00 to 200.00(°F)
T
Platinum
Pt100 24 -50.00 to 200.00(°C) / -50.00 to 200.00(°F)
resistance
thermometer
25
4 to 20mA One of the following ranges is used depending on scaling.
Current input
0 to 20mA 26
-19999 to 32400
1 to 5V 27
-1999.9 to 3240.0
Voltage input
0 to 5V 28 -199.99 to 324.00
-19.999 to 32.400
0 to 10V 29
*The default is"5".
*s.err will be displayed when a platinum resistance thermometer is mistakenly connected while
input type is not set for it. To clear the s.err display, correct the wiring and cycle the power supply.
Alarms
Alarm output function
Setting Alarm type
Positive alarm value (X) Negative alarm value (X)
Output off
No alarm function
0
*1 1 Deviation upper/lower limit
X
ON
2
Deviation upper limit
OFF
SP
X
ON
3
Deviation lower limit
OFF
SP
L H
*1 4 ON
Deviation upper/lower range
OFF
SP
L H
Deviation upper/lower limit
5 ON
*1
standby sequence ON OFF
SP
X
Deviation upper limit
ON
6
standby sequence ON
OFF
SP
X
Deviation lower limit
7 ON
standby sequence ON
OFF
SP
X
ON
8 Absolute value upper limit
OFF
0
X
ON
9 Absolute value lower limit
OFF
0
Absolute value upper limit X
ON
10
standby sequence ON
OFF
0
X
Absolute value lower limit
ON
11
standby sequence ON
OFF
0
LBA (only for alarm 1)
12
13 PV change rate alarm
X
ON
RSP absolute value upper limit
14
OFF
0
X
ON
15 RSP absolute value lower limit
OFF
0
*1: Upper and lower limits can be set for parameters 1, 4 and 5 to provide for
different types of alarm. These are indicated by the letter "L" and "H".
• The default alarm type is "2"
Error display (trouble shooting)
When an error has occurred, the No.1 display shows the error code. Take
necessary measure according to the error code, referring the table bellow.
No.1 display Meaning Action
Check the setting of the Input Type parameter,
Input error
s.err check the input wiring, and check for broken or
(S. Err)
*2
shorts in the temperature sensor.
After the correction of A/D converter error, turn the
power OFF then back ON again. If the display
A/D converter error
remains the same, the controller must be repaired.
e333
(E333)
*2 If the display is restored to normal, then a
probable cause can be external noise affecting the
control system. Check for external noise.
Turn the power OFF then back ON again. If the
display remains the same, the controller must be
Memory error
e111 repaired. If the display is restored to normal, then
(E111)
a probable cause can be external noise affecting
the control system. Check for external noise.
If the input value exceeds the display limit ( -19999 to 32400), though it is within the control
range, [[[[ will be displayed under -19999 and ]]]] above 32400. Under these conditions,
control output and alarm output will operate normally.
Refer to E5CN-H/E5AN-H/E5EN -H User's Manual Advanced Type (Cat. No. H157) for details of control range.
*2: Error shown only for "Process value / Set point". Not shown for other status.
Warning Symbols
CAUTION
Do not touch the terminals while power is being supplied.
Doing so may occasionally result in minor injury due to electric shock.
Do not allow pieces of metal, wire clippings, or fine metallic shavings or filings from installation to
enter the product. Doing so may occasionally result in electric shock, fire, or malfunction.
Do not use the product where subject to flammable or explosive gas. Otherwise, minor injury from
explosion may occasionally occur.
Never disassemble, modify, or repair the product or touch any of the internal parts. Minor electric
shock, fire, or malfunction may occasionally occur.
CAUTION - Risk of Fire and Electric Shock
a) This product is UL listed as Open Type Process Control Equipment. It must be mounted in an enclosure that
does not allow fire to escape externally.
b) More than one disconnect switch may be required to de-energize the equipment before servicing.
c) Signal inputs are SELV, limited energy.
d) Caution: To reduce the risk of fire or electric shock, do not interconnect the outputs of different Class 2 circuits.
If the output relays are used past their life expectancy, contact fusing or burning may occasionally occur. Always
consider the application conditions and use the output relays within their rated load and electrical life expectancy.
The life expectancy of output relays varies considerably with the output load and switching conditions.
Tighten the terminal screws to between 0.74 and 0.90 N•m. Loose screws may occasionally result in fire.
Set the parameters of the product so that they are suitable for the system being controlled. If they are not suitable,
unexpected operation may occasionally result in property damage or accidents.
A malfunction in the Digital Controller may occasionally make control operations impossible or prevent
alarm outputs, resulting in property damage. To maintain safety in the event of malfunction of the Digital
Controller, take appropriate safety measures, such as installing a monitoring device on a separate line.
Suitability for Use
OMRON shall not be responsible for conformity with any standards, codes, or regulations that
apply to the combination of the products in the customer's application or use of the product.
Take all necessary steps to determine the suitability of the product for the systems, machines,
and equipment with which it will be used.
Know and observe all prohibitions of use applicable to this product.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE
OR PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN
DESIGNED TO ADDRESS THE RISKS, AND THAT THE OMRON PRODUCT IS PROPERLY
RATED AND INSTALLED FOR THE INTENDED USE WITHIN THE OVERALL EQUIPMENT
OR SYSTEM.
See also Product catalog for Warranty and Limitation of Liability.
Installation
In the pack: Individual mounting (mm) Side-by-side mounting (waterproof not possible) (mm)
*Main unit
*Watertight packing
*Adapter
*Instruction manual
*Terminal cover (Provided only for models with "-500"
suffix only)
+0.6
45
0
Solderless terminal size: M3.5
• Insert the controller through the hole in the panel. Push the adapter on from the rear
Terminal cover: E53-COV17
and fasten temporarily, removing any gap between the controller, panel and adapter.
USB-Serial Conversion Cable
Finally, secure two fixing screws alternately keeping the torque to between 0.29 to
(Sold Separately)(E58-CIFQ1)
0.39 N • m.
• Make sure that the surrounding temperature does not exceed the allowable operating
temperature given in the specifications especially when two or more controllers are
mounted.
Operation indicators
• No.1 display
• SUB1: Auxiliary output 1 indicator
Process value or set data symbol
Lit when the function assigned to
auxiliary output 1 is ON.
• No.2 display
• SUB2: Auxiliary output 2 indicator
Set point, set data read-out value or
Lit when the function assigned to
changed input value
auxiliary output 2 is ON.
• SUB3: Auxiliary output 3 indicator
Lit when the function assigned to
• Up and Down keys
auxiliary output 3 is ON.
Use the keys to change the values
• HA: Heater burnout alarm/Heater short
displayed on the No.2 display.
alarm/Heater overcurrent alarm indicator
Each press of key increments or advances
Lit when a heater burnout alarm, heater
the values displayed on the No.2 display.
short alarm, or heater overcurrent alarm
Each press of key decrements or returns
has occurred.
the values displayed on the No.2 display.
Operation stopped.
Initial Setting Level
(Control/alarm are both stopped.)
in-t
Input Type *3
5
in-h
Scaling Upper Limit
*6
(only when setting analog input)
100
in-l
Scaling Lower Limit
*6
(only when setting analog input)
0
dp
Decimal Point
*6
(only when setting analog input)
0
c
°C=
Temperature Unit
d-u
f
*6 °F=
c (C stands for Celsius, F for Fahrenheit)
sl-h
SP Upper Limit
1300.0
sl-l
: SP Lower Limit
-200.0
PID/ONOFF
cntl
onof
In ON/OFF control =
pid In 2-PID control = pid
Standard or Heating/Cooling
s-hc
Standard control =
Heating and cooling control =
stnd
(Select standard control or heating
and cooling control as required)
st ST (Self-Tuning)
*6
ST ON = on
on
ST OFF = off
ptrn
Program Pattern
Vary with "L", "H" values
off
X
ON
cp
Control Period (Heating)
OFF
*6
SP
(Unit: Seconds)
20
X
ON
OFF
SP
c-cp
Control Period (Cooling)
*6
Vary with "L", "H" values
(Unit: Seconds)
20
Vary with "L", "H" values
Direct/Reverse Operation
orev
In Reverse operation (Heating) =
X
ON or-r
In Direct operation (Cooling) =
OFF
SP
X
ON alt1
OFF
*6 Alarm 1 Type: Specified Models Only
SP
2
X
ON
OFF
0
alh1
X
ON *6
Alarm 1 Hysteresis
OFF 0.2
0
X
ON
OFF alt2
0
*6
Alarm 2 Type: Specified Models Only
X
ON 2
OFF
0
alh2
*6 Alarm 2 Hysteresis
0.2
tr-t
X
ON *6 Transfer Output Type
OFF off
0
X
ON
OFF tr-h
0
*6
Transfer Output Upper Limit
100.0
tr-l
*6 Transfer Output Lower Limit
0.0
o1-t
*6
Linear Current Output
Status at error 4-20
Control
Alarm
output
sqr
Operates Extraction of Square Root Enable
OFF *6
as above the
(Only when analog input is set)
off
upper limit.
amov
OFF OFF Move to Advanced Function Setting Level
*6
0
Initial setting level enables users to specify their preferred
operating conditions
OFF OFF
(input type, alarm type, control method, etc.)
*3: Refer to the adjoining tables for details of input types and alarm types.
*4: Applicable only to models with alarm functions.
*5: Operation is stopped when moved to the initial setting level.
(control/alarm are both stopped.)
Precautions for Safe Use
Be sure to observe the following precautions to prevent operation failure, malfunction, or adverse affects on the
performance and functions of the product. Not doing so may occasionally result in unexpected events.
Use the product within specifications.
(1) The product is designed for indoor use only. Do not use the product outdoors. Do not use or store the product
in any of the following locations.
•Places subject to splashing liquid or oil atmosphere.
•Places subject to direct sunlight.
•Places subject to dust or corrosive gas (in particular, sulfide gas and ammonia gas).
•Places subject to intense temperature change.
•Places subject to icing and condensation.
•Places subject to vibration and large shocks.
(2) Use/store within the rated temperature and humidity ranges.
Provide forced-cooling if required.
(3) To allow heat to escape, do not block the area around the product.
Do not block the ventilation holes on the product.
(4) Be sure to wire properly with correct polarity of terminals.
(5) Use specified size (M3.5, width 7.2 mm or less) crimped terminals for wiring. To connect bare wires to the
terminal block, use copper braided or solid wires with a gage of AWG24 to AWG14 (equal to cross- sectional
area of 0.205 to 2.081 mm 2 ). (The stripping length is 5 to 6 mm.) Up to two wires of same size and type, or
two crimped terminals can be inserted into a single terminal.
(6) Do not wire the terminals which are not used.
(7) Allow as much space as possible between the controller and devices that generate a powerful high-
frequency or surge.
Separate the high-voltage or large-current power lines from other lines, and avoid parallel or common wiring
with the power lines when you are wiring to the terminals.
(8) Use this product within the rated load and power supply.
(9) Make sure that the rated voltage is attained within two seconds of turning ON the power using a switch or
relay contact. If the voltage is applied gradually, the power may not be reset or output malfunctions may
occur.
(10) Make sure that the Digital Controller has 30 minutes or more to warm up after turning ON the power before
starting actual control operations to ensure the correct temperature display.
(11) When executing self-tuning, turn the load and the unit ON simultaneously, or turn the load ON before you
turn the controller ON.
(12) A switch or circuit breaker should be provided close to this unit.
The switch or circuit breaker should be within easy reach of the operator, and must be marked as a
disconnecting means for this unit.
(13) Always turn OFF the power supply before pulling out the interior of the product, and never touch nor apply
shock to the terminals or electronic components. When inserting the interior of the product, do not allow the
electronic components to touch the case.
(14) Do not use paint thinner or similar chemical to clean with. Use standard grade alcohol.
(15) Design system (control panel, etc) considering the 2 second of delay that the controller's output to be set
after power ON.
(16) The output may turn OFF when shifting to certain levels. Take this into consideration when performing
control.
(17) Refer to the instruction sheet for installing Option unit (E53CNH03N / E53-CNHBN / E53-CN03N /
E53-CNBN / E53-CNHH03N / E53-CNQ03N / E53-CNQHN / E53-CNPBN / E53-CNPHN / E53-CNQBN /
E53-CNQHHN).
(18) The number of non-volatile memory write operations is limited. Therefore, use RAM write mode when
frequently overwriting data during communications or other operations.
(19) When disassembling the Temperature Controller for disposal, use suitable tools.
(20) Do not use the Temperature Controller if the front sheet is peeling or torn.
Connections
The E5@N-H is set for a K thermocouple (input
+1
(48 x number of units - 2.5)
type of 5) by default. If a different sensor is used,
0
an input error (s.err) will occur. Check the setting
of the Input Type parameter.
Control output 1
Relay output
250VAC 3A
(resistive load)
Voltage output
When waterproofing is required, be sure to mount the (for driving SSR)
12VDC 21mA
controller separately.
Linear voltage output
Attach the waterproof packing from the terminal side
0-10VDC
and then insert the controller to the panel.
Load: 1 kΩ min.
Recommended panel thickness is 1 to 5 mm.
Current output
0-20mADC
4-20mADC
Load 600Ω max
• A heater burnout alarm, heater short alarm, heater overcurrent alarm, or input alarm is output to the output to which the alarm 1 functi on is assigned.
• Since the voltage output (control output) is not electrically insulated from the internal wiring, one or other of the control output terminals must be left
unearthed when using an earthed thermocouple thermometer. (Connection makes measurements unreliable due to sneak currents.)
• The last character of the lot number "R" indicates that reinforced insulation is provided between input power supply, relay outputs, and between other
terminals.
• OUT1: Control output 1 indicator
Lit when control output 1 is ON and not lit
when it's OFF.
For a current output, lit except for a 0% output.
• OUT2: Control output 2 indicator
Lit when control output 2 is ON and not lit
when it's OFF.
• STOP: control stop indicator
Lit when event input or "Run/Stop "is stopped
during operation.
During control stop, functions other than
control output are valid.
• CMW: communications writing enable/ disable
indicator
Lit when communications writing is
"enabled" and is out when it is "disabled".
Settings shown above is the parameters displayed for the models without options.
(Options include heater burnout detection, communications, event inputs, and
control output 2.)
*5
Check the wiring before turning ON the power supply.
POWER ON
Operation Level
PV/SP
25.0
s.err is displayed when
25.0
connected sensor is
0.0
different from input type.
0.0
b a n k
*6
Bank No.
0
Hold down
for at least
sp-m Set Point During
3 seconds
*6
SP Ramp
(No.1display flushes,
0.0
then the control stops.)
prst
*6 Program Start
rset
Hold down
for at least
sktr
Soak Time Remain
1 second *6
0
RUN/STOP
r-s
*6
When control start
run
When control stop
al-1
*6
Alarm Value 1 *4
0.0
stnd
h-c
al1h
*6 Alarm Value Upper Limit 1
0.0
al1l
*6
Alarm Value Lower Limit 1
0.0
●
Advanced Function
al-2
Setting Level
*6
Alarm Value 2 *4
0.0
Hold down
for at least
al2h
*6
Alarm Value Upper Limit 2
1 second
0.0
al2l
init
Parameter
*6
Alarm Value Lower Limit 2
Initialization
off 0.0
or-r
or-d
Operation level should normally
be used during operations.
Moving to the next level is
*3
*4
possible when the password
(-169) is input.
Hold and M keys
down for at least
1 second
*3
Protect Level
*4
oapt
icpt
wtpt
off
AT (auto-tuning)
prlp
AT in Adjustment level
*
Designate "at-2: 100% AT execute" or
"at-1: 40% AT execute" to execute AT and
Restricts which settings can be displayed
"off: AT cancel" to cancel AT.
or changed, and restricts change by key
"at" flashes
operation.
"100%AT Execute"
at at
off at-2
"AT cancel"
Also when AT execution ends, the
display automatically returns to "off".
Other functions
For details about advanced function setting level,bank setting level,pid setting level
or manual control level,refer to E5CN-H/E5AN-H/E5EN-H Digital Controllers
User's Manual Advanced Type (Cat. No. H157).
For communications details, refer to E5CN-H/E5AN-H/E5EN-H Digital Controllers
Communications Manual Advanced Type (Cat. No. H159).
Specifications
Power supply voltage
Operating voltage range
Power consumption
Indication accuracy
(Ambient temperature: 23°C)
Event input
Contact input
No-contact input
Control output 1
Control output 2
Control method
Auxiliary outputs
Ambient temperature
Ambient humidity
Storage temperature
Altitude
Recommended fuse
Weight
Degree of protection
Installation environment
Memory protection
Transfer output
(The applicability of the electric terminals varies with the type of machine.)
Auxiliary output
• 100-240V AC Type
( Relay outputs )
+
• 24V AC/DC Type (no polarity)
Control outpu ut Auxiliary output2
1
- Auxiliary output 1
+
A
DO NOT DO NOT
mA USE USE
B
- -
-
V Input power supply
DO NOT B
+
USE +
Communications
Communications Control output 2 Event Inputs and p Communications
( ( (RS-485) ) ) and
and
( ( (RS-485) and 2 CTs Control output 2 (RS-232C)
Control output 2
2 CTs
RS-232C
B(+) + SD
B(+)
11 11 11 11
Control output 2 2 2 ntrol outpu p p p
RS-485 RS-485
12VDC,21 mA A VDC,21 m RD
12 12 12
12
EV1
A(-) -
A(-)
SG
DO NOT
13 13 13
13
EV2
USE
+ +
14 CT2 14 14
CT2 14
Control output 2 rol output p p p Control output 2 trol outpu p p p
CT1 CT1
CT1
12VDC,21 mA DC,21 m 12VDC,21 mA DC,21 m
15 15 15
15
- -
.
•
C / F : temperature unit
° °
The temperature unit is displayed
when the displayed
temperature.
When this parameter is set to"
"C" is displayed, and when set to
" F", "F "is displayed.
°
This flashes while ST (Self-Tuning) is
activated.
•
:Protection indicator
Lit when Setting Change Protect is
ON (disables the Up and Down Keys).
MANU: Manual output indicator
•
Lit when the Auto/Manual Mode is set
to Manual Mode.
Adjustment Level
Only the value set to the ins : temperature input shift parameter is
applied to the entire temperature input range. When the process
value is 200 ° C, the process value is treated as 201.2
shift if the input shift value is set to 1.2
The process value is treated as 198.8
shift value is set to -1.2 °C.
l.adj
Press
(less than
1 second)
AT Execute / Cancel
at
*6
100%AT Execute
off
40%AT Execute
Press
ins
(less than
*6
1 second) 0.0
●
insh
Bank Setting Level *6
0.0
d.bnk
Display Bank
insl
Selection
0 *6
0.0
p
= run
Press *6
= stop
8.0
(less than
1 second)
i
●
*6
PID Setting Level
233.0
d
d.pid
Display PID
*6
Selection
*4 1
40.0
c-sc
*6
Press
*4
1.00
(less than
1 second)
c-db
*6
0.0
*4
*6: The grayed-out setting items may not be displayed according to the models and setting.
Protection function
*4
Protection function, to prevent unwanted settings, restricts the setting items to be used
or designates if operation of the key is valid or invalid.
Operation / Adjustment protection
The following table shows the relationship between settings and protect limits related to
Operation level and Adjustment level.
Hold and M keys
down for at least
Level
3 seconds
Process value
Operation level PV/SP
Others
Adjustment level
Initial setting/Communications protection
Operation / Adjustment
Protect
This protect level restricts movement to the initial setting level,
0
communications setting level and advanced function setting level.
Initial setting Communications
Initial Setting /
Set value
Communication Protect level setting level
0
0
1
Setting Change Protect
2 ×
Setting change protection
Password to Move
to Protect Level Setting changes by key operation are restricted.
0
OFF off: Setting can be changed by key operation
ON on : Setting cannot be changed by key operation ("
(Protect level settings can all be changed.)
OMRON EUROPE B.V.
Wegalaan 67-69, NL-2132 JD Hoofddorp The Netherlands
Phone 31-2356-81-300
FAX 31-2356-81-388
OMRON ELECTRONICS LLC
One Commerce Drive Schaumburg, IL 60173-5302 U.S.A
Phone 1-847-843-7900
FAX 1-847-843-7787
OMRON ASIA PACIFIC PTE. LTD.
No. 438A Alexandra Road # 05-05/08 (Lobby 2),
Alexandra Technopark, Singapore 119967
Phone 65-6835-3011
FAX 65-6835-2711
OMRON Corporation
Shiokoji Horikawa, Shimogyo-ku, Kyoto 600-8530 JAPAN
100 to 240 VAC, 50/60 Hz or
24 VAC, 50/60 Hz /24 VDC
85 to 110% of the rated voltage
Approx. 8.5 VA (100 to 240 VAC)
Approx. 5.5 VA (24 VAC) /
Approx. 3.5 W (24 VDC)
Thermocouple:
(±0.1 % of indication value or ±1°C,
whichever is greater) ±1 digit max.
Platinum resistance thermometer:
(±0.1 % of indication value or ±0.5°C,
whichever is greater) ±1 digit max.
Analog input: ±0.1 % FS ±1 digit max.
Output current: approx. 7 mA per contact.
ON:1 k Ω max., OFF: 100 k Ω min.
ON: residual voltage 1.5 V max.,
OFF: leakage current 0.1 mA max.
Relay output :SPST-NO
250VAC, 3A(resistive load)
Voltage output (for driving SSR):
12 VDC, 21 mA
Current output: 4 to 20 mADC, 0 to 20mADC
Load: 600 Ω max.
Linear voltage output 0-10VDC
Ω
Load: 1 k min.
Electrical life of relay: 100,000 operations
(Long-life model: 1 million operations)
Voltage output (for driving SSR): 12 VDC, 21 mA
ON/OFF or 2-PID control
Relay outputs: 250 VAC,
3 A (resistive load), Electrical life of relay:
100,000 operations
-10 to 55 ° C
(Avoid freezing or condensation)
RH25 to 85%
-25 to 65 ° C
(Avoid freezing or condensation)
Max. 2,000m
T2A, 250 VAC, time-lag,
low-breaking capacity
Approx. 150 g (main unit only)
Front panel: IP66
Rear case: IP20, Terminal section: IP00
Installation category II, pollution
degree 2 (as per IEC61010-1)
Non-volatile memory
(Number of write operations: 1,000,000)
4 to 20 mA DC, Load : 600Ωmax.
Auxiliary output
( Relay outputs )
250VAC 3A
(resistive load)
A heater burnout alarm, Heater Short
alarm, heater overcurrent alarm, or input
alarm is output to the output to which the
alarm 1 function is assigned.
Event Inputs and
and CT
Transfer output Transfer output
+
11 11
11
Control output 2 l output 2 p p p p
12VDC,21 mA C,21 mA
12 12
12
-
EV1
DO NOT
13 13
13
USE
EV2
+ +
14
14 14 4-20 mADC
transfer 4-20 mADC
transfer
(Load: 600Ω max.) (Load: 600Ω max.)
output output
15 15
15
-
-
Conformance to EN/IEC Standards
value is a
This is a class A product.
C", In residential areas it may cause radio
°
interference, in which case the user may
be required to take adequate measures
to reduce interference.
Conformance to Safety Standards
Reinforced insulation is
provided between input power
supply, relay outputs, and
between other terminals.
°
C after input
C.
°
C after input shift if the input
°
of-r
Manual Reset Value
Adjustment Level
*6
(Unit: %)
50.0
hys
Hysteresis
at-2 *6
(Heating)
at-1 1.0
chys
Temperature Input Shift
Hysteresis
*6
(Unit: °C or °F)
(Cooling)
1.0
Upper Limit Temperature
Input Shift Value
soak
*6 Soak Time
when 2 point input shift
is selected 1
Lower Limit Temperature
Input Shift Value wt-b
*6 Wait Band
when 2 point input shift
off
is selected
sprt
Proportional Band SP Ramp Set Value
*6
off
ol-h
Integral Time
MV Upper Limit
*6
(Unit: secs)
105.0
ol-l
Derivative Time
*6 MV Lower Limit
(Unit: secs)
-5.0
orl
Cooling Coefficient *6 MV Change Rate Limit
0.0
sqrp
Extraction of Square
Dead Band *6
Root Low-cut Point
0.0
Adjustment level is for entering set
values and shift values for control.
: Can be displayed and changed
Set value
: Can be displayed
0 1 2 3
× : Display or shifting to another level
is not possible.
× ×
× × ×
Default setting : 0
: Change to
Advanced function
other levels
setting level
possible
× : Change to
other levels
×
not possible
× ×
Default setting : 0
" will light.)
